FieldServer Data Aire (DAP) FS-8704-49 Release note

A Sierra Monitor Company
APPLICABILITY & EFFECTIVITY
Effective for all systems manufacture after May 1, 2001
Driver Manual
(Supplement to the Fiel Server Instruction Manual)
FS-8704-49 Data Aire (DAP)
Driver Version:
1.07
Document Revision: 9

FS-8700-49_Data_Aire_DAP Table of Contents
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
TABLE OF CONTENTS
1. Data Aire Description..................................................................................................... 4
1.1. Performance Issues - DARTIII only............................................................................ 4
1.2. Data Alarm Network Module Network LED Operation ................................................ 4
2. Driver Scope of Supply.................................................................................................. 5
2.1. Supplied by FieldSer er Technologies for this dri er.................................................. 5
3. Har ware Connections .................................................................................................. 6
4. Configuring the Fiel Server as a Data Aire Client ....................................................... 7
4.1. Data Arrays/Descriptors............................................................................................. 7
4.2. Client Side Connection Descriptions .......................................................................... 8
4.3. Client Side Node Descriptors ..................................................................................... 9
4.4. Client Side Map Descriptors....................................................................................... 9
4.4.1. FieldServer Related Map Descriptor Parameters.................................................... 9
4.4.2. Driver Related Map Descriptor Parameters............................................................10
4.4.3. Timing Parameters ................................................................................................10
4.4.4. Map Descriptor E ample 1 - Everything.................................................................11
4.4.5. Map Descriptor: E ample 2 – Writing a Set-Point. .................................................11
4.4.6. Map Descriptor: E ample 3 – Writing multiple points using one message..............12
Appen ix A. Data Tables....................................................................................................13
Appendix A.1. Data Table 1: Array Locations of ‘E erything’...............................................13
Appendix A.2. Data Table 2 - Point Descriptions.................................................................18
Appendix A.3. Data Table 3 - Unit Types ............................................................................25
Appen ix B. A vance Topics...........................................................................................26
Appendix B.1. Additional Dri er Specific Map Descriptor Parameters .................................26
Appendix B.2. DA_Func Parameter - Permitted alues.......................................................27
Appendix B.3. DA_Field Parameter - Permitted alues. ......................................................28
Appendix B.4. DA_Method Parameter Values and Notes....................................................28
Appendix B.5. Ad anced Map Descriptor 1:Collecting Data From Multiple Fileds ...............29
Appendix B.6. Ad anced Map Descriptor Example 2:Collecting Error Messages................30
Appendix B.7. Ad anced Map Descriptor Example 3: Using Special DA Field ....................30
Appendix B.8. Ad anced Map Descriptor Example 4: - Using DA_Assoc............................31
Appendix B.9. Ad anced Map Descriptor: Example 5 - Using a special / diagnostic
command.: 31
Appendix B.10. Ad anced Map Descriptor: Example 6 – Turning Dap’s On/Off. .................32
Appen ix C. Troubleshooting Tips....................................................................................33
Appendix C.1. Bad Values ..................................................................................................33
Appendix C.2. Dead Nodes.................................................................................................33
Appendix C.3. Noise ...........................................................................................................33
Appendix C.4. Ignored Messages .......................................................................................33
Appendix C.5. Dri er limitation............................................................................................33
Appendix C.6. Baud Rate....................................................................................................33
Appendix C.7. Wiring. .........................................................................................................33
Appendix C.8. Stuck Unit. ...................................................................................................34
Appendix C.9. Number of Units...........................................................................................34
Appen ix D. Error Messages .............................................................................................35
Appendix D.1. Exposing Dri er Statistics ............................................................................38

FS-8700-49_Data_Aire_DAP Table of Contents
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Appen ix E. Writing ata to DAP Devices ........................................................................40
Appendix E.1. Background..................................................................................................40
Appendix E.2. Associated Map Descriptors.........................................................................40
Appendix E.3. Starting/Stopping DAP de ices ....................................................................41
Appendix E.4. DAP Unit Errors ...........................................................................................41
Appendix E.5. Using DA_Assoc correctly with Writes/Toggling Values ...............................46
Appen ix F. Write Through’s.............................................................................................47

