Fimer TRIO-20.0-27.6-TL-OUTD-US User manual

Solar Inverter
TRIO-20.0-27.6-TL-OUTD-US (-A)
Quick Installation Guide
In addition to what is explained in this quick installation guide, the safety and installation information provided in the product manual must be read and
followed. The technical documentation for the product is available at the website.
The device must be used in the manner described in the manual. If this is not the case the safety devices guaranteed by the inverter might be
ineffective.

2
1. Labels and Symbols
The labels on the TRIO inverter carry the markings, main technical data and identification of the equipment and manufacturer. The technical data shown
in this quick installation guide does not replace that shown on the labels attached to the equipment.
• PV source conductors must be Listed PV wire rated 1000V minimum per NEC 690.35.
• PV output conductors shall consist of sheathed (jacketed) multi-conductor cables or be installed in an approved raceway and must be isolated from
enclosure and system grounding, as required by NEC 690.35 and is responsibility of the installer.
• The TRIO is designed without an isolation transformer and intended to be installed per NFPA 70, 690.35 with an ungrounded PV array and can be used
only with PV modules that do not require one of the terminals to be grounded.
• All PV source and output circuit conductors must have disconnects complying with NEC, Section 690, Part III.
• To reduce risk of fire, connect only to circuit provided with 40A for 20kW and 50A for 27.6kW maximum branch circuit overcurrent protection in
accordance with NEC (ANSI/NFPA 70). See Maximum AC OCPD requirement in Technical Data table, Section 17.
• For models that do not include AC output overcurrent protection, the end user is responsible for providing protection for AC output circuit.
• Output circuits must be isolated from enclosure and system grounding, required by Articles 690.40 and 690.42 of NEC, ANSI/NFPA 70, and are the
responsibility of the installer.
In the manual and/or in some cases on the equipment, the danger or hazard zones are indicated with signs, labels, symbols or icons.
UL 1741; CSA-C22.2 No. 107.1-01 Grounding (earth)
General warning - Important safety information System earth conductor
(main grounding protective earth, PE)
Hazardous voltage
ø
Phase
Hot surfaces Direct and alternating currents, respectively
2. Frequency disconnect
This inverter has been factory programmed to automatically disconnect from the utility distribution system in compliance with UL 1741 and IEEE 1547
specifications. Default voltage and frequency trip limit and trip time settings to comply with these standards are shown in table below. The Service menu
can be used to adjust Voltage and Frequency Trip Limit and Trip Time Parameters according to Grid requirements of installation locale. Refer to technical
manual for instructions to use the Service menu.
Cond.
Simulated Utility Source Max.time (sec) @60Hz before
cessation of current to simulated
utility
Voltage (V) Frequency (Hz)
A< 0.50 Vnom (Fixed) Rated (60 Hz) 0.16 (Fixed)
B 0.50 Vnom ≤ V < 0.88 Vnom (Adj. Set Points 55% to 88%) Rated (60 Hz) 2 (Default)(Adj. Set Points 0.16 to 5 sec)
C1.10 Vnom < V < 1.20 Vnom(*) (Adj. Set Points 110% to 115%) Rated (60 Hz) 1 (Default)(Adj. Set Points 0.16 to 5 sec)
D(*)1.20 Vnom ≤ V(Fixed) Rated (60 Hz) 0.16 (Fixed)
ERated f>60.5Hz (Default)(Adj. 60.2 to 63.0 Hz) 0.16 (Default) (Adj. 0.16 to 300 sec)
FRated f<59.3 Hz (Default)(Adj. 59.8 to 57.0 Hz) 0.16 (Default) (Adj. 0.16 to 300 sec)
GRated f < 57.0 Hz 0.16 (Fixed)
HRated f > 63.0 Hz 0.16 (Fixed)
3. List of components
Components available for all models Quantity
3 pin connector for
configurable relay 2
9 pin connector for
communication and control
signals
4
L-key, TORX TX20 1
Jumpers for parallel input
mode 2
Components available for all models Quantity
Jumper cables for parallel
input, (-S1, -S1A, -S1B models)1+1
Bracket for wall mounting 1
4. Select installation location
Installation position -
• Install on a wall or strong structure capable of bearing weight.
