Fieldmann FZK 70305-0 User manual

FZK 70305-0

2
FZK 70305-0
English.................................................................................................................................................................................................. 3 - 19
Česky .................................................................................................................................................................................................21–37
Slovensky........................................................................................................................................................................................... 39–55
Magyarul............................................................................................................................................................................................57–73
Polski .................................................................................................................................................................................................75–91

EN
ELECTRIC TILLER USER’S MANUAL
3
Thank you for purchasing this cordless tiller.
Before using it, please carefully read this User manual and keep it in a safe place for
further use. This product was designed and built according to our high norms for reliability, ease of use and
safety of operation. With proper care, it will give you many years of reliable problem-free service.
TABLE OF CONTENTS
1. General safety instructions ...................................................................................................................................4
Important safety notice...........................................................................................................................................4
Packaging ......................................................................................................................................................................6
User manual...................................................................................................................................................................6
2. Basics of work safety .................................................................................................................................................7
Work clothes/work area..........................................................................................................................................8
Interrupting work..........................................................................................................................................................8
Other risks........................................................................................................................................................................8
3. Symbols ...........................................................................................................................................................................9
4. Purpose of use..............................................................................................................................................................9
5. Machine description ..............................................................................................................................................10
6. Assembly........................................................................................................................................................................11
7. Using.................................................................................................................................................................................15
Removing foreign objects....................................................................................................................................15
8. Maintenance ..............................................................................................................................................................15
9. Storage ...........................................................................................................................................................................17
10. Technical specifications........................................................................................................................................17
11. Disposal..........................................................................................................................................................................18
Table of contents EN3
CORDLESS TILLER
USER'S MANUAL
Li-ION
20V
FASTPOWER

EN 4
FZK 70305-0
General safety instructions
1. GENERAL SAFETY INSTRUCTIONS
Important safety notice
Carefully unpack the product and take care not to throw away any part of the packaging before you find all the
parts of the product.
Store the product in a dry place out of reach of children.
Read all warnings and instructions. Failure to follow warnings or instructions may lead to injury by electrical
shock, fire and/or serious injuries.
Before using, check that everybody that will be using the machine has read and understood these safety
instructions and other information contained in this user's manual.
ATTENTION: Use appropriate hearing protection when using this machine. Under certain conditions and
after a certain period of using the machine, the produced noise may cause hearing loss.
Inspection of damaged parts
Before every use, all damaged parts must be carefully inspected to determine whether they will work correctly and
fulfil their function. Check the adjustment and fastening of moving parts, damaged parts, fastening elements and
other conditions which may affect operation. All damaged parts must be repaired or replaced.
Do not use in a hazardous environment
Do not use the machine in rain, during a storm or in a damp or wet environment. Do not operate the machine in an
environment where there are gases or in an explosive environment. The motors on these machines spark during
operation and these sparks could ignite the vapours.
Keep out of the reach of children
Bystanders, children and animals must be at a safe distance.
Dress appropriately
Do not wear loose clothing and jewellery and keep long hair inside a protective mesh cap. They could become
caught in the moving parts. When working outside, it is recommended to wear gloves and solid footwear.
Use safety glasses
When using this product, wear safety glasses with protective sides. In the case of a dusty environment, use a face
mask or respirator.
Double insulation
The tiller is equipped with double insulation. This means that all metal parts are insulated from the electrical power
supply. This is achieved by an insulating layer between the electrical and mechanical parts. Double insulation
provides you with the highest possible level of safety.
EN 4

