FiberHome AN6001-G16 Instruction Manual

AN6001-G16
Optical Line Terminal Equipment
User Manual
FiberHome Telecommunication Technologies Co., Ltd.
September 2019

Thank you for choosing our products.
We appreciate your business. Your satisfaction is our goal.
We will provide you with comprehensive technical support
and after-sales service. Please contact your local sales
representative, service representative or distributor for any
help needed at the contact information shown below.
Fiberhome Telecommunication Technologies Co., Ltd.
Address: No. 67, Guanggu Chuangye Jie, Wuhan, Hubei, China
Zip code: 430073
Tel: [phone] (for Malaysia)
[phone] (for South Asia)
[phone] (for South America)
Fax: [phone]
Website: http://www.fiberhomegroup.com

Legal Notice
are trademarks of FiberHome Telecommunication Technologies Co., Ltd.
(Hereinafter referred to as FiberHome)
All brand names and product names used in this document are used for
identification purposes only and are trademarks or registered trademarks
of their respective holders.
All rights reserved
No part of this document (including the electronic version) may be
reproduced or transmitted in any form or by any means without prior
written permission from FiberHome.
Information in this document is subject to change without notice.

Contents
1Documentation Guide .....................................................................................1
2Product Introduction........................................................................................3
2.1 Product Appearance .........................................................................4
2.2 Product Positioning...........................................................................5
2.3 Power Supply Mode..........................................................................5
3Product Highlights...........................................................................................7
4Product Specification ......................................................................................9
4.1 List of Functions and Features ........................................................10
4.2 Major Technical Specifications ........................................................12
5Web-Based Configuration Guide ...................................................................14
5.1 Configuring Device Management Parameters..................................15
5.2 Logging into the Web Configuration GUI Locally ..............................20
5.3 Introduction to the Web Configuration GUI.......................................22
5.4 Device Management.......................................................................23
5.4.1 Device Information............................................................23
5.4.2 Resetting the System........................................................24
5.4.3 Save to Flash....................................................................25
5.4.4 Time Calibration................................................................25
5.4.5 User Management ............................................................26
5.4.6 System Software Upgrade ................................................27
5.5 Authentication and Authorization.....................................................28
5.5.1 PON Port Authentication Mode .........................................28
5.5.2 ONU List...........................................................................29
5.5.3 Unauthorized ONU List .....................................................30
5.5.4 Pre-Authorizing an ONU ...................................................32
5.5.5 ONU Capability Set...........................................................33
5.6 Local Service..................................................................................36
5.6.1 Configuring the Local VLAN Data......................................36

5.6.2 Adding VLAN to Ports .......................................................38
5.6.3 Multicast Service ..............................................................40
5.6.4 Voice Service....................................................................46
5.7 QinQ...............................................................................................51
5.7.1 QinQ Profile......................................................................52
5.7.2 OLT QinQ Domain ............................................................53
5.7.3 Binding a QinQ Profile.......................................................55
5.7.4 Attaching / Detaching a Domain to / from an ONU..............56
5.7.5 Attaching / Detaching a Domain to / from a PON Port ........58
5.8 Management VLAN ........................................................................60
5.8.1 Management VLAN ..........................................................60
5.8.2 Configuring the VLAN IP Address......................................61
5.8.3 Binding Sub VLANs to Super VLANs.................................63
5.8.4 ARP Proxy Switch on VLAN..............................................65
5.9 Port Service....................................................................................66
5.9.1 Data Port ..........................................................................66
5.9.2 Voice Port.........................................................................73
5.9.3 VEIP Service Configuration...............................................76
5.9.4 CATV Service ...................................................................82
5.9.5 WiFi Service .....................................................................83
5.9.6 WAN Service ....................................................................86
5.10 ONU Management..........................................................................88
5.10.1 ONU Device Information ...................................................88
5.10.2 ONU Upgrade...................................................................89
5.10.3 Rebooting an ONU ...........................................................90

11 Documentation Guide
Document Orientation
This manual aims to instruct users in configuring services of the AN6001-G16
through the Web GUI. To help users better understand and implement service
configurations, we provide basic configuration rules, network planning, Web GUI-
based operation procedures and typical service examples in this manual.
Intended Readers
uCommissioning engineers
uOperation and maintenance engineers
Version
Version Description
AInitial version, corresponding to the equipment version
V101R001.
Content
Summary Chapter
Configuring equipment
management
uConfiguring Device Management Parameters
uLogging into the Web Configuration GUI Locally
uIntroduction to the Web Configuration GUI
uDevice Management
uAuthentication and Authorization
uONU Management
Configuring major services
uLocal Service
uQinQ
uManagement VLAN
uPort Service
Version: A 1

AN6001-G16 Optical Line Terminal Equipment User Manual
Related Documentation
Document Applied to
AN6001-G16 Optical Line Terminal Equipment
Product Overview Network planning phase
AN6001-G16 Optical Line Terminal Equipment Quick
Installation Guide
Network deployment phase / network
maintenance phase
AN6001-G16 Optical Line Terminal Equipment CLI
Configuration Guide
Network deployment phase / network
maintenance phase
AN6001-G16 Optical Line Terminal Equipment
UNM2000 Configuration Guide
Network deployment phase / network
maintenance phase
2Version: A