• Install vertically with a maximum incline of +/- 5°.
• Maintain minimum clearance measurements shown.
• Ensure sufficient working area in front of inverter for wiring box access.
• Choose a location that allows unobstructed airflow around inverter.
• Position multiple inverters side-by-side, maintaining minimum clearances. Multiple inverters can also be placed in
staggered arrangement.
• Minimum clearances for staggered arrangements include width of inverter plus additional allowances for inverters
arranged above or below.

3
Environmental checks - See Technical Data,Section 17, to check environmental
parameters.
• Maximum operational ambient air temperature must be considered when
choosing location. Installing the inverter where operating temperatures exceed
specifications will result in power derating. It is recommended the inverter be installed
within specified temperature range.
• Exposure to direct sunlight will increase operational temperature of inverter
and may cause output power limiting. It is recommended to use a sun shade to minimize
direct sunlight when ambient air temperature around unit exceeds 104°F/40°C.
• Due to acoustical noise (about 50dBA at 1 m) from inverter, do not install in
rooms where prolonged presence of people or animals is expected.
ATTENTION –AIf installed indoors, the inverter must be inaccessible to unqualified
persons.
5. Wall mounting
When mounting the TRIO, first secure mounting bracket to desired location and
then install wiring box followed by inverter unit. When completely tightened wiring
box will move up to meet inverter. It is recommended to employ flexible conduit
methods to allow for possibility of inverter removal.
• Using a level, position mounting bracket on wall and use as a drilling template.
• Drill required holes using a drill with 10mm bit.
• Attach bracket to wall with ten wall anchors, 10mm in diameter, found in mounting kit.
• When installed in seismic Zone 3 or higher, the five center wall anchors must be
fixed into a wood/steel wall stud or concrete/masonry wall.
• When installing flexible conduit, provide enough conduit to allow for approximately
1”-1½” of vertical movement between inverter and wiring box.
• Prior to making conductor connections in wiring box, provide enough conductor to
allow for movement of wiring box in final stages.
• Hook wiring box on bracket by inserting heads of rear screws in bracket slots.
• Remove wiring box front cover 08.
• Loosen connector screws 07 to remove coupling cover 04 and store in pocket at
left-rear of wiring box.
• Locate four bolts protruding from rear of inverter chassis; use as mounting studs
and insert into four associated slots on mounting bracket as shown at right.
• Lift inverter using two people and orient it to bracket so four studs are just above
their associated slots.
NOTE: For easier lifting and handling, an optional lifting kit is available containing
handles and eyebolts that can be attached to holes in side of inverter unit.
• Clamp screw 05 is accessed externally at bottom of wiring box and used to
physically secure wiring box to inverter chassis.
• Push screw 05 upwards until it mates with inverter chassis and thread initially
by hand.
• Using a 20mm socket, tighten clamp screw 05 to lift wiring box toward inverter
until mating connectors of wiring box and inverter chassis seat fully.
DO NOT COMPLETELY TIGHTEN AT THIS TIME.
• Once wiring box and inverter are connected via screw 05, push screws 07 upward
to mate with inverter and initially thread by hand.
• Use a 13mm socket wrench to tighten connector screws 07 to at least 13.3-14.75
ft-lbs (18-20Nm) torque.
• Finish tightening clamp screw 05 to a torque of 13.3 ft-lbs (18Nm).
• Secure bottom of wiring box to wall bracket by tightening machine screw
through bottom locking tab 31 and into bottom hole of mounting bracket.
• If using rigid conduit, secure the conduit to the inverter using the knockouts.
