Fieldmann FDB 201401-E User manual

'%#&

1
3
6
7
2
4
5
9
3
A
8
10
11

4
E
B C
D
F G
2
8
)'%(

5
OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER
ENContents
Electrical Angle Grinder
INSTRUCTION MANUAL
Thank you for your purchase of the electrical circular saw. For your personal
safety, read and understand the Instruction Manual before using. Keep the Instruction
Manual in a safe place for future reference.
CONTENTS
GENERAL SAFETY INSTRUCTIONS ............................................................................................. 
SYMBOLS ..............................................................................................................................................
MACHINE DESCRIPTION AND ITEMS DELIVERED .............................................................
GENERAL SAFETY INSTRUCTIONS ............................................................................................
SPECIAL SAFETY INSTRUCTIONS ............................................................................................. 1
USE AND OPERATION .................................................................................................................. 1
WORKING WITH ANGLE GRINDER ........................................................................................ 
CLEANING AND MAINTENANCE ........................................................................................... 1
OPERATION AND MAINTENANCE HINTS ............................................................................ 1
TECHNICAL SPECIFICATIONS ................................................................................................... 
DISPOSAL ........................................................................................................................................... 
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.


OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER
ENSymbols
2. SYMBOLS

  
   
   
    
   
      
8VHHDUVSURWHFWLYHHTXLSPHQW

EN Machine description and items delivered | General safety instructions
3. MACHINE DESCRIPTION AND ITEMS
DELIVERED
Machine Description (See fig. 1)
Switch
Side Handle
Disk Lock-Button
Spindle
Protective Cover
Case
1 -
2 -
3 -
4 -
5 -
6 -
Screw of Protective Cover
Washer
Grindstone
Tightening Female Screw
Tightening Spanner
7 -
8 -
9 -
10 -
11 -
Items Delivered
Remove all contents from the box and inspect to ensure no damage was incurred during
shipping, and that the items listed below are included.:
Angle grinder
Side Handle
Tightening nuts
Flange key
Disc guard
Instruction Manual
Should the components be missing or damaged, contact the dealer of the machine.
4. GENERAL SAFETY INSTRUCTIONS
Please read these safety instructions carefully, remember them and keep
them in a safe place
WARNING! When using electric machinery and power tools, it is important to abide by
and adhere to the following safety instructions for reasons of protection against injury caused
by electric current, injury of persons and risk of starting fires. The term “power tools” used
in the instructions below refers to power tools that are plugged into a power supply (by a
power cord) as well as tools running on a battery pack (cordless). Keep all warnings and
instructions for further use.
Work environment
Keep the work area clean and well lit. Untidiness and dark places on the job site are usually
causes of accidents. Store tools that are not used.
)'%(


OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER
ENGeneral safety instructions
Do not use power tools in an environment where there is risk of starting a fire or explosion;
this refers to places where there are flammable liquids, gases or dust. Sparks form on the
power tool’s commutator, which can cause dust or fume ignition.
When using power tools, unauthorized persons, especially children, should be denied entry to
the job site! In case you are interrupted, you can lose control of the current activity. In any
case, do not leave the power tool without supervision. Prevent animals from approaching the
equipment.
Electrical safety
The power tool’s power plug must correspond to the power outlet. Never alter the plug in any
way. If the tool’s plug has a safety peg, never use an adapter of any kind. Undamaged plugs
and corresponding outlets prevent the risk of injury by electric current. If the power cord is
damaged, it must be replaced by a new power cord that can be obtained from an authorized
service centre or the importer.
Avoid bodily contact with grounded items, e.g. piping, radiators, kitchen ranges and
refrigerators. The risk of injury by electric current is greater if your body is connected to the
ground.
Do not expose power tools to rain, moisture or dampness. Never touch power tools with wet
hands. Never wash power tools with running water and never submerse them into water.
Do not use the power cord for any other purpose than originally intended. Never carry or pull
the power tools by the power cord. Do not pull the plug out of the outlet by pulling on the cord.
Avoid mechanical damage to the power cord by sharp or hot objects.
Power tools were manufactured exclusively for the AC power supply. Always check if the
electrical voltage corresponds to the data printed on the tool’s serial number label.
Never work with a tool that has a damaged power cord or plug, or that has fallen on the
ground and is damaged in any way.
In the case of using an extension cord, always check that its technical parameters
correspond to the data printed on the tool’s serial number label. If the power tool is used
outdoors, use an extension cord that is appropriate for exterior use. When using an extension
cable drum, the cord must be unwound to prevent the cord from overheating.
If the power tool is used in moist areas or outdoors, it is permitted to use it only if it is plugged
into an electric circuit with a residual current device ≤30 mA. Using a circuit with an RCD
lowers the risk of injury by electric current.
Grasp hand power tools at the designated isolated grip areas because, during operation,
one may come into contact with the cutting or drilling fittings with a hidden conductor or with
the power cord.