FS-8700-49_Data_Aire_DAP Page 4 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
1. Data Aire Description
The Data Aire Dri er is capable of direct connection to a network of Data Aire DAP de ices.
The FieldSer er is connected in a RS-485 loop topology. Two FieldSer er ports are required
per loop. The dri er is an acti e client. All data is obtained by poll & response.
Connection to a DART is not supported by this dri er.
The dri er may be configured ery simply (See Section 4.4). A number of ad anced
configurations are also a ailable and are described in Appendix B. The dri er supports the
common message formats for common Data Aire DAP de ices. A list of the supported
messages is pro ided in the manual.
The information that follows describes how to expand upon the factory defaults pro ided in the
configuration files included with the FieldSer er.
1.1. Performance Issues - DARTIII only
Data Aire communication is based on a ery low baud rate. In addition inter-message timing
constraints and o erhead requirements for acti e messages in a Dart configuration add
significant time to each transaction. It is not possible to write a setpoint to a de ice until the
de ice has been successfully read, and the result of the write will not be seen until the next
read is complete. The result of a write may not be seen for some time due to slow
communications and significant inter poll delays.
1.2. Data Alarm Network Mo ule Network LED Operation
DAP-II units communicate with a DART unit by using a Data Alarm Network Module. This
module pro ides a RS-485 communications link. Installed on the card are se eral LEDS.
The table below explains how the LEDS appear under normal (correctly functioning)
operation.
LED LED Appearance
FUSE
The Network Module has a blown fuse detection circuit. If one (or more) of
the fuses has an open circuit, then the FUSE LED will be lit. Normally, this
LED is dark.
DS1 &
DS3
Communications signals enter and lea e the Network Module. These LEDS
reflect the communications acti ity. When first powered up, both LED's will
be lit and the illumination will be steady. As the DART communicates with
the network, both LED’s will begin to flicker in unison. All of the Network
Module LED’s will flicker at the same time.
NETWORK
At some point the DART will send a communication message to a specific
network-connected DAP-II that requires a reply to the DART. If the message
is recei ed without error, the DAP-II will reply by engaging a relay on the
Network Module and transmitting a message. When this happens the
NETWORK LED will come on. Whene er a NETWORK LED is seen to
come on it means that the communications into the Network Module is
satisfactory. It is still possible to ha e a wiring problem downstream of the
module that pre ents the message from being recei ed by the DART

FS-8700-49_Data_Aire_DAP Page 5 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
2. Driver Scope of Supply
2.1. Supplie by Fiel Server Technologies for this river
Fiel Server Technologies
PART # Description
RS-485 connection adapter
FS-8700-49 Dri er Manual.

FS-8700-49_Data_Aire_DAP Page 6 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
3. Har ware Connections
The FieldSer er is connected to the DAP de ices as shown in connection drawing.
Configure the DAP de ices according to manufacturer’s instructions
DATE: 1/22/01
BY: MN
MODEL 8051
MANUAL - DataAire
BASE NAME:
FILE NAME: T28700-49.VSD
RS485
9600 N81
MODEL 8051
Power Net 2 Net 1
R2 R1
DC AUX Power
Et hernet
10 Base T RS 485
(Opto - Isolated)
RS 232
1 Rx
2 CTS
3 DSR
4 GRO UND
GRO UND 5
DTR 6
RTS 7
Tx 8
18
P8 P7 P6 P5 P4 P3 P2
P1
0V
Gnd _ + Gnd FG _ +
_5V 5 00 m
A
FG
+ 12V 500 m
A
_12V 5 00 m
A
+5V 1 . 5A
SYSTEM NODE: 8
CONFIG PC
(RUISYS)
R2 R1
RS 485
(Opto - Isolated)
Gnd _ + Gnd FG _ +
Dap/Chiller/Dap80
+OUT -OUT SHD
FOR THIS WIRING
ARRANGEMENT THIS
IS THE PRIMARY PORT
SECONDARY PORT
TO OTHER DEVICES
+IN -IN SHD
Dap/Chiller/Dap80
+OUT -OUT SHD +IN -IN SHD

FS-8700-49_Data_Aire_DAP Page 7 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
4. Configuring the Fiel Server as a Data Aire Client
For a detailed discussion on FieldSer er configuration, please refer to the FieldSer er
instruction manual. The information that follows describes how to expand upon the factory
defaults pro ided in the configuration files included with the FieldSer er (See “.cs ” sample files
pro ided with the FieldSer er).
This section documents and describes the parameters necessary for configuring the FieldSer er
to communicate with a Data Aire Ser er
4.1. Data Arrays/Descriptors
The configuration file tells the FieldSer er about its interfaces, and the routing of data
required. In order to enable the FieldSer er for Data Aire communications, the dri er
independent FieldSer er buffers need to be declared in the “Data Arrays” section, the
destination de ice addresses need to be declared in the “Client Side Nodes” section, and
the data required from the ser ers needs to be mapped in the “Client Side Map Descriptors”
section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal alue being the
default.
Section Title
Data_Arrays
Column Title Function Legal Values
Data_Array_Name Pro ide name for Data Array Up to 15 alphanumeric
characters
Data_Array_Format Pro ide data format. Each Data
Array can only take on one format.
Float, Bit, UInt16, SInt16,
Packed_Bit, Byte,
Packed_Byte,
Swapped_Byte
Data_Array_Length
Number of Data Objects. Must be
larger than the data storage area
required by the Map Descriptors for
the data being placed in this array.
1-10,000
Example
// Data Arrays
Data_Arrays
Data_Array_Name, Data_Format, Data_Array_Length,
DA_AI_01, UInt16, 200
DA_AO_01, UInt16, 200
DA_DI_01, Bit, 200
DA_DO_01, Bit, 200