EN
ELECTRIC TILLER USER’S MANUAL
5
General safety instructions
Overheating protection
If the tiller is blocked by a foreign object or its motor is overloaded, a safety mechanism will automatically turn the
motor off. Release the start lever and wait until the motor cools down (approximately 15 minutes) before starting
the tiller again.
Disconnect the machine from the power supply if you will not be using it, if you are going to wash or repair
it. Do not leave it without supervision.
Do not damage the power cord
Never carry the machine by the power cord or tug on it in order to pull it out of the power socket. Protect the power
cord against heat, oil and sharp edges.
Use the machine properly
Do not use this appliance for other purposes than those for which it is intended (see chapter "Purpose of use").
Do not overestimate your abilities
Lead the tiller only at walking speed. When working, constantly maintain a firm posture and balance.
Lighting
Use the tiller only during daylight or strong artificial lighting.
Store the machine under a roof when not in use
If you are not using the tiller, place it under a roof in a dry location to which children do not have access.
Perform meticulous maintenance of the machine
For the best performance and lowest risk of injury, keep the machine clean and regularly check the extension cord
and replace it when it is damaged. Keep the handles dry, clean and unstained by oil.
Pay attention
Pay attention to what you are doing. Apply common sense. Do not use the tiller if you are tired or under the influence
of drugs or medication.
WARNING:: Do not use the tiller in the vicinity of underground electric or telephone cables, pipes or hoses.
If the tiller hits a foreign object, immediately turn it off, wait until the blades come to a stop and check them
for damage. If necessary, seek out the services of an authorised service centre. If the tiller begins to vibrate
excessively, immediately turn it off and identify the cause. Vibrations usually indicate a problem.
ATTENTION: Danger of cuts! When cleaning or carrying out maintenance on the tiller, please use
protective gloves and take care.
Before starting any type of maintenance or repair work on the tiller, turn it off, wait until the blades come to a stop
and disconnect it from the power supply.
ATTENTION: The blades will not come to a stop immediately after the tiller is turned off.
EN5

EN 6
FZK 70305-0
General safety instructions
ATTENTION: Risk of injury. Keep your hands, legs and other parts of your body and clothing always well
away from the rotating blades of the tiller.
Packaging
The product is packed in a package that prevents damage during transport. This packaging is a resource and can
be recycled.
User manual
Before you start working with the machine, read the following safety instructions and carefully study the funda-
mentals for work with the machine. Get familiar with the controls and correct use of the equipment. Keep the
user’s manual in a safe place for easy future reference. Save the original packaging, including the internal packing
material, guarantee card and proof of purchase receipt for at least the time of the guarantee. If you need to ship this
machine, pack it in the original cardboard box to ensure maximum protection during shipping or transport (e.g.
when moving or when you need to send this product for repair to a service centre).
NOTE: If you hand over the appliance to somebody else, do so together with this user's manual. Following
the instructions in the included user's manual is a prerequisite for the proper use of the power tool. The user’s
manual also contains operating, maintenance, and repair instructions. The manufacturer assumes no re-
sponsibility for accidents or damages arising from failure to comply with these instructions.
EN 6

EN
ELECTRIC TILLER USER’S MANUAL
7
Basics of work safety
2. BASICS OF WORK SAFETY
Never use the machine if the power cable is damaged or visibly worn.
In the event that you connect the tiller using a damaged power cord to a power source
and then touch the place that is uninsulated before the tiller is disconnected from the
power source, you subject yourself to a risk of injury by electrical shock.
Also, never touch the blades until the machine is disconnected from the power source
and until the blades completely stop.
Make sure that the extension cable never comes into contact with the blades. The
blades could damage the power cable insulation and create a risk of an electric
shock when a part of the body touches the exposed wire when it is live.
Disconnect the machine from the voltage source (i.e. pull the power cable plug out of
the mains power socket):
• If you need to leave the machine without supervision.
• If you are planning to carry out troubleshooting.
• Before every inspection, every cleaning or repairs.
• If you impact a foreign object when working with it.
• If the machine vibrates excessively.
RECOMMENDATION: Only connect the machine to a power source that has a residual current device
(RCD) with a maximum leakage current of 30mA.
If the power cord is damaged, it must be replaced by the manufacturer or by an authorised customer service.
This machine must not be operated by persons with limited physical, sensory or mental abilities (including
children). Furthermore, it must not be used by inexperienced people who do not have the technical knowledge
to operate it. These people must be supervised by a competent person or instructed about the basics of work
safety.
If children are moving around in the vicinity of the machine, it is necessary to watch that they do not play with
the machine.
A tingling sensation in one's hands or their numbness are indications of excessive vibrations. If this happens,
shorten the work cycle, take sufficiently long breaks, share the work among several people or in the event of
long term use of the tiller, use special anti-vibration gloves when working.
An unavoidable associated consequence of using the tiller is that it emits noise when it is running. Therefore,
only do noisy work during dedicated hours, or when this type of activity is normal. Respect quiet times and
try to limit the work to the shortest possible time. We also recommend that you and the persons near the tiller
wear ear protectors.
EN7

