Firehawk FHB10W User manual

PLEASE read all instructions BEFORE beginning to pair a system!
1.0 Plug alarm into pattress and switch on radio
base, the pattress led will flash green twice per
second. If not please complete step 6.0
2.0 Bring alarm & radio base together then twist/slide to lock into place.
3.1 Place two alarms on the table spaced approximately
20cm APART.
3.2 Press the TEST BUTTON on one alarm and wait
THREE SECONDS.
3.3 Press the TEST BUTTON on the other alarm.
3.4 Watch carefully as both pattresses FLASH GREEN
AND RED
3.5 As soon as one FLASHES GREEN ONLY, move it to one side.
3.6 The other pattress will continue to flash red/green until it BEEPS ,then it will FLASH GREEN
(The CO will BEEP FOUR TIMES) THE TWO ALARMS ARE NOW PAIRED.
3.7 There is now a 10 SECOND WINDOW to allow another device to be added to the system Step 4.0
If no other devices are to be added proceed to Step 5.0
(Repeat steps 1.0 and 2.0 for each alarm)
Wait for smoke or heat alarm to BEEP TWICE Wait for the CO alarm to BEEP FOUR TIMES
1CONNECT
2ALARM ASSEMBLY
3PAIRING TWO ALARMS
SMOKE ALARM FHB10W HEAT ALARM FHH10W CO ALARM CO7B (10Y)W
20cm
PAIRED
PRESS
& WAIT
FOR 3
SECS.
3.1 3.2 3.3 3.4 3.5
3.2 3.3
PAIRED
20cm
UNPAIRED
ALARM(S)
Pairing Radio Linked Alarms Instructions

PAIRED
Fireblitz Extinguisher Ltd Units 15/17 Manford Industrial Estate, Manor Road, Erith, Kent DA8 2AJ.
Tel: [phone] |Fax: [phone] |Email: sales@fireblitz.co.uk |www.fireblitz.co.uk
Fireblitz reserve the right to change the design or specification details without prior notice.
REF: RADIOINSTRUCT09/20
4.1 To add additional alarms to the system simply PLACE THE PAIRED ALARM THAT BEEPED
(see section 3.6) approximately 20cm apart to a ASSEMBLED ALARM (see point 2.0)
UNPAIRED ALARM.
4.2 Firstly, press the TEST BUTTON on the PAIRED ALARM and wait THREE SECONDS.
4.3 Then press the TEST BUTTON on the UNPAIRED ALARM.
4.4 Repeat steps 3.4 to 3.6
5.1 When all alarms have been added to the system (smoke / heat alarm will BEEP ONCE,
CO alarms will BEEP FOUR TIMES) the pattresses will now continue to FLASH GREEN .
5.2 Once pattresses have stopped FLASHING GREEN .and BEEPING the alarms are now
READY FOR INSTALLION.
5.3 If any device fails to beep and flashes red please reset all devices step 6.0 and repeat the pairing
process.
5.4 Assuming everything went to plan please now test each alarm in the system.
4PAIRING TWO ALARMS
5PAIRED ALARMS READY FOR INSTALLATION
20cm
PRESS
& WAIT
FOR 3
SECS.
4.1 4.2 4.3
PAIRED
UNPAIRED
ALARM(S)
6.1 To reset the pattress, remove the alarm device
and press the black button. This will restore
factory settings and unlearn all paired devices.
The Led will flash red four times then begin to
flash green as in step 1.0.
6.2 Start again and repeat pairing process.
6DEVICE RESET