FS-8700-49_Data_Aire_DAP Page 8 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
4.2. Client Si e Connection Descriptions
Connections
Column Title Function Legal Values
Port
This is the FieldSer er port
connected to the DART’s RS-
232 port.
P1-P8, R1-R2
1
(P1-P8) requires 232/485
con erter.
Secondary_Port*
The return loop from the DAP
de ices is connected to this
port. (Loop connected to Tx+
& Tx- terminals.
P1-P8, R1-R2
1
(R1-R2) requires 232/485
con erter.
Baud* Specify baud rate 2400/9600
2
(Vendor
Limitation)
Parity* Specify parity None
Data_Bits* Specify data bits 8
Stop_Bits* Specify stop bits 1
Protocol Specify protocol used. Either
keyword may be used. DAP, Daire
Handshaking* Specify hardware
handshaking None
Poll Delay* Time between internal polls 0-32000s, 1s
Example
// Client Side Connections
Connections
Port, Secondary Port, Protocol, Baud, Parity, Data_Bits, Stop_Bits, Poll_Delay
R1, R2, DAP, 2400, None, 8, 1, 0.100s
1
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports a ailable on specific hardware.
2
DAP V9.5 or later supports 9600
Use this port identifier in the client side node
configuration described in Section 4.3.

FS-8700-49_Data_Aire_DAP Page 9 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
4.3. Client Si e No e Descriptors
Section Title
Nodes
Column Title Function Legal Values
Node_Name Pro ide name for node Up to 32 alphanumeric characters
Node_ID Modbus station address of
physical ser er node 1-259
Protocol Specify protocol used DAP
Connection Specify which port the de ice is
connected to the FieldSer er P1-P8, R1-R2
3
Example
// Client Side Nodes
Nodes
Node_Name Node_ID Protocol Connection
Unit1, 1, DAP, R1
4.4. Client Si e Map Descriptors
4.4.1. Fiel Server Relate Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map
Descriptor
Up to 32 alphanumeric
characters
Data_Array_Name
Name of Data Array
where data is to be
stored in the
FieldSer er
One of the Data Array
names from “Data Array”
section abo e
Data_Array_Offset Starting location in Data
Array
0 to maximum specified in
“Data Array” section abo e
Function Function of Client Map
Descriptor RDBC, WRBC, WRBX
3
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports a ailable on specific hardware.
This is the connection to the primary port identified with the
'Port' keyword in the connection configuration described in
Section 4.2

FS-8700-49_Data_Aire_DAP Page 10 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
4.4.2. Driver Relate Map Descriptor Parameters
Column Title Function Legal Values
Node_Name Name of Node to fetch data
from
One of the node names
specified in “Client Node
Descriptor” abo e
Data_Type Data type Register, Coil, AI, DI
Length Length of Map Descriptor 1
Address Starting address of read block
Not required for client
configuration - used in
simulation configuration only.
DA_Func*
Only required when the function
is a Read (rdbc).
Tells the dri er to poll the
de ice for all the data that is
a ailable. The data is de ice
specific.
Other uses of this parameter
are discussed in Appendix B .
E erything – See Appendix A
DA_Field
Required when the function is a
write (wrbc) or when the Map
Descriptor is associated with a
write by means of the
DA_Assoc parameter alue.
This is the name of the data
field whose alue you wish to
set in the de ice.
Other uses of this parameter
are discussed in Appendix B.
See Appendix A.2 for a list of
permitted alues.
DA_Assoc
Use to associate passi e Map
Descriptors with an acti e Map
Descriptor. Multiple fields can
be associated with one WRBC
Map Descriptor, thus writing
multiple alues to one de ice
using just one message.
Any positi e integer. See
Appendix E
4.4.3. Timing Parameters
Column Title Function Legal Values
Scan_Inter al Rate at which data is polled ≥0.1s

FS-8700-49_Data_Aire_DAP Page 11 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
4.4.4. Map Descriptor Example 1 - Everything
The FieldSer er listens passi ely for all possible data from the de ice called ‘unit1’ and stores the data in an array called ‘DA_01’.
The data that is obtained from ‘unit1’ is dependent on the type of de ice. Irrespecti e of the de ice type the arrangement of data, stored in DA_01, is fixed. If a data field cannot be obtained from ‘unit1’ then the array is left with a zero alue for that data field.
// Client Side Map Descriptors Map Descriptors Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Address, Length, DA_Func, Scan_Inter al Read_Node_01, DA_01, 0, RDBC, Unit1, 0, 1300, E erything, 2.5s
4.4.5. Map Descriptor: Example 2 – Writing a Set-Point.
// Client Side Map Descriptors Map Descriptors Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_Name, Address Length, DA_Field, Scan_Inter al Write_SP_01, DA_SETPOINTS, 0, WRBC, Unit1, 0, 1, nom_h_setpt, 120s
It is recommended that the format of the Data Array be FLOAT as the data read from the unit consists of bits, bytes and real numbers.
The node name connects the Map Descriptor to a node definition which in turn is connected to a port.
Always set the Address
to zero and the length to 1300 as this is the max number of data points that can be read
Tells the dri er that this Map Descriptor is used to (poll &) store a complete data set from the unit.
The scan inter al is used to control the minimum time between poll messages. It may take se eral polls / messages to obtain a complete data set (the number is dependent on the
unit type.)
The setpoint is obtained from this Data Array.
Always lea e the
address set to zero and the length as one
.
Select the data field from Appendix B.3. Ensure that the keyword can be written to the unit type identified as unit1. Example. If unit1 is a Chiller then the abo e Map Descriptor will not function correctly as it can only be used to write to unit types 7,9,14,15.
This is how often the data will be written to the de ice. Reduce the scan inter al when using a dart. The dart will only take control of the de ices when the network has been idle for at least 50 seconds. If polls are generated too often, the dart will ne er exercise control.

