Bionaire LC0760 Manual

99.97% HEPAair cleaners
MODEL LC0760/LC1060/LC1460
Read instructions before operating. Retain for future reference.
Instruction Leaflet
INFO-LINE
If after having read this leaflet, you have any
questions or comments on your air cleaner,
call 1-800-253-2764 in North America.
☎

2
AIR CLEANER SAFETY
PLEASE READ AND SAVE
THESE IMPORTANT
INSTRUCTIONS.
IMPORTANT SAFEGUARDS
1. When using electrical appliances, basic safety precautions
should always be followed to reduce the risk of fire, electric
shock, and injury to persons, including the following:
2. Read all instructions before using the appliance
3. To avoid fire or shock hazard, plug the appliance directly
into a 120V AC electrical outlet.
4. Remove plastic bag over filter before use.
5. Keep the cord out of heavy traffic areas. To avoid fire haz-
ard, NEVER put the cord under rugs, near heat registers,
radiator, stoves, or heaters.
6. To protect against electrical hazards, DO NOT immerse
in water or other liquids. Do not use near water.
7. Close supervision is necessary when any appliance
is used by or near children, or by disabled people.
8. Always unplug the air cleaner before moving it, opening the
grill, changing filters, cleaning, or whenever the air cleaner
is not is use. Be sure to pull by the plug and not the cord.
9. NEVER drop or insert any object into any openings.
10. DO NOT operate any appliance with a damaged cord
or plug, if motor fan fails to rotate, after the appliance
malfunctions, or if it has been dropped or damaged in any
manner. Return appliance to manufacturer for examination,
electrical or mechanical adjustment, or repair.
11. Use appliance only for intended household use as
described in this manual. Any other use not recommended
by the manufacturer may cause fire, electric shock, or injury
to persons. The use of attachments not recommended or
sold by Bionaire®may cause hazards.
12. DO NOT use outdoors.
13. NEVER block the air openings or place on a soft surface
such as a bed or sofa, as this could cause the unit to tip
over, blocking the Air Intake Grill.

3
14. Keep unit away from heated surfaces and open flames.
15. DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void your
warranty. The inside of the unit contains no user serviceable
parts. All servicing should be performed by qualified
personnel only.
PLEASE SAVE THESE
INSTRUCTIONS.
CONSUMER SAFETY INFORMATION
WARNING: To reduce the risk of fire or electric shock,
DO NOT use this air cleaner with any solid-state speed
control device.
THIS PRODUCT IS EQUIPPED WITH A POLARIZED AC
(Alternating Current) PLUG (a plug having one blade wider than
the other). This plug will fit into the power outlet only one way. If
the plug does not fit fully into the outlet, reverse the plug. If it
still does not fit, contact qualified
personnel to install the proper outlet.
DO NOT DEFEAT THE SAFETY
PURPOSE OF THIS POLARIZED
PLUG IN ANY WAY.
The length of cord used on this
appliance was selected to reduce the hazards of becoming tan-
gled in, or tripping over a longer cord. If a longer cord is neces-
sary an approved extension cord may be used. The electrical
rating of the extension cord must be equal to or greater than
the rating of the air cleaner. Care must be taken to arrange the
extension cord so that it will not drape over the countertop or
tabletop where it can be pulled on by children or accidentally
tripped over.
CONGRATULATIONS!
By choosing a Bionaire®Air Cleaner you have acquired a lifetime
of fresher air.
Your Bionaire®Air Cleaner represents the culmination of years
of research and development into the problems of cleaning
air in home or office environments. It is a top-quality, affordable
machine offering a unique filtration process that represents a
breakthrough in the application of modern technology.

