WARNING: For your safety the information in
this manual must be followed to minimize the risk
of fire or explosion or to prevent property damage,
personal injury or death.
—Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of any other appliance.
—WHAT TO DO IF YOU SMELL GAS
tDo not try to light any appliance.
t
tClear the room, building or area of all occupants.
t
t
—Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
English Page 2 – 48
Español Pág 49 – 98
The Governor of California to publish a list of substances known to the state of
California to cause cancer or reproductive harm and requires businesses to warn
customers of potential exposures to such substances.
Gas appliances contain or produce substances, which can cause death, or serious
illness and which are known to the State of California to cause cancer, birth
defects, or other reproductive harm. To reduce the risk from substances in fuel
or from fuel combustion, make sure this appliance is installed, operated, and
maintained according to the manufacturers instructions.
In the state of Massachusetts
Installation must be performed by a qualified or licensed contractor, plumber, or gasfitter
qualified or licensed by the state.
Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions
carefully.
If you cannot reach your gas supplier, call the fire
department.
Do not touch any electrical switch; do not use any
phone in your building.

3
Contents
Dryer Safety 5
Important Safety Instructions 6
Warranty 8
Installation Instructions 9
Installer Responsibilities, Location Requirements 10
Dimensions 12
Exhausting 13
Maximum Length of Exhaust Duct 15
Alternative Exhaust Directions 17
Exhaust Venting 19
Installation 20
Grounding Instructions 21
Electrical Requirements 22
Gas Requirements 25
Level Machine, Final Installation Check List 28
Features 29
Operating Instructions 30
Reversing the Door 32
Quick Start / Using Your Dryer 33
Care Labels 38
Drying Special Items 39
Other Features 41
Cleaning 42
Trouble Shooting 44
Limited Warranty 46
US
CA

4
Thank you for buying a Fisher & Paykel dryer.
We hope you enjoy using the dryer as much as we have enjoyed designing it. We’ve gone to a lot
of effort to ensure it treats your clothes with the utmost care, drying them gently so they will look
better for longer. We know you’ll enjoy the benefits of its easy loading drum.
Please take the time to read this User Guide carefully. It will help you operate and maintain your
new dryer.
Your safety, and the safety of others is very important. Located
on your dryer and throughout this guide are safety messages and
instructions; it is important that you understand and follow them.

5
Dryer Safety
WARNING
Fire Hazard
To reduce the risk of re, electric shock, or injury to persons, read
the IMPORTANT SAFETY INSTRUCTIONS before operating this
appliance.
Failure to follow to do so can result in death or electric shock.
Symbols
Symbols will be used in this Guide to highlight when extra care is required. Abide by these at all
times to ensure you and your family are not harmed while operating your dryer.
It is important to always act with caution and use common sense when operating your dryer. Use
only as per instructed by the User Guide.
This is the safety alert symbol. This symbol alerts you to hazards that can kill
or hurt you and others.
The safety alert symbol and the word DANGER or WARNING will precede all
safety messages. These words mean:
You can be killed or seriously injured if you don’t
immediately follow instructions.
You can be killed or seriously injured if you don’t follow
instructions.
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and
tell you what can happen if the instructions are not followed.
US
CA
WARNING
DANGER