EN General safety instructions
Personal safety
When using a power tool, be careful and alert, pay special attention to the activity you are
doing. Concentrate on your work. Do not work with power tools if you are tired or if you
are under the influence of drugs, alcohol or medication. When using power tools, even a
momentary lapse in attentiveness can lead to severe personal injury. Do not eat, drink or
smoke while working with power tools.
Use protective gear. Always use eye protection. Use protective gear corresponding to the type
of work you are doing. Protective gear such as respirators, safety shoes with antiskid
treatment, head protection or ear protection, used in accordance with working conditions,
lower the risk of personal injury.
Avoid unintentional operation of tools. Do not carry tools that are plugged into the electric grid
with your finger on the switch or release trigger. Before connecting the tool to a power supply,
make sure that the switch or release trigger are in the “off” position. Carrying tools with your
finger on the switch or plugging the tool into an outlet with the switch in the “on” position can
cause serious injury.
Before turning tools on, remove all adjustment wrenches and tools. The adjustment wrench or
tool that stays connected to the rotating part of the power tool can cause personal injury.
Always stand firmly and keep your balance. Work only in places that you can reach safely.
Never overestimate your own strength. Do not use power tools if you are tired.
Dress appropriately. Use working clothes. Do not wear loose clothing or jewellery. Make sure
that your hair, clothing, gloves or other body parts do not come overly close to rotating or
heated parts of the power tool.
Connect the equipment to the dust exhaust. If the tool offers the possibility to connect
equipment for capturing dust or dust suction, make sure that it is properly connected and
used. Using this equipment can reduce danger resulting from dust.
Firmly fasten the workpiece. Use a carpenter’s clamp or vice to secure the piece you will be
cutting.
Do not use power tools if you are under the influence of alcohol, drugs, medication or other
narcotics or addictive substances.
This equipment is not intended to be used by persons with limited physical, sensory or mental
abilities (including children) or persons with insufficient experience and knowledge, unless
they are supervised or received instructions to use the equipment from a person responsible
for his/her safety. Children must be supervised in order to ensure that they are not playing
with the equipment.
Using power tools and their maintenance
Always disconnect the power tool from the electric grid if there is any problem during work,
before every cleaning or maintenance, during every shift and after finishing work! Never work
with power tools if they are damaged in any way.
If the tool starts emitting abnormal noises or odours, immediately stop working.
)'%(

1
OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER
ENGeneral safety instructions
Do not overload power tools. The power tool will function better and more safely if it operates
at speeds for which it was designed. Use correct tools that are designated for the given
activity. The correct tool works better and more safely.
Do not use power tools that cannot be turned on safely and cannot be turned on and off
with a control switch. Using this type of tool is dangerous. Faulty switches must be repaired at
a certified service centre.
Disconnect the tool from the power supply before you start setting, changing accessories or
maintenance. This measure will prevent the risk of accidental start-up.
Store unused power tools so that they are out of the reach of children and unauthorized
persons. Power tools in the hands of inexperienced users can be dangerous. Store power
tools in a dry and safe place.
Keep power tools in good condition. Regularly check the setting of moving parts and their
movability. Check if the protective cover or other parts that can limit the safe functioning of the
power tool are not damaged. If the tool is damaged, ensure its proper repair before the next
use. Many injuries are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained and sharpened tools make work
easier, limit the risk of injury and work with them is much more easily controlled. Using other
accessories than those listed in the instruction manual can cause damage to the tool and
can cause injury.
Use power tools, accessories, work tools, etc. in accordance with these instructions and in a
way that is described for the specific power tool and with regard to the given working
conditions and the type of job. Using tools for other purposes than those intended can lead to
dangerous situations.

