Fidlock FW User manual
some buckle options
concept: S
V-BUCKLE 20SNAP buckleSNAP buckle flat SLIDER 25HOOK 15 FW HOOK 20 helmet HOOK flat
classic buckle on a strap,
for easy and quick
in and out
adjustable buckle or by
hook-and-loop area,
additional triglide or
flexible straps
All our products close automatically
using magnetic attraction !
Once engaged they form a strong and
secure mechanical connection !
some buckle options
concept: B S
HOOK 40 tough HOOK 25
HOOK 40 beltSNAP buckle SLIDER 40
V-BUCKLE 25
V-BUCKLE 40
conventional lacing or
sock + buckle on a strap,
for additional support or
cosmetics only
adjustable buckle or by
hook-and-loop area,
additional triglide or
flexible straps
FIDLOCK
prototype
some buckle options
concept: B S -
STRIPE FW STRIPE FW V-BUCKLE sewable V-BUCKLE 20 HOOK 15 FW HOOK flat
conventional lacing or
sock + buckle on a strap
- but with a stitchable base,
for additional support or
cosmetics only
SNAP pushSNAP S sewable STRIPE slim
adjustability by buckle,
hook-and-loop area,
additional triglide or
flexible straps
FIDLOCK
prototype
some buckle options
concept: WINCH T
rope / wire housed in fabric
flap, tunnel, or other lacing
construction
detach handle to open
whole flap,
turn handle to tighten
WINCH momentum WINCH elegance
FIDLOCK
prototype
Development in
Progress!
We are looking for FEEDBACK!
Prototypes for testing available,
if you are interested - Let‘s talk!
some buckle options
concept: C
SNAP pushSNAP buckleMINI TURN
Contact us to learn about the
various ways to customize
your buckle with your own
color or logo!
Customized housings, designs
or even function required?
No problem - get in contact to
learn about the process!
You want your FIDLOCK part
to be fully integrated into
another part or you
need a different attachment
method? - Let‘s talk!
FIDLOCK
prototype
Fidlock Footwear concepts / 18.02.2021
Not all availible styles of FIDLOCK
closures are shown in this presentation.
For more detailed information on FIDLOCK,
working principles and technical specs for
each style please check out our website.
The full range of our catalogue products can
be found there.
In case you desire a certain way of
attachment for your closure (like for stitching
or a different webbing size, etc. ...) which is
not in our catalogue simply get in contact.
Some of the shoes shown in this presentation
were modified by FIDLOCK and do not
represent or indicate the ideas or partnership
of/with the brand of these shoes.
F
!
P K
H F T
D D
P: +49 (0) 511/ 961 593 13
M: +49 (0) 160/ 59 74 108
E: .@.
S W
K A M
P: +49 (0) 511 961 593038
M: +49 (0) 160 507 855 9
E: .@.
All our products close automatically
using magnetic attraction !
Once engaged they form a strong and
secure mechanical connection !
T Y F Y A !