HOW YOUR HEPA AIR CLEANER WORKS
Dirty, dust-laden air is drawn through the Air Intake Grill of the
unit where it first passes through the HEPA filter cartridge.
The HEPA media removes virtually all airborne particles passing
through it.
Additionally, the filter is treated with Microban®antimicrobial
protection. This protects the filter by inhibiting the growth of
odor-causing bacteria and mold on the filter surface.
The air then passes through an activated carbon filter, which
helps to remove odors.
Finally the outlet air stream has a negative ion emitter which
further enhances the cleaning of the air through the electrostatic
precipitation of small airborne particles.
Clean air is not a luxury – It is a necessity!
FEATURES AND CONTROLS
1. Air Intake Grill – Air is drawn into the front/top
(depending on unit orientation) of the air cleaner.
2. Air Exit Grill – After the air has been cleaned, it is
dispersed into the surroundings through the outlet grill.
3. Negative Ion Source – A feature of the air cleaner is the
incorporation of a negative ion generator. Negative ions help
clean the air by electrostatic precipitation of small airborne
particles. If the unit is close to a wall and/or in a very polluted
area, some deposition of particles on objects surrounding
the Air Cleaner will occur and may accelerate the natural
darkening of the immediate environment. To avoid
discoloration of walls, move unit away from wall
or operate ionizer only as needed.
4. Function Switch – The units mode of operation is controlled
by a simple rotary switch. The user can select the unit to
have fan operation with or without ions being emitted.
This switch also turns the unit “off”. 4
Fig 1
Function Switch
Fan Control
Air Intake Grill
Air Exit Grill
Negative ion Source
Filter Check Light
Filter Condition Monitor

5. Indicator Lights – Indicator lights tell the user when the unit
is on, (“Power” symbol), and when the unit's mode is set to
have ions emitted, (“Ions” symbol).
6. Filter Condition Monitor – When the ball, at high speed
setting, reaches the high end of the indicator scale, the filter
cartridge is loaded with particulate pollutants and needs
changing (LC0760 & LC1060).
7. Fan Control – The air-cleaning rate of the unit can be
controlled for maximum efficiency and convenience. The
two speed fan control is used to select the operating speed
of the fan. The unit is designed to run continuously at the
low speed setting. For extended motor life, it is recommend-
ed that the high speed setting be used only when necessary.
8. Filter Check Light (LC1460) – An electric switch senses the
condition of the filter cartridge and turns on an indicator light
if the filter cartridge needs to be changed.
PRE-OPERATING INSTRUCTIONS
1. When removing the unit from the packing case, visually
check for shipping damage. Please contact both the shipper
and your dealer immediately if the unit bears any sign of
damage from mishandling. All Bionaire®units are carefully
inspected before leaving our factory.
2. KEEP SHIPPING CARTON AND PACKING for use in the
unlikely event that your Bionaire®unit needs servicing. If this
unit is shipped without the original packing, damage could
occur and void the warranty.
3. PLEASE REFER TO THE FOLLOWING PROCEDURE
BEFORE OPERATING YOUR NEW Bionaire®Air Cleaner.
WARNING: Check the operating voltage shown on
the back of the unit. Do not operate at voltages other
than shown.
OPERATING INSTRUCTIONS
1. Remove the inlet grill, remove the HEPA filter cartridge and
the carbon filter and remove any plastic wrapping or panels
from them. Re-install the filters as per the section “Filter
Replacement”.
2. After re-installing the filters, choose a suitable location,
table top, shelf or wall (see wall-mount instructions)
ensuring that both the air intake and exit are not obstructed.
The air cleaner can be placed as a vertical “tall” unit, or
5

