FILL-RITE 900CD Series User manual

900CD SERIES DIGITAL METER
Installation and Operation Manual

fillrite.com
2
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
Table of Contents ........................................................2
Thank You! ................................................................. 2
About This Manual ..................................................... 2
Safety Information ......................................................2
Installation .................................................................3
Meter Calibration ........................................................4
Procedure for Meter Calibration ..................................4
Operating Instructions ................................................5
Low Battery Warning ...................................................6
Storage .......................................................................6
Troubleshooting Guide ................................................6
Fluid Compatibility .....................................................7
Assembly and Disassembly .........................................7
Repair .........................................................................8
Safety Testing Approvals ............................................ 8
Replacement Parts Information ..................................9
900 Series Digital Meter Replacement Parts Kit .........9
Electrical Installation Information ............................10
Fill-Rite Product Warranty ...................................... 10
Technical Specifications and Information .................11
Certification Information .......................................... 11
Table of Contents
Thank You!
Thank you for your purchase of the Fill-Rite 900
Series Digital Meter! Your Fill-Rite product comes
with over 80 years of fluid transfer experience behind
it, providing you the value that comes with superior
performance, user friendly design, long service life,
and solid, simple engineering.
For all product questions, please contact Fill-Rite
Technical Support at 1 [phone] or via email
at FillRiteTech@fillrite.com (M-F, 8 AM – 5 PM ET).
About This Manual
From initial concept and design through its final production, your Fill-Rite meter is built to give you years of trouble free
use. To ensure it provides that service, it is critical that you read this entire manual prior to attempting to install or
operate your new meter. Become familiar with the terms and diagrams, and pay close attention to the highlighted
areas with the following labels:
Emphasizes an area in which personal injury or even death may result from failure to follow
instructions properly. Mechanical damage may also occur.
These boxes contain information that illustrates a point that may save time, or be key to
proper operation, or clarifies a step.
Failure to observe a “Caution” may cause damage to the equipment.
WARNING
CAUTION
NOTICE
DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
At Fill-Rite, your satisfaction with our products is paramount to us. If you have questions or need assistance with
your product, please contact us at 1 [phone] or via email at FillRiteTech@fillrite.com (M-F, 8 AM – 5 PM ET).
Safety Information
This product is not suited for use with fluids intended for human or animal consumption or
fluids containing water. Nickel plated meters are approved for use with non-potable water,
antifreeze, certain agricultural chemicals, and other specialized water applications.
This product should not be used to transfer fluids into any type of aircraft.
WARNING
WARNING

fillrite.com
3
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
To insure safe and proper operation of your equipment, it is critical to read and adhere to
all of the following safety warnings and precautions. Improper installation or use of this
product can cause serious bodily injury or death!
1. NEVER smoke near the meter, or use the meter near open flames when metering a
flammable liquid! Fire can result!
2. A “Fill-Rite” Filter should be used on the meter outlet to insure no foreign material is
transferred to the fuel tank.
3. Threaded pipe joints and connections should be sealed with the appropriate sealant or
sealant tape to minimize the possibility of leaks.
4. Storage tanks should be securely anchored to prevent shifting or tipping when full or
empty.
5. To minimize static electricity build up, use only static wire conductive hose when mete-
ring flammable fluids, and keep the fill nozzle in contact with the container being filled
during the filling process.
6. DO NOT exceed 50 psi/ 3.5 BARS line pressure.
7. DO NOT install additional foot valve or check valve without a pressure relief valve;
cracking may result.
WARNING
Installation
Meters are furnished for horizontal piping; left to right flow.
Flow ports can be changed to any of four positions for horizontal or vertical
piping and for either direction of flow.
1. Determine direction for fluid to flow.
2. Install meter observing directional arrow on casting on back of
meter (circled). Liquid MUST flow in the direction of the arrow for
proper operation.
3. Remove four screws on corners of meter face (Torx T25 bit required).
4. Rotate meter face assembly to desired orientation.
5. Replace four screws.
6. Complete installation by making sure the joints are properly sealed
and meter is positioned for easy viewing and use.
Threaded pipe joints and connections should be sealed with the appropriate sealant or
sealant tape to minimize the possibility of leaks.
CAUTION
If you have purchased this meter as part of a “Kit”, the meter flange base is drilled
with 4 holes. This allows the meter to be used with 300 and 700 series pumps. Line the
meter bracket up for installation and insert the bolts in the two holes that align with
the corresponding holes on the pump outlet. Once the meter bracket is bolted securely
in place install the two plugs in the holes that were not used to prevent moisture from
entering them.
NOTICE