6
Important Safety Instructions
WARNING
Electric Shock Hazard
Follow the safety precautions outlined in this User Guide.
Failure to do so can result in death or electric shock.
Safety Precautions
Read all instructions carefully before using this dryer.
Use this dryer only for its intended purpose as described in this User Guide.
To minimize the possibility of electric shock, unplug this dryer from the power supply or
disconnect the dryer at the household distribution panel (by removing the fuse or switching off
the circuit breaker) before attempting any user maintenance or cleaning.
Installation must conform with local codes, or in absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1/NFPA 54 or the Canadian Natural Gas and Propane Installation Code, CSA B149.1.
Installations and service must be performed by a qualified or licensed contractor, plumber or
gasfitter qualified or licensed by the state, province, or region where this appliance is being installed.
This dryer must be properly installed and located in accordance with the Installation Instructions
before it is used.
This dryer, when installed, must be electrically grounded in accordance with local codes, or in the
absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical
Code, CSA C22.1.
Do not install or store the dryer where it will be exposed to water or exposed to the weather.
Connect to a properly protected, rated and sized power supply circuit to avoid electrical overload.
Do not repair or replace any part of the appliance or attempt any servicing, unless specifically
recommended in the published user repair instructions that you understand and have the skills to
carry out.
When disconnecting the dryer, pull by the plug rather than the cord or junction of the cord plug,
to avoid damage to the cord or junction of the cord plug.
Make sure the cord is located so that it will not be stepped on, tripped over or otherwise subject
to stress or damage.
Do not tamper with the controls.
Note: Turning the Cycle Selector knob to anOFF position does NOT disconnect the appliance
from the power supply.
Do not operate this dryer if it is damaged, malfunctioning, partially disassembled or has missing
or broken parts, including a damaged cord or plug.
This dryer must be directly connected to an approved fixed electrical outlet. It cannot be
plugged into an extension cord or an adaptor plug.

7
Important Safety Instructions
WARNING
Fire Hazard
Only dry fabrics that have been washed with water.
Do not use heat to dry articles containing foam rubber or similarly
textured rubber-like materials. Dry on the Flu cycle.
A clothes dryer produces combustible lint and must be exhausted
outdoors. Take care to prevent the accumulation of lint around
the exhaust opening and in the surrounding area.
Failure to follow these instructions can result in death or personal
injury.
To Reduce the Risk of Fire in a Tumble Dryer the Following Should
be Observed:
Do not place items in a tumble dryer that have previously been cleaned in, washed in, soaked
in, or spot cleaned with flammable liquids or solids. They are a fire or explosion hazard. Highly
flammable substances commonly used in domestic environments include acetone, denatured
alcohol, gasoline, kerosene, some brands of spot removers and dry cleaning solvents, turpentine,
waxes, wax removers, vegetable oil, fish oil, massage oil, and cooking oil.
Do not leave hot oil-affected items in a pile or stack. This can prevent heat from escaping and can
create a fire hazard. Oil-affected items can ignite spontaneously, especially when exposed to heat
sources such as a tumble dryer. The items become warm causing an oxidation reaction in the oil.
This oxidation creates heat. If the heat cannot escape the items can become hot enough to catch
fire.
Do not use heat to dry items containing rubber, foam rubber, plastic or similar materials, (such as
padded bras, bath mats, rugs, bibs, baby pants, plastic bags, pillows etc), as these materials might
melt or burn. Some rubber materials when heated can under certain circumstances produce fire
by spontaneous combustion. Dry only on the FLUFF cycle.
Unless specifically recommended by their manufacturer, do not use fabric softeners or similar
products in a tumble dryer.
Do not store or use gasoline or other flammable gases and liquids near this or any other
appliance.
Keep the area around the exhaust opening and adjacent surrounding areas free from the
accumulation of combustible materials such as lint, paper, rags, chemicals etc.
Do not store any items that may burn or melt (such as paper materials, plastics or plastic
containers, etc) next to the dryer.
Clean the lint filter each time you use the dryer, before or after each load.
US
CA

