Fimer PVS-175-TL User manual

Product Manual
PVS-175-TL
(175 kW, A.1 version)

IMPORTANT SAFETY INSTRUCTIONS.
ATTENTION –AThis manual contains important safety instructions that must be followed
during the installation and maintenance of the equipment.
SAVE THESE INSTRUCTIONS!
NOTE –DKeep this document in a safe place near the inverter for easy access during
installation, operation and maintenance.
The installer must read this document in its entirety and scrupulously follow the instructions given in
it before installing this equipment, since FIMER cannot be held responsible for damage caused to
people and/or things, or the equipment, if the conditions described below are not observed.
The purpose of this document is to support the qualified technician, who has received training and/or
has demonstrated skills and knowledge in construction, to install, operate and maintain the inverter.
This manual covers the inverter only, and NO other equipment (photovoltaic modules, external
disconnects, etc) to which it is connected.
Warranty requirements are included in the Terms and Conditions of sale included with the inverter
order.
NOTE –DAny changes made to the product or to the installation conditions that hasn’t been
approved by FIMER will void the warranty.
NOTE –DAll pictures and illustrations shown in this user manual are indicatives and must be
intended as support for installation instruction only. Actual product may vary due to product
enhancement. Specifications subject to change without notice. The latest version of this
document is available on the FIMER website.
The products are designed to be connected and communicate information and data via a network
interface. It is the user’s sole responsibility to provide and continuously ensure a secure connection
between the product and the user’s network or any other network (as the case may be). The user shall
establish and maintain any appropriate measures (such as but not limited to the installation of firewalls,
application of authentication measures, encryption of data, installation of anti-virus programs, etc) to
protect the product, the network, its system and the interface against any kind of security breaches,
unauthorized access, interference, intrusion, leakage and/or theft of data or information. FIMER and
its affiliates are not liable for damages and/or losses related to such security breaches, any
unauthorized access, interference, intrusion, leakage and/or theft of data or information. The data,
examples and diagrams in this manual are included solely for the concept or product description and
are not to be deemed as a statement of guaranteed properties.
All persons responsible for applying the equipment addressed in this manual must satisfy themselves
that each intended application is suitable and acceptable, including that any applicable safety or other
operational requirements are complied with. In particular, any risks in applications where a system
failure and/or product failure would create a risk for harm to property or persons (including but not
limited to personal injuries or death) shall be the sole responsibility of the person or entity applying
the equipment, and those so responsible are hereby requested to ensure that all measures are taken
to exclude or mitigate such risks. This document has been carefully checked by FIMER but deviations
cannot be completely ruled out. In case any errors are detected, the reader is kindly requested to
notify the manufacturer. Other than under explicit contractual commitments, in no event shall FIMER
be responsible or liable for any loss or damage resulting from the use of this manual or the application
of the equipment.