fillrite.com
4
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
Meter Calibration
Meter calibration is required upon installation, after disassembly, after significant wear, or when dispensing a different
viscosity fluid. Calibration must be done between 6 and 40 GPM (23 and 151 LPM). Meter calibration can be easily
changed by following the calibration procedure. A container of KNOWN volume will be needed for the calibration procedure.
For the 900 Series Digital Meter, a five gallon container or larger, or a 20 liter container or larger should be used.
Procedure for Calibration
Unit of measure and calibration is configured using a 3-step process:
1. Select the desired unit of measure.
2. Fill a container with a known volume using the desired fluid.
3. Enter the amount of fluid dispensed.
Prior to calibration, the unit must be placed in calibration mode. Simultaneously press and hold the CAL and TOTAL
buttons for 5 seconds to enter Calibration Mode.
When calibrating, the totalizers will not increase in value.
NOTICE
4. The unit will default to the last unit of measure used.
5. Press and release the TOTAL button to toggle through
the available units of measure.
6. Press and hold the CAL button for 2 seconds to move
to the next step.
7. If the meter is left untouched for 2 minutes or the
RESET button is pressed, the unit will automatically exit
Calibration Mode and ignore any changes in volume.
8. CAL 2 will be displayed.
9. Begin dispensing fluid into the container.
10. FILL will begin to blink after fluid flow is detected.
11. Dispense the desired amount fluid; stop flow as soon
as desired level is reached.
12. Press and hold the CAL button for 2 seconds to move
to the next step.
Dispensing into a container with a known volume allows the unit to automatically calculate
the internal scaling value to compensate for fluid viscosities and the system flow rate.
NOTICE
If left untouched for 2 minutes, or the RESET button is pressed, the meter will exit
Calibration Mode and any dispensed fluid will be ignored.
NOTICE

fillrite.com
5
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
14. The left-most digit will begin blinking.
15. Use the TOTAL button to scroll from 0 to 9 until
the desired number has been selected.
16. Press and release the CAL button to move to the
next digit.
17. Repeat Steps 3 - 4 until the amount of dispensed
uid has been entered.
18. If you make a mistake entering a digit, press and
release the CAL button repeatedly until the digit is
active again.
19. Press and hold the CAL button for 2 seconds to complete the calibration process regardless of the current
digit selected.
20. If at the last digit and the CAL button is pressed for less than 2 seconds, the process should roll back to the
left-most digit, but retain the current value. This allows the user to edit an incorrect value.
21. An error check for gross calibration errors (+/- 15%) will be performed unless USER units are selected. If an
error is detected, the meter will display Err0 until a button is pressed and the calibration process is aborted.
22. If the meter is left untouched for 2 minutes or the RESET button is pressed, the unit will automatically exit
Calibration Mode and ignore any changes.
Operation Instructions
For accurate measurement and to prevent meter damage, dispenser and piping must always be filled with liquid and be
free of air. The meter portion of your dispenser should be calibrated per instructions in this manual prior to its use.
The Fill-Rite 900 Series Digital Meter face incorporates three buttons that control all the operation and calibration functions.
To turn the display on, or wake the meter from “Sleep” mode, simply press any button on the face. The display will turn on
and you can proceed with the function you desire. Dispensing fluid will also turn the meter display on.
13. Pressing and holding the CAL button for 2 seconds before dispensing into a container will cause the meter to
skip a fill operation and only change the unit of measure.
For maximum accuracy, try to get as close as possible to the dispensed volume without
changing flow rate.
NOTICE
• The last count and selected totalizer is retained and displayed when the meter is turned on.
• Pressing and releasing the TOTAL button will switch between the resettable and non-resettable totalizers.
(The R icon will be displayed when the resettable total is displayed).
• Pressing and holding the RESET button for 2 seconds
will reset the counter.
• Pressing and holding the RESET button and TOTAL
buttons for 2 seconds will reset the totalizer. The
resettable totalizer must be active in order to reset it.
• Pressing and holding the RESET button and CAL
buttons for 2 seconds will display the software version
for 2 seconds and then perform a segment check for 3
seconds, and then restore the display.
• Pressing and holding the CAL button for 5 seconds will
place the meter into a Deep Sleep mode. Pressing any
button twice will bring the meter out of deep sleep mode.
When the meter is in the “Deep Sleep” mode, dispensing fluid will NOT turn the meter on.
The meter will not display or accumulate any fluid that is dispensed while in
“Deep Sleep” mode.
NOTICE