31
06
05
03
04
08
04
05
02
07
01
32
01 Mounting bracket 06 Handles (optional )
02 Wiring box 07 Connector screws
03 Inverter 08 Wiring box cover
04 Coupling connector cover 31 Bottom locking tab
05 Clamp screw
80
cm
50
cm
50cm 50cm
80
cm
50
cm
50cm 50cm

4
6. Switchbox components
TRIO-XX.X-TL-OUTD-S-US-480 TRIO-XX.X-TL-OUTD-S1B-US-480
TRIO-XX.X-TL-OUTD-S1-US-480 TRIO-XX.X-TL-OUTD-S1A-US-480
SWITCHBOX COMPONENTS
09 Communication card
17 AC terminal block
10 Service cable opening with plastic threaded plug, trade size 1/2“ 18 AC board (behind 19 in -S1A and behind 20 in –S1B
11 DC cable openings with plastic threaded plug*, trade size 1”, 1 ½” 19 Class II AC surge protection (-S1A version)
13 DC terminal block (-S version) 20 Fused AC disconnect switch (-S1B version)
14 DC disconnect switch handle 22 DC fuse holders (-S1, -S1A, -S1B versions)
15 Class II DC surge protection (-S1, -S1A, -S1B versions) 27 Equipment ground conductor (EGC) busbar
16 AC cable opening, plastic threaded plug ,trade size 1” 28 AC ground (The DC EGC is common with the AC side and no
other interconnecting jumpers are required.)
* If a 2” conduit is needed for DC cable, DC cable entries can be punched to ccommodate using a knockout hole punch in location of existing knockouts.
7. List of supplied components
TRIO version -S with AFD Switchbox components with AFD TRIO -S1, -S1A, -S1B with AFD
All -A versions include the arc fault
detection board 29 and paralleling
terminal block 30 mounted on rail in wiring box, in
addition to components listed above.
Unless specified, wiring instructions for versions
with AFD are the same as versions without AFD,
although 29 and 30 may not be shown.

5
8. DC input mode configuration
ATTENTION –ATo operate in parallel mode from a common array, use jumpers provided to connect input channels in parallel as shown below.
In addition, input mode switch a01 located on communication card 09 must also be set to correct input mode.
See section 11 for location of switch a01 on communication card 09 in order to change default.
Setting input mode switch a01
• TRIO is shipped with input mode switch
in independent configuration.
• Switch a01 will be in right most position
(default INDEPENDENT mode).
• Move switch a01 to left-most position
to select PAR (parallel) mode.
Parallel mode -S version without AFD
• Parallel two channels by inserting solid
copper jumpers 12 into DC terminal blocks
13 between both channels as shown at right.
• One jumper connects POSITIVE input
(red) and second jumper connects
NEGATIVE input (black).
• Tighten in place with at least 53 in-lbs
(6Nm) torque.
Parallel Mode -S1, -S1A, -S1B versions without AFD
• Use red jumper cable to interconnect positive terminals (+IN1, +IN2).
• Use black jumper cable to interconnect negative terminals (-IN1, -IN2).
• Plug jumper wires into feeder terminals in positions shown at right.
• Tighten screw on top of each feeder terminal to 53 in-lbs (6 Nm) torque, pull on wire
to confirm it is secure.
9. DC input connections
WARNING –BWHEN CONNECTING THE DC CONDUCTORS VERIFY POLARITY PRIOR TO TERMINATING.
CONFIRM MAXIMUM SYSTEM VOLTAGE WILL NEVER EXCEED 1000V PER NEC REQUIREMENTS. FAILURE
TO PERFOM THESE CHECKS MAY CAUSE ARCING AND POTENTIAL FIRE.
For suitable wire size (AWG), refer to NFPA National Electrical Code, Table 310.15(B) . Use only Copper (Cu) wire rated for 75°C or 90°C (167°F or
194°F), solid or with type B or type C stranding (19 strands maximum). For conductors with finer stranding, a suitable UL listed wire ferrule must be used.
-S DC input connections - versions with and without AFD
• Remove threaded plastic plug and nut from DC cable opening 11 and insert conduit connector.