8
Important Safety Instructions
The dryer must be exhausted to the outside. Carefully follow the venting details in the Installation
Instructions.
Keep the floor around your dryer clean and dry to reduce the possibility of slipping.
If your dryer is running and you want to unload or add clothes, open the dryer door.
Do not reach into the appliance if the drum is moving.
Close supervision is necessary if this dryer is used near children. Do not allow children to play
inside, around or with this dryer or any other appliance.
Never climb on, climb into, or stand on the dryer top or drum.
Undergarments that contain metal reinforcements should not be placed directly in the dryer.
Damage to the dryer can result if the metal reinforcements come loose during drying. If you wish
to dry these items use a drying rack (available as an optional accessory refer to page 9).
The interior of the appliance and exhaust duct should be cleaned periodically by qualified service
personnel.
When discarding or storing old clothes dryer, remove the door.
Warranty
Your dryer has been made to the highest standards. Years of development and rigorous testing
ensure that you have bought a world-class product, in the unlikely event that a problem should
occur, refer to the Limited Warranty section at the back of this Guide (refer to page 46).
If you have a problem with your dryer refer to our troubleshooting section. If your problem is not
referenced, please always contact your Fisher & Paykel Authorized Service Agent or our Customer
Care Center (Toll Free 1 888 9 FNP USA (1 888 9 367 872)) rather than attempting to fix it yourself.

9
Installation Instructions
Clothes dryer installation must be performed by a qualified installer.
Install the clothes dryer according to the manufacturer’s instructions and local codes.
Do not install a clothes dryer with flexible plastic venting materials. If flexible metal (foil-type)
duct is installed, it must be of a specific type identified by the appliance manufacturer as suitable
for use with clothes dryers. Flexible venting materials are known to collapse, be easily crushed,
and trap lint. These conditions will obstruct clothes dryer airflow and increase the risk of fire.
To reduce the risk of sever injury or death, follow all installation instructions.
Save these instructions
Read the Important Safety Instructions on pages 6 – 8 before you start
installing your dryer.
Check to make sure you have all the tools and parts necessary to correctly install this appliance.
Tools Required
/”nut driver or socket wrench
Phillips screwdriver
Flat-blade screwdriver
Adjustable wrench 200 or 250mm (8”or 10”) for gas connections (gas models only)
Pipe joint compound (pipe dope or tape) for gas pipe connections that is resistant to LP Propane,
Butane and Natural Gas (gas dryer only)
Level
Caulking gun and compound (for installing new exhaust vent)
Gloves
Safety glasses
Knife
Duct tape
Accessories
Mobile Home Installation Kit Part No 14-D346-33
Drying Rack Kit Part No WE1M396
Cover Plate to Rear of Cabinet Kit Part No WE1M454
See the rating plate in the door opening to identify the appropriate kit number (Mxx) for
conversion to LP or natural gas.
Parts Needed
Check with local codes and read electrical, gas and venting requirements before purchasing parts.
If you need to purchase a power supply cord kit or power supply cable, they must meet the
requirements on page 23.
US
CA
WARNING - Risk of re

10
To the Installer
The correct installation of the dryer is your responsibility.
Be sure you read the following instructions carefully before you start to install the dryer. These
instructions should be left with the home owner for future reference.
It is Your Responsibility to:
Observe all governing codes and ordinances.
Check code requirements. Some codes limit or do not permit installation of clothes dryers in
garages, closets, mobile homes or sleeping quarters. Contact your local building inspector.
Adhere to these installation instructions.
Allow for spacing requirements with side by side installations (refer page 11).
Make sure you have all items necessary for correct installation.
Properly install the dryer.
Contact a qualified installer as appropriate to ensure that the electrical and gas installation meets
all national and local codes and ordinances. (See page 6).
Location Requirements
WARNING
Explosion Hazard
Keep ammable materials and vapors, such as gasoline, away
from the dryer.
Place dryer at least 460mm (18 inches) above the oor for a
garage installation.
Failure to do so can result in death, explosion, re, or burns.
The dryer must be installed or stored in an area which is not exposed to water or weather.
It is extremely important that the dryer is installed in a well ventilated location. This dryer must
exhaust air outdoors. Do not install the dryer in any room or closet which does not permit the
free flow of replacement air.
Allow sufficient room behind the dryer for the exhaust. The air intake is at the rear of the dryer.
Ensure that there is a sufficient air passage on each side of the dryer for intake air.