fillrite.com
6
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
• After 30 seconds of inactivity, the display will blank to conserve battery power.
• If the meter is connected to the external power source, the display will not blank unless forced into deep sleep mode.
• If external power is removed, the meter will revert to battery only operating characteristics and vice-versa.
• The counter and totalizer 2 can be reset even if fluid flow is detected. The meter will continue counting
during the 2 second RESET button press, then reset to 0, then resume counting.
“Deep Sleep” mode is designed to maintain a status of operational readiness while offering
battery conservation. The meter should be placed in this mode when:
• Flushing the unit so the dispensed volume is not counted.
• Traveling over rough surfaces (off-road) where fluid is being jostled and you
don’t want volume from the motion to be counted.
• Extending battery life; there is no penalty for repeatedly placing it in deep sleep.
NOTICE
Low Battery Warning
The digital display includes a “Low Battery” warning
indicator. When the battery reaches a level low enough
to require replacement, the display will show “BAT” as a
reminder to change the battery. When necessary, replace
batteries per procedure on page 7.
Concern Possible Concern Recommended Repair
Counter
inaccurate
Meter miscalibrated Check calibration and recalibrate as necessary (directions on
page 4).
Air in lines or metering chamber Check line seals and joints for leakage; seal leaks appropriately.
Measuring gears or disc
are sticking
Clean or replace internal metering components as necessary.
Low flow
capacity
Clogged meter chamber Clean meter chamber; clean or replace screens and filters
in piping.
Meter body
cracks
Excess line pressure Install pressure relief valve to allow high pressure to bleed
back to the tank. Replace meter.
Nutating
Disc Broken
Sudden high pressure fluid
hitting disc
Avoid surge flows by installing a shut-off valve on outlet of
meter; install meter as close to the pump as possible, keep
piping full of liquid. Replace meter chamber assembly.
Storage
If your meter is to be stored for a period of time, clean it thoroughly. This will help protect the meter from possible damage.
Troubleshooting Guide
The following Troubleshooting Guide is designed to help you with basic digital diagnostics and repairs if you should
encounter abnormal service from your 900 Series Meter. We recommend you use only genuine Fill-Rite parts.
These parts, and additional service information is available through your authorized Fill-Rite dealer.
Further troubleshooting information can be found in your pump manual. If you need additional assistance, please
contact our Technical Support at 1 [phone] or via email at FillRiteTech@fillrite.com (M-F, 8 AM – 5 PM ET).
You can also visit fillrite.com.