EN 8
FZK 70305-0
Basics of work safety
Do not use the electric tiller with damaged, deformed or worn out safety mechanisms (start safety switch, safety
cover) and/or blades. To avoid incorrect balance, faulty parts and bolts must be replaced in sets without exception.
Prior to starting work, look for and remove foreign objects (for example stones, branches, etc.).
If during work you hit an obstacle or if the blades jam up then turn the electric tiller off, pull the power plug out
of the socket and wait until the blades come to a stop. Then remove the obstacle. Check the electric tiller for
damage and if necessary seek assistance at an authorised service centre.
Only use the electric tiller for purposes described in this user's manual.
Do not pull the tiller along a hard surface (concrete, footpaths) or up/down stairs. Do not overload the motor.
Do not place any additional weight on the tiller. After you have finished using the tiller, disconnect it from the
power supply and check the machine and in particular the blades for damage and if necessary seek out an
authorised service centre.
Be particularly careful when walking backwards. You could stumble!
When working on a slope, always work perpendicular to the slope and maintain a safe and firm posture.
Pay increased attention when changing direction on a slope and do not work on extremely steep slopes.
Work only under good visibility.
Work clothes/work area
You are responsible for safety in the work area.
Make sure that there are no people (especially children) or animals in the vicinity of the work area.
Wear robust work boots and long pants to provide protection to your legs. Never use the tiller when wearing
sandals or barefoot.
Keep hands and feet away from the blades – in particular when starting the machine! Keep the extension cord
away from the blades.
Acquaint yourself with the surroundings and be aware of potential risks which could be ignored due to the
noise of the machine.
Never use the machine when it is raining or in a damp or wet environment. Never work in the direct vicinity of
swimming pools and garden ponds.
Interrupting work
Never leave the electric tiller in the work area without supervision.
When you interrupt work, always leave the electric tiller in a safe location and disconnect it from the power
supply.
When moving the tiller from one work area to another, turn it off and wait for the blades to come to a stop.
Disconnect the power cord.
Other risks
Despite the fact that our products are designed to meet the valid technical norms and safety directives in force,
there still remain certain risks to the user associated with the operation of the machine:
• Stones and other fragments may fly out of the area of the blades.
• If the operator of the machine fails to use hearing protection, they risk subsequent deafness.
• Finger injury during blade maintenance.
• Inhalation of dust particles created when working with the tiller.
• Electrical shock when uninsulated parts are touched.
EN 8

EN
ELECTRIC TILLER USER’S MANUAL
9
Symbols | Purpose of use
3. SYMBOLS
Warning:
Read the user's manual!
Do not use in rain or in wet conditions!
Other people must remain at a safe distance!
Rotating parts! The blades of the tiller stop only some time after the motor is shut
off.
In accordance with the basic safety standards of European directives in force.
This machine is protected by double insulation and so it is not necessary to use a
grounding wire.
Always check that the voltage in the grid corresponds to the voltage on the rating
label.
Use hearing protection!
Use eye protection!
Use respiratory tract protection!
4. PURPOSE OF USE
The FIELDMANN cordless tiller is designed for breaking up larger lumps of soil and hardened chunks of soil on
small to medium size horticultural areas, home gardens and garden allotments. It is not intended for use on public
fields, in parks, sports centres, on roads, in agriculture or forestry.
The cordless tiller must not be used to smash stones or for ploughing up grass areas!
Following these instruction is a prerequisite for the correct use of the cordless tiller.
EN9