22 Product Introduction
Product Appearance
Product Positioning
Power Supply Mode
Version: A 3

AN6001-G16 Optical Line Terminal Equipment User Manual
2.12.1 Product Appearance
The AN6001-G16 is a small-sized cassette-shaped optical line access equipment
developed by FiberHome. It is designed with pluggable modularized power cards,
fan unit, core switch service cards and optical modules for easy installation,
deployment and maintenance. It provides GPON access, carrier-class reliability,
sound security mechanism and selective QinQ functions. The UNM2000 is used as
the network management system to enable centralized management, maintenance
and monitoring of the equipment.
The AN6001-G16 supports three power supply schemes: DC-AC, dual-DC, and
dual-AC. The figures below show the appearance of the equipment.
Figure 2-1 AC-DC Power Supply Scheme
Figure 2-2 Dual-DC Power Supply Scheme
Figure 2-3 Dual-AC Power Supply Scheme
4Version: A

2 Product Introduction
2.22.2 Product Positioning
The AN6001-G16 mainly serves for telecommunications, radio and television
operators, and provides the last-mile fiber access solution. The small-sized (1U)
cassette-shaped OLT can be deployed in outdoor cabinets and applied to sparsely-
populated villages, towns, and urban villages which have insufficient equipment
rooms and harsh outdoor environment. It caters to the demand of multiple service
scenarios including home access, enterprise access and mobile backhauling.
Generally, the equipment is located at the edge of the access network and
connected to the terminal equipment directly. That is, it lies between the user
equipment and the distribution layer equipment.
2.32.3 Power Supply Mode
The AN6001-G16 provides three power supply schemes: dual-DC, dual-AC and
DC-AC hybrid schemes. All these schemes support 1+1 redundancy backup.
AC Power Supply
The AN6001-G16 supports 110 V / 220 V active-standby AC power supply featuring
lightning protection, filtering, lightning protection failure alarm and input voltage
detection.
Version: A 5

AN6001-G16 Optical Line Terminal Equipment User Manual
DC Power Supply
The AN6001-G16 supports -48 V active-standby DC power supply featuring voltage
monitoring, failure alarm reporting and protection switching.
The table below describes the model numbers, appearance and input / output
specifications of the PDPs for the DC power supply scheme of the AN6001-G16.
Item PDP260B PDP296B
Model 3000063-1FA
3000063-2FA
3000068-1FA
3000068-2FA
Appearance
Range of input
voltage -38 V to -60 V -38 V to -60 V
Number of input
channels
Two channels of power (one active
and one standby)
Two channels of power (one active
and one standby)
Input current The maximum current of a single
channel is 96 A.
The maximum current of a single
channel is 96 A.
Range of output
voltage -38 V to -60 V -38 V to -60 V
Number of output
channels Six channels of output power Six channels of output power
Output current The maximum current of a single
channel is 32 A.
The maximum current of a single
channel is 32 A.
Note:
The AN6001-G16 is equipped with the PDP260B (3000063) by default.
When lightning protection is required, use the PDP296B (3000068)
instead.
6Version: A

33 Product Highlights
High-density Modularized Integration
u1U high, designed with modularized core switch service card, fan card and
power card for easy installation and replacement.
uSupports 16 GPON ports, two 10GE uplink ports (SFP+), two GE uplink optical
ports (SFP) and two GE uplink electrical ports to allow access of 1024 ONUs.
Flexible Deployment
Supports mounting in 19-inch / 21-inch cabinets or outdoor cabinets and mounting
on the wall. Suitable for long-haul broadband access applications in villages, towns
and factories. Provides users with access to multiple services such as broadband,
voice and IPTV services; caters to various access demands of telecommunications,
radio and television operators as well as the customer premises network; and saves
the backbone optical fiber resources.
Carrier-class Reliability
uSupports 1+1 redundancy protection for PON ports, uplink ports and power
interfaces. All the slots meet the requirement of fault tolerance.
uSupports Type B PON protection, detection of rogue ONUs and detection of
optical links.
uSupports service switching with the WTR time less than 50 ms.
Abundant Ethernet Functions
uProvides versatile VLAN processing functions, including selective QinQ, VLAN
translation and VLAN aggregation.
uProvides overall QoS functions, including dynamic bandwidth allocation, priority
control, multiple traffic classification mechanisms, and queue scheduling to
meet the QoS demand of different services such as VoIP, IPTV and Internet
access.
uProvides sound ACL functions, including L2, L3 and user-defined ACLs.
Version: A 7

AN6001-G16 Optical Line Terminal Equipment User Manual
uSupports IGMP Snooping and Proxy, IGMPv3 and MLDv2 source address
filtering, and rate control for multicast packets.
uSupports STP/MSTP, link aggregation, DHCP and port isolation.
uSupports both IPv4 and IPv6 to enable smooth migration to the next-generation
IP network.
Remote Management and Easy Maintenance
uProvides visualized management based on GUI EMS, which covers
configuration, alarm and performance monitoring, data statistics, user
management and so on.
uSupports management based on command lines with downward compatibility.
uSupports remote software upgrade, which simplifies operation and saves man
power.
8Version: A