EN  General safety instructions | Specific safety instructions
Service
Do not change parts of the tool, do not perform repairs on your own and do not interfere with
the tool’s construction in any way. Leave tool repairs to qualified persons.
Each repair or product modification performed without our company’s permission is
inadmissible (it can cause injury or harm to the user).
Always leave tools to be repaired in a certified service centre. Use only original or
recommended spare parts. This will ensure your and your tool’s safety.
5. SPECIAL SAFETY INSTRUCTIONS
WARNING!
Safety warning for works such as grinding, surfacing, wire brushing,
polishing or abrasive cutting
Before use, please read these safety instructions and keep them
in a safe place.
Upon failure to follow the instructions specified in this manual, there is a risk of injury.
Angle grinder conforms to applicable technical regulations and standards.
These electro-mechanical tools are intended for use as grinder, surface grinder, wire
brusher, polisher or cutting tool. It is necessary to read all safety warnings, instructions,
illustrations and specifications for the electro-mechanical tools. Non-compliance with
the below mentioned instructions can lead to injury by electrical current, fire and/or
serious injury.
It is not recommended to use the tools for works such as grinding, surfacing, wire
brushing, polishing or cutting. Using the tools for work, for which it is not designed,
may cause risks and injury of persons.
Accessories not specifically designed and recommended by the tool's manufacturer
may not be used. The mere fact, that an accessory can be connected to your tool
does not guarantee its safe operation.
The nominal speed of the accessory has to be at least equal the maximal speed marked
on the tool. Accessories, operating at higher speeds than its nominal speed, can break
and fall apart.
The outer diameter and thickness of the accessory has to be within the limits of the
nominal range for particular electromechanical tools. The accessories of incorrect size
cannot be sufficiently guarded or controlled.
Chucking dimensions of disks, flanges, support blocks or other accessories have to be
suitable for the tool's spindle. The accessories with chucking holes, which do not match
the assembly dimensions of electromechanical tools, will be unbalanced, can generate
excessive vibrations and can cause loss of control.
FDB 2001-E

Safety warning for works such as grinding, surfacing, wire brushing,
polishing or abrasive cutting
It is prohibited to use damaged accessories. The accessories have to be checked prior
to each use: splitting and cracks of grinding disks, cracks of support blocks, tearing of
excessive wear, loose or broken wires on wire brushes. If the accessories or tools were
dropped, check it for damage or install undamaged accessories. After checking and
installation of the accessories the operator and bystanders have to stand outside the
plane of the rotating accessories and the tool has to be left running idle at the highest
speed for one minute. During this trial period damaged accessory usually breaks or
falls apart.
Personal protective equipment has to be used. According to condition a face shield or
safety goggles have to be used. Use dust mask, hearing protection, gloves and work
apron, capable of arresting small fragments of the abrasive material or work piece, as
appropriate. Eye protection has to be capable of arresting flying fragments, generated
during various work activities. Dust mask or respirator has to be able of filtering particles,
generated during a particular activity. Long-term exposure to high-intensity noise can
cause loss of hearing.
Bystanders have to keep a safe distance from the working area. Everyone entering the
working area has to use personal protective equipment. Fragment of the work piece or
damaged accessories may fly away and cause injury even outside the immediate
working area.
During work, during which the tool can touch a hidden wiring or its own power supply, the
electromechanical tool has to be held by the insulated holding surfaces. Contact of the
tool with a "live" wire can cause the metallic parts of the electromechanical tool to become
"live" and may cause an injury by electric current.
Mobile power supply has to be placed outside the reach of the rotating tool. In case the
operator looses control, the mobile power supply can be cut or ground through, and a
hand or arm of the operator may be dragged to the rotating tool.
Electromechanical tool may not be put down before the tool stops completely. Rotating
tool may get caught on a surface and may pull the tool out of the operator's control.
Electromechanical tool may not be started while the tool is carried by the operator. Rotating
tool may, in case of a accidental contact, catch clothing and be pulled to the body.
Ventilation holes of the tool have to the cleaned regularly. The motor ventilator brags dust
into the casing and excessive accumulation of metallic dust can cause an electric hazard.
Work with electromechanical tool in the vicinity of flammable materials is prohibited.
Ignition of the materials by sparks may occur.
Use of accessories requiring cooling by liquid is prohibited. Use of water or other coolants
may cause injury or death by electric current.
1ENSpecific safety instructions | Use and operation
OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER

