Ops-Core Mesh Helmet Cover User manual

SIZEFAST HELMET CUT
HIGH CUT
(FAST XP & LE)
SUPER HIGH CUT
(FAST MT) M L XL XXL
06-16-000 REV. C
FOR FAST HIGH CUT & SUPER HIGH CUT HELMETS
MESH HELMET COVER
Fold the Mesh Cover’s Rear Velcro Tab over the edge of the
helmet shell and secure it to the newly placed Rear Velcro
Circle. Cut off any excess Velcro on Cover’s Tab.
Push the Rear Fitband Tab up and over the Cover’s
secured Velcro Tab as shown.
Pull the back of the Mesh Helmet Cover down. Align
both back side edges with the back side edges of the
FAST Side Rails (ARCs) as shown.
ATTACH BACK OF HELMET COVER
SECURE MESH HELMET COVER
Repeat Steps A-C for the opposite side, then
tighten both Rear Fitband Screws.
Loosen the Rear Chinstrap Anchor T-Nut and slide the Rear
Fitband Tab all the way back so that the corner of the helmet
shell is exposed. Clean area with Rubbing Alcohol, then adhere
a Velcro Circle to the exposed helmet shell corner as shown.
Velcro Circle
Location
Rear
Fitband Tab
Anchor T-Nut
Rear Fitband
Tab
Rear Velcro
Tab
Rear Velcro
Tab
INSTALLATION CONTINUED
Cover
Velcro Tabs
FAST Side
Rail (ARC)

ATTACH FRONT VELCRO CIRCLES
Clean area with rubbing alcohol, then attach the remaining two Velcro
circles to the target areas on the Front EPP Pad as shown.
SECURE FRONT OF COVER AND RE-ATTACH FITBAND
Re-attach
the Fitband
to the Front
EPP Pad.
Fitband
Velcro
Tab
Align the Shroud with the existing 3-hole pattern on the front of your Helmet
Cover and helmet shell. Insert a T-nut through the Shroud’s top hole from the
front (outside) of the helmet Cover, then helmet shell. Use your ngers to
loosely attach a 1/2” screw from the inside of the helmet shell. Repeat for the
remaining 2 holes. Finish by using a screwdriver to tighten all 3 screws from the
inside of the shell, making sure the Shroud is securely fastened to the helmet.
NOTE: TIGHTEN SCREWS UNTIL SECURED. DO NOT OVER TIGHTEN, THIS WILL
CAUSE DEFORMATION TO HELMET SHELL AND COMPROMISE HELMET’S
BALLISTIC CAPABILITIES.
Using the Velcro
tabs on the Mesh
Helmet Cover,
secure them to
the inside of the
Front Pad using
the Velcro Circles
from Step 4.
Insert a screw from the inside of your
helmet shell and mark where the hole
should go on the helmet cover. Using
a sharp object, make a small cut on in
the cover where the screw pokes out.
Remove the screw and repeat for the
other two holes.
INSTALLATION
ATTACH SIDES OF HELMET COVER
Attach the sides of the Mesh Helmet Cover by aligning the Side Exterior Velcro of the Cover with the Side Exterior Velcro
on the helmet as shown. Be sure to line up the bottom edges of the Cover with the top edges of the FAST Side Rails
(ARCs). Repeat for both sides.
SHROUD REMOVAL
Make sure the bungees are not attached to the Shroud. Remove the Shroud from your helmet using
a screwdriver. Set aside the Shroud, Washers and T-Nuts. Save the shorter screws for later use
without the Mesh Helmet Cover.
Front EPP Pad
Fitband Comfort Pad
NOTE: IF YOUR FRONT EPP PAD DOES NOT HAVE SHROUD
SCREW ACCESS HOLES, YOU MUST FIRST DISASSEMBLE THE
FRONT CHINSTRAP HARDWARE AND COMPLETELY REMOVE
THE FRONT EPP PAD TO ACCESS THE SHROUD SCREWS.
FAST Side
Rail (ARC)
Side Exterior
Velcro
Shroud
Screw Access Holes
Front EPP Pad
DETACH FITBAND
Place your index nger behind the center of the Fitband Comfort
Pad and carefully bend away from the Front EPP Pad as shown.
Pinch the Fitband Comfort Pad and use your thumb to slide the pad
sideways ½” towards the center of the helmet along the Front EPP
Pad. Repeat on both sides until the pad is released from the key slots.
NOTE: DO NOT PULL THE FITBAND COMFORT PAD AWAY FROM THE
FRONT EPP PAD OR YOU MAY BREAK THE FRONT EPP PAD KEY SLOTS.
MESH COVER INSTALLATION PREP
RE-ATTACH SHROUD
