FIM X5 Operating instructions

FIM Manufacturing Inc.
12556 Stave Lake Rd.
Mission, BC V2V4J1 Canada
Tel : [phone] ax: 604-820-4078
e-mail: inf[email protected] www.fim-umbrella.com
X5 Retractable Sunshade
INSTRUCTIONS FOR ASSEMBLY AND RECOMMENDATIONS FOR USE
READ T ESE INSTRUCTIONS IMMEDIATELY
These instructions are provided to facilitate assembly and use of the X5 sunshade, and for your safety.
It is recommended to follow the instruction carefully.
Failure to do so may result in damage to objects or injury to people. If in doubt, always consult a technically expert
person.

This symbol indicates very important information. Strictly follow instruction accompanied by this symbol. This
does not mean that the other information contained in this handbook is not important.
Keep this handbook for future reference.
IMPORTANT SAFETY INSTRUCTIONS
APPLIES TO ALL IN T IS SECTION
1. INSTRUCTIONS
Please completely read and follow all the instructions.
Damage or injuries may occur if the sunshade is not assembled and used as described herein.
For safe use it is essential that anyone using the sunshade should have read all the instruction in
advance.
Only persons familiar with the safety aspects should operate this sunshade.
2. PRECAUTIONS
The sunshade X5 is intended for sun protection, not as a protection against all bad weathers. It must
be closed and removed from the frame in case of strong winds or storms, as well as heavy rain or
snow.
Always close and remove the sunshade from its frame at night, when you are not at home or whenever
it is not under control.
The base must be ballasted with a minimum weight of 130 kg
(approx. 290 lbs).
Always remove the handle from the winch and keep it out of children's reach.

GettingStarted
1.ConnectingUmbrellaTop
Unwrapthetopandstructureandplacethemonaflatsurface
asshowninthefirstimage
Slideinboltandsecure
withlocknut.Tighten
securely,butdonot
overtighten.
2.Connectingthestabilizer

3.Attachingthepolesleeve
YourX5isnowreadytobesetontotheumbrellabase.Beforeproceeding
pleaseseethefollowingsetupandoperatinginstructionsfordetailsonhowto
properlyuseandoperatetheumbrella.

ASSEMBLY INSTRUCTION
STANDARD CROSS BASE ASSEMBLY (Fig. 1)
Take out the content of the hardware bag I) and assemble the base as shown in pict. 2
CAUTION: tighten the base bolts well
Place floor slabs in the appropriate places of the base
 CAUTION: ballast the base with a weight of at least 130 KG (≈290 lbs)
OPTIONAL OFFSET ALUMINUM BASE ASSEMBLY (Fig. 2)
Take out the content of the hardware bag I) and assemble the base as shown in pict. 2
 CAUTION: tighten the base bolts well
Place floor slabs in the appropriate places of the base
 CAUTION: ballast the base with a weight of at least 130 KG (≈290 lbs)
You can now slide the umbrella onto the base support tube as shown in Fig. 3, making sure the pole is seated firmly in
the square recess of the rotation disk 'O'
OW TO USE YOUR SUNS ADE
ATTAC ING T E CRANK BOX (Fig. 4)
Screw the thumbscrew [T] into the threaded insert on the pole. Slide crankbox over the stud of the thumbscrew and insert the nipple
[B] into the hole [B'], then tighten the thumbscrew to lock the crankbox in place.Insert crank handle into the recess of the crankbox.
OPENING T E SUNS ADE (pict. 6 - 7)
IMPORTANT: Before opening the sunshade remove the tie string and slightly open it by pulling the ribs with your hands
To open the sunshade, gently turn the handle D) of the winch U) clockwise, taking care not to force the mechanism.
If there is furniture near the sunshade which could hinder the opening, proceed in the following way:
1. Fig.6) insert the pin of the handle Q) into the hole made in the pole of the sunshade A) and open the sunshade turning the
handle D) clockwise
2. when the ribs are above the furniture for reference see picture 7) extract the handle Q) from the hole made in the pole of the
sunshade A)
3. complete the opening of the sunshade
ROTATION OF T E SUNS ADE AROUND T E BASE (Fig. 8)
The frame rotates 360º around the base and can be fixed in 20 different positions by inserting the pin S) into the orientation ring O).
INCLINATION OF T E SUNS ADE (pict. 9 – 10 - 11)
make this operation starting from the open sunshade
1. Fig.9) rotate the handle D) counter clockwise, and at the same time pull the handle Q) downwards. In this way the sliding
carrier L) lowers and the sunshade tilts.
2. Fig.10) when the desired tilt position has been reached rotate the handwheel P) clockwise to lock the sliding carrier L). If
needed, tension the cover by turning the handle (D) clockwise after the slider has been locked.
3. to bring the sunshade in horizontal position, unlock the sliding carrier L) by turning the handwheel P) counter clockwise. Then,
turn the crank handle clockwise until the top is in horizontal position and the fabric is taut.

