Firehawk FHH10W User manual

FHH10W
READ AND RETAIN THIS USER MANUAL
5. TESTING THE SYSTEM
Test the full system using the test button of the alarms and or Deaf Alerts if
fitted.
1. Undo the alarm from the pattress without
disconnecting the wires and permanently
attach it to the chosen location.
See sec 4 para 2 above.
2. Fit all alarms to their own Radio Pattresses
by lining up as shown here:
3. Close the alarm onto the Radio Pattress
and turn the alarm clockwise to lock it into
place. This action automatically turns the
alarm on.
Press the test button on each alarm and wait for the other alarms to sound
before testing all other alarms in the same way. The alarm should sound
three times with a flashing red light then stop. Allow at least 5 seconds after
a successful test before testing the next one. After testing check that the
red light flashes approximately every minute. Test the alarm once a week to
ensure correct operation.
The Radio Interlinked System is now ready for use.
Do not change any components of the system for those made by other
manufacturers. Up to 15 alarms may be paired to the system.
WARNING: The electronic test button provides a full test of the alarms
functionality. Do not try to test the alarm using either heat smoke or naked
flame as damage will occur.
6. USER INFORMATION
Protect your Home Against Fire
Contact your local Fire Brigade for a home safety check, this information is
free and will identify potential fire hazards in and around your home.
Make sure all occupants of the home know what a fire alarm sounds like.
Prove and practise a fire escape plan and arrange a suitable and safe assembly
point.
What to Do if the Alarms Sound
Alarms sounds are as follows:
\
Full alarm indicating Repeating series of 3 beeps every ••• ••• ••• •••
smoke and fire 4 seconds with flashing light
Low Battery Single beep every minute • • • •
Test button jammed One beep every 11 seconds • • • •
Fault Double beep every minute •• •• •• ••
Ensure everyone leaves the building as soon as possible.
• Do not run.
• Do not stop to collect belongs.
• If it is safe to do so, close all windows and doors as you escape to prevent
the spread of fire.
• Smoke is the main cause of death from fire. If trapped inside the building,
cover your mouth, conserve breath and crawl to safety.
Do not silence a fire alarm until you know the cause of the alarm
and when all occupants are safely outside the building.
Silencing an alarm
Do not silence a smoke alarm until you are certain there is no fire. The fire
alarm that has detected a fire will be flashing its red light in the centre of
the test button once every second, all other alarms in the system will just be
sounding.
To silence the fire alarm system, press the test button on any alarm in that
system. If one alarm continues to sound, it will be the one that has detected
a fire. Check for a fire in its area and for its flashing red light. ONLY if you are
certain there is no fire, press its test button to silence it. If you are not certain,
evacuate the property and call your fire and rescue service on 999.
7. ALARM MAINTENANCE
A regular program of fire alarm maintenance will help to keep your alarm in good
working order.
• Test the alarm weekly making sure that all interconnected alarms in the
system sound within 10 seconds.
• Vacuum the alarms every six months and wipe them with a damp cloth.
• Do not paint the alarm.
A fire alarm is a sensitive life-saving device. The life of this alarm can be
significantly reduced by adverse environments, incorrect location and a failure
to regularly clean and maintain it according to the instructions. Incorrect
location and a lack of reasonable care may also cause it to malfunction and
will invalidate the warranty.
8. TROUBLE SHOOTING
The battery in the alarm will last ten years and the battery in the pattress will
last seven years - they are both non-replaceable. At the end of its life the
alarm will beep once every minute for a minimum of one month.
The life of the battery can be significantly shortened by periods of storage
or use in temperatures below 5°C or above 30°C. It will also be shortened
by frequent or extended periods in full alarm often caused by conditions
such as cigarette smoke, steam, aerosol spray and condensation. In these
circumstances the warranty will be void.
If this happens at night you can press the test button to silence the battery
warning for 10 hours. Replace the alarm as soon as possible.
Problems are indicated in five ways;
1. The alarm beeps twice every minute indicating a malfunction.
2. The alarm beeps once every minute indicating a low battery.
3. The full alarm sounds for no reason. (A repeating series of three beeps with
flashing light)
4. The alarm does not sound when pressing the test button.
5. The test button light remains steadily on or off. (i.e. does not flash
approximately once every minute, when the unit is not in alarm)
Inspect for obvious damage. Check that the alarm has been installed in
accordance with the instructions. In the case of repeated nuisance alarms,
check that it is free from dust, cobwebs and external contamination from
such things as cigarette smoke, drying paint, spray from household aerosols
and steam that will ultimately shorten the life of the alarm and invalidate the
warranty.
If this does not correct the problem, do NOT attempt to repair. There are
no user serviceable parts internally. If the smoke alarm is within the warranty
period and terms, indicate the nature of the problem and return the unit with
proof of purchase to the address at the end of this manual. Units beyond
warranty cannot be economically repaired.
