Fiat Blue&Me 2012 500 Abarth User manual

(1)Requires Bluetooth enabled mobile phone. (2)Always sit properly with head restraints properly adjusted. Never
place anything in front of the head restraint. (3)Always sit properly in the seat with the seat belt fastened. Children
12 and under should always be in a backseat correctly using an infant or child restraint system or the seat belt
positioned correctly for the child’s age and weight. (4)No system, no matter how sophisticated, can repeal the
laws of physics or overcome careless driving actions. When the ESC warning lamp flashes, the driver needs to use
less throttle and adapt speed and driving behavior to prevailing conditions. Always drive carefully, consistent with
conditions. Always use your seat belt. (5)Always check entire surroundings before backing up.
SAFETY/SECURITY
Front seat reactive head restraints(2) — Standard
Dual advanced driver and front-passenger air bags(3) — Standard
Front and rear side-curtain air bags for outboard occupants(3) — Standard
Driver's knee blocker air bag(3) — Standard
Front-seat mounted side air bags(3) — Standard
Electronic Stability Control (ESC)(4) includes Traction Control and Brake
Assist — Standard
Antilock brake system (ABS) — Standard
Security alarm — Available
Antitheft engine immobilizer system — Standard
Tire Pressure Monitoring System — Standard
Rear Park Assist System(5) — Available
Hill Start Assist — Standard
PRODUCT HIGHLIGHTS
Engine: 1.4L 16V MultiAir I-4 — Standard
5-speed manual and 6-speed automatic transmissions —
Standard or available, depending on model
Rail-driven convertible soft top — Standard on Cabrio
50/50 split-folding rear seatback with adjustable head
restraints — Standard
Blue&MeTM Hands-free Communications with USB,
Bluetooth®(1) and iPod® interface — Standard
TomTom® Navigation with Blue&Me Hands-free Connect —
Available
Satellite radio — Available
Power door locks/mirrors/windows — Standard
Center console-mounted 12-volt power accessory outlet —
Standard
Fixed glass roof or power sunroof with one-touch open —
Available
Premium leather-trimmed steering wheel, shift knob and
seating — Standard
Electronic Vehicle Information Center — Includes outside
temperature, trip, average fuel, distance to empty, low fuel,
service and range data — Standard
Bose® Premium Audio Package — Available
Steering wheel-mounted audio controls — Standard
eco:Drive — Lets the user track how efficiently they are
driving — Available
The newest addition to the Chrysler Group LLC fleet family delivers a distinctively European flair with decidedly American values.
The flared aerodynamic design and stylish painted-pocket 15- or 16-inch wheels show Continental design cues, but the world-class
1.4-liter engine with MultiAir® technology helps reduce emissions, sips gas, delivers up to 10 percent better power and fuel efficiency
than comparable engines. It also interfaces with advanced technology to communicate ideal fuel consumption to the driver — ideal
advantages for our American distances. As shown below, the list of safety and security features is both impressive and important,
demonstrating that one very compact and efficient car can make a deep impact when it comes to style and performance.
CHRYSLER GROUP FLEET
FIAT 500