44 Product Specification
List of Functions and Features
Major Technical Specifications
Version: A 9

AN6001-G16 Optical Line Terminal Equipment User Manual
4.14.1 List of Functions and Features
Classification Function
Access features GPON access
Layer 2 switching functions
Supports 802.1Q VLAN.
Supports selective QinQ (VLAN Stacking).
Supports independent learning of MAC addresses.
Supports shared learning of MAC addresses.
Clears Layer 2 forwarding table globally.
Allows the OLT to forward data based on the MAC
address.
Supports configuring the MAC address aging time for the
OLT and ONU.
Supports Layer 2 port dynamic aggregation and
implements the LACP.
Port mirroring
Supports ingress and egress mirroring.
Supports flow mirroring.
Port aggregation
Supports the IEEE 802.3ad protocol.
Supports static or LACP dynamic port aggregation.
Port isolation
Supports isolation of GPON ports.
Supports isolation of uplink ports.
QoS functions
Supports 4-level HQoS functions.
Supports IPv4 / IPv6 QoS.
Multicast functions
Supports IGMP Proxy / Snooping and MLD Proxy.
Supports the IGMP V1 / V2 / V3 and MLD V1 / V2
protocols.
Supports multicast VLAN.
Supports multicast copy broadcast.
Supports multicast information statistics.
Supports multicast user management.
Supports multicast program management.
Voice functions
Supports VoIP voice service.
Supports H.248 and SIP protocols.
Supports PPPoE configuration.
Supports DHCP configuration.
Supports query of NGN statistics information.
Supports query of NGN resource status.
10 Version: A

4 Product Specification
Classification Function
Supports voice intercommunication inside the PON.
Layer 3 functions
Supports VLAN Layer 3 interface.
Supports ARP proxy.
Supports DHCP Relay, DHCP Snooping or DHCP Server.
Isolates illegal DHCP Server.
Supports dynamic routing based on OSPF.
Supports static routing.
Line identification functions
Supports relay agent Option18 / Option37 function of
DHCPv6.
Supports DHCP option82 and PPPoE+.
Network features
Supports cascading over Ethernet networks.
Supports bidirectional forwarding detection (BFD).
Supports the STP protocol (IEEE802.1D), RSTP protocol
(IEEE 802.1w) and MSTP protocol (IEEE 802.1s).
Supports the ERPS function.
Operations and maintenance
Supports remote operation and user management.
Supports operation authority classification.
Supports exception handling for the equipment.
Supports version and data management.
Supports saving and querying the performance statistics
and historical data.
Supports remote upgrade of the software.
Supports automatic rollback during software upgrade.
Synchronizes equipment configuration with EMS
configuration.
Supports the License function.
Clocks
Clock in the system
1588v2 clock
Adaptive clock recovery
Synchronous Ethernet clock
System redundancy
Supports 1+1 protection for PON ports.
Supports 1+1 protection for uplink ports.
Supports 1+1 protection for DC or AC power interfaces.
Security features
Each uplink port supports up to 120 ACL rules.
Authenticates ONU terminals and reports illegal ONU
registration events.
Version: A 11

AN6001-G16 Optical Line Terminal Equipment User Manual
Classification Function
Supports limit on maximum number of MAC addresses
learned to prevent attacks by users' MAC addresses.
Supports filtering MAC addresses.
Supports filtering packets and binding ports based on the
source MAC address, destination MAC address, Ethernet
type, VLAN, CoS, source IP address, destination IP
address, IP port and protocol type.
Prevents DoS attacks.
4.24.2 Major Technical Specifications
Item Description
Dimensions of the subrack without mounting
ears (H × W × D) 44.4 mm × 443 mm × 220 mm (1U)
Dimensions of the subrack with mounting ears
for 19-inch cabinets (H × W × D) 44.4 mm × 480 mm × 225 mm
Dimensions of the subrack with mounting ears
for 21-inch cabinets (H × W × D) 44.4 mm × 530 mm × 233 mm
Overall weight 4.5 kg
Power
DC voltage range: -38.4 VDC to -57.6 VDC
AC voltage range: 90 VAC to 290 VAC
Overall power consumptionNote 1 Maximum power consumption: 90 W
Static power consumption: 57 W
System switching capability 44G
Slot bandwidth 20G
Management and monitoring interface
CONSOLE/ESC: RS232 local debugging serial port / RS485
environment monitoring port
1PPS/TOD: clock interface
ETH: out-of-band network management interface
DC1-7: dry contact interface
PON port 16 GPON ports
Uplink interface
10GE1/10GE2: 10GE uplink port (SFP+)
GE3/GE4: GE uplink optical port (SFP)
GE5/GE6: GE uplink electrical port
Working temperatureNote 2 Long-term operating temperature: 0°C to 45°C
Short-term operating temperature: -10°C to 55°C
12 Version: A