9. PRODUCT WARRANTY
Fireblitz guarantees to you, as a purchaser, that the enclosed fire alarm will be
free from defects in material, workmanship or design under normal use and
service for a period of 10 years. The enclosed Radio Pattress is guaranteed
for 7 years. These Guarantees are not assignable. Our liability to you, under
this guarantee is limited to repairing or replacing any part which we find to be
defective in material, workmanship or design, free of charge to the customer,
upon sending the alarm with proof of date of purchase, postage paid to
Fireblitz Extinguisher Ltd, Units 15/17 Manford Industrial Estate, Manor Road,
Erith, Kent DAB 2AJ. The terms of this guarantee will not apply in the following
circumstances:
• If the alarm has been modified, dismantled, contaminated, damaged,
neglected or otherwise abused or altered following the date of purchase,
• If it fails to operate due to incorrect siting, installation or maintenance
• Damage caused by failure to abide by the instructions supplied.
It is specifically drawn to the users attention that substantial periods in alarm
will shorten alarm life, during which time the fire alarm will have provided
valuable protection; no Claim under the guarantee will be entertained. The
liability of Fireblitz Ltd, arising from the sale of this alarm or under the terms
of this guarantee shall not in any case exceed the cost of replacement of the
alarm. In no case, shall Fireblitz Ltd be liable for consequential loss or damage
resulting from the failure of the alarm or the breach of this or any other
guarantee, express or implied or for damage caused by failure to abide by the
instructions supplied.
This guarantee does not affect your statutory rights.
Fireblitz Extinguisher Ltd.
Units 15-17 Manford Industrial Estate,
Manor Road. Erith, Kent DA8 2AJ
Telephone: [phone]
TECHNICAL HELPLINE 0800 008 6568
Text on 07885 831239
Email: customerservices@fireblitz.co.uk
7
YEAR
WARRANTY
MANUAL
WIRELESS (RADIO LINKED)
Heat Alarm
10 YEAR LITHIUM BATTERY OPERATED
BS5446-2:2003
Licence number
KM654703

1. FHH1OW PRODUCT OVERVIEW
All FireHawk heat alarms are approved to BS5446:2 :2003, the most recent
and rigorous Standard. The FHH10W comes with Advanced Thermistor
based detection, controlled by bespoke software that is specifically designed
for applications where smoke alarms would be unsuitable, such as kitchens,
garages and dusty areas.
Product Features
• Radio interlinkable to other heat, smoke or Carbon Monoxide alarms. By
connecting up to 15 alarms, they will be connected by radio link so that
when one alarm sounds all connected alarms will sound.
• Two sealed in long life batteries.
• Bespoke software maximises detection ability, false alarm rejection and
Alarm Silence operation.
• Power automatically switched on as alarm is installed onto its Radio Pattress
and switched off when it is removed.
• Red LED flashes approximately every minute confirming the alarm is
receiving power and ready to detect fire conditions.
• End of life low battery warning beeps once every minute.
• Low battery warning silence allows you to silence the warning at night and
replace the alarm during the following day.
• Extra large test button for ease of use to test sensitivity, circuitry, battery
and alarm sounder.
• Loud 85 dB piezo-electric sounder automatically resets when hazardous
situation has passed.
• Alarm Silence feature allows you to silence nuisance alarms by pressing the
test button, ideal in non-emergency situations. The red LED flashes every
2-3 seconds while the alarm is in the silenced mode and automatically
resets in approximately ten minutes.
• Easy installation. Fixing screw kit supplied and there is no need to fit the
batteries!
IMPORTANT NOTE: For minimum total property protection install at
least one SMOKE ALARM in the escape route from each floor of your
home and within 3 metres of all bedroom doors.
Heat alarms are most suitable for kitchens, boiler rooms, workshops and
garages where steam, cooking fumes, dirt and dust contaminate smoke alarms
causing nuisance alarms and in some cases a failure to detect a fire early.
When installing heat alarms in living and working accommodation they should
always be interlinked to smoke alarms and should not be used in escape routes
from the building.
Photoelectric (Optical) Smoke Alarms are best for sensing smouldering
fires and are therefore most suitable for rooms containing soft furnishings,
carpets bedding and clothes, such as hallways, living rooms and bedrooms.
Photoelectric alarms are recommended by BS5839 part 6 for living
accommodation where most fires are started by electrical equipment and
smouldering material.
These alarms should be interconnected to heat alarms. See diagrams below.
All alarms should be interlinked.
Recommended siting of smoke and heat alarms in:
SINGLE STOREY HOME WITH ONE SLEEPING AREA
SMOKE ALARMS FOR MINIMUM PROTECTION
SMOKE ALARMS FOR INCREASED PROTECTION
HEAT ALARMS
SINGLE STOREYHOME WITH TWO SLEEPING AREAS
SMOKE ALARMS FOR MINIMUM PROTECTION
SMOKE ALARMS FOR INCREASED PROTECTION
HEAT ALARMS
MULTIPLE STOREY HOME WITH MULTIPLE SLEEPING AREAS
SMOKE ALARMS FOR MINIMUM PROTECTION
SMOKE ALARMS FOR INCREASED PROTECTION
HEAT ALARMS
SMOKE ALARMS FOR MINIMUM PROTECTION
SMOKE ALARMS FOR INCREASED PROTECTION
HEAT ALARMS
Position of alarms
on apex ceilings:
Recommended position of alarms.