FS-8700-49_Data_Aire_DAP Page 12 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
4.4.6. Map Descriptor: Example 3 – Writing multiple points using one message.
Additional information is provided in Appendi B
// Client Side Map Descriptors Map Descriptors Map_Descriptor_Name, Data_Array_Name, Data_Array_Offset, Function, Node_name, Address, Length, DA_Field, DA_Assoc, Scan_Inter al Write_Map Descriptor_1, DA_SETPOINTS, 0, WRBC, Unit1, 0, 1, nom_h_setpt, 2, 120s Write_Map Descriptor_1, DA_SETPOINTS, 1, passi e, Unit1, 0, 1, t_setpt, 2,
A 'Write' and a passi e to the same node. This write
will update two fields, the nom_h_setpt and the t_setpt. The write Map Descriptor. must precede the passi e. For a Dart, use wrbx instead of wrbc.
Associate the passi e Map Descriptor to the acti e (wrbc) Map Descriptor. In
this way the dri er will use only one message to write to the de ice. The message will be built using both Map Descriptors. This method reduces the communication load. The association is made using the DA_Assoc parameter. Use unique positi e integers. Omitting the DA_Assoc parameter when using ‘passi e’ Map Descriptors will produce ambiguous results.

FS-8700-49_Data_Aire_DAP Page 13 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Appen ix A. Data Tables
Appendix A.1. Data Table 1: Array Locations of ‘Everything’
In the following table the array location indicates the offset in the Data Array at which a data
field can be found. (This offset is relati e to the offset specified in the Map Descriptor) The
columns headed 2, 3 … indicate the unit types for which the data fields are a ailable. For
example: The field ‘d_temp’ can be read from unit types 2, 5,6,7,9 but not from any of the
other unit types. It is beyond the scope of this manual to describe each field and to indicate
alid ranges. Such information should be obtained from the Data Aire Corporation.
‘x’ Indicates Read only
‘X’ Indicates a point that can be read & written.
‘w’ Indicates a write only point.
Array
Location
Metho
Num
Elements
Data Fiel 2 3 4 5 6 7 8 9 14 15 Message Type
1 1 1 Zone w w w w w w w w w Dap-Config
2 1 1 Inhibit w w w w w w w w w Dap-Config
3 4 1 unitType x x x x x x x x x x Dap-Unit
4 2 1 temp x x x x x Dap-Stat
5 2 1 hum x x x x x Dap-Stat
6 2 1 d_temp x x x x x Dap-Stat
7 3 8 mode x x x x x Dap-Stat
23 3 8 hold x x x x x Dap-Stat
39 1 1 cs_on x x x x x Dap-Stat
40 1 1 hs_on x x x x x Dap-Stat
41 1 1 al ePCT x x x x x Dap-Stat
42 1 1 hVl PCT x x x x x Dap-Stat
43 4 14 Errors - see Appendix E.4
for more information x
x x x x Dap-Stat
57 2 1 hiTemp x x x x x Dap-Stat
58 2 1 loTemp x x x x x Dap-Stat
59 2 1 hiHum x x x x x Dap-Stat
60 2 1 loHum x x x x x Dap-Stat
61 1 1 chilled_water x x x x x Dap-Stat
62 1 1 compressor_config x x x x x Dap-Stat
63 1 1 heat_strip_config x x x x x Dap-Stat
64 1 1 hum_config x x x x x Dap-Stat
65 1 1 csUtilPct x x x x x Dap-Stat
66 1 1 hsUtilPct x x x x x Dap-Stat
67 1 1 al eUtilPct x x x x x Dap-Stat
68 1 1 humUtilPCT x x x x x Dap-Stat
69 1 1 alrm_select_1 x x x x x Dap-Stat
70 1 1 alrm_select_2 x x x x x Dap-Stat
71 1 1 alrm_select_3 x x x x x Dap-Stat
72 1 1 alrm_select_4 x x x x x Dap-Stat

