FIC A985 User manual

Notebook Specification
FICA985 Service Manual A-1
Appendix
This appendix providesthe technical specification of the A985 notebook:
A.1 System Specification
MICROPROCESSOR
CPUType Intel Pentium-4-M Northwood Processor
Clock Speed Pentium-4-M CPU at 1.6/1.7/1.8/2.0/2.1/2.2GHz
Internal L1 Cache 12KB code and 8KB data
Internal L2 Cache 512 KB
CPUPackage uFCPGA packaging
SYSTEM LOGIC CHIPSET
Chipset Type • SIS 650 - North Bridge
• SIS 961 - South Bridge
Thermal controller Integrated in South Bridge
MEMORY MODULE
Package 200 Pins SO-DIMM (1.25 )
Size 128 / 256 / 512MB
Mode DDR SDRAM
Frequency 266 MHz (Northwood)
DataPath 64Bit
Refresh CBR Refresh
SupplyVoltage 2.5V
Extension Upgradable to max. 1024MB using 512 MB SODIMM x2
ParitySupport No parity bit for all memory
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

Notebook Specification
A-2 FICA985 Service Manual
BIOS ROM
ROM Type 512K x8 CMOS Flash Memory –49LF040A (SST)
ROM Size 4M-bit
Boot Code Sector 64KB Top Sector
Package 32-pin lead PLCC Package
Erase/ Program • 70 ms (typical) Chip-Erase Time
• 18ms (typical) Sector-Erase / Block-Erase Time
• 14us (typical) Byte-Program Time
• 8 seconds (typical) Chip-RewriteTime
• Single-Pulse Program or Erase
Program Voltage 3.0V~3.6V
SupplyCurrent • Active = 6mA (typical)
• Standby = 10uA (typical)
VIDEO SUBSYSTEM
Video Chipset SIS 650(Integrate in North Bridge)
Video RAM Shared from System Memory from 8MB up to 64MB
Bus Interface • 66Mhz Host-to-PCI Bridge
• A.G.P. v2.0 Compliant
Addressing Linear Addressing
3D engineclock speed Upto143 Mhz
Maximum Resolution at CRT 2048 x1536 at 32-bit color (16 millioncolors)
Maximum Color at CRT 32-bit color (16 millioncolors)
External CRTconnector 15-pin D-Subfemale
I/O SUBSYSTEM
I/OController SMSC LPC47N267
Parallel / Printer Port (LPT1) 25-pin D-sub female connector (with EPP/ECP support)
Serial / COM Port (COM1) • Type: 9-pinD-sub male RS-232 connector
• Baud Rate: 300 –38400bps (UART 16C550A)
• Drivers / Receiver: Maxim MAX3243 (SSOP, 28-pin)
KEYBOARDSUBSYSTEM
Keyboard Controller ENE KB38867
Firmware Version Version: 1.47
Package 64-pin TQFP
Host Interface 8042-style host interface
Keyboard Scan Local 16x8keyboardswitch matrix
External PS/2Keyboard Mini-DIN PS/2 connector
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

Notebook Specification
FICA985 Service Manual A-3
SOUND SUBSYSTEM
Audio Controller Integratedin SouthBridge
Audio Codec ALC201 CODEC (Analog Devices)
Compatibility SoundBlaster 16 (Pro) & AC’97Revision2.2
WavetableFunction Software
Connection Full-Duplex
Volume AnalogH/WVolume
Built-in Speaker 2-way (left andright) mini stereo 1W8 speakers
Built-in Microphone Mono
Line-Out Jack 1xline-out jack with 50mW/20ohm drivingcapability supported
S/PDIF out
Microphone Jack 1x3.5p microphone jackwith 50mW/20ohm drivingcapability
POINTING DEVICE SUBSYSTEM
Chipset Controller Mitsubishi M38867E4HP Version 1.47
Package 64-pin TQFP
Touchpad Type Synaptics TM41PDG351-1 Glide Point
Interface PS/2
External PS/2 Mouse Mini-DIN PS/2 connector (share with PS/2keyboard)
PCMCIASUBSYSTEM
Chipset Controller O2MicroOZ6912PCI-cardbus bridge
PCMCIASlot Configuration 1 TypeI or TypeII
BusType 32-bit PCI CardBus
Compatibility Yenta ™PCI to PCMCIA CardBus BridgeRegisters
Compliance ACPI-PCI Bus Power Management Interface Spec Rev 1.1
POWER MANAGEMENT UNIT (PMU)
PMU Controller Mitsubishi M38859FFHP (PMU08)
PMU Modes VideoTimeout, Hard Disk Timeout, SuspendtoRAM(STR)
mode, Suspendto Disk (STD) mode
Others LCD Cover-Switch STR, ACPI, DMI 2.0, Thermal Control
STATUS LEDINDICATORS
Number of LEDs 8 LEDs
PowerStatus LED Green color whenpowering on
Green color blinkingwhen in STR or STD
Amber color in Battery Low.
BatteryChargeLED Green color in charging status
Lights off when thebattery is fully charged or no battery installed
Internet / Mail LED Green color blinkingwhen a new mail is arriving
HDD LED Green color when accessing the HDD
FDD LED Green color when accessing the FDD
Num Lock LED Green color for Num Lock activate on keyboard
Caps Lock LED Green color for Caps Lock activate on keyboard
Scroll Lock LED Green color for Scroll Lock activate on keyboard
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