• Tighten to chassis to maintain NEMA 4X compliance.
• Connect raceway to chassis, pulling conductors through raceway and DC cable openings 11.
• Connect to DC terminal block 13.
• Acceptable conductor cross-section ranges from #12 AWG to #2AWG, copper conductors only.
• Tighten with at least 53 in-lbs (6Nm) torque.
• Connect any Equipment Grounding conductors in raceway to EGC busbar 27.
- Connection of inputs on the S2F / S2X model
WARNING –BReversing polarity may result in serious damage. Always check the polarity before
connecting up each string! Each input is equipped with protection fuses: check that the fuse current
rating is properly sized for the photovoltaic modules installed.
For string connections using the S2F / S2X wiring box, the quick fit connectors (multicontact or weidmuller)
situated at the bottom of the mechanics are used.
For each input channel, there are two groups of connectors:
- Input connectors (MPPT1) (19) with codes 1A, 1B, 1C, ...
- Input connectors (MPPT2) (20) with codes 2A, 2B, 2C, ...
Connect all the strings included in the design of the system and always check the tightness of the
connectors.
a01
PAR IND
Parallel Mode -S1, -S1A, -S1B versions with AFD
• Use black jumper cable to interconnect negative terminals
-IN1, -IN2.
• DO NOT CONNECT RED JUMPER CABLE.
• Plug jumper wire into feeder terminals in position shown at
left for -IN1, -IN2.
• Tighten screw on top of each feeder terminal to 53 in-lbs (6
Nm) torque, pull on wire to conrm it is secure
• Insert one solid copper jumper 12 into positive input
paralleling terminal block 30 (located next to AFD board) as
shown at right.
• Tighten in place with at least 53 in-lbs (6Nm) torque.
Parallel mode -S version with AFD
• Connect NEGATIVE input (black) in DC terminal block 13 as shown at left using one copper
jumper 12.
• Parallel POSITIVE inputs by inserting second jumper 12 into positive input paralleling terminal
block 30 (located next to AFD board 29), as shown at right.
• Tighten in place with at least 53 in-lbs (6Nm) torque to ensure a low resistance connection.
ATTENTION –AA removable transparent cover prevents access to live parts on
upper DC side of wiring box. Remove four screws in place and remove cover to
connect jumpers.

6
10. Communication card
ATTENTION –AA removeable transparent cover prevents access to the communication card in the wiring box; remove four screws in place and
remove cover to connect wiring. *Refer to technical manual for connections to a03, a04, a05, a06 and Remote a07.
a01 Input mode switch for selecting parallel or independent input
(default = INDEPENDENT , right most position)
a02 Rotary switches for setting country and language of display
a03
Switch for setting analog sensor 1 to Volts or mA *
a04 Switch for setting analog sensor 2 to Volts or mA *
a05 Connection to multi-function relay*
a06 Connection of environmental sensors: AN1,AN2,PT100, PT1000,
and auxiliary 24V service output *
a07
Connection for RS-485 PC line (SERVICE), RS-485 PMU line (MODBUS), auxiliary 5V
output, and remote ON/OFF*
a08 Termination resistance switch for RS-485 PMU line (MODBUS)
a09 Termination resistance switch for RS-485 PC line (SERVICE)
a10 RS-485 PC communication card housing (SERVICE)
a11 RS-485 PMU communication card housing (MODBUS)
a12 NA; for factory use only (default = left most position)
a12 Inverter data memory card housing
a14 CR2032 battery housing
11. Serial communications
Two RS-485 communication lines are available:
1) SERVICE/PC - dedicated line using AURORA Protocol,
2) MODBUS/PMU - dedicated line for MODBUS RTU
• Remove threaded plastic plugs from service cable opening 10 and replace with conduit connector.
• RS-485 cables must be connected to terminal block a07 on communication card 09.
• Connect either communication port using terminal block a07 (PC+T/R, PC-T/R and GND).