FS-8700-49_Data_Aire_DAP Page 14 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Array
Location
Metho
Num
Elements
Data Fiel 2 3 4 5 6 7 8 9 14 15 Message Type
73 3 56 bitErrors - see Appendix
E.4 for more information x
x x x x Dap-Stat
185 1 1 runtime_c1 x x x x x Dap-Xtra
186 1 1 runtime_c2 x x x x x Dap-Xtra
187 1 1 runtime_c3 x x x x x Dap-Xtra
188 1 1 runtime_c4 x x x x x Dap-Xtra
189 1 1 runtime_ht1 x x x x x Dap-Xtra
190 1 1 runtime_ht2 x x x x x Dap-Xtra
191 1 1 runtime_ht3 x x x x x Dap-Xtra
192 1 1 runtime_hum x x x x x Dap-Xtra
193 1 1 runtime_e ap x x x x x Dap-Xtra
194 1 1 runtime_cond x x x x x Dap-Xtra
195 1 1 runtime_dehum x x x x x Dap-Xtra
196 1 1 runtime_esc x x x x x Dap-Xtra
197 1 1 runtime_cwc x x x x x Dap-Xtra
198 4 20 errors x x x x x Dap-Xtra
218 6 10 errage x x x x x Dap-Xtra
258 1 1 ersion x x x x x Dap-Xtra
259 2 1 tmbmair x x x x x Dap-Xtra
260 2 1 tmbhum x x x x x Dap-Xtra
261 1 1 tmbairdb x x x x x Dap-Xtra
262 6 13 runtimes (as array) x x x x x Dap-Xtra
314 3 80 bitErrors x x x x x Dap-Xtra
474 4 1 adj_rate X X X Dap-Menu
478 1 1 alrm_delay_1 X X X Dap-Menu
479 1 1 alrm_delay_2 X X X Dap-Menu
480 1 1 alrm_delay_3 X X X Dap-Menu
481 4 1 alrm_enable_1 X X X Dap-Menu
482 4 1 alrm_enable_2 X X X Dap-Menu
483 4 1 alrm_enable_3 X X X Dap-Menu
484 4 1 alrm_select_1 X X X Dap-Menu
485 4 1 alrm_select_2 X X X Dap-Menu
486 4 1 alrm_select_3 X X X Dap-Menu
487 1 1 chilled_water X X X Dap-Menu
488 1 1 compressor_config X X X Dap-Menu
489 1 1 c_mode X X X Dap-Menu
490 2 1 fire_lim X X X Dap-Menu
491 1 1 heat_strip_config X X X Dap-Menu
492 1 1 hi_cal X X X Dap-Menu
493 1 1 hi_h_cal X X X Dap-Menu
494 2 1 hi_t_lim X X X Dap-Menu
495 1 1 humid_config X X X Dap-Menu
496 1 1 h_calib X X X Dap-Menu
497 1 1 lead_lag X X X Dap-Menu

FS-8700-49_Data_Aire_DAP Page 15 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Array
Location
Metho
Num
Elements
Data Fiel 2 3 4 5 6 7 8 9 14 15 Message Type
498 1 1 loc_h_deadband X X X Dap-Menu
499 1 1 loc_h_setpt X X X Dap-Menu
500 2 1 loc_t_dband X X X Dap-Menu
501 2 1 loc_t_setpt X X X Dap-Menu
502 1 1 lo_cal X X X Dap-Menu
503 1 1 lo_h_lim X X X Dap-Menu
504 2 1 lo_t_lim X X X Dap-Menu
505 1 1 main_int X X X Dap-Menu
506 1 1 passwd_a X X X Dap-Menu
507 1 1 passwd_b X X X Dap-Menu
508 1 1 rst_mode X X X Dap-Menu
509 1 1 s_delay X X X Dap-Menu
510 2 1 t_calib X X X Dap-Menu
511 1 1 oice X X X Dap-Menu
512 1 1 rg X X X Dap-Menu
513 1 1 cat1 X X X Dap-Menu
514 1 1 cat2 X X X Dap-Menu
515 1 1 cat3 X X X Dap-Menu
516 2 1 d_calib X X X Dap-Menu
517 2 1 lo_d_lim X X X Dap-Menu
518 1 1 ptc X X X Dap-Menu
519 2 1 supplyT x x x Chiller-Stat
520 2 1 returnT x x x Chiller-Stat
521 4 1 coolOn1 x x x Chiller-Stat
522 4 2 coolOn2 x x x Chiller-Stat
523 4 2 coolOn3 x x x Chiller-Stat
524 2 1 al ePct x x x Chiller-Stat
525 4 1 pumpsOn x x x Chiller-Stat
526 4 1 condOn x x x Chiller-Stat
527 4 1 modFail x x x Chiller-Stat
528 2 1 hiSupT x x x Chiller-Stat
529 2 1 loSupT x x x Chiller-Stat
530 2 1 hiRetT x x x Chiller-Stat
531 2 1 loRetT x x x Chiller-Stat
532 1 1 csUtilPct1 x x x Chiller-Stat
533 1 1 csUtilPct2 x x x Chiller-Stat
534 1 1 csUtilPct3 x x x Chiller-Stat
535 1 1 al eUtilPct x x x Chiller-Stat
536 3 48 Errors - see Appendix E.4
for more information x
x x Chiller-Stat
584 1 1 mode x x x Chiller-Stat
585 6 11 runtimes x x x Chiller-Xtra
596 3 80 errold x x x Chiller-Xtra
676 6 10 errage x x x Chiller-Xtra

