UV-AIRE®AIR PURIFYING SYSTEM
Model: UV-16R
Duct Board Mounting Instructions
Mount the supplied metal mounting plate onto the duct with duct tape in either a vertical or horizontal1.
position as shown in Figure 2 of main instruction sheet. (See Figure 1)
Bend tabs outward as shown in Figure 2.
2.
Using a knife or blade, cut out a rectangle opening in the duct using the mounting plate as a template.3.
(See Figure 3)
Remove the cut piece of duct. (See Figure 4)
4.
Bend both tabs down and through duct at first bend point. (See Figures 5 & 6)5.
Bend both tabs at the second bend point up or down to pinch the duct material and grip the duct material.6.
(See Figures 7 & 8)
Using a screwdriver or pointed object, locate mounting holes by poking holes through the duct tape.
7.
(See Figure 9)
Continue installation using main instruction sheet beginning at step 5 on page 3.
8.
Figure 9Figure 8Figure 7Figure 6
Figure 5
Figure 1 Figure 3 Figure 2 Figure 4
WARNING: Never expose eyes or skin to UVC light from any source. Looking directly at the UVC light may cause permanent eye damage or blindness.
Never operate the UV-Aire Air Purifying System out of the plenum. Avoid touching the glass portion of the lamp with your hands.
© Field Controls, LLC P/N 46512300 Rev A 10/09