11
Location Requirements
Alcove or Closet Installation
When installing a dryer in a closet/alcove it must be
exhausted to the outdoors. No other fuel burning appliance
can be installed in the same closet or alcove.
The total ventilation area must be a minimum of 387cm
2
(60 sq. in.) of open area equally
distributed. If the closet contains both a washer and a dryer, doors must contain a minimum of
774cm
2
(120 sq. in.) of open area equally distributed. The openings must never be obstructed (a
louvered door with the minimum air opening is acceptable). Minimum installation clearances are
required but more clearance is recommended.
The area in which the dryer is located must be
kept clear and free from combustible materials,
gasoline and other flammable vapors and liquids.
A dryer produces combustible lint so the area
around the dryer must be cleaned regularly to
keep it free of lint.
US
CA
min 50mm (2”) min 76mm (3”)
minimum clearance
required
1430mm (56 /”)
25mm (1”) 25mm (1”) 25mm (1”)
WARNING
total ventilation area
774cm2(120 in. sq.)

12
Location Requirements
Bathroom or Bedroom Installation
The Dryer MUST be vented to the outdoors. See EXHAUST information.
Dimensions
Exhaust Outlet Location
Mobile or Manufactured Home Installation
Installation must comply with the current CAN/CSA Z240 MH series Mobile Home Installation
Codes or the Manufactured Home Construction & Safety Standard, title 24, part 32-80 or, when
such standard is not applicable, with American National Standard for Mobile Home, AINSI/NFPA
NO. 501B.
The dryer MUST be vented to the outdoors with the termination securely fastened to the mobile
home structure. (See EXHAUST information).
The vent MUST NOT be terminated beneath a mobile or manufactured home.
The vent duct material MUST BE METAL.
The vent MUST NOT be connected to any other duct, vent, or chimney.
Do not use sheet metal screws or other fastening devices which extend into the interior of the
exhaust vent.
In addition to the above, for gas dryers:
Kit 14-D346-33 MUST be used to attach the dryer securely to the structure.
Provide an opening with a free area of at least 161cm sq. (25 sq. in.) for introduction of outside air
into the dryer room.
Exhaust outlet
298mm (11 /”)
114mm (4 /”)

13
Exhausting
WARNING
Fire Hazard
The dryer must be vented to the outdoors.
Use rigid or thick wall exible metal exhaust duct.
Do not use a plastic exhaust duct.
Do not use a metal foil exhaust duct.
Failure to follow these instructions can result in death or re.
The dryer must be exhausted to the outdoors. This will prevent the build up of lint and moisture
in the room in which it is located and reduce the risk of fire.
This appliance must always be vented to the outdoors.
Only rigid or flexible metal duct shall be used for exhausting.
In Canada and in the United States, only those foil-type flexible ducts, if any, specifically identified
for use with the appliance by the manufacturer and that comply with the Outline for Clothes
Dryer Transition Duct, Subject 2158A, shall be used.
In Canada and in the United States, the required exhaust duct diameter is 102 mm (4”).
Exhaust ducting products can be purchased from your local Appliance store or Hardware store.
Plastic or metal foil flexible duct can kink, sag, be punctured, reduce airflow, extend drying times
and affect dryer operation.
A minimum of 100mm (4”) thick wall flexible metal or rigid galvanized metal duct must be used.
Using ducts larger than 100mm (4”) diameter may result in more lint accumulating.
Using straight rigid metal ducting will minimize lint accumulation. Thick wall flexible metal
ducting may be used but care must be exercised to avoid sharp bends which may squash the
duct and cause blockages. Do not use plastic ducting or thin wall flexible metal ducting.
Use duct tape to secure joints. Do not use screws as they collect lint.
Keep ducting as short and straight as possible. Do not exceed the maximum exhaust duct
lengths stated later in these installation instructions.
Do not exhaust the dryer into a chimney or gas vent, a wall, a ceiling, an attic, a crawl space, or
any concealed space in a building. Do not exhaust the dryer under a house or mobile home or a
porch, or into a window well or other area that will accumulate lint.
The exhaust duct should end with an exhaust hood with a
swing out damper to prevent back drafts and entry of wild
life. Never use exhaust hoods with a magnetic damper. The
hood should have at least 305mm (12 inches) clearance
between the bottom of the hood and the ground or other
obstruction. The hood opening should point down. Never
install a screen over the exhaust outlet.
US
CA
305mm (12”)