FS-8700-49_Data_Aire_DAP Page 16 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Array
Location
Metho
Num
Elements
Data Fiel 2 3 4 5 6 7 8 9 14 15 Message Type
854 4 1 adjust_rate x x x Chiller-Menu
855 4 1 auto_ack X X X Chiller-Menu
856 2 1 aux_setpt X X X Chiller-Menu
857 4 1 backup_mods X X X Chiller-Menu
858 2 1 backup_setpt X X X Chiller-Menu
859 4 1 cmota X X X Chiller-Menu
860 4 1 comp_type X X X Chiller-Menu
861 4 1 ptc X X X Chiller-Menu
862 2 1 hi_r_lim X X X Chiller-Menu
863 2 1 hi_s_lim X X X Chiller-Menu
864 4 1 LL_policy X X X Chiller-Menu
865 2 1 lo_r_lim X X X Chiller-Menu
866 2 1 lo_s_lim X X X Chiller-Menu
867 1 1 main_int X X X Chiller-Menu
868 4 1 mods_configd X X X Chiller-Menu
869 1 1 network_ID X X X Chiller-Menu
870 1 1 op_1_delay X X X Chiller-Menu
871 1 1 op_2_delay X X X Chiller-Menu
872 4 1 op_1_message X X X Chiller-Menu
873 4 1 op_2_message X X X Chiller-Menu
874 1 1 password X X X Chiller-Menu
875 4 4 relay_mask_0 X X X Chiller-Menu
879 4 4 relay_mask_1 X X X Chiller-Menu
883 4 4 relay_mask_2 X X X Chiller-Menu
887 4 1 restart_mode X X X Chiller-Menu
888 4 1 re erse_ al e X X X Chiller-Menu
889 4 1 sc_alarm_on X X X Chiller-Menu
890 1 1 start_delay X X X Chiller-Menu
891 1 1 supply_dband X X X Chiller-Menu
892 2 1 supply_setpt X X X Chiller-Menu
893 4 1 temp_scale X X X Chiller-Menu
894 4 1 al e_ oltage X X X Chiller-Menu
895 4 1 oice X X X Chiller-Menu
896 4 1 water_ al e X X X Chiller-Menu
897 1 1 return_cal X X X Chiller-Menu
898 1 1 supply_cal X X X Chiller-Menu
899 4 1 adj_rate X X X X Dap80-Menu
900 1 1 alrm_delay_1 X X X X Dap80-Menu
901 1 1 alrm_delay_2 X X X X Dap80-Menu
902 1 1 alrm_delay_3 X X X X Dap80-Menu
903 1 1 alrm_delay_4 X X X X Dap80-Menu
904 4 1 alrm_select_1 X X X X Dap80-Menu
905 4 1 alrm_select_2 X X X X Dap80-Menu
906 4 1 alrm_select_3 X X X X Dap80-Menu