Additional safety instructions for grinding and cutting
Safety warnings specific for grinding and abrasive cutting:
EN 1 General safety instructions | Specific safety instructions
FDB 2001-E
Kick-back is a sudden reaction on pinching or seizing of a rotating disk, support block,
brush or other accessory. Pinching or seizing causes sudden stoppage of a rotating
tool, which subsequently causes, that uncontrolled tool moves in the opposite direction
to the rotation of the tool in the moment of seizing.
Kick-back is a consequence of the use of electromechanical tools and/or incorrect
working procedures of conditions and it can be prevented by the compliance with the
below described safety measures.
The tool has to be held firmly while maintaining a correct position of the body and arms
to resist the forces of the kick-back. Auxiliary handle has to be used if the tool is fitted with
it, for maximum control of the kick-back or reaction torque when starting the tool. The
operator can control the reaction torques and the kick-back forces if the correct safety
measures are observed.
Do not put hands in the vicinity of the rotating tool. The kick-back of the tool may throw the
operators arm away.
Do not stand in the area, into which the tool might be thrown by the kick-back. Kick-back
will throw the tool in the opposite direction to the movement of the disk at the moment of
seizure.
Pay special attention to the machining of corners, sharp edges etc. Prevent skipping and
seizure of the tool. Corners, sharp edges or skipping tends to cause seizure of a rotating
tool and loss of control or kick-back.
Never attach saw chain woodcarving disk or toothed saw disk to the tool. These disks
frequently cause a kick-back or loss of control.
Use types of disks recommended for a particular electromechanical tool and particular
guard, which is designed for the selected disk. Disks, for which the electromechanical toll
was not designed, cannot be appropriately guarded and are dangerous.
Protective guard has to be securely attached to the electromechanical tool and placed for
maximum safety so the smallest possible part of the disk is uncovered from the operator's
point of view. A protective guard helps to protect the operator from fragments of the disk,
accidental contact with the disk and sparks, which could ignite clothing.
The disks may be used only for a recommended purpose. For example: grinding with the
side of a cutting disk is prohibited. Abrasive cutting disks are intended for a circumferential
cutting, side forces applied on these disks could shatter them.
Always use undamaged disk flanges with appropriate size and shape. Correct disk flanges
support the disk and reduce the risk of shattering. Flanges for cutting disks may be different
from flanges for grinding disk.
Do not use worn disks, with larger original dimensions, intended for larger electromechanical
tools. Disks intended for larger electromechanical tools are not suitable for higher speeds of
smaller tools and may shatter.

Additional safety instructions for cutting
Additional safety warnings specific for abrasive cutting:
Additional safety instructions for surfacing
Safety warnings specific for surfacing:
Additional safety instructions for polishing
Safety warnings specific for polishing:
-Cutting disk may not strike material or exert excessive pressure. Do net attempt to
achieve excessive depth of cut. Overloading of the disk increases the risk of distortion
or seizing of the disk and kick-back or breaking of the disk.
Do not stand in line with the rotating disk or behind it. In the moment when a disk is
moving in the point of contact away from the operator's body, kick-back may throw the
spinning disk and electromechanical tool directly on the operator.
If the disk seizes or cutting is interrupted for any reason, electromechanical tool has to be
switched off and held motionless, until the disk stops completely. The operator may not
attempt to remove the cutting disk from a cut while the disk is moving, because it may
cause a kick-back. Check the situation and take steps to prevent seizure of the disk.
Do not start the cutting in the work piece again. Let the disk to reach full speed and insert it
carefully into the cut. It the tool is restarted with the disk inserted in the cut, it may lead to
its seizure, pushing up or a kick-back.
Panels and other large work pieces have to be supported to reduce the risk of seizure and
kick-back. Large pieces of work have a tendency to bend under its own weight. The supports
have to be placed beneath the work piece close to the line of cutting and close to the edges
of the work piece on both sides of the disk.
Pay special attention while "cutting into a cavity" into current walls of other blind spaces.
The penetrating disk may cut through a gas or water line, electric cables or objects, which
may cause a kick-back.
Do not use sand paper of excessive size for the grinding disk. Follow the manufacturer's
instructions while selecting the sand paper. Large sand paper, which extends over the
grinding disk, represents a risk of tearing and may cause seizure, tearing of the disk or a
kick-back.
Do not let any loose parts of the polishing sleeve or its attachment strings rotate freely.
All lose attachment strings have to be slipped beneath or cut away. Loose and rotating
attachment strings may get caught in the operator's fingers or in the work piece.
1ENSpecific safety instructions | Use and operation
OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER

Additional safety instructions for wire brushing
Safety warnings specific for wire brushing:
EN 1General safety instructions | Specific safety instructions
FDB 2001-E
This product is not intended for wire brushing
Wire bristles are thrown away even during normal work. Do not overload wires
by excessive pressure on the brush. Wire bristles may easily penetrate light
clothing and/or skin.
If a protective guard is recommended for wire brushing, make sure any contact
between the wire disk or brush and the protective cover is prevented. Wire disk
or brush may, due to loading or centrifugal forces during work, increase its
diameter.
Do not use other accessories except for grinding, cutting and diamond discs.
Never use the tools without the safety screen.
Always use eye protection (protective goggles or safety shield) and hearing protection.
Do not use any cutting and grinding discs for side grinding.
Make sure to keep the vents free of any obstacles during dusty work.
During wall cutting check that there are no electric lines in the walls (using metal detector).
Never water-cool grinding disc.
Do not touch the edge after machining, it may be hot.
Never attach the grinding machine to the work bench.
Make sure that the rotational speed specified on the grinding disc is higher than or equals the
rotational speed of the angle grinder specified in the type label.
Do not cut any material that requires a cut with maximum depth exceeding the depth of the
grinding disc.
Do not cut and grind light metals with higher magnesium content than 80% as such metals
are flammable
Make sure that the grinding disc has the right dimensions and is correctly mounted on the
spindle.
Handle the grinding discs very carefully and in accordance with instructions supplied with the
grinding disc.
Inspect the grinding disc before each use.
Do not use grinding discs that are cracked or otherwise damaged.
Make sure that the grinding disc is mounted according to instructions.
After mounting the grinding disc, let the grinder run at idle speed in a safe place. If the grinder
shows strong vibrations or if the grinding disc shows visible damage, immediately turn off the
grinder and try to identify the cause.

1ENSpecific safety instructions | Use and operation
Do not use any reducers or other auxiliary parts for mounting grinding discs intended for
different spindle diameter.
Make sure that the material is adequately supported or fixed.
Never use grinding disc to remove burrs.
Make sure to prevent the sparks from hitting a person or igniting inflammable goods.
Do not work with the grinder if someone is standing in the line of the grinding disc. Make sure
to clean up the working area around you.
Press the locking knob of the disc (3) only after the engine and spindle of the grinder have
completely stopped !
Remember that the grinding disc will continue to rotate for a while after switching off the
grinder due to inertia.
Always use the auxiliary handle supplied with the tool.
Loss of control over the electric tools could cause injury.
WARNING! Use means of protection against noise, dust and vibrations !!!
WARNING! Keep these safety instructions!!!
6. USE AND OPERATION
This angle grinder is intended for household or hobby use only.
The manufacturer and importer do not recommend using this tool in extreme conditions and
under high load.
Any other additional requirements must be agreed between the manufacturer and the
customer.
The machine is intended for cutting, grinding, rough-working and polishing of metals, stones
and ceramic articles, if a suitable disc is used.
Use the machine and attachments (note the manufacturer‘s specifications) only for the
intended range of applications.
Any other use is strictly forbidden.
Attaching the side handle (Figure B)
Mount the side handle (2) into one of the mounting holes.
How to attach and remove the safety guard (Figure C)
Unscrew the bolt of the safety guard fastening clamp (7).
Attach the safety guard (5) as shown in the figure (C) and tighten the bolt firmly.
Use reverse procedure to remove the safety guard.
WARNING! Never use the grinder without the safety screen.
OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER

EN1 Use and operation | Working with angle grinder
How to attach and remove the grinding disc (Figure D,E,F)
WARNING! Before attaching or removing the grinding disc always unplug the supply cable
of the grinder from the socket.
Put the grinder onto table with the spindle facing up.
Attach the safety guard (5) according to instructions specified above.
Fit the washer (8) on the spindle (4).
Fit the grinding disc (9) on the washer.
Screw the tightening nut (10) onto the spindle.
Press the locking knob (3) and firmly tighten the tightening nut (10) using the Phillips
screwdriver.
If grinding disc is used, tighten the tightening nut (10) with the guiding lobe facing down (E1).
If cutting disc is used, tighten the tightening nut (10) with the guiding lobe facing up (E2).
WARNING! Press the locking knob of the spindle (3) only after the engine and the spindle
of the grinder have stopped and are not running!
You must hold the locking knob of the spindle (3) during the entire replacement of the disc.
Release the locking knob.
Use reverse procedure to remove the grinding disc.
Switching On and Off (Figure G)
Switch on the grinder by sliding the switch (1) to position “I”
Switch off the grinder by sliding the switch (1) to position “0”.
7. WORKING WITH ANGLE GRINDER
The optimum angle of disc to work piece is 150°.
Maintain the largest possible distance between the disc and operator.
Exert only slight pressure and no lateral load on the disc. Note the direction of rotation
and watch out for flying sparks.
Avoid knocking the work piece.
If the disc diameter is less than 80 mm, change the disc.
)'%(