Verde Chiaro
(Light Green)
Verde Olivo
(Olive Green)
Bianco Perla
(Pearl White
3-Coat)
Argento
(Silver)
Bianco
(White)
Rosso
(Red)
BFLT12-020
Grigio(1)
(Gray)
POWERTRAINS
3-door Hatchback Cabrio
Engine Transmissions Pop Sport Lounge Pop Lounge
1.4L 16V MultiAir® I-4
101 hp
98 lb-ft of torque
5-Speed Manual S S S
1.4L 16V MultiAir I-4
101 hp
98 lb-ft of torque
6-Speed Automatic OOSOS
S = Standard. O = Optional.
DIMENSIONS(1)/SPECIFICATIONS
Exterior
Wheelbase 90.6
Length 139.6
Height 59.8
Width 64.1
Tires (Base Model) (set of 4) — Standard P185/55R15
— Spare Tire Service Kit
Cargo Capacity — Normal cu ft (L) Seats up 9.5 (269)
— Maximum cu ft (L) Seats folded 30.2 (855)
Seating Capacity — Standard 4
Fuel Capacity — Gal (L) 10.5 (40.0)
Track — Front 55.4
— Rear 55.0
EPA Fuel Economy est. mpg (city/highway) — Standard engine and transmission 29/37
Interior
Head Room — Front 38.9
— Rear 35.6
Shoulder Room — Front 49.4
— Rear 46.4
Hip Room — Front 47.9
— Rear 42.6
Leg Room — Front 40.7
— Rear 31.7
Passenger Interior Volume (cu ft) 85.1
EPA Volume Index (cu ft) 75.6
(1)All dimensions are in inches unless otherwise noted.
EXTERIOR PAINT COLORS
Mocha Latte
Espresso
(1)Premier Edition.
Rosso Brillante
(Brilliant Red
3-Coat)
Azzuro
(Blue)
Rame
(Copper)
Nero
(Black)
Giallo
(Yellow)
STANDARD ON ALL 2012 FIAT 500 MODELS
Air Bags(1) — Dual advanced driver and front-passenger
— Front-seat mounted
— Supplemental rear side air bag inflatable curtains for driver- and
passenger-side outboard occupants
Air Filtration System
AM/FM/CD MP3 Radio
Antenna — Roof-mounted for Hatchback models, windshield-mounted for
Cabrio models
Auxiliary Audio Input Jack
Battery — Maintenance-free
Brakes — Four-wheel disc ABS
Carpet — Floor
Child Seat Anchor System (LATCH)
Console — Floor with cup holders
Convertible Soft Top — Cabrio models only
Daytime Running Lamps — Default is “off”; programmable by dealer
Defroster — Rear window
Door Handles — Chrome
Door Locks — Power
Driver and Passenger Front-Seatback Pockets
Driver’s Easy Entry Seat with Memory
Electronic Stability Control (ESC)(2) — Includes Traction Control and
Brake Assist
Floor Mats — Premium front
Fuel Tank — 10.5-gallon
Glass — Tinted
Headlamps — Bi-halogen projector
Hill Start Assist
Passenger Assist Handle — All models except Pop
Power Outlet — 12-volt, center console-mounted
Reactive Head Restraints(3) — Front
Rear Cargo Shelf Panel
Remote Entry
Seat Belts — Front three-point with shoulder adjustment
— Rear, outboard and center three-point
Seats — Manual driver’s seat
— Rear — 50/50 split-folding seatbacks
Speed Control — Steering wheel-mounted controls
Speedometer — 140-mph, with tachometer
Steering — Power, electric
Steering Column — Tilt, manual
Tire Pressure Monitoring System
Tire Repair Kit
Windows — Power, driver’s and front-passenger one-touch down
Windshield Wipers — Front variable intermittent, rear washer/wiper
(1)Always sit properly with seat belt fastened. Children 12 and under should always be in
a backseat correctly using an infant or child restraint system or the seat belt positioned
correctly for the child’s age and weight. (2)Always drive carefully, consistent with conditions.
Always wear your seat belt and obey traffic laws. (3)Always sit properly with the head
restraint properly adjusted. Never place anything in front of the head restraint.
Chrysler is a registered trademark of Chrysler Group LLC. Chrysler Group LLC reserves the
right to make changes at any time, without notice or obligation. All product specifications
are based on authorized information as of 5/10/11. Photographs are for representational
purposes only. The Bluetooth word mark and logo are registered trademarks and are
owned by Bluetooth SIG, Inc. FIAT and MultiAir are registered trademarks and Blue&Me
is a trademark of Fiat S.p.A. TomTom is a registered trademark of TomTom International
BV. Bose is a registered trademark of Bose Corporation. iPod is a registered trademark of
Apple Inc.
FIAT 500

Fiat 500 CHRYSLER GROUP FLEEt
TRIM COMBINATIONS
Model Pop Lounge Sport Lounge
Seat Colors Red Gray Brown
Black/
Gray Ivory/Black
Gray/
Brown
Gray/
Black
Leather
Black Red Brown
Interior Environment Color
Gray/
Ivory
Gray/
Black
Gray/
Ivory
Gray/
Black
Gray/
Ivory
Gray/
Black
Gray/
Black
Gray/
Ivory Gray/Black
Gray/
Black
Gray/
Ivory
Gray/
Black
Gray/
Ivory
Exterior Colors
PXR
Nero
(Black) • • • • • • • • • • • • •
PBP
Azzuro
(Blue) • • • • • • • •
PRA
Rosso Brillante
(Brilliant Red 3-Coat) • • • • • • • • • • • • • •
PLB
Rame
(Copper) • • • • • • • • • •
PTM
Espresso
(Espresso) • • • • • • • • • •
PAJ
Grigio
(Gray) • • • • • • • • • • • • •
PGA
Verde Chiaro
(Light Green) • • • • • • • • • •
PTA
Mocha Latte
(Mocha Latte) • • • • • • • • •
PFP
Verde Olivo
(Olive Green) • • • • • • • • • • • •
PWH
Bianco Perla
(Pearl White 3-Coat) • • • • • • • • • • • • • •
PR1
Rosso
(Red) • • • • • • • • • • • • • •
PS2
Argento
(Silver) • • • • • • • • • • • • • •
PW3
Bianco
(White) • • • • • • • • • • • • • •
PYF
Giallo
(Yellow) • • • • • • • •
POweRTRAINS
2012 FIAT 500 3-door Hatchback 2012 FIAT 500 Cabrio
Engine Transmissions Pop Sport Lounge Pop Lounge
1.4L 16V MultiAir® I-4 Five-Speed Manual 21A 21D 21A
1.4L 16V MultiAir I-4 Six-Speed Automatic 22A 22D 22J 22A 22J
SeleCTed FeATuReS ANd OPTIONS
2012 FIAT 500 3-door Hatchback 2012 FIAT 500 Cabrio
Features Pop Sport Lounge Pop Lounge
Mechanical
Alternator — 160-amp • • • • •
Battery — Maintenance-free • • • • •
Brakes
— Antilock 4-wheel disc with Electronic Brake Distribution
• • • •
— Antilock 4-wheel disc with Electronic Brake Distribution with
Red front and rear calipers
•