fillrite.com
7
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
If in doubt about compatibility of a specific fluid, contact supplier of fluid to check for
any adverse reactions to the following wetted materials:
Aluminum, Stainless Steel, Fluorocarbon, Polyester, Nickel, Acetal.
CAUTION
Figure 1
Fluid Compatilibity
The 900CD Series Meter IS compatible with the following fluids:
Diesel Fuel, Bio-Diesel (up to B20), Mineral Spirits, Heptane, Hexane, Gasoline, E15
The 900CD Series Meter IS NOT compatible with the following fluids:
Bleach, Hydrochloric Acid, Ink, Sulfuric Acid, Salt Water
Assembly and Disassembly
The 900 Series Digital Meter consists of a chamber housing, measuring chamber, drive shaft, digital counter assembly,
and cover. The design of the meter is such that it can be completely disassembled without disturbing the piping (refer
to diagram on page 9 for item number parts).
Accessing the Battery
For access to the batteries (2 AA batteries) (Figure 1):
1. Remove the four screws at the top and bottom of the front bezel (Torx #T25).
2. Lift bezel off. Batteries are located on the back side of the display; use a Phillips head screwdriver to remove
the cover to access the batteries.
3. Reassemble by reversing this procedure.
To reduce the risk of explosion DO NOT mix old batteries with new batteries, or mix
batteries of different manufacturers.
WARNING
Batteries may ONLY be replaced with the following:
• Duracell MN1500 • Duracell MX1500 • Energizer E91
WARNING
To reduce the risk of ignition of a flammable explosive atmosphere, batteries MUST be
changed ONLY in a location known to be non-hazardous.
WARNING

fillrite.com
8
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
Meter Chamber Assembly
The Meter Chamber consists of upper and lower
chambers, a nutating disc, and four screws
(Figure 2).
1. To expose the meter chamber assembly
and seal remove the 4 screws.
2. The meter chamber can be
dislodged by removing the
4 screws (see Figure 2).
3. Reassemble by reversing this procedure.
If replacing any components of the meter chamber, the complete assembly must be
replaced due to its precision method of construction. This will assure a proper fit,
and correct operation of the chamber.
NOTICE
Figure 2
When returning a meter for service, it must be triple rinsed and accompanied by a note
stating what chemicals have been pumped through it.
Meters not adhering to these specifications may be refused for service.
NOTICE
Repair
Meters needing repairs should be taken to an authorized repair facility. Meters MUST be triple rinsed before taking
them in for repairs.
Safety Testing Approvals
The Fill-Rite 900CD Series Meters have been tested for compliance to the standards set forth by Underwriters
Laboratories (UL), UL Canada, ATEX, and other testing organizations.
To determine which specific compliances apply to your particular meter, refer to the faceplate for information
and compliance logos (see “Certification Information” on page 11).

fillrite.com
9
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
Replacement Parts Information
Replacement parts can be obtained through any authorized Fill-Rite dealer. Be sure to use only genuine Fill-Rite
replacement parts for your service and maintenance needs.
Kit Number # Description Qty
900CDKT 1 Required Seal 3
2 Required Fasteners 6
3 Magnetic Driver 1
4 Chamber Assembly 1
900 Series Digital Meter Replacement Parts Kit