Notebook Specification
A-4 FICA985 Service Manual
HOT-KEYDEFINITION
Numberof hot-keys 8 <Fn> key combinations
DisplayMode Fn+ F3(LCD/ CRT/ TV/ LCD&CRT)
DisplayStretch / Normal Fn+ F5
PC Speaker On / Off (Mute) Fn+ F6
BrightnessUp Fn+ F8
BrightnessDown Fn+ F9
Internet Function Key Internet Button
Mail Function Key Mail Button
A.2 Display Specification
14.1 XGATFT LCD(HANNSTAR)
LCD Model HSD141PX11-A
LCD Type 14.1 XGA TFT
DisplayArea H285.696xV214.272[mm]
DisplayPixels H1024xV768 pixels
Pixel Pitch H0.279xH0.279 [mm]
Displaycolors 262K Colors
Module Size 298.5(W) x227.5(H) x5.8(D) [mm]
Weight Approx. 550g
Contrast Ratio 200:1(typ.)
Power Supply 3.3V
ResponseTime 30ms (max)
Operating Temperature 0 to 50 degrees Celsius
Storage Temperature -20 to 60 degrees Celsius
15.0 SXGATFT LCD (HANNSTAR)
LCD Model HSD150PX14-A
LCD Type 15.0 SXGA+ TFT
ActiveArea H304.1xV228.1 [mm]
DisplayPixels H1400xV1050pixels
Pixel Pitch 0.218[mm]
Displaycolors 262K Colors
Module Size 315.7(W) x240.5(H) x7(D) [mm]
Weight Approx. 650g
Contrast Ratio 250:1 (typ.)
Brightness 150 (cd/m²)
Viewing Angle(U/D/L/R) 10/30/45/45
Power Supply 3.3V
ResponseTime 40ms (max)
Operating Temperature 0 to 50 degrees Celsius
Storage Temperature -20 to 60 degrees Celsius
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

Notebook Specification
FICA985 Service Manual A-5
A.3 DVD/CD-RW Combo Drive Specification
Drive Manufacturer MKE UJDA730FC-A
Physical Dimension 128.0 x12.7 x129[mm] ( W* H *D )
Weight 300g
Loading Manual tray loading
Ejection Manual eject usingtheeject button
Auto eject using the eject command on software
Host Interface EnhancedIDE (ATAPI)
Access Time(1/3stroke) DVD-ROM180ms Typ.
CD-ROM130ms Typ.
DataTransfer Rate
(ATAPI Interface) 16.7MByte/s (PIO Mode 4) 16.7MByte/s (Multi word DMA transfer mode-2)
33.3MByte/s (UltraDMA transfer mode-2)
DataTransfer Rate (sustained) Max. 10,800Kbyte/s (DVD); Max.3,600Kbyte/s(CD)
DataWrite Rate Max. 1,200Kbyte/s (CD-R) ; Max.600Kbyte/s(CD-RW)
Starting Time Max. 15sec (Except Multi Session)
Stop Time Max. 6 sec (Except DVD-RAM)
DataBuffer Capacity 2MB
SupplyVoltage +5VDC+/- 0.25V
MTBF 60,000H (Duty 20%)
A.4 KeyboardSpecification
Keyboard Type JME K9801
Type of key switch Membrane (PE) Switch
Number of keys 87 keys with embedded numeric keypad
Compatibility Enhanced101/102emulation
Travel 3.0 mm ±0.3mm
Keyboard Height 6.8 ±0.3 mm
7.0 ±0.3 mm (SPACE Key)
Keycap Pull Off Force ≥500g
SupplyVoltage 6V
Operating Temperature -10to 60 degrees Celsius
A.5 Touch Pad Specification
Touch Pad Type Synaptics GlidePoint TM41PDG351-1
Interface PS/2(compatiblewithMicrosoft MouseDriver)
SupplyVoltage 5V
SupplyCurrent 4.0mA (Max) Operating
Dimension W65 xH49 xD2.82 (D1.07 PCB ) mm
Weight 8g.
Operating Temperature 0to60degrees Celsius
StorageTemperature -40to 65 degrees Celsius
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