Fiat 500 CHRYSLER GROUP FLEEt
SeleCTed FeATuReS ANd OPTIONS
2012 FIAT 500 3-door Hatchback 2012 FIAT 500 Cabrio
Features (cont.) Pop Sport Lounge Pop Lounge
Mechanical (cont.)
Engine Block Heater O O O O O
Engine Cover — Painted, with FIAT badging • • • • •
Exhaust System
— Bright stainless steel exhaust tips
• • • • •
Fuel Filler System — Cap non-locking • • • • •
Fuel Tank — 10.5-gallon • • • • •
Speed Control — Located on steering wheel • • •
Steering — Power electric • • • • •
Suspension
— Normal duty
• • • •
— Sport (includes Sport power steering tuning) •
Exterior Features
Badging
— FIAT front fascia and liftgate
• • • • •
— 500 Cabrio, B-pillars • •
Belt Molding
— Black
• • •
— Chrome • •
Body Kits — Sills •
Bodyside Molding — Body-color with integrated 500 badge • •
Door Handles — Chrome • • • • •
Front and Rear Fascia
— Body-color
• •
— Body-color, Sport •
— Body-color with chrome accents • •
Glass — Tinted • • • • •
Bright Accent Color • • • • •
Headlamps
— Bi-halogen projector
• • • • •
— Fog lamps • • •
— Daytime running lamps (Dealer-activated) • • • • •
Mirrors, Exterior
— Manual folding, power aiming, heated body-color
• • •
— Manual folding, power aiming, heated chrome • •
Spoiler — Body-color •
Tires
— P185/55R15 All-Season
• • • •
— P195/45R16 All-Season •
— Compact spare O O O O O
— Tire repair kit • • • • •

Fiat 500 CHRYSLER GROUP FLEEt
SeleCTed FeATuReS ANd OPTIONS
2012 FIAT 500 3-door Hatchback 2012 FIAT 500 Cabrio
Features (cont.) Pop Sport Lounge Pop Lounge
Exterior Features (cont.)
Wheels
— 15-inch steel wheels with wheel covers (Style-1)
• •
— 15-inch aluminum (Style-1) O O
— 15-inch aluminum (Style-2) •
— 15-inch aluminum (Style-3) Cabrio •
— 16-inch aluminum (Style-1) •
— 15-inch aluminum with premium finish O O
Windows — Power with driver and front-passenger
one-touch down
• • • • •
Wipers
— Two-speed variable intermittent
• • • • •
— Rear window washer/wiper • • •
Interior Features
Air Conditioning
— Manual single-zone
• • •
— Automatic single-zone O • •
Air Filtration — Micron air filter • • • • •
Antenna — Roof-mounted for Hatchback and in windshield for Cabrio • • • • •
Cup Holders
— Front: one large and two small
• • • • •
— Rear: two floor-mounted cup holders • • • • •
Defroster — Rear window • • • • •
Door locks — Power • • • • •
Electronic Vehicle Information Center — Includes trip odometer,
outside temperature, average fuel, distance to empty, low fuel,
service and range data
• • • • •
Fixed Glass Roof •
Floor Mats — Front with 500 logo • • • • •
Front Door Pockets • • • • •
Interior Accents
— Door trim with accent-colored inserts
• • • • •
— Chrome door handles • • • • •
Lighting
— Front reading map lights, driver and passenger
• • • • •
— Rear cargo area lamp • • • • •
Mirrors, Interior
— Rearview, electrochromic (included in Luxury Leather
Package P4)
P P
— Visor with covered vanity mirror, driver and
passenger side
• • • • •
Passenger-Assist Handle • • •
Power Accessory — 12-volt power outlet located in center console • • • • •
Power Sunroof — With one-touch express open O O O