fillrite.com
10
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
Batteries may ONLY be replaced with the following:
• Duracell MN1500 • Duracell MX1500 • Energizer E91
WARNING
To reduce the risk of explosion DO NOT mix old batteries with new batteries, or mix
batteries of different manufacturers.
WARNING
Electrical Installation Information
Internal Power (Battery Power)
All 900 Series Digital Meters are battery powered. The meter is equipped with a battery tray located behind the
faceplate on the circuit board itself. Power on these units is supplied by two alkaline “AA” batteries. With normal use,
these batteries should provide 2 – 4 years of use. The digital display contains an integral warning of low battery level
(see page 6 for details). If there are questions regarding appropriate replacement batteries for your meter, please
contact Fill-Rite Technical Support at 1 [phone] or via email at FillRiteTech@fillrite.com (M-F, 8 AM – 5 PM ET).
Incorrect battery selection may void UL certification.
Fill-Rite Product Warranty
Fill-Rite (“Manufacturer”) warrants each consumer buyer of its Fill-Rite products (“Buyer”) from the date of invoice
or sales receipt, that goods of its manufacture (“Goods”) shall be free from defects of materials and workmanship.
Duration of the warranty is as follows:
• Heavy Duty Products – Two Years
Manufacturers sole obligation under the foregoing warranties will be limited to either - at Manufacturers option -
repairing or replacing defective goods (subject to limitations hereinafter provided) or refunding the purchase price
for such Goods theretofore paid by the buyer, and Buyers exclusive remedy for breach of any such warranties will
be enforcement of such obligations of the Manufacturer. If the Manufacturer so requests the return of such Goods,
the Goods will be redelivered to the manufacturer in accordance with Manufacturers instructions FOB Factory. The
remedies contained herein shall constitute the sole recourse of the Buyer against the Manufacturer for breach of
warranty. IN NO EVENT SHALL THE MANUFACTURER’S LIABILITY FOR ANY CLAIM FOR DAMAGES ARISING OUT OF
THE MANUFACTURE, SALE, DELIVERY, OR USE OF THE GOODS EXCEED THE PURCHASE PRICE. The foregoing
warranties will not extend to goods subject to misuse, neglect, accident, improper installation or maintenance,
or have been repaired by anyone other than the Manufacturer or its authorized representative. THE FOREGOING
WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES OF MERCHANTABILITY, FITNESS FOR
PURPOSE OF ANY OTHER TYPE, WHETHER EXPRESSED OR IMPLIED. No person may vary the forgoing warranties
or remedies, except in writing signed by a duly authorized officer of the Manufacturer. The Buyer’s acceptance of
delivery of the Goods constitutes acceptance of the foregoing warranties and remedies, and all conditions and
limitations thereof.
Fill-Rite recommends you retain your sales receipt as proof of purchase.

fillrite.com
11
INSTALLATION AND OPERATION MANUAL
| 900CD DIGITAL METER
Dimensions:
6.75" (H) x 8.46" (W) x 4.10" (D)
Accuracy: ± 1.25 %
Repeatability:
± 0.25% at calibrated flow rate.
Flow Rate: 6 to 40 GPM
Pressure Rating: 50 psi
Construction: Aluminum
Units of Measure:
ounces, pints, quarts, liters, gallons,
1 special “Unit of Measure” option
Counter: 4 digit resettable counter; (.01 – 9999 units)
Totalizers: 7 digit non-resettable “Master” totalizer, 7-digit resettable secondary
Mounting Options: Can be installed for vertical or horizontal mounting by rotating display accordingly
Approvals: UL / cUL / ATEX Listing (see page 6 for information on specific certifications)
Power Supply: 2 “AA” batteries (Alkaline or approved equivalent; Lithium optional for extended battery life);
optional external power supply on certain models
Expected Battery Life: 2 - 4 years of normal use with standard Alkaline batteries
Operating Temperature Range: -40° to 140°F (-40° to 60°C).
Specific conditions of use:
• The Series 900CD may be used with only Part No. MN1500 or MX1500 cells manufactured by Duracell or Part No.
E91 cells manufactured by Energizer.
• The housing of the Series 900 meters is made of powder coated aluminum. Care must be taken in the end use
to ensure coating does not wear away to expose bare metal or that the device must be used only in applications
where it is protected from friction sparking.
Technical Specifications and Information
Certification Information
The following is a list of standards used to attain certification:
• IEC 60079-0, 7th ed.,
• EC 60079-11, 6th ed.,
• EN IEC 60079-0:2018
• EN 60079-11:2012,
• CAN/CSA C22.2 No. 60079-0:15,
• CAN/CSA C22.2 No. 60079-11:14,
• UL913, 8th ed.,
• UL60079-0, 5th ed.,
• UL 60079-11, 5th ed.,
• CAN/CSA C22.2 No. 157-92. (Rev 2016)

Fill-Rite Company
8825 Aviation Drive
Fort Wayne, Indiana 46809 USA
T 1 [phone]
1 [phone]
F 1 [phone]
fillrite.com | sotera.com | gormanrupp.com
DC000159-000 Rev. 6