• Use cable designed
for use with RS-485
communications (ie Belden
3106A), which is a data cable
wire with one twisted pair,
one ground conductor, and a shield with drain wire (or equivalent).
On the last inverter in a daisy chain, or on single inverter, activate
termination resistance of communication line by moving switch a08 or a09
to ON position.
• Address on inverter is set through user interface on display panel area b7
(section 13). Default address is set at 2.
ATTENTION –AA removeable transparent cover prevents access to the communication card in the wiring box; remove four screws in place and
remove cover to connect wiring. *Refer to technical manual for connections to a03, a04, a05, a06 and Remote a07.
12. Display and keypad
• Operating parameters are displayed on LCD 23.
• LEDs 24 indicate operating state of inverter.
• Keypad 25 is used to review data on cyclical display b7.
POWER ALARM GFI ESC UP DOWN ENTER
DC
AC
24 25
b7
23
• GREEN POWER LED - On if inverter is working correctly. Flashes when
checking grid or if there is insu󰀩cient sunlight.
• YELLOW ALARM LED - Inverter has detected an anomaly. Anomaly is
shown in area b7.
• RED GFI LED - Ground fault on DC side of PV array. Error is shown
in area b7.
• ESC - Used to access main menu, go to previous menu or go to
previous digit to be edited.
• UP - Used to scroll up menu options or move numerical scale in
ascending order.
• DOWN - Used to scroll down menu options or move numerical scale in
descending order.
• ENTER - Used to conrm an action, access submenu for selected
option (indicated by > arrow symbol) or move to next digit to be edited.
Description of symbols and display fields on LCD 23
b1 RS485 data transmission b8 Power graph b15 DC/AC circuit part
b2 RS485 line present b9 Total energy b16 AC voltage
b3 Warning b10 Daily energy produced b17 AC current
b4 Temperature derating b11 PV voltage > Vstart b18 Connection to grid
b5 Instantaneous power b12 DC voltage b19 Grid status
b6 MPP scan running b13 DC current b20 Cyclic view on/off
b7 Graphic display b14 DC/DC circuit part
PMU -T/R
PMU +T/R
GND COM
+5V OUT
R ON/OFF
a07
SH
PC +T/R PC -T/R
POWER ALARM GFI ESC UP DOWN ENTER POWER ALARM GFI ESC UP DOWN ENTER POWER ALARM GFI ESC UP DOWN ENTER
S4
PMU PC
S2
OFF ON
OFF ON
a08
a09
TERM.
120

7
13. Configure display settings
Before commissioning, it may be necessary to set inverter configurations prior to grid connection by accessing the SETTINGS menu from the display.
ATTENTION –AThe man adjustable parameters and instructions for accessing the SETTINGS menu are explained below
With only array connected, set DC disconnect switch to ON. GREEN POWER LED will flash and YELLOW ALARM LED will be steady. LCD will read
"Missing Grid". Press ESC to open menus. Use DOWN key to scroll to Settings, and press ENTER. SETTINGS menu requires an access password.
Default password is 0000, pressing ENTER four times loads four zeroes on the display and opens the submenu.
• Area b7 has two visible text lines and the UP and DOWN keys are used to scroll through the menu items.
• Arrow (>) on the left side of the display highlights the current selection.
• Press UP or DOWN keys to move the arrow to the desired selection and press ENTER to open the associated submenu.
• To return to the preceding menu, press the ESC key.
Address: the RS485 address may need to be changed or assigned; DEFAULT address is
set at 2 for a single inverter.
• Scroll to Address and press ENTER to open submenu. Address values are assigned
manually using any value in the range [2 to 63]. Scroll DOWN to number (2) and press ENTER.
• Press UP and DOWN keys to scroll through numbers and press ENTER to select, ESC
to cancel.
Vstart:Vstart Parameter may need to be adjusted when short strings are used in PV array.
Change activation voltage only if necessary.
• Scroll DOWN to Vstart and press ENTER; Voltage range can be 250V to 500V ; (Default setting is 360V.)