EN 10
FZK 70305-0
Machine description
5. MACHINE DESCRIPTION
A Main Unit
This is the main part of the machine.
B Lower Bars
The lowers bars connect to the main unit.
C Handle Bars
You must hold these with both hands when in
use.
D Middle Bar
The middle bar connects to the lowers bars.
E Tine Blades
F 2 × Wheels
These attach onto the wheel axle.
G 2 × Wheel Covers
These slot onto the wheels after you have
attached them onto the wheel axle.
H Wheel Axle
Assemble the wheels onto this.
H1 Wheel Axle Bracket
This attaches to the lower bars. There is a wheel
height adjuster pin which allows you to choose
from two positions. You can choose from the
working position (the wheels are up from the
ground and the transport position (the wheels
are on the ground).
I 2 × Washers For The Wheels
These are part of the wheel assembly.
J 2 × Spirt Pins
These are part of the wheel assembly.
K Cable Clips
These keep the cable secure and tight to the
machine.
L 4 × Wing Nuts
These secure the bars together. You can loosen
them to fold the handlebar down for storage.
M 4 × Bolls
These secure the bars together.
N Upper Bar:
This connects to the middle bar.
O 2 × Bolts To Attach Wheel Axle To Machine
These secure the wheel axle onto the lower bars.
P 2 × Spacers
These slot onto the bolts (O).
Q 2 × Washers
These are part of attaching the wheel axle onto the
lower bars.
R 2 × Nuts
Use these to secure the wheel axle onto the lower
bars.
S 1 × Washer
This is part of attaching the wheel axle to the right-
hand lower bar (if stood behind the handlebars).
W Wheel Height Adjuster Pin
Use this pin to select a position for the wheels
(transport positon or working position).
Fig. 1
A
B
C
D
E
F
EN 10

EN
ELECTRIC TILLER USER’S MANUAL
11
Assembly
6. ASSEMBLY
There are 6 steps to the assembly:
STEP 1. Assemble The Wheels
STEP 2. Attach The Wheels
STEP 3. Attach The Middle Bar
STEP 4. Attach The upper Bar
STEP 5. Attach The Cable Clips
STEP 6. Cable Holder On Handle
STEP 1: Assemble The Wheels
1. Place the wheel (F) on the axle (H).
2. Place a washer (I) over the axle on top of the wheel.
STEP 1: Assemble The Wheels (Continued)
5. Place a split pin (J) through the axle hole. You must spread the split pin after inserting it. This will stop the
wheel from falling off.
EN11

EN 12
FZK 70305-0
Assembly
6. Fit a wheel cover (G) onto the wheel (F) and clip it into place. You must line up the tabs on the wheel cover
into the slots on the wheel.
7. Do this for both wheels.
STEP 2: Attach The Wheels
1. Place the spacer (P) onto the bolt (O). Then insert the bolt through the hole on the wheel axle bracket (H1).
Make sure the washer fits inside the hole as shown.
2. Right-hand side (opposite the wheel height adjuster pin) - Place the washer (S) onto the bolt
(O) before inserting the bolt through the hole on the lower handlebar.
Left-hand side (next to the wheel height adjuster pin) - There is no need to add a washer to this
side. Push the bolt through the hole on the lower handlebar.
EN 12

EN
ELECTRIC TILLER USER’S MANUAL
13
Assembly
STEP 3: Attach The Middle Bar
1. Connect the middle bar (D) to the lower bars (B) using the wing nut (L) and bolt (M).
STEP 4: Attach The Upper Bar
1. Connect the upper bar (N) to the middle bar (D) using the wing nut (L) and bolt: (M).
Make sure the upper
bar is attached the
correct way as shown
in this image.
EN13

EN 14
FZK 70305-0
Assembly
STEP 5: Attach The Cable Clips
1. Attach the cable onto the right-hand handlebar (D) using the cable clips (K) provided. This will keep the cable
secure and tight to the machine.
STEP 6: Cable Holder On Handle
Make sure the machine is disconnected from power before you do this. If the machine
is plugged in, you may accidentally press the trigger.
This holds the cable in place while in use and prevents strain on the cable.
1. Make a small loop in the power cable (Y).
2. Put the loop through the hole in the handle and on to the hook (U).
3. Slowly pull the loop to remove slack.
EN 14

