First Alert First Alert SCO1BN User manual

Description:
The FCD2BN is an AC-powered plug-in CO alarm. It is microprocessor controlled for accurate and
reliable operation. Meets UL2034. Single-button test/silence. Permanent CO sensor.Alarm indicator
light: Power shines constant red, during Alarm LED flashes when CO alarm levels are detected.
Also have malfunction/service mode alert. Loud, 85dB horn. 5-Year Limited Warranty.
Cat. FCD2BN 120V AC Plug-In
Description:
The FCD3BN is a basic battery-operated CO alarm designed for portability. Easily mounts on wall,
ceiling or rests on dresser or shelf. Includes action chart describing how to respond to an alarm.
Meets UL2034. Includes 9-volt alkaline battery.Test/silence button silences the alarm while
continuing to monitor CO levels. Permanent CO sensor.Three indicator lights: Battery flashes green
for power,Alarm flashes red when CO alarm levels are detected, Service flashes yellow if service or
replacement is required. Loud, 85dB horn. 5-Year Limited Warranty.
Cat. FCD3BN 9V Battery Operated
Description:
The FCD2DDBN is an AC-powered plug-in CO alarm with digital display. It is microprocessor
controlled for accurate and reliable operation. Meets UL2034. Single-button test/silence. Permanent
CO sensor. Peak Level Memory displays highest CO sensed.Alarm indicator light: Power shines
constant red, during Alarm LED flashes when CO alarm levels are detected.Also have
malfunction/service mode alert. Loud, 85dB horn. 5-Year Limited Warranty.
Cat. FCD2DDBN 120V AC Plug-In w/Digital Display
Description:
The FCD4CN-3 is an AC-powered plug-in CO alarm with 9V battery backup, digital display and
exclusive, patented IR remote control test/silence. Can be operated with most householdTV/VCR
remote controls. Microprocessor-controlled for accurate and reliable operation. Meets UL2034.
Single-button test/silence/scroll function. 9-volt alkaline battery included. Digital display with Peak
Level Memory. Permanent CO sensor.Alarm indicator light: Power shines constant red, during
Alarm LED flashes when CO alarm levels are detected.Also have malfunction/service mode alert.
Loud, 85dB horn. 5-Year Limited Warranty.
Cat. FCD4CN-3 120V AC Plug-In w/9V Battery
Back-up and Digital Display
Description:
The SCO1BN is a battery-operated smoke and CO combination alarm. Can be mounted on wall
or ceiling. Meets both UL217 and UL2034. Includes 9-volt alkaline battery. Ionization smoke sensing
technology provides warning in case of fire. CO alarm warns of elevated CO levels. Easy alarm
identification through different horn sounds and lights.Test/silence button.Three indicator lights:
Battery flashes green for power,Alarm flashes red when CO alarm levels are detected, Service
flashes yellow if service or replacement is required. Loud, 85dB horn. 5-Year Limited Warranty.
Cat. SC01BN 9V Battery Operated Combination
Smoke & Carbon Monoxide Alarm
CARBON
MONOXIDE
ALARMS
BRK2462 8/6/03 1:17 PM Page 1

Packaging Type: Carton
Individual Carton Master Pack
Dimensions: 8.66"L, 2.47"D, 5.66"H 15.63"L, 9.00"D, 6.31"H
Weight: 0.65 lbs 3.90 lbs
Cube: 0.07 ft30.51 ft3
UPC: 0 29054 15001 1 100 29054 15001 8
Quantity: 16
Packaging Type: Carton
Individual Carton Master Pack
Dimensions: 8.66"L, 2.47"D, 5.66"H 15.63"L, 9.00"D, 6.31"H
Weight: 0.68 lbs 4.08 lbs
Cube: 0.07 ft30.51 ft3
UPC: 0 29054 85633 3 100 29054 85633 0
Quantity: 16
Packaging Type: Carton
Individual Carton Master Pack
Dimensions: 8.66"L, 2.16"D, 5.66"H 13.69"L, 9.00"D, 6.31"H
Weight: 0.72 lbs 4.32 lbs
Cube: 0.06 ft30.451 ft3
UPC: 0 29054 15000 4 100 29054 15000 1
Quantity: 16
Packaging Type: Clam
Individual Clam Master Pack
Dimensions: 9.75"H, 2.40"D, 6.63"L 7.13"H, 5.25"D, 10.88"W
Weight: 0.74 lbs 2.22 lbs
Cube: 0.09 ft30.20 ft3
UPC: 0 29054 85618 0 800 29054 85618 6
Quantity: 13
Packaging Type: Carton
Individual Carton Master Pack
Dimensions: 8.59"L, 2.16"D, 7.29"H 8.94"L, 7.19"D, 7.94"H
Weight: 0.97 lbs 2.91 lbs
Cube: 0.08 ft30.30 ft3
UPC: 0 29054 15002 8 100 29054 15002 5
Quantity: 13
CARBON MONOXIDE ALARMS
©2003 BRK Brands, Inc. CM2462
Manufactured By:
BRK Brands, Inc
3901 Liberty Street Road
Aurora, IL 60504-8122 BRK ELECTRONICS®is a registered trademark of BRK Brands, Inc.