as a horizontal “low profile” unit, depending on your
personal preference.
3. Plug the power cord into a wall outlet.
4. Set the unit to the desired mode of operation, “Fan/On”
or “Fan/Ions”.
5. Select the desired fan speed (LC1060 & LC1460 “Low,”
“Med” or “High”) (LC0760 “Low” or “High”).
Low Airflow - For continuous, extra quiet filtration.
Medium Airflow - For continuous filtration.
High Airflow - For maximum, transient pollution filtration.
NOTE: Maximum filtration efficiency may not be reached
until after the first 48 hours of operation.
CLEANING INSTRUCTIONS
Be sure the unit is switched off and unplugged from the power
outlet.
PLASTIC HOUSING - A soft cloth and non-abrasive cleaner
may be used to remove any excessive dirt or fingerprints.
Treated like any other quality appliance, your Bionaire®unit
will retain its attractive appearance for many years.
ION EMITTER PINS - FIRST, TURN OFF AND UNPLUG THE
UNIT. Reach into the air exit grill with a cotton swab dipped into
alcohol to clean any dirt that may have accumulated on the pins.
Use caution when cleaning pins.
WARNING: Do not wash the HEPA filter cartridge or the
carbon filter. These are disposable items.
FILTER REPLACEMENT
To keep your unit operating at peak efficiency, the HEPA filter
cartridge should be replaced as needed or as indicated by the
Filter Condition Monitor (figure 2, LC0760 & LC1060). The HEPA
filter cartridge is designed with large media surface areas and
may last up to one year in typical operation. The rate at which
the filter clogs with particulates depends on the volume and
quality of air being filtered. If the unit is used continuously on
high in a room with a strong source of particulates, such as a
work shop, then the effective life of the filter will be reduced. In a
cleaner environment, operating mainly on lower speeds, the filter
will last longer. The carbon filter should be replaced regularly,
about every three months or when odor removal effectiveness
is noticeably reduced. 6

Filter Condition Evaluation
To test the condition of the filter cartridge, turn the unit on high
speed and observe the output airflow of the unit. When the filter
cartridge becomes clogged with particles there will be a notice-
able drop in air flow and the air output will no longer be steady.
Additionally, the indicator ball will be hovering in the upper region
of the flow meter (figure 2, LC0760 & LC1060).
Replacing the Carbon Filter
1. Unplug the unit. Place unit on its back.
2. Press on the two side catches to release the front
inlet grill (figure 3).
3. Carefully remove the HEPA filter cartridge (figure 4).
4. Remove and discard the carbon filter located in
the base of the unit (figure 4).
5. Remove any protective wrap from the
replacement carbon filter and place it in the
base of the unit (figure 5).
6. Mark the new installation date on the side
of the HEPA filter cartridge. Insert it in the unit
with the foam tape of the filter pressing
against the carbon filter (figure 5).
7. Install the inlet grill (figure 6).
Replacing the HEPA Filter Cartridge
1. Repeat steps 1-5 of carbon filter replacement.
2. Remove any protective wrapping or panels from the new
HEPA filter cartridge, mark the new installation date on the
side panel of the HEPA Cartridge and place foam side first in
the unit (figure 5).
3. Install the inlet grill (figure 6).
7
Fig 2
Fig 3
Indicator Ball
Side Catches

8
THE ADDITIONAL BENEFIT OF NEGATIVE IONIZATION.
This Bionaire®model is a compact air cleaner offering the
benefits of negative ionization. Behind the outlet grill you will
notice two sharp pins pointing into the airstream. This is the
ionization source.
Responding to the challenge of improving the quality of indoor
air, Bionaire®introduced compact air cleaners to combine
the revolutionary HEPA filter system along with ion generators
producing millions of negative ions.
In order to maintain the ion output, the emitter pins should
be cleaned, as per the “Cleaning Instructions”, when an
accumulation of dust is noticed on the tips of the pins.
After extended use, dust may collect around the outlet panel.
This is due to the electrostatic precipitation process initiated
by the negative ions emerging from the unit. This dust does
not originate from the discharged air but is drawn out of the
uncleaned air going past the air outlet. It is additional evidence
of the air-cleaning effectiveness of negative ions. The dust is
easily removed by wiping the panel with a soft cloth.
WALL-MOUNTING
There are two keyhole slots on the back which allow
the unit to hang on two suitable screws inserted into a wall.
Select #8 Pan Head screws that are approximately
1" - 1 1/4" long that can be inserted into and retained by the
keyhole slots. Verify their suitability before fixing them in the wall
by sliding them into the keyhole slots.
Carefully mark the two hole locations horizontally on the
wall (distance between holes should be; 4.5 inches (11.4 cm).
Make sure that the screws are of correct length to give reliable
support. The use of wall plugs or expansion devices will be
needed for plaster board walls.
Drive screws into the wall leaving a gap of 3/8 inch (9.5 mm)
between the wall and the underside of the screw head.
Hold the air cleaner against the wall, insert the screw heads
into the keyhole slots, carefully lower the unit to fully engage the
Fig 4 Fig 5 Fig 6