EN
ELECTRIC TILLER USER’S MANUAL
15
Using | Maintenance
7. USING
To prepare a garden bed for sowing, it is recommended to use on of the following patterns:
Loosening pattern A – Travel over the loosened area twice, the second time in cross direction to the first run, see
fig.11.
Loosening pattern B – Travel over the loosened area twice, the second time overlap the first run, see fig.11.
Before use, remove all visible stones or other foreign objects.
AB
Fig. 11
ATTENTION: Before moving the tiller from one area to another, turn the motor off and wait until the blades
stop rotating. Be careful that the blades do not touch the ground while the tiller is being moved. The blades
and the machine itself may be damaged even when the motor is turned off.
Removing foreign objects
During operation a stone or root may become stuck in the blades or high grass or weeds may become tangled
around the shaft. To clean the blades or the shaft, first release the starting lever, wait until the blades come to a
complete stop and disconnect the tiller from the power supply. Release or remove foreign objects from the blades
or the shaft. To make the removal of tall grass of weeds easier, remove one or several of the blades.
8. MAINTENANCE
Disconnect the power source before performing maintenance.
While performing maintenance use protective gloves.
Before every use, check that the extension cord exhibits no signs of damage or ageing. Replace the power cord
if it is frayed or otherwise damaged. Check the condition of the blades and ensure that all threaded connections
are pulled tight. If the blades are blunt, sharpen or replace them. For support, call an authorised service centre.
Only replace worn out or damaged parts with original spare parts. Parts from a different tiller/cultivator may not
necessarily be compatible, which may result in a dangerous situation.
EN15

EN 16
FZK 70305-0
Maintenance
Check that all safety mechanisms are safe and in good condition. Repair or replace it if necessary. Lubricate the
blades and shaft once per season. Before putting the tiller away at the end of the season, check that it is not dam-
aged. Repair or replace damaged parts.
ATTENTION: Clean the tiller after every use. Neglecting proper cleaning may result in damage to the tiller or
a reduction in its performance. Clean the bottom motor bearer plate and the blade cover with a brush and a
soft wiping cloth dipped in a soap and water solution.
Never use a hose with water to clean the tiller!Never wash the tiller under running water,
in particular with pressurised water.
If you want to remove soil and dirt from the gearbox and blades, use a stiff brush or a dampened cloth. Clean the
holes on the motor cover and remove all grass and dirt remains. After cleaning the blades and shaft, immediately
wipe them dry and apply a thin layer of oil to prevent corrosion.
Installing and removing the blades
For this task, we recommend that you contact an authorised service centre.
Worn out blades provide only a low level of performance and overload the motor.
Check the blades before each use. Sharpen or replace the blade if necessary. For support, contact an authorised
service centre.
WARNING:: Injuries may occur when working on the blades. Use protective gloves.
To remove the blades from the shaft (fig.12), screw out the hex bolt M8 x 40 from the shaft. Take the blades off the
shaft. To install the blades, proceed in reverse order.
Fig. 12 M8× 40 M8 ×40

EN
ELECTRIC TILLER USER’S MANUAL
17
Storage | Technical specifications
9. STORAGE
ATTENTION: Risk of fire! The gearbox may be very hot both during and after use.
Store the tiller at a safe distance from fuels, oils, Vaseline and gasses.
Thoroughly clean the entire machine and its accessories.
Store it out of reach of children in a stable safe position in a cool dry location, avoid both excessively high and
excessively low temperatures. Protect it against the exposure to direct sunlight. If possible, store it in the dark. Do
not store in plastic bags to prevent the accumulation of moisture.
At the end of every season, perform a general inspection of the machine and remove any deposits that may have
accumulated. At the start of every season, make sure that you have checked the condition of the machine. If repairs
are necessary, please contact one of our service centres (address is on the warranty card).
Store the tiller in a clean dry location to which children do not have access.
For long term storage, ensure that the tiller is protected against corrosion and frost.
At the end of a season or if you will not be using the tiller for longer than a month, wipe all metal surfaces with a
cloth dipped in oil or spray it with a thin layer of oil to protect it from corrosion. Fold down the handle and store the
tiller in a suitable location.
10. TECHNICAL SPECIFICATIONS
Charger Voltage: ....................................................................................................................................................100-240V/50-60HZ
Rated Voltage:.........................................................................................................................................40 V (2 x 20V Li-ion battery)
No-load Speed: ...............................................................................................................................................................................180rpm
Working Width: .............................................................................................................................................................................. 360mm
Working Depth:.............................................................................................................................................................................. 220mm
Blade:..................................................................................................................................................................................................4*4pcs