• If more than one input, select Vstart 1 or 2
• Use DOWN key to move arrow to desired selection and press ENTER.
• Second display screen will open; press ENTER to confirm or ESC to cancel.
14. Commissioning
The inverter commissioning procedure is as follows:
1. Turn the DC disconnect switch in the ON position. If there are two separate external disconnect switches (one for DC and the other for AC), first close
the AC disconnect switch and then the DC disconnect switch.
2. Once powered, icon b11 comes on to indicate that the voltage from the PV array has reached the Vstart threshold.
For input voltages lower than Vstart, icon b11 remains off, “Waiting Sun” is shown in display area b7 and voltage
and current are present (icons b12 and b13).
3. Assoonas“WaitingSun”conditionsaremet,theinvertershowstheAFDboardself-testrunning. Theresultsareshownindisplayareab7.
If a problem on the AFD board is detected, the self-test will result in an error. Refer to section 16 below.
4. If there are no irregularities, the grid connection sequence starts. Once all the checks are
completed, icon b19 comes on. During these checks, icon b19 is flashing.
5. Icon b14 flashes to indicate the start-up phase; at the same time icon b15 will come on.
6. Immediately following the grid connection will start. Icon b18 will be displayed in steps until the connection is complete. After the inverter is connected,
the icon b18 will stay “plugged in”.
If there is not sufficient sunlight to connect to the grid, the unit will repeat the procedure until all the parameters controlling connection to the grid (grid
voltage and frequency, confirmation of no ground fault) are within range. During this procedure, the green LED flashes ON and OFF.
15. Arc fault detection
For –A models only, the AFD performs a self-test when the system is started. The inverter display shows the results of the self-test in area b7.
• If the self-test results are OK, the inverter will continue to AC grid connection.
• If a potential problem on the AFD board is detected, the self-test will result in error E053.
Refer to the technical manual online for possible solutions to clear the error.
During normal operation the input current is continually measured and analyzed.
• If a DC arc fault is detected during operation, the inverter is disconnected from AC grid and error E050 will be shown on display.
• Press and hold the ESC key for three seconds to clear the E050 error which will start the self-test.
• If self-test results are OK, the inverter will reconnect to the AC grid; if the DC arc fault is still present, the self-test will result in error E053. Refer to the
technical manual online for solutions. The AFD self-test can be manually started anytime using the following procedure:
1. Turn off the inverter (switching off both DC and AC switches),
2. Turn on both the DC and AC switches and wait for display communication of the self-test result.
Waiting Sun . . . .
Test Arc Sensor
OK
Arc Self Test
E053
Arc Fault
E050
0***
>Address
Display settings
Address
>2
>Vstart1
Vstart2
Language
>Vstart

FIMER_TRIO-20.0_27.6-TL-OUTD-US_Quick Installation Guide_EN_RevB
8
For more information
please contact your
local FIMER
representative or visit:
fimer.com
We reserve the right to make technical changes or
modify the contents of this document without prior notice.
With regard to purchase orders, the agreed particulars
shall prevail. FIMER does not accept any responsibility
whatsoever for potential errors or possible lack of
information in this document.
We reserve all rights in this document and in the
subject matter and illustrations contained therein. Any
reproduction, disclosure to third parties or utilization of
its contents – in whole or in parts – is forbidden without
prior written consent of FIMER. Copyright© 2021 FIMER.
All rights reserved.