Fiat 500 CHRYSLER GROUP FLEEt
SeleCTed FeATuReS ANd OPTIONS
2012 FIAT 500 3-door Hatchback 2012 FIAT 500 Cabrio
Features (cont.) Pop Sport Lounge Pop Lounge
Interior Features (cont.)
Rear Cargo Shelf Panel • • • • •
Shift Knob
— Leather-wrapped • •
— Black • •
— Urethane with chrome accent •
Speedometer — 140-mph • • • • •
Steering Column — Manual tilt • • • • •
Steering Wheel
— Leather-wrapped (included in Communication Package on Pop)
• • • •
— Leather-wrapped, Sport appearance •
Steering Wheel-Mounted Audio Controls
(included in Convenience Package P1)
• • • • •
Tachometer • • • • •
Seating
Seating
— Cloth bucket with driver’s seat armrest
• •
— Premium cloth with driver’s armrest and seatback logo • •
— Sport cloth/vinyl bucket with driver’s seat armrest •
— Leather with driver’s seat armrest and seatback logo
(included in Luxury Package)
P P
— Driver’s seat with manual height adjuster • • • • •
— Heated front seats (requires 6-speed automatic; included in
Luxury Leather Package)
O O/P O/P
— Front seatback pockets, driver and passenger sides • • • • •
— Driver’s seat easy entry and memory • • • • •
— In-seat storage, passenger side • •
Rear
— 50/50 split fold-down rear seatbacks with adjustable
head restraints
• • • • •
Sound and Communication Systems
AM/FM/CD/MP3 Radio • • • • •
Audio Systems
— 6 speakers
• •
— Bose® Premium Audio Package O • • O •
Auxiliary Audio Input Jack • • • • •
Blue&Me hands-free connect — Includes Bluetooth,
® USB & iPod®
interface
• • • • •
Satellite Radio P P • P •
TomTom® Navigation with Blue&Me hands-free communication O O O
Safety and Security
Air Bags(1)
— Dual advanced driver and front-passenger
• • • • •
— Supplemental driver knee-blocker air bag • • • • •
— Supplemental front-seat mounted side air bags • • • • •
— Supplemental side air bag inflatable curtains for driver and
front-passenger outboard occupants and rear seats
• • • • •

Fiat 500 CHRYSLER GROUP FLEEt
SeleCTed FeATuReS ANd OPTIONS
2012 FIAT 500 3-door Hatchback 2012 FIAT 500 Cabrio
Features (cont.) Pop Sport Lounge Pop Lounge
Safety and Security (cont.)
Child Seat Anchor System (LATCH) • • • • •
Electronic Stability Control(2) — Includes Traction Control and
Brake Assist
• • • • •
Engine Immobilizer System — Antitheft engine immobilizer • • • • •
Front-Passenger Seat Belt Alert • • • • •
Front Seat Reactive Head Restraints(3) • • • • •
Front Seat Belts with Pretensioners and Load Limiters • • • • •
Hill Start Assist • • • • •
Rear Park Assist System(4) P • •
Remote Entry (includes driver’s door) • • • • •
Security Alarm P P • P •
Tire Pressure Monitoring System • • • • •
Packages
Convenience Group — Rear Park Assist, electrochromic rearview
mirror, heated front seats
O
Luxury Leather Package — Includes leather seats, electrochromic
rearview mirror, and heated front seats
O O
Safety & Convenience Package — Satellite radio, alarm O
Smoker’s Package O O O O O
• = Included. P = Available within package noted. O = Optional.
(1) The advanced front air bags in this vehicle are certified to the new federal regulations for advanced air bags. Children 12 years and younger should always ride buckled up in a rear seat. Infants
in rear-facing child restraints should never ride in the front seat of a vehicle with a passenger air bag. All occupants should always wear their lap and shoulder belts properly.
(2) Always drive carefully, consistent with conditions. Always wear your seat belt and obey traffic laws.
(3) Always sit properly with head restraint properly adjusted. Never place anything in front of the head restraint.
(4) Always check entire surroundings before backing up.
FIAT and MultiAir are registered trademarks and Blue&Me is a trademark of Fiat S.p.A. Chrysler and Uconnect are registered trademarks of Chrysler Group LLC. Chrysler Group LLC reserves
the right to make changes at any time, without notice or obligation. All product specifications are based on authorized information as of 5/10/11. Photographs are for representational purposes
only. The Bluetooth word mark and logo are registered trademarks and are owned by Bluetooth SIG, Inc. TomTom is a registered trademark of TomTom International BV. Bose is a registered
trademark of Bose Corporation. iPod is a registered trademark of Apple Inc.