14
Exhausting
To reduce condensation, insulate any ducting which passes through unheated areas.
Slope the duct gently downwards to the hood, to drain condensation and reduce lint build up.
Avoid sag or loops in the duct as they may collect and store water and accumulate lint.
Before using an existing exhaust duct system for a dryer ensure that:
No plastic or other potentially combustible duct or flexible metal foil ducting has been used.
The duct is not pierced, kinked or crushed.
The duct does not exceed the maximum recommended length for the new dryer.
The exhaust hood damper opens and closes freely and with sufficient movement.
Static pressure in the exhaust ducting does not exceed 250Pa (1 inch of water column), or is not
less than 0 inches of water column (i.e. negative pressure), when measured with a manometer in
the first 150mm (6”) of the duct, with the dryer running on Fluff (no heat) setting.
The exhaust duct system meets all relevant local, state, province and national codes.
All ducting should be inspected and cleaned at least once a year to remove accumulated lint.
Frequently check that the damper on the exhaust hood moves sufficiently and opens and shuts
freely.
Mobile Home Installations
A Mobile Home Installation Kit is available (see Accessories page 9 and notes page 12).
Determine Vent Duct Length
Different types of vent arrangements are shown below.

15
Exhausting
Choose a route that will provide the straightest and most direct path outdoors. Plan the
installation to use the fewest number of elbows and turns.
When using elbows (rigid duct) or making turns (thick wall flexible metal duct), allow as much
room as possible. With thick wall flexible metal duct bend duct gradually to avoid kinking and
avoid 90˚ turns.
Maximum Length of Exhaust Duct
The maximum length of the exhaust duct system depends upon:
The type of ducts (rigid or thick walled flexible metal).
The number of elbows or bends used.
Refer to the exhaust duct length chart for the maximum duct lengths you can use. Do not use1
duct runs longer than specified in the exhaust duct length charts (refer to next page).
Exhaust duct systems longer than specified will:
Accumulate lint creating a potential fire hazard.
Shorten the life of the dryer.
Reduce performance, resulting in longer drying times and an increased energy usage.
Determine the number of elbows/bends you will need.2
In the following table, find the maximum length of rigid metal duct on the same line as the3
number of elbows/bends to be used (refer to next page).
The total length of flexible metal duct shall not exceed 2.4m (8 ft).4
US
CA
recommended acceptable

16
Maximum Length of Exhaust Duct
Preferred 4” Hoods
When you have a 100mm (4”) Hood
Maximum length of 100mm (4”) diameter metal duct.
Number of 90°
elbows/bends Rigid
0 27.4m 90ft
1 18.3m 60ft
2 13.7m 45ft
3 10.7m 35ft
4 7.6m 25ft
Acceptable 2 /” Hoods
When you have a 60mm (2 /”) Hood
Maximum length of 100mm (4”) diameter metal duct.
Number of 90°
elbows/bends Rigid
0 18.3m 60ft
1 13.7m 45ft
2 10.7m 35ft
3 7.6m 25ft
4 4.6m 15ft
For exhaust systems not covered by the exhaust duct length charts (such as multiple unit hook-
ups, plenums, and power-assist fans), call our Customer Care Center:
TOLL FREE 1 888 9 FNP USA (1 888 9 367 872).

