Installing Trim Kit
When installing the Microwave and Trim Kit in combination with a Wall Oven or Warming Drawer, please follow the
recommendations in the Microwave Installation/ Use & Care Manual.
1. Cut opening in the cabinet face per the following
dimensions:
Height: 17” + 1/16”, –0
Width: 24-3/4” + 1/16”, –0
NOTE: Refer to diagram at the
bottom of the page. The
minimum cabinet depth is 20”.
When installing the Microwave
and Trim Kit in combination
with a Wall Oven or Warming
Drawer, please follow the
recommendations in the
Microwave Installation/ Use &
Care Manual.
2. Add adequate platform base support in the bottom
of the cabinet for trim kit base to rest on.
3. Mark a centerline on the front edge of the cabinet
bottom (Fig. 01).
4. Place trim kit base and align centerline mark to the
triangular notch on the front edge of the base (Fig.
02).
5. Drill 1/8” pilot holes in the cabinet using the base
as a template and install a screw through the base
into the cabinet bottom to prevent the base from
shifting (Fig. 03).
6. Insert Microwave into opening on top of the base.
The Microwave feet should sit in the recesses on
the base for correct alignment. The Microwave
should be plugged in at this point.
7. Place the right and left mounting bracket supports
by resting the bottom edges of the supports on the
bottom of the cutout (Fig 04). The long flange on
Fig. 05
Fig. 06
https://producthelp.fisherpaykel.com/us/Cook/Microwave_Ovens/MOTTK-FP/Installation_Guide_MOTTK-FP/02_installing_tri…
Updated: Wed, 25 Jan 2023 18:12:28 GMT
Powered by
1

the side supports should clear the side of the
cutout by approximately 1/16” (Fig. 05). Install top
and bottom screws into the cabinet face by first
drilling 1/8” pilot holes (see inserts 3 and 4).
8. Install trim kit face by inserting top pins of trim into
corresponding sockets on the top corners of clip
support plates (see insert 1).
9. Finish the assembly by inserting the bottom pins
into the corresponding sockets on front edge of the
base (see insert 3). Check for proper door opening
clearances.
Fig. 07
Fig. 09
https://producthelp.fisherpaykel.com/us/Cook/Microwave_Ovens/MOTTK-FP/Installation_Guide_MOTTK-FP/02_installing_tri…
Updated: Wed, 25 Jan 2023 18:12:28 GMT
Powered by
2

Fig. 08
When installed, the trim assembly is positioned symmetrically over the cut-out
