Fisher & Paykel WM1490F1 User manual

Drain Hose
Drain Hose Placement in a Stand Pipe
or Tub
1. To guide the drain hose over the tub or standpipe
the hose guide must be fitted to the drain hose.
The height of the standpipe or tub should be
between 800 – 1200mm.
2. Secure the hose guide so it cannot become
dislodged from the standpipe or tub.
• If the drain hose is placed
on the ground or if the
standpipe or tub is less
than 800mm high, the
washing machine will
continuously drain while
being filled (siphon).
• Regularly check that your
standpipe or tub is free
from lint or other
obstructions, which may
affect how your machine
works or may cause
flooding.
Fitting the drain hose guide
https://producthelp.fisherpaykel.com/eu/Wash/Front_Loaders/FabricSmart/WM1490F1/Installation_Guide_WM1490F1/06_Dr…
Updated: Thu, 11 Nov 2021 20:35:09 GMT
Powered by
1

Attaching Drain Hose to Spigot
1. Guide drain hose through hose guide
2. Secure hose guide to back wall of cupboard
using a screw. The height of the drain hose
should be between 500 – 800mm from ground
level.
3. Attach drain hose to spigot and secure using a
hose clamp ensuring the blanking insert is
cleared from spigot.
4. Check for leaks.
• The drain hose should be checked from time to
time and replaced if any damage (eg wear, cuts,
bulges, kinks, leaks, etc) is found. Do not bend the
drain hose sharply, as this may cause it to split.
• In multi-storey apartments or any upper floor, the
machine should be installed on a floor equipped
with a drain.
• Draining must comply with local by-laws. Attaching drain hose to spigot