FS-8700-49_Data_Aire_DAP Page 17 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Array
Location
Metho
Num
Elements
Data Fiel 2 3 4 5 6 7 8 9 14 15 Message Type
907 4 1 alrm_select_4 X X X X Dap80-Menu
908 4 1 ant-enable X X X X Dap80-Menu
909 4 1 autoflush_time X X X X Dap80-Menu
910 4 1 auto_ack X X X X Dap80-Menu
911 4 1 comp_config X X X X Dap80-Menu
912 4 1 control_type X X X X Dap80-Menu
913 4 1 c_mode X X X X Dap80-Menu
914 4 1 da_ olts X X X X Dap80-Menu
915 4 1 dehum_on X X X X Dap80-Menu
916 2 1 d_calib X X X X Dap80-Menu
917 4 1 esa er_supp_comp X X X X Dap80-Menu
918 2 1 fire_lim X X X X Dap80-Menu
919 4 1 heater_config X X X X Dap80-Menu
920 2 1 hi_h_lim X X X X Dap80-Menu
921 2 1 hi_t_lim X X X X Dap80-Menu
922 4 1 humid_config X X X X Dap80-Menu
923 2 1 h_calib X X X X Dap80-Menu
924 1 1 h_dband X X X X Dap80-Menu
925 4 1 lead_lag X X X X Dap80-Menu
926 2 1 lo_d_lim X X X X Dap80-Menu
927 2 1 lo_h_lim X X X X Dap80-Menu
928 2 1 lo_t_lim X X X X Dap80-Menu
929 2 1 main_int X X X X Dap80-Menu
930 1 1 network_id X X X X Dap80-Menu
931 2 1 nom_h_setpt X X X X Dap80-Menu
932 1 1 password X X X X Dap80-Menu
933 4 1 ptc X X X X Dap80-Menu
934 3 16 relay_1_mask_0 X X X X Dap80-Menu
950 3 16 relay_1_mask_1 X X X X Dap80-Menu
966 3 16 relay_1_mask_2 X X X X Dap80-Menu
982 3 16 relay_2_mask_0 X X X X Dap80-Menu
998 3 16 relay_2_mask_1 X X X X Dap80-Menu
1014 3 16 relay_2_mask_2 X X X X Dap80-Menu
1030 3 16 relay_3_mask_0 X X X X Dap80-Menu
1046 3 16 relay_3_mask_1 X X X X Dap80-Menu
1062 3 16 relay_3_mask_2 X X X X Dap80-Menu
1078 4 1 re erse_ al e X X X X Dap80-Menu
1079 4 1 rst_mode X X X X Dap80-Menu
1080 4 1 sc_alarms X X X X Dap80-Menu
1081 1 1 s_delay X X X X Dap80-Menu
1082 2 1 t_calib X X X X Dap80-Menu
1083 1 1 t_dband X X X X Dap80-Menu
1084 2 1 t_setpt X X X X Dap80-Menu
1085 4 1 al e_config X X X X Dap80-Menu

FS-8700-49_Data_Aire_DAP Page 18 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Array
Location
Metho
Num
Elements
Data Fiel 2 3 4 5 6 7 8 9 14 15 Message Type
1086 4 1 oice X X X X Dap80-Menu
1100 1 1 sensor_1_name x x Dap80-Analog
1101 1 1 sensor_1_units x x Dap80-Analog
1102 1 1 sensor_1_type x x Dap80-Analog
1103 1 1 sensor_1_min_ al x x Dap80-Analog
1104 1 1 sensor_1_max_ al x x Dap80-Analog
1105 1 1 sensor_1_cal x x Dap80-Analog
1106 1 1 sensor_2_name x x Dap80-Analog
1107 1 1 sensor_2_units x x Dap80-Analog
1108 1 1 sensor_2_type x x Dap80-Analog
1109 1 1 sensor_2_min_ al x x Dap80-Analog
1110 1 1 sensor_2_max_ al x x Dap80-Analog
1111 1 1 sensor_2_cal x x Dap80-Analog
1112 1 1 sensor_1_input x x Dap80-Channels
1113 1 1 sensor_2_input x x Dap80-Channels
1114 1 1 sensor_3_input x x Dap80-Channels
Appendix A.2. Data Table 2 Point Descriptions
Fiel Server
Array
Location
Fiel Server Data
Fiel Point Description Message Type
D/A Control Panel
Type
1 Zone Zone ID DAP config All
2 Inhibit Unit On/ Standby/ Off
Status DAP config All
3 Unit Type Type Of DAP Panel DAP Unit All
4 temp Current Temperature DAP Stat All
5 hum Current Humidity DAP Stat All
6 d-temp Current discharge
temperature DAP Stat All
7 mode Current Unit mode (see
note 1) DAP Stat All
23 hold
Current Functions are
inhibited by Network (see
note 2)
DAP Stat All
39 cs_on Cooling stages on DAP Stat All
40 hs_on Heating stage on DAP Stat All
41 al ePCT Openning Percentage of
Chilled water al e DAP Stat All
42 hVl PCT Openning Percentage of
hot water al e DAP Stat All
43 errors Alarm (see note 3) DAP Stat All
57 hiTemp Highest Temperature in
the last 24 hrs DAP Stat All
58 loTemp Lowest Temperature in
the last 24 hrs DAP Stat All
59 hiHum Highest Humidity in the
last 24 hrs DAP Stat All

