Fieldsheer MOBILE WARMING MWMJ31 User manual

PREMIUM
HEATED GEAR
®
WWW.FIELDSHEER.COM
FOLLOW US
serial number
1 YEAR
PRODUCT WARRANTY
U.S. BASED
CUSTOMER SERVICE
1 AN GARANTIE DU PRODUIT
1 AÑO DE GARANTÍA DEL PRODUCTO
SERVICE CLIENTÈLEE BASÉ AUX ÉTATS-UNIS
SERVICIO DE ATENCIÓN AL CLIENTE
UBICADO EN ESTADOS UNIDOS
ONLINE REGISTRATION
USER MANUAL
Model:MWMJ31
Model number may vary.
check your care label to verify.

fieldsheer.com Stay Warm, Stay ComfortabelTM
1 2
® ®
INTRODUCTION
Thank you for purchasing our premium heated gear,
premium heated gear is abattery powered bluetooth®
premium heated gear. your garment is designed to deliver
heat on demand at the touch of a button. wirelessly control
your desired heat via the mobile warming® connect app
available for download for free in app store® or available on
google play®. to ensure optimal performance of your heated
gear, please carefully read through this user manual prior to
using the garment.
Stay up to date with the latest product information by
registering your garment at fieldsheer.com/productl. You can
also find other great Fieldsheer products at fieldsheer.com.
The function of Bluetooth in this product is to use Bluetooth
app to connect heating products for temperature control and
wireless adjustment.
Read
registration card Scan registration card Register your product
TECHNOLOGY
PRODUCT INTRODUCTION
Reflect H eating
Heating L ayer
Proprietary Fieldsheer® powered by Mobile Warming®
technology is specially engineered for cold weather conditions.
Mobile Warming®’s comprehensive heating technology keeps
you warm and comfortable in all weather conditions. Our
exclusive heating technology utilizes ultra-fine fiber elements
powered by lightweight, rechargeable, Lithium-Ion batteries.
As heat builds, Mobile Warming® technology reflects and
directs heat back towards the body ensuring that you stay
warm. The combination of unique materials, construction
techniques, and innovative design results in the most
advanced heated gear available.

Stay Warm, Stay ComfortabelTM fieldsheer.com
TABLE OF CONTENTS GARMENT CARE
Garment Care
Battery use and Maintenance
Quick Start Guide
Heat Ratings
Warranty and Legal
4
5-6
7-9
10-11
12-14
Entretien du vêtement
Utilisation et entretien de la batterie
Guide de démarrage rapide
Évaluation de la chaleur
Garantie et mentions légales
Cuidado de la prenda
Uso de la batería y mantenimiento
Guía de inicio rápido
Potencias caloríficas
Garantía y aspectos legales
17
21-23
24-25
26-28
18-20
31
34-37
38-39
40-42
32-34
Refer to your garment Premium Heated Gear label for care
details
• Disconnect battery pack from the garment(s)
• Machine wash delicate cycle in warm water
• Tumble dry with low heat
• Do not wring
• Do not dry clean
• Do not bleach or use other harsh chemicals
• Do not Iron
• Recommend hanging up if storing for extended period of
time
Mobile Warming®'s powerful lithium-ion battery technology
was designed and engineered to provide you with safe and
reliable power, allowing you to be warm and comfortable.
Please follow the instructions below to optimize your
lithium-ion battery usage.
3 4
® ®
dcfbe
l

fieldsheer.com
BATTERY USE BATTERY MAINTENANCE
Never dispose of batteries in the garbage. Disposal of
batteries in the garbage is unlawful under state and
federal environmental laws and regulations. Always take
used batteries to your local battery recycling center.
This product contains chemicals known to the state of
California to cause cancer and birth defects or other
reproductive harm
For more information visit www.P65warnings.ca.gov
Do not use battery if you notice a change of shape (lumps),
over-heating when charging or if rust or corrosion on the
battery connectors is found. Use only with the charging
adaptor provided with your product to charge your battery.
USB CHARGING BATTERY
To charge your battery, use the
supplied micro-USB cable. Connect
the USB end to your computer or
any USB powered source like the
USB wall adaptor included with
your phone or tablet.
IMPORTANT: This product is intended to be used by an adult and
therefore is the sole responsibility of the Purchaser to follow
detailed instructions and warnings. The Purchaser agrees to
indemnify Manufacturer for any unintended use/misuse.
• Avoid running Lithium-Ion batteries completely dead. This will
result in performance problems and reduced battery life.
• Lithium-Ion batteries by nature have diminished capacity
output in extremely cold temperatures. We recommend
keeping batteries inside the garment to maximize battery
performance.
• Do not allow Mobile Warming battery(s) to come in contact
with water or liquids. If water or other liquids enter the battery
interior, immediately unplug the battery from the garment.
• Do not use if you feel the battery is compromised.
• Avoid allowing your Micro-USB or DC jack ports from being
contaminated with debris that could interfere with operations.
Suggest to check ports before each use.
Micro-USB Cable
BATTERY STORAGE
• Disconnect battery from garment.
• Power off battery(s) if applicable.
• Fully charge battery(s) prior to storage
• Keep battery(s) in cool dry place out of direct sunlight
• Charge every 6 months to maintain battery life. It is important to
keep your battery charged
• Do not store Mobile Warming batteries below - 4℉(- 20 ℃)
5 6
® ®
CHARGING
12V BATTERY
ASA16U17
100% 75%
50% 25%