Notebook Specification
A-6 FICA985 Service Manual
A.6 Internal Modem Specification
Modem Type MDC FAX/MODEM UNIT
Chipset Lucent Mars3 1648
Modem Chipset Interface Mini-PCI Interface(Type 3B)
Wake Up Function Supports Ring-in ResumeWake Up function
Connection Mode V.90Kbps
Speakerphone Full duplex speakerphone (FDSP)
Fax Transmission Way Half Duplex
Modem Speed 56Kbps
Modulation Format V.90PCM
A.7 Internal LAN Specification
LAN Type Realtek 8100BL
LAN Chip Interface On-Board
Speed 10/100 Mbps Auto-Negotiation
Wake Up Function Supports Wake-on-LAN (WOL) & LAN-BOOT function
A.8 Power Supply
AC POWERADAPTER(DELTA)
Adapter Type ADP-65DB
Input Voltage 100 to240VAC
Input Frequency 50to 60 Hz
Input Current 1.5A Maxat 110VAC
0.7A Maxat 220VAC
Efficiency 83% Min withthe AC input set at 115v/50Hz
In-Rush Current (Cold Start) 50A Max at 100 VAC
100A Maxat 240VAC
Output Power 60W
Output Voltage +19Vdc (main)
Output Current Limit 5.2A~6.0A
Over VoltageProtection 25V Max
Over Temperatureprotection 110~130degree C
LEDDisplay Green LED(On / Off)
Dimension L133 xW58 xH29[mm]
LITHIUM ION(LI-ION) BATTERYPACK
Model Sanyo Li-Ion Rechargeable Smart Battery
Cell Number 8
Rating (Nominal) Voltage 14.8V
Typical Capacity 4000 mAH
Watts 51.84W
Charging Voltage 16.8V
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

Notebook Specification
FICA985 Service Manual A-7
Charging Efficiency 100%
EVD1 14.0V
EVDF 12.0V
A.9 Inverter Specification
Input Voltage 5.0V
Start Voltage 1200Vrms (min)
Output Current 6mA (max)
Frequency 30~70KHz
Efficiency 75% (min)
Brightness Control Voltage 0.94~1.86V
A.10 DC/DC Specification
Controller MAX1631
Input Voltage 8~ 20V
Output Current 7A (5V) / 4.5A (3.3V) / 120mA (12V)
Frequency 200KHz
Support Mode OVP / OCP
A.11 Charger Specification
Controller Mitsubishi 3886X
Input Voltage 18.5~ 20V
LITHIUM ION (LI-ION) BATTERY PACK
Max. Temperature 60 degrees
Max. Charger Voltage 4.35V / cell
Charger EntryTemperature 0 –50 degrees
Max. Timer 300minutes
Trickle ChargerDetect 0< V < 3V / cell
Output Current (system off) 1.6A (Min) / 1.7A (Typ) / 1.8A (Max)
Output Current (system on) constant power
Trickle ChargerCurrent 120mA
Ripple& Noise 500mV
Efficiency 90%
A.12 Mechanical Specification
Unit Dimensions
(WxD xH) inmillimeters 325x269 x40mm (Front)
Unit Weight Approximately 3.2Kg (6.6 lbs) with 14.1 LCD System with
HDD, FDD, CD-Rom & One Li-Ion Battery Pack
PDF created with FinePrint pdfFactorytrial version http://www.fineprint.com

Notebook Specification
A-8 FICA985 Service Manual
A.13 Environmental Requirements
Temperature
OperatingTemperature
Storage Temperature
0oC to40oC
-20oCto 60oC
Humidity
Operating& Storage
40oC / 85% RH Over 48hours
Shock (Non-operating)
Unpacked
Acceleration: 50G
Duration Time: 11ms
No. ofTimes: 3Times
Direction: 6 face
Drop
Package
Drop Height: 91cm (under10Kg)
76cm (over10Kg)
Drop Phase: 1corner, 3 line, 6 face
Electro-Static Discharge (ESD)
Contact: +/- 6KV
Air: +/- 10KV