9
screw heads into the slots. Adjust height of the screw head as
required to suit the wall’s contours.
AIR CLEANER TROUBLESHOOTING GUIDE
SERVICE INSTRUCTIONS
Do NOT attempt to repair or adjust any electrical or mechanical
functions on this unit. Doing so will void the warranty. The inside
of the unit contains no user serviceable parts. All servicing
should be performed by qualified personnel only.
If you need to exchange the unit, please return it in its original
carton, with a sales receipt, to the store where you purchased
it. If you are returning the unit more than 30 days after the date
of purchase, please see the enclosed warranty.
Should your air cleaner require service, please consult the
enclosed lists of authorized service centers for the one closest
to you, or please call 1-800-253-2764 in North America for
further assistance.
4. If you have any other questions or comments,
feel free to write to us:
PO Box 400
Milford, MA 01757
USA Canada
6385 Shawson Drive
Mississauga, Ontario
Canada, L5T IS7
Visit our website www.bionaire.com
Solution
Problem
✔Make sure the electrical outlet or circuit breaker is
working.
✔ Check that the unit is plugged in.
✔ Check that front inlet grill is securely in place.
✔ If unit continues to not operate call 1-800-253-2764
for assistance.
✔If the Filter Condition Light is on, or the Indicator Ball
is hovering in the upper region of the filter monitor, it is
indicating low performance and the filter needs to be
replaced. For replacement filters call 1-800-253-2764
or visit www.bionaire.com.
✔ Make sure inlet and outlet are not blocked.
✔ Check carbon filter.
✔Because on negative ions emerging from the unit,
dust may collect. To remove wipe panel or wall with soft
cloth. Move unit further from wall.
☛Decreased airflow.
☛Unit will not operate.
☛Dust on front grills or wall.

FILTER REPLACEMENT NUMBERS
#LC-0760 #LC-1060 #LC-1460
Filter Cartridge: One HEPA filter cartridge.
Order No: #A0701H #A1001H #A1401H
Carbon filter: Four activated carbon filters.
Order No: #A0702C #A1002C #A1402C
TWO (2) YEAR LIMITED WARRANTY
Bionaire®warrants for TWO (2) YEARS from the date of original pur-
chase, to repair or, if repairs are not commercially applicable to replace
without charge (parts and labor), any supplied or manufactured part
of this air cleaner which, upon inspection by an authorized service
center, proves to have failed in normal use due to defects in mate-
rial or workmanship, or, at its option, to replace the unit. If the
product can not be reasonably repaired the consumer may elect a
free replacement or refund.
Operations under conditions other than those recommended or at
voltages other than the voltage indicated on the unit, or any
attempts by unauthorized personnel to service the unit or modify it,
will render the guarantee void.
Bionaire®shall not be liable for any personal injury, property dam-
age or any incidental or consequential damages of any kind (includ-
ing water damage), resulting from defects, malfunctions, misuse,
improper installation or alteration of the product.
BIONAIRE®EXPRESSLY DISCLAIMS ALL RESPONSIBILITY
FOR CONSEQUENTIAL DAMAGES OR INCIDENTAL LOSSES
FOR BREACH OF EXPRESS OR IMPLIED WARRANTIES
CAUSED BY USE OF THIS PRODUCT. SOME STATES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCE-
DENTAL OR CONSEQUENTIAL DAMAGE.
The provisions of this warranty are in addition to, and not a modification
of, or subtraction from the statutory warranties and other rights and
remedies contained in any applicable legislation and to the extent
that any such provision purports to disclaim, exclude or limit any
such statutory warranties or other rights or remedies, such
provisions shall be deemed to be amended to the extent
necessary to comply therewith.
For Warranty Service, please call 1-800-253-2764 in North America.
A Bionaire®consumer service representative will help determine
which is the best procedure in order for your air cleaner to be
repaired.
KEEP THIS NUMBER FOR FUTURE REFERENCE.
10

428-867