1
OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER
ENCleaning and maintenance | Operation and maintenance hints
8. CLEANING AND MAINTENANCE
Before cleaning and maintenance, always unplug the supply cable of the tool from the socket.
Your tool requires no additional lubrication or maintenance. It contains no parts that can be
repaired by you.
Never use water or chemical cleaners to clean your tool. Wipe the tool using a dry cloth.
Keep the engine fan apertures clean.
If you notice very weak sparking in the engine area, your tool is in good order. If the sparking
is more intense, it indicates the engine fault.
Never clean any part of the toll using a hard, sharp or rough object.
Inspection and Replacement of Carbon Brushes
Carbon brushes need to be checked on a regular basis.
In case of wear and tear, replace both carbon brushes simultaneously. Attach the carbon
brush holders.
After attaching new carbon brushes, let the grinder run, without load, for 5 minutes.
Use only correct types of carbon brushes.
Storage if the tool is not used for a long time
Do not store the tool in places with high temperatures.
Store the equipment in a place with constant temperature and humidity.
9. OPERATION AND MAINTENANCE
HINTS
Store the machine, Instruction Manual and the accessories in the original packaging. In
this way you will always have all the information and parts ready to hand.
Devices are to a large extent free of maintenance, you only need a damp cloth to clean the
casing. Do not drop electrical machines into water. Please note additional hints given in the
Instruction Manual.

EN1 7HFKQLFDOVSHFLILFDWLRQV
)'%(
1.TECHNICAL SPECIFICATIONS
Power supply...................................................................................................................................... 230V~/ 50Hz
Power input.........................................................................................................................................................8
Speed.................................................................................................................................................... rpm
Protection class............................................................................................................................................................. II
Disc diameter .............................................................................................................................................. Ø  mm
Spindle thread ....................................................................................................................................................... M 14
Power supply cable length............................................................................................................................... 1.8 m
LpA: (sound pressure level)................................................................................................................ dB(A)
LwA: (sound power level).....................................................................................................................dB (A)
7ibration level.............................................................................................BI%NT,NT
,QVWUXFWLRQV0DQXDOODQJXDJHYHUVLRQRQO\
$PHQGPHQWVWRWH[WDQGWHFKQLFDOSDUDPHWHUVDUHUHVHUYHG
&KDQJHVLQWKHWH[WGHVLJQDQGWHFKQLFDOVSHFLILFDWLRQVPD\FKDQJHZLWKRXWSULRUQRWLFHDQGZHUHVHUYHWKH
ULJKWWRPDNHWKHVHFKDQJHVNHHSLWIURPWXUQLQJDVWKHGULOOELWURWDWHV


OPERATING INSTRUCTIONSELECTRICAL ANGLE GRINDER
ENTechnical specifications

     
 

%& $ 
& ' 
 
 !""#$

( () 
    
  

    

 


 
 
  

 !  
 
  
 

 "

# !



 #     $ %
 
$ 
% 
&
#
' !  

' $ %
' 
(
'&
')

EN 'LVSRVDO
.DISPOSAL
The machine and its accessories are made of various materials, e.g. of metal and plastics.
Hand-over damaged components to sorted waste. Get yourselves informed at a respective
authority.
INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED PACKAGING.
Put any used package material to the place determined by the municipality for waste
disposal.
DISPOSAL OF USED ELECTRIC AND ELECTRONIC EQUIPMENT
This symbol on products or accompanying documents means that used
electric or electronic products must not be put to ordinary municipal waste.
Hand over such products to determined collection points for proper disposal,
restoration and recycling. Alternatively, in some countries of the European
Union or other European countries you can return your products to your local
dealer when you buy an equivalent new product. By dutiful disposal of this
product you can preserve precious natural resources and you help prevent any
potential adverse effects on the environment and human health which could
be the results of wrong waste disposal. Ask your local authority or the nearest
collection point for additional details. In case of improper disposal of this waste
kind penalties can be imposed in accordance with national regulations.
For companies in the European Union countries
Should you want to dispose of electric and electronic devices, ask your dealer
or vendor for necessary information. Disposal in other countries outside the
European Union. Should you want to dispose of this product, ask your local
authorities or your dealer for necessary information about disposal method.
This product fulfils all basic requirements of the EU directives that apply to it.
Text, design and technical specifications can change without prior notice and we reserve
the right for their change.
)'%(