First Alert®is a registered trademark of the First Alert Trust.
www.brkelectronics.com
Distributed By:
Alarm Dimensions: 5.3"L, 3.3"W, 1.4"H
Weight: 5.9 oz.
Operating Voltage: 120 VAC, 60 Hz
Power: .09 amps
Temp Range: 40ºF (4ºC) to 100ºF (38ºC)
Humidity Range: 10% to 90% Relative Humidity
Audio Alarm: 85dB at 10 ft.
Test Button: Electronically simulates a carbon monoxide condition,
causing the unit to alarm
Alarm Reset: Automatic when CO clears; Press Test/Silence button to reset manually
Indicator LEDs: AC Power: Constant Red LED
CO Alarm: Audio Alarm (4 beeps, pause, 4 beeps) and rapidly flashing Red LED
Listing: UL2034
FCD2BN Technical Specs FCD2BN Packaging Specs
Alarm Dimensions: 5.3"L, 3.3"W, 1.4"H
Weight: 5.9 oz.
Operating Voltage: 120 VAC, 60 Hz
Power: .09 amps
Temp Range: 40ºF (4ºC) to 100ºF (38ºC)
Humidity Range: 10% to 90% Relative Humidity
Audio Alarm: 85dB at 10ft.
Test Button: Electronically simulates a carbon monoxide condition, causing the unit to alarm
Alarm Reset: Automatic when CO clears; Press Test/Silence button to reset manually
Indicator LEDs: AC Power: Constant Red LED
CO Alarm: Audio Alarm (4 beeps, pause, 4 beeps) and rapidly flashing Red LED
Listing: UL2034
FCD2DDBN Technical Specs FCD2DDBN Packaging Specs
Alarm Dimensions: 5"L, 4.9"W, 1.5"H
Weight: 11.36 oz.
Operating Voltage: 9V DC
Temp Range: 40ºF (4ºC) to 100ºF (38ºC)
Humidity Range: 10% to 90% Relative Humidity
Audio Alarm: 85dB at 10 ft.
Test Button: Electronically simulates a carbon monoxide condition, causing the unit to alarm
Alarm Reset: Automatic when CO clears; Press Test/Silence button to reset manually
Indicator LEDs: DC Power: Flashes Green when unit is receiving power; Horn “chirps” every 30
seconds when battery is low
Service Status: Flashes Yellow when unit needs service or replacement; Horn “chirps” when light flashes
CO Alarm: Audio Alarm (4 beeps, pause, 4 beeps) and rapidly flashing Red LED
Listing: UL2034
FCD3BN Technical Specs FCD3BN Packaging Specs
4.063
5.375 1.769
Alarm Dimensions: 5.3"L, 3.3"W, 1.4"H
Weight: 7.6 oz.
Operating Voltage: 120 VAC, 60 Hz, 9V DC
Power: .09 amps
Temp Range: 40ºF (4ºC) to 100ºF (38ºC)
Humidity Range: 10% to 90% Relative Humidity
Audio Alarm: 85dB at 10 ft.
Test Button: Electronically simulates a carbon monoxide condition, causing the unit to alarm
Alarm Reset: Automatic when CO clears; Press Test/Silence button to reset manually
Indicator LEDs: AC Power: Constant Red LED
CO Alarm: Audio Alarm (4 beeps, pause, 4 beeps) and rapidly flashing Red LED
Listing: UL2034
FCD4CN-3 Technical Specs FCD4CN-3 Packaging Specs
Alarm Dimensions: 5.6"Dia., 1.8"H
Weight: 11.2 oz.
Operating Voltage: 9V DC
Temp Range: 40ºF (4ºC) to 100ºF (38ºC)
Humidity Range: 10% to 90% Relative Humidity
Audio Alarm: 85dB at 10 ft.
Test Button: Electronically simulates a carbon monoxide condition, causing the unit to alarm
Alarm Reset: Automatic when CO clears; Press Test/Silence button to reset manually
Indicator LEDs: DC Power: Flashes Green when unit is receiving power;
Horn “chirps” every 30 seconds when battery is low
Service Status: Flashes Yellow when unit needs service or replacement; horn “chirps” when light flashes
Smoke Alarm: Audio Alarm (3 beeps, pause, 3 beeps) and rapidly flashing Red Smoke LED
CO Alarm: Audio Alarm (4 beeps, pause, 4 beeps) and rapidly flashing Red CO LED
Listing: UL2034
SC01BN Technical Specs SC01BN Packaging Specs
5.562
5.562 2.086