16-06-2021
16. Characteristics and technical data
Technical Data Values TRIO-20.0-TL-OUTD TRIO-27.6-TL-OUTD
Nominal Output Power W20000 27600
Maximum Output Power W22000* 30000*
Rated Grid AC Voltage V480 480
Number of Independent MPPT Channels 2 2
Maximum Usable Power for Each MPPT Channel W12000 16000
Absolute Maximum Voltage (Vmax) V1000 1000
Start- Up Voltage (Vstart) V360 (adj. 250-500) 360 (adj. 250-500)
Full Power MPPT Voltage Range V 450-800 520-800
Operating MPPT Voltage Range V200-950 200-950
Maximum Usable Current (Idc max) for both MPPT in Parallel A
50.0 61.8
Maximum Usable Current (Idc max) per MPPT Channel A 25.0 30.9
Maximum Short Circuit Current (Isc max) per MPPT Channel A30.0 36.0
Max. Short Circuit Current (Isc max) for both MPPT in Parallel A60.0 72.0
Number of Wire Landing Terminals per MPPT Channel -S version: 2, -S1, -S1A, -S1B version: 8
Array Wiring Termination Type
-S version: Terminal Block, Screw Terminal, Copper Only 12AWG-2AWG,
type B or C stranding 19 strand max per conductor
S1, -S1A, -S1B version: Touch-safe fuse holder, Screw Terminal, Copper
Only 12AWG-6AWG, type B or C stranding (19 strand max per conductor)
Grid Connection Type 3Ø/3W or 4W+Ground 3Ø/3W or 4W+Ground
Default Voltage Range
V 422-528 422-528
Adjustable Voltage Range V240-552 240-552
Nominal Grid Frequency Hz 60 60
Adjustable Grid Frequency Range Hz 57-63 57-63
Maximum Current (Iac max/phase) ARMS 27.0 36.0
Power Factor > 0.995 > 0.995
Total Harmonic Distortion At Rated Power %<3 <3
Grid Wiring Termination Type Spring Tension Clamp Terminal, Copper wiring only, 6AWG-4AWG, type
B or C stranding
(19 strand max per conductor)
Fault Current ARMS
35.0 46.0
Reverse Polarity Protection Yes. Passive inverter protection only.**
Supplementary Over-Voltage Protection Type For Each MPPT
-S1, -S1A, -S1B versions only: Plug-in Class II Modular Surge Arrester
PV Array Ground Fault Detection Meets UL1741/NEC 690.5 requirements
Anti-Islanding Protection Meets UL1741/IEEE1547 requirements
Supplementary Over-Voltage Protection Type -S1A version: Plug-in Class II Modular Surge Arrester
Maximum Efficiency %98.2 98.2
CEC Efficiency %97. 5 97.5
Feed-In Power Threshold WRMS 65 70
Stand-by Consumption WRMS <8 <8
User-Interface (Display) 5.5” x 1.25” Graphic Display
Standard Communication Interfaces
(1) RS485 Connection can be configured for AURORA Protocol or
Modbus RTU.
Optional Remote Monitoring Logger AURORA Logger Commercial (optional)
Ambient Operating Temperature Range F(°C) -22 to +140 (-30 to +60) , Derating above +113 (45)
Ambient Storage Temperature Range F(°C) -40 to +185 (-40 to +85)
Relative Humidity %RH 0-100 condensing
Acoustic Noise Emission Level
dbA @1m <50 <50
Maximum Operating Altitude without Derating ft(m) 6560 (2000) 6560 (2000)
Enclosure rating NEMA 4X
Conduit Connections Bottom: (2) Concentric EKOs 1”,1½ ” , (2) ½” plugged openings, (1) 1”
plugged opening
Optional PV String Combiner Fuse Size/Type A/V mm 15/1000 10x38 15/1000 10x38
DC Switch Current Rating (Per Contact) A36 36
Optional AC Fused Disconnect Current Rating (Per Contact) A35 45
Isolation Level Transformerless. Floating Array Required
Safety and EMC Standard UL 1741, IEEE 1547, IEEE1547.1, CSA C22.2 107.1-01-2001, FCC Part 15
Sub-part B Class B Limits
Safety Approval cCSAus
All data is subject to change without notice.
*Capability enabled within maximum input current, maximum input power, maximum output current, and ambient operating temperature limits.
**In -S1, -S1A and -S1B models, string polarity must be verified before connection. Please refer to installation manual for correct installation procedure.