FS-8700-49_Data_Aire_DAP Page 19 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Fiel Server
Array
Location
Fiel Server Data
Fiel Point Description Message Type
D/A Control Panel
Type
60 LoHum Lowest Humidity in the
last 24 hrs DAP Stat All
61 Chilled_water Water Val e setting DAP Stat All
62 Compressor_config Compressor configuration DAP Stat All
63 heat_strip_config Heating configuration DAP Stat All
64 hum_config Humidifier configuration DAP Stat All
65 csUtilPct Utilization Percentage of
cooling in the last 24 hrs DAP Stat All
66 hsUtilPct Utilization Percentage of
heating in the last 24 hrs DAP Stat All
67 Val eUtilPct
Utilization Percentage of
CW al e in the last 24
hrs
DAP Stat All
68 humUtilPct
Utilization Percentage of
humidifier in the last 24
hrs
DAP Stat All
69 alrm_select_1 Message for optional
alarm Input #1 selection DAP Stat All
70 alrm_select_2 Message for optional
alarm Input #2 selection DAP Stat All
71 alrm_select_3 Message for optional
alarm Input #3 selection DAP Stat All
72 alrm_select_4 Message for optional
alarm Input #4 selection DAP Stat All
73 bitErrors Alarm History DAP Stat All
185 runtime_c1 Compressor 1 runtime DAP-Xtra All
186 runtime_c2 Compressor 2 runtime DAP-Xtra All
187 runtime_c3 Compressor 3 runtime DAP-Xtra DAP046 only
188 runtime_c4 Compressor 4 runtime DAP-Xtra DAP046 only
189 runtime_ht1 Heating stage 1 runtime DAP-Xtra All
190 runtime_ht2 Heating stage 2 runtime DAP-Xtra All
191 runtime_ht3 Heating stage 3 runtime DAP-Xtra All
192 runtime_hum Humidification runtime DAP-Xtra All
193 runtime_e ap Blower/ Fan runtime DAP-Xtra All
194 runtime_cond Condenser runtime DAP-Xtra All
195 runtime_dehum dehumidification runtime DAP-Xtra All
196 runtime_esc Energy sa er runtime DAP-Xtra All
197 runtime_cwc Chilled water Val e
runtime DAP-Xtra All
198 errors Alarm History DAP-Xtra All
218 errage Alarm History time (hrs) DAP-Xtra All
258 ersion DAP II software re ision
number DAP-Xtra All
259 tmbmair Temperature setpoint DAP-Xtra DAP049,048,046
260 tmbhum Humidity setpoint DAP-Xtra DAP049,048,046
261 tmbairdb Temperature deadband DAP-Xtra DAP049,048,046
262 runtimes runtimes array (in hrs) DAP-Xtra DAP049,048,046
314 bitErrors DAP-Xtra DAP049,048,046

FS-8700-49_Data_Aire_DAP Page 20 of 48
Fiel Server Technologies 1991 Tarob Court Milpitas, California 95035 USA Web:www.FieldSer er.com
Tel: [phone] Fax: [phone] Toll_Free: 888-509-1970 email: support@FieldSer er.com
Fiel Server
Array
Location
Fiel Server Data
Fiel Point Description Message Type
D/A Control Panel
Type
474 adj_rate Adjustment rate DAP Menu DAP049,048,046
478 alrm_delay_1 optional alarm 1 delay
setting DAP Menu DAP049,048,046
479 alrm_delay_2 optional alarm 2 delay
setting DAP Menu DAP049,048,046
480 alrm_delay_3 optional alarm 3 delay
setting DAP Menu DAP049,048,046
481 alrm_enable_1 Enable optional alarm 1
for alarm relay DAP Menu DAP049,048,046
482 alrm_enable_2 Enable optional alarm 2
for alarm relay DAP Menu DAP049,048,046
483 alrm_enable_3 Enable optional alarm 3
for alarm relay DAP Menu DAP049,048,046
484 alrm_select_1 Select alarm message for
Optional alarm input 1 DAP Menu DAP049,048,046
485 alrm_select_2 Select alarm message for
Optional alarm input 2 DAP Menu DAP049,048,046
486 alrm_select_3 Select alarm message for
Optional alarm input 3 DAP Menu DAP049,048,046
487 Chilled_water Chilled water Val e
configuration DAP Menu DAP049,048,046
488 Compressor_config Compressor configuration DAP Menu DAP049,048,046
489 c_mode Unit in Centigrade
temperature mode? DAP Menu DAP049,048,046
490 fire_lim Firestat temperature
setting DAP Menu DAP049,048,046
491 heat_strip_config Heating configuration DAP Menu DAP049,048,046
492 hi_cal A to D high limit setting DAP Menu DAP049,048,046
493 hi_h_limit High humidity alarm limit
setting DAP Menu DAP049,048,046
494 hi_t_lim High temperature alarm
limit setting DAP Menu DAP049,048,046
495 humid_config Humidifer configuration DAP Menu DAP049,048,046
496 h_calib Humidity calibration offset DAP Menu DAP049,048,046
497 lead_lag Compressor lead/lag
setting DAP Menu DAP049,048,046
498 loc_h_ddband humidity deadband setting DAP Menu DAP049,048,046
499 loc_h_setpt Humidity setpoint DAP Menu DAP049,048,046
500 loc_t_dband Temperature deadband
setting DAP Menu DAP049,048,046
501 loc_t_setpt Temperature setpoint DAP Menu DAP049,048,046
502 lo_cal A to D low limit setting DAP Menu DAP049,048,046
503 lo_h_lim Low humidity alarm limit
setting DAP Menu DAP049,048,046
504 lo_t_lim Low temperature alarm
limit setting DAP Menu DAP049,048,046
505 main_int Maintenance schedule
setting DAP Menu DAP049,048,046
506 passwd_a Password A setting DAP Menu DAP049,048,046
507 passwd_b Password B setting DAP Menu DAP049,048,046