MAINTENANCE AND CARE
WAS ING T E COVER
1. Remove the cover from the sunshade.
2. Wash the cover by hand with a neutral detergent in lukewarm water at max. 30 ºC ≈90 ºF)
3. Allow the cover to dry but do not tumble dry or iron it.
4. Place the cover again on the frame.
STORING T E SUNS ADE AT T E END OF T E SEASON
At the end of the season, before storing your parasol away, clean the frame with a damp cloth and dry it.
6 CAUTION: Check the integrity of all components. Should there be any damaged parts, contact the dealer where
it was purchased to order the relevant spare parts.
Touch up any possibly chipped parts with paint.
For perfect conservation of the parasol during the winter months it is advisable to store it in a dry room.IMPORTANT: to avoid damage
caused by mould or oxidation never store your X5 away when it is wet or damp.
IMPORTANT: to avoid damage caused by mould or oxidation never store your X5 away when it is wet or damp.
Standard Cross Base
Optional Offset Base
H1
NOTE:
This base (parts H,H1 and G plus hardware) 
is packaged in a separate carton!

Call toll-free at 1-888-551-5221 with any questions
DECK MOUNT PLATE - INSTALLATION
HARDWARE AND TOOLS REQUIRED:
⇒on wooden sundecks
•Drill with ¼” drill bit
•2 galvanized lag screws 3/8” x 4”, 2 galvanized lag screws 3/8” x 2 1/2”, 4
galvanized washers 3/8”
•Ratchet with ½” socket
INSTALLATION PROCEDURE:
•Place plate on the deck with 2 of the mounting holes centered over a deck
joist. Mark all 4 holes and pre-drill with the ¼” bit. (See enclosed drawing for
details)
•Use the 4” lag screws to fasten the plate through the decking into the joist. It
may be helpful to lubricate the screws before inserting them.
•Use the 2 1/2” lag screws to fasten the plate to the 2x4 or 2x6 running
perpendicular to the joist. On decks accessible from underneath, it is
preferable to use 3/8” x 3” hex bolts with a nut and large washer below the
deck.
•IMPORTANT: Tighten the screws well, but to not use excessive force. On new
(green) sundecks, occasional re-tightening may be required due to shrinkage
of the lumber.
HARDWARE AND TOOLS REQUIRED:
⇒on concrete patios
•Hammer drill (e.g. Hilti) with ½” concrete bit
•4 concrete spread anchors, 4 3/8” x 2” mounting bolts with washers. Consult
with your building supply specialist for proper combination of anchors and
bolts to achieve a minimum pullout strength of 200 lbs. per anchor.
•Ratchet with ½” socket
INSTALLATION PROCEDURE:
•Place plate on the concrete making sure it is not tipping or riding on a high
spot. Check plate with a level, shim if necessary.
•Mark fastening holes, drill to proper depth.
•Fasten plate with bolts into anchors

Deck Joist
Locking Pin
mounting hole
Support Tube
2 1/2" Lag Bolts
3 1/2" Lag Bolts
Deckmount Plate - correct placement

GROUND INSERT BASE - INSTALLATION
MATERIALS AND TOOLS REQUIRED:
1-2 bags of quick set ready mix concrete (please consult with your building supply
store for exact quantity)
2 gallon mixing bucket
small hand shovel or trowel
1 piece of 2x6 18-20” long
2 - 4” C-clamps
Carpenters Level
INSTALLATION PROCEDURE:
1. Clamp the ground insert base with the flat top plate to the center of the 2x6
2. Determine exact location for the umbrella base.
3. VERY IMPORTANT: The umbrella ro a ion disk ‘O’ allows for a number of
fixed posi ions in a full 360º Circle. If you need o posi ion and lock he
umbrella over an exac spo (e.g. he cen er of a able), make sure o
orien he ground inser sleeve so i allows you o properly lock he
umbrella in place wi h he locking pin ‘U’ a ha specific loca ion.
4. Once the proper location and orientation for the base have been established
prepare a hole approximately 10x10" square and 18" deep and fill it with quick-set
ready-mix concrete (Sakrete) to about 1" below he surface level. Make sure to
follow the mixing instructions carefully.
5. Push the ground sleeve into the mixture and agitate it with quick short strokes it so
the concrete will bond to the metal. Lower the sleeve until the 2x6 rests on the
ground surrounding the hole suspending the sleeve in the concrete. This way it is
assured that the top of the plate is flush with the surrounding ground once the
concrete has set.
6. Take a water level to check if the top of the 2x6 is exactly level in all direc ions !
If it is not simply use shims or wedges to raise the board where necessary.
Complete this step carefully as the umbrella post might appear to “lean” if the base
is not installed plumb.
7. Let the concrete set overnight. Remove the board and make sure not to knock the
sleeve hard (concrete takes up to 7 days to cure). Cover the open holes on top of
the base plate with masking tape.
8. Fill the remaining space around the top plate with some ready mix. (Do no fill the
1” space inside the tube – this space is required to fully insert the locking pin). Tap
the concrete in nicely and finally drag your 2x6 held on edge across the base with
a zigzag motion to smooth the surface. Let it sit for a few hours and then clean off
the top plate with a damp cloth. Make sure to let the concrete cure for at least 3
days in warm conditions and up to 7 days if the temperature is below 50deg.
Fahrenheit /10deg. Celsius