Recommended in a room, corridor or escape route.
SMOKE ALARMS FOR MINIMUM PROTECTION
SMOKE ALARMS FOR INCREASED PROTECTION
HEAT ALARMS
2. CHOICE AND LOCATION OF ALARMS
The life of the alarm can be significantly reduced by adverse environments,
incorrect location and a failure to regularly clean and maintain it according to
the following instructions. Incorrect location and a lack of reasonable care may
also cause it to malfunction and will invalidate the warranty.
• Do not install heat alarms on walls.
• Do not locate near fans or extractors; these can pull smoke and heat away
from the alarm.
• Do not install in bathrooms and showers
• Do not install in rooms where the normal temperature may exceed 40°C or
fall below 0°C. These may cause nuisance alarms.
• Do not install in the peak of an A frame ceiling; this may delay heat
reaching it due to still air. (see diagram above for minimum distances from
the peak)
• Do not install less than 300mm from walls and beams due to still air.
• Do not install less than 300mm from light fittings.
• Do not install heat alarms in sleeping areas such as bedrooms, nurseries,
playrooms or areas where the elderly and disabled may spend long periods
of time.
• Do not install on poorly insulated ceilings where cold air boundary layers
may delay heat from reaching the alarm.
• Do not install near objects that may delay or prevent heat from reaching
the alarm.
• Avoid installing within 1500mm of fluorescent light fittings that could
cause nuisance alarms.
• Do not paint the alarm.
• The location of alarms must be in accordance with Part B of the applicable
Building Regulations. Further help and guidance can also be found in
BS5839 Part 6.
WARNING: Do not store alarms in temperatures below 5 degrees and
above 30 degrees, and in low humidity; this may cause beeping and
nuisance alarms when first installed. These will clear after a short time
when the alarm has become acclimatised. Extended periods under these
conditions will reduce the life of the alarms and invalidate the warranty.
3. FURTHER DETAIL ON ALARM LOCATION
• At least one SMOKE alarm should be installed in the escape route from all
floors of the building.
• The detection element of the heat alarm should be between 25mm and
150mm below the ceiling.
• Heat alarms should be mounted at least 300mm from any wall or light
fitting.
• Heat alarms should NOT be mounted on walls.
• Do not use heat alarms in escape routes.
• No heat alarm should be further than 5.3 metres from other heat or smoke
alarms.
• To give the earliest warning of a developing fire all smoke and heat alarms
in your home should be interlinked (other than those in point 2 of Choice
and Location of Alarms above).
4. INSTALLATION PROCEDURE
Pairing the Radio System
Refer to the separate “Instructions for Pairing Radio Linked Alarms” packaged
with this alarm.
1. When the pairing of the complete system has been completed, test all
alarms to make sure they all link to one another. If they do not, re-pair the
alarms according to the instruction sheet packed with the alarms.
2. Now take the complete alarm to the rooms of their location and test the
system again to make sure that they still operate correctly in their new
location
3. Now separate the alarms from their radio pattresses by depressing the
security tag shown below and twisting the alarm anticlockwise
4. Fix them to your final chosen location by referring to sections 2, 3, and 4
above and re-assemble the alarm to the pattress as shown below
5. You need to ensure surfaces do not contain hazardous materials eg
asbestos. The screw fittings supplied are suitable for use on wood, plaster
and plasterboard but on other surfaces such as concrete where adhesive
material or adhesive pads may be better. For certain applications, the
installer may need to source their own fixings.
6. Screw the pattress to ceiling using the fixings provided. You may also
use two half-moon shaped and double sided fixing pads available from
Fireblitz.
7. Alternatively, you may use any proprietary builders fixing adhesive
normally used to fix skirting boards and other light building components
to walls etc.
NOTE: Be sparing with any adhesives used on the back of the radio
pattress to avoid excess adhesive squeezing through holes onto the
circuit board. When using adhesive pads or adhesives make sure
the surfaces are flake free, clean, dry and flat. Take care to use all
appropriate Health and Safety precautions when fixing the pattress and
alarm to their surface - in particular use appropriate access equipment,
protect yourself from dust and wear eye protection.
Do not change any components of the system for those made by other
manufacturers. Up to 15 alarms may be paired to the system.
WARNING: The electronic test button provides a full test of the alarms
functionality. Do not try to test the alarm using either heat smoke or
naked flame as damage will occur.
SMOKE ALARMS FOR MINIMUM PROTECTION
SMOKE ALARMS FOR INCREASED PROTECTION
HEAT ALARMS