Stay Warm, Stay ComfortabelTM fieldsheer.com
QUICK START GUIDE QUICK START GUIDE
9 10
® ®
1 2
23
3
7.MW CONNECT™ APP
Allows you to control your Bluetooth®
enabled garment with your mobile device.
This product controls the operation of the product through
the APP on the mobile phone.
1. The phone downloads the
connection software.
2-1. If you are using an iPhone, search for MW connect in
the appstore and download the software: After
downloading the software, open the software and the
dialog box "MW CONNECT ™" pops up. If you want to use
Bluetooth, click the OK option in the dialog box, And
then click Finish
3. Find a black cable with DC connector in
the battery pocket and plug it into the
allotted battery DC connector. Press the
battery switch button. At this time, you will
see the Bluetooth controller light up and
the clothing will heat up.
4. Enter the "MW CONNECT"App
on the mobile phone, click the
button in the upper left corner of
the App, click ADD/VIEW
5. a list of available GARMENTS will be listed in the search
interface. Select the GARMENT(S) in the list and rename each.
Click OK after renaming. Select FINISH to complete the
bluetooth pairing process
2-2. For Android, please download and install the
installation package provided. After downloading, enter
the App interface and click "Allow Access to Location
Services" button. In the new dialog box, click" Allow in use
only ".
OK
ALLOW
1
3
24
1

MW74V022
7.4V 2250mAh
HEAT RATINGS
NOTE: Heat and time
are estimated and
may vary depending
on conditions.
Exposing battery to
extreme temperatures
may impact these
estimates.
Thawdaddy vest
Power Ratings Based on Fully Charged Battery
7.4v
3 Heat Zones
2.5Hrs.
100%
5.0Hrs.
50%
3.0Hrs.
75%
10 Hrs.
25%
MW74V022
7.4V 2200mAh 7.4V 4000mAh
MW74V040
3 Heat Zones 4 Heat Zones
Jackets & Vest Heat Ratings
7.4v Power Ratings Based on Fully Charged Battery
3.2Hrs.
100%
6.5Hrs.
50%
4.3Hrs.
75%
13Hrs.
25%
2.0Hrs.
100%
5.0Hrs.
50%
3.0Hrs.
75%
10 Hrs.
25%
123
6. on the MW Connect(tm) Home screen,
Battery level is shown on the upper left
and Heat Level is shown on the upper
right. GARMENT being controlled will be
shown in the middle.
To control heat level, select one of the
colored buttons on the bottom of the
screen. RED is 100%, Orange is 75%, Green
is 50% and Blue is 25%
7. Press the clothes icon on the interface for 3-5 seconds, and a
shutdown interface will pop up. Click OK, and the heating
device will shut down. Meanwhile, the mobile App can no
longer control the Bluetooth heating device unless it is
connected again according to the steps
Stay Warm, Stay ComfortabelTM fieldsheer.com
HEAT RATINGSQUICK START GUIDE
9 10
® ®
3S
Power OFF
Garment?

Stay Warm, Stay ComfortabelTM
fieldsheer.com
HEAT RATINGS LEGAL & WARRANTY
LIMITED ONE YEAR WARRANTY
LEGAL
Fieldsheer Apparel Technologies warrants to the original
purchaser of this Fieldsheer® branded product
(the“Product”) that the construction, electrical heating
components and battery of the Product shall be free from
factory defect in materials and workmanship for a period one
(1) year from the date of original purchase when the Product
is purchased from an authorized reseller and used as
recommended by Fieldsheer Apparel Technologies. During
the warranty period, Fieldsheer Apparel Technologies will, at
its option and at no additional charge to you, repair or
replace the Product, or any part of the Product, if it becomes
defective, malfunctions, or otherwise fails to conform with
this Limited One Year Warranty.
Any damage caused to any Fieldsheer® products by misuse,
abuse, improper care, accident, normal wear and tear, or the
natural breakdown of materials over an extended period of
time and use are not covered in this warranty. Any alterations
or repairs (attempted or otherwise) performed on any
Fieldsheer® products voids any and all warranties offered by
Fieldsheer® for that particular item.
6 Heat Zones 8 Heat Zones
5 Heat Zones 6 Heat Zones
Jackets & Vest Heat Ratings
12v Power Ratings Based on Fully Charged Battery
MW12V52
12V 5200mAh 12V 5200mAh
MW12V52
Jackets & Vest Heat Ratings
7.4v Power Ratings Based on Fully Charged Battery
11 12
® ®
2.3Hrs.
100%
2.8Hrs.
100%
5.5Hrs.
50%
3.5Hrs.
75%
11Hrs.
25%
4.0Hrs.
50%
3.0Hrs.
75%
8.0Hrs.
25%
7.4V 4000mAh
MW74V040
2.2Hrs.
4.0Hrs.
50%
8.0Hrs.
25%
2.8Hrs.
75%
7.4V 4000mAh
MW74V040
2.5Hrs.
100% 100%
5.0Hrs.
50%
10Hrs.
25%
3.0Hrs.
75%

Stay Warm, Stay ComfortabelTM fieldsheer.com
LEGAL & WARRANTY FCC WARNING
FCC WARNING
Fieldsheer®, Mobile Warming®, Stay Warm, Stay
Comfortable, MW connect™ and its related logos and images
are property of Tech Gear 5.7 Inc and/or its affiliated
companies
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any use of such
marks by Fieldsheer® Apparel Technologies is under license.
Other trademarks and trade names are those of their
respective owners
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
NOTE 2: Any changes or modifications to this unit not
expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure
requirement.
13 14
® ®