EN 18
FZK 70305-0
Disposal
11. DISPOSAL
Instructions and information about the handling of used packaging
Dispose of used packaging material at a site designated for waste in your municipality.
Theapplianceanditsaccessoriesaremanufacturedfromvariousmaterials,e.g.metalandplastic.
Take damaged parts to a recycling centre. Inquire at the relevant government department.
This appliance meets all the basic requirements of the EU directives.
Changes in the text, design and technical specifications may be made without prior notice and we reserve
the right to make these changes.
User manual in the original language.

EN
ELECTRIC TILLER USER’S MANUAL
19
Declaration of conformity

h>Zd/KEK&KE&KZD/dz

WƌŽĚƵĐƚďƌĂŶĚŽƌĚůĞƐƐDŽƚŽƌ,ŽĞ&/>DEE

dLJƉĞŵŽĚĞů&<ϳϬϯϬϱͲϬĂƐĨĂĐƚŽƌLJŵŽĚĞůtZϴϴϬϭͲtͲ^ͲϯϲϬ,ϭ
ϰϬs;ϮdžϮϬsďĂƚƚĞƌLJƉŽǁĞƌĞĚͿǁŽƌŬŝŶŐǁŝĚƚŚϯϲϬŵŵ
>WсϳϳϱĚ;Ϳ>tсϵϭϲĚ;Ϳ

DĂŶƵĨĂĐƚƵƌĞƌ &^dZĂƐ
h^ĂŶŝƚĂƐƵϭϲϮϭϮϱϭϬϭ\şēĂŶLJnjĞĐŚZĞƉƵďůŝĐ
sdŶŽϮϰϳϳϳϳϰϵ

dŚŝƐĚĞĐůĂƌĂƚŝŽŶŽĨĐŽŶĨŽƌŵŝƚLJŝƐŝƐƐƵĞĚƵŶĚĞƌƚŚĞƐŽůĞƌĞƐƉŽŶƐŝďŝůŝƚLJŽĨƚŚĞŵĂŶƵĨĂĐƚƵƌĞƌ

dŚĞŽďũĞĐƚŽĨƚŚĞĚĞĐůĂƌĂƚŝŽŶĚĞƐĐƌŝďĞĚĂďŽǀĞŝƐŝŶĐŽŶĨŽƌŵŝƚLJǁŝƚŚƚŚĞƌĞůĞǀĂŶƚhŶŝŽŶ
ŚĂƌŵŽŶŝnjĂƚŝŽŶůĞŐŝƐůĂƚŝŽŶ
ŝƌĞĐƚŝǀĞDϮϬϬϲϰϮ ŝƌĞĐƚŝǀĞDϮϬϭϰϯϬh  
ŝƌĞĐƚŝǀĞEKϮϬϬϬϭϰ ŝƌĞĐƚŝǀĞZŽ,^ϮϬϭϭϲϱh

dŚĞƌĞůĞǀĂŶƚŚĂƌŵŽŶŝnjĞĚƐƚĂŶĚĂƌĚƐĂŶĚƚŚĞŽƚŚĞƌƚĞĐŚŶŝĐĂůƐƉĞĐŝĨŝĐĂƚŝŽŶƐ
 E/^KϭϮϭϬϬϮϬϭϬ EϲϬϯϯϱͲϭϮϬϭϮнϭϭнϭϯнϭнϭϰнϮ 
 EϳϬϵϭϵϵϳнϰ  EϲϮϯϯϮϬϬϴ
 EϱϱϬϭϰͲϭϮϬϭϳнϭϭ EϱϱϬϭϰͲϮϮϬϭϱ





WůĂĐĞŽĨŝƐƐƵĂŶĐĞWƌĂŐƵĞ EĂŵĞWĞƚƌhŚĞƌͲZĞƐƉŽŶƐŝďůĞWĞƌƐŽŶ
ĂƚĞŽĨŝƐƐƵĂŶĐĞϭϯϬϲϮϬϮϮ ^ŝŐŶĂƚƵƌĞ

