1
Minirack
250320/270720
INHALT
CONTENT
1x 700009031 Minirack
1x 700010875 Rohradapter links
1x 700010876 Rohradapter rechts
1x 700010878 Schraubensatz:
1x 700009031 Minirack
1x 700010875 Tube adapter left
1x 700010876 Tube adapter right
1x 700010878 Screw kit:
BMW F 900 R 2020-
Artikel Nr.: / Item-no.:
6606524 01 01 schwarz/black
BMW F 900 XR 2020-
Artikel Nr.: / Item-no.:
6606525 01 01 schwarz/black
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
2x Zylinderschraube ISK M8x55
2x Linsenschraube M8x20
4x Senkschraube M6x16
4x Selbstsichernde Mutter M6
4x U-Scheibe Ø6,4
2x U-Scheibe Ø8,4
2x Aludistanz Ø18xØ9x30 schwarz
1x Logo Hepco & Becker ø30m
4x Verschlussstopfen 8mm
2x Allen screw M8x55
2x Filister head screw M8x20
4x Countersunk screw M6x16
4x Self lock nut M6
4x Washer Ø6,4
2x Washer Ø8,4
2x Alu spacer Ø18xØ9x30 black
1x Emblem Hepco & Becker ø30m
4x Plastic plugs 8mm
Nicht kompatibel mit originaler Kofferhalterung.
Not compatible with original side case holder.
2
WICHTIG
IMPORTANT
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,wie
man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf
das entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist.
Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
6606524/6525 01 01
VORBEREITUNG
PREPARING
Die Alupins aus den Soziushaltegriffen entfernen, diese entfallen. Die hinteren Schrauben unterhalb der Sitzbank entfer-
nen, diese entfallen. Sollte die originale Kofferhalterung montiert sein, so entfällt diese.
Remove the aluminium pins from the pillion handles, these are no longer necessary. Remove the rear screws underneath
the seat, these are not necessary. If the original side case holder is mounted, it is not needed.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
1
2
2x
2x
2x
2x
Montage der Rohradapter rechts/links außen:
Die Montage erfolgt an den freien Gewinden
mit den Linsenschrauben M8x20 sowie
U- Scheiben Ø8,4.
Montage der Rohradapter rechts/links unten:
Die Montage erfolgt an den freien Gewinden
mit den Zylinderschrauben M8x55.
Zwischen Adapter und Rahmen die Aludistan-
zen Ø18xØ9x30 fügen.
Fastening of the tube adapters
right/left outside:
On the free thread with the filister head
screws M8x20 and washer Ø8.4.
Fastening of the tube adapters right/left bottom:
On the free thread with the allen screws
M8x55. Add alu spacer Ø18xØ9x30 bet-
ween adapter and frame.
Fahrtrichtung/driving direction
Fahrtrichtung/
driving direction
In Kombination mit dem C- Bow entfallen die Alu-
distanzen Ø18xØ9x30.
In combination with C- Bow the alu spacers
Ø18xØ9x30 are not used.
3
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
3
4x 4x
4x
4x
Montage der Alupalette:
Auf den zuvor montierten Rohradaptern mit
den Senkkopfschrauben M6x16.
Von unten mit den selbstsichernden Muttern
M6 sowie U-Scheiben Ø6,4 verschrauben.
Nun alle Teile festziehen und Logo einkleben.
Die nicht benutzten Bohrungen mit den Ver-
schlussstopfen Ø8mm verschließen.
Fastening of the alu palette:
On the tube adapters with countersunk head
screws M6x16. Secure it with self lock nuts
M6 and washers Ø6,4.
Now, screw on all bolts and nuts and stick
the logo into the cutout. Seal up the 4 holes
not in use with the plastic plugs Ø8mm.
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile wieder montieren.
Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the dismantled parts.
Please notice our enclosed service information.
6606524/6525 01 01
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
Als weiteres Zubehör lieferbar:/ Also available:
F 900 R F 900 XR
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
6306524 00 01 6306525 00 01 C-Bow Halter / C-Bow holder
5036524 00 01 5036525 00 01 Frontschutzbügel / Front guard
5046524 00 01 5046525 00 01 Heckschutzbügel / Rear guard
5066524 00 09 5066525 00 09 Tankring
42116524 00 91 42116525 00 91 Seitenständerplatte / Side stand enlargement
