Fimer PVS-60-TL-US User manual

Product Manual
PVS-60-TL-US

2
001036AG-F
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important safety instructions that must be followed during the installation
and maintenance of the equipment.
SAVE THESE INSTRUCTIONS!
Keep this document in a safe place near the inverter for easy access during installation, ope-
ration and maintenance.
THE INSTALLER MUST READ THIS DOCUMENT IN ITS ENTIRETY BEFORE INSTALLING
THIS EQUIPMENT.
Operators are required to read this manual and scrupulously follow the instructions given in it,
since FIMER cannot be held responsible for damage caused to people and/or things, or the
equipment, if the conditions described below are not observed.
The purpose of this document is to support the qualied technician, who has received training
and/or has demonstrated skills and knowledge in construction, to install, operate and maintain
the inverter. This manual covers only inverter, not any equipment (photovoltaic modules, external
disconnects, etc) to which it is connected.
Warranty requirements are included in the Terms and Conditions of sale included with the
inverter order.
NOTE: Any changes made to the product or to the installation conditions that hasn’t been
approved by FIMER will void the warranty.
All pictures and illustrations shown in this user manual are indicatives and must be intended as
support for installation instruction only. Actual product may vary due to product enhancement.
Specications subject to change without notice. The latest version of this document is availa-
ble on the FIMER website.
FCC REMARKS
The equipment has been tested and found to comply with the limits for a Class B digital de-
vice, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.

3
001036AG-F
The products are designed to be connected to and to communicate information and data via
a network interface. It is the user’s sole responsibility to provide and continuously ensure a
secure connection between the product and the user’s network or any other network (as the
case may be). The user shall establish and maintain any appropriate measures (such as but
not limited to the installation of rewalls, application of authentication measures, encryption
of data, installation of anti-virus programs, etc) to protect the product, the network, its system
and the interface against any kind of security breaches, unauthorized access, interference,
intrusion, leakage and/or theft of data or information. FIMER and its afliates are not liable for
damages and/or losses related to such security breaches, any unauthorized access, inter-
ference, intrusion, leakage and/or theft of data or information. The data, examples and dia-
grams in this manual are included solely for the concept or product description and are not to
be deemed as a statement of guaranteed properties. All persons responsible for applying the
equipment addressed in this manual must satisfy themselves that each intended application
is suitable and acceptable, including that any applicable safety or other operational require-
ments are complied with. In particular, any risks in applications where a system failure and/or
product failure would create a risk for harm to property or persons (including but not limited to
personal injuries or death) shall be the sole responsibility of the person or entity applying the
equipment, and those so responsible are hereby requested to ensure that all measures are
taken to exclude or mitigate such risks. This document has been carefully checked by FIMER
but deviations cannot be completely ruled out. In case any errors are detected, the reader
is kindly requested to notify the manufacturer. Other than under explicit contractual commit-
ments, in no event shall FIMER be responsible or liable for any loss or damage resulting from
the use of this manual or the application of the equipment.

4
001036AG-F
Product manual
PVS-60-TL-US string inverters
1 - Safety and accident prevention
2 - Introduction and general information
3 - Characteristics
4 - Lifting and transport
5 - Installation
6 - Instruments
7 - Operation
8 - Maintenance
9 - Attachments
PVS-60-TL-US-Product manual EN-Rev A (M000047AG)
EFFECTIVE 29/07/2019
© Copyright 2019 FIMER. All Rights Reserved.

5
001037AG-F