17
Detach and remove the bottom, right or
left side knockout as desired. Remove the
screw inside the dryer exhaust duct and
save. Pull the duct out of the dryer. Protect
sharp edges around the knockout and
exhaust opening with tape.
Cut the duct as shown and keep portion A.
Alternative Exhaust Directions
This dryer can be vented from the rear, right, left, and bottom side of the cabinet and must be
exhausted to the outdoors.
Note:
The gas dryer can not be exhausted directly through the right side of the cabinet.
Dryer Exhaust to Right , Left or Bottom of Cabinet
Tab Location
Through the rear opening, locate the tab in the
middle of the dryer base. Lift the tab to about
45° using a flat blade screwdriver.
Adding New Duct
Reconnect the cut portion (A) of the duct to
the blower housing. Making sure that the
shortened duct is aligned with the tab in the
base. Use the screw saved previously to secure
the duct in place through the tab on the dryer
base.
US
CA
Remove
screw
and save
Remove
desired knockout
(one only)
Bend tab
up 45°
Fixing hole
9”
BA
Fixing
Hole
Right or
left side
exhaust
Portion “A”

18
Alternative Exhaust Directions
Adding Elbow and Duct for Exhaust to Right or Left Side of Cabinet
Adding Elbow for Exhaust through Bottom of Cabinet
Adding Cover Plate to Rear of Cabinet (Sides and Bottom Exhaust)
Insert the elbow through the rear opening and connect it
to the dryer internal duct.
Apply duct tape on the joint between the dryer internal
duct and elbow, as shown above.
CAUTION!
Internal duct joints must be secured with tape,
otherwise they may separate and cause a safety
hazard.
Connect standard metal elbows and ducts to complete
the exhaust system. Cover back opening with a plate (kit
WE1M454) available from your local service provider. Place
dryer in final location.
Preassemble 100mm (4”) elbow with 100mm
(4”) duct. Wrap duct tape around joint.
Insert duct assembly, elbow first, through the
side opening and connect the elbow to the
dryer internal duct.
CAUTION!
Be sure not to pull or damage the electrical
wires inside the dryer when inserting the duct.
Apply duct tape as shown on the joint between
the dryer internal duct and the elbow.
CAUTION!
Internal duct joints must be secured with tape,
otherwise they may separate and cause a safety
hazard.
Plate (kit WE1M454)
Duct tape
Exhaust can
be added to
left or right side
Duct tape

19
Exhaust Venting
WARNING
Fire Hazard
Use metal exhaust duct.
Do not use a plastic exhaust duct.
Do not use thin metal foil exhaust duct.
Failure to do so can result in death or re.
Read the exhaust section (pages 13 – 18) before installing the exhaust system to determine the1
maximum allowable exhaust duct length.
Do not use sheet metal screws when assembling ducting. Always use suitable duct tape. Never
use plastic or thin metal foil flexible exhaust material.
The exhaust outlet is located close to the center of the rear of the dryer. Make sure you join the2
exhaust duct to the dryer with duct tape only. This will prevent lint and dust from escaping from
the dryer and exhaust system.
The exhaust vent can be routed up, down, left, right or straight out the back of the dryer. Refer to3
diagram.
US
CA
Exhaust outlet
298mm (11 /”)
114mm (4 /”)

20
Installation
Parts and literature are packaged inside the dryer drum.
WARNING
Excess Weight Hazard
Use two or more people to move and install the dryer.
Failure to do so can result in back or other injury.
Only remove the packaging at the customer’s premises.
This will ensure the appliance arrives in pristine condition and reduces the risk of damage when
transporting to the customer’s home.
Unpacking
Make sure dryer is in a suitable location for installation.
Consider installing the dryer before the washing machine in a side by side installation, this will
allow better access to electrical and exhaust connections.
Foam Removal from Dryer Legs
Tilt the dryer sideways and remove the foam shipping pads by pulling at the sides and breaking
them away from the dryer legs. Be sure to remove all of the foam pieces around the legs.
