2506 Series Multi-TrolRReceiver/Controllers
(Type 2506, 2516, 2516F)
Contents
Introduction 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Scope of Manual 2. . . . . . . . . . . . . . . . . . . . . . . . . .
Description 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Educational Services 4. . . . . . . . . . . . . . . . . . . . . .
Installation 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Mounting the Controller 5. . . . . . . . . . . . . . . . . . . .
Actuator Yoke Mounting 5. . . . . . . . . . . . . . . . . .
Wall Mounting 5. . . . . . . . . . . . . . . . . . . . . . . . . . .
Actuator Diaphragm Case Mounting 6. . . . . . . .
Pipestand Mounting 7. . . . . . . . . . . . . . . . . . . . . .
2500 Series Controller/Transmitter
and 2506 Series Receiver/Controller
Mounting 7. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connections 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supply Connection 8. . . . . . . . . . . . . . . . . . . . . . .
Output Connections 9. . . . . . . . . . . . . . . . . . . . . .
Instrument Connection 10. . . . . . . . . . . . . . . . . .
Vents 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Remote Set Point Connection 11. . . . . . . . . . . .
Startup 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adjustments 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Set Point Adjustment 12. . . . . . . . . . . . . . . . . . . . .
Remote Set Point Adjustment 12. . . . . . . . . . . . . .
Proportional Band Adjustment 12. . . . . . . . . . . . .
Reset Adjustment
(Type 2516 Receiver/Controller Only) 13. . . .
Anti-Reset Windup Valve Adjustment
(Type 2516F Receiver/Controller Only) 13. . .
Calibration 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Principle of Operation 14. . . . . . . . . . . . . . . . . . . . . .
Type 2506 Receiver/Controllers 15. . . . . . . . . . .
Types 2516, 2516F Receiver/Controllers 15. . . .
Maintenance 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing Controller Action 16. . . . . . . . . . . . . . . .
Troubleshooting 17. . . . . . . . . . . . . . . . . . . . . . . . .
Testing Relay Deadband 17. . . . . . . . . . . . . . . . . .
Replacing Receiver/Controller Parts 17. . . . . . . .
Bellows Replacement 17. . . . . . . . . . . . . . . . . . .
Changing the Relay 18. . . . . . . . . . . . . . . . . . . . .
Changing Proportional or Reset Valve 19. . . . .
Parts Ordering 19. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts Kits 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
W4687 / IL
Figure 1. Type 2506 Multi-TrolRReceiver-Controller
W4688 / IL
Figure 2. Type 2516 Multi-TrolRReceiver-Controller
Instruction Manual
Form 1041
November 2005 2506 Series Receiver/Controllers

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
2
Contents (Continued)
Parts List 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Receiver/Controller Common Parts 19. . . . . . . . .
Anti-Reset Windup Valve for
Type 2516F Only 22. . . . . . . . . . . . . . . . . . . . . .
Type 2516F Reset and Anti-Reset Windup
Valve Assembly 22. . . . . . . . . . . . . . . . . . . . . . .
Mounting Parts 23. . . . . . . . . . . . . . . . . . . . . . . . . .
Yoke Mounting 23. . . . . . . . . . . . . . . . . . . . . . . . .
Wall Mounting 23. . . . . . . . . . . . . . . . . . . . . . . . . .
Case Mounting 23. . . . . . . . . . . . . . . . . . . . . . . . .
Pipestand Mounting 24. . . . . . . . . . . . . . . . . . . . .
2500 Series Controller/Transmitter
and 2506 Series Receiver/Controller
Mounting 24. . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction
Scope of Manual
This manual provides installation, startup,
calibration, maintenance, and parts ordering
information for 2506 Series Multi-TrolR
receiver/controllers. Figure 1 shows a Type 2506
receiver/controller. Figure 2 shows a Type 2516
receiver/controller.
A 2506 Series receiver/controller is often used with a
2502 Series Level-Trol®controller/transmitter. For
information about 2502 Series controller/transmitters
or associated equipment such as pressure
regulators, sensors, accessories, or related control
devices, see the appropriate instruction manual, or
contact your Fisher®sales office.
No person may install, operate, or maintain a 2506
Series Multi-Trol receiver/controller without first D
being fully trained and qualified in valve, actuator
and accessory installation, operation and
maintenance and Dcarefully reading and
understanding the contents of the manual. If you
have any questions about these instructions, contact
your Fisher sales office.
Description
See table 2.
The receiver/controllers described in this manual
provide:
DProportional-only control: Type 2506 (with snap
action: Type 2506S)
DProportional-plus-reset control (Type 2516)
DProportional-plus-reset-plus-anti-reset windup
control (Type 2516F)
See figures 9, 10, and 11.
The receiver/controller takes a pneumatic input
signal from either a 2500 Series
controller/transmitter or a control device. The unit
then provides a pneumatic output signal that
operates a final control element.
When a Type 2506 receiver/controller is used to
provide proportional-only control, the pneumatic
output signal from the unit can also be piped to a
remote receiving indicator or recording device. This
provides a visual indication of receiver/controller
action.
The INCREASE OUTPUT PRESSURE adjustment is
used to increase or decrease the output pressure in
relationship to the input pressure. Changing this
adjustment changes the position of the nozzle in
relationship to the beam/flapper assembly. In turn,
the amount of supply pressure released by the relay
is changed and the pneumatic output signal that
operates a final control element is affected.
If a remote set point signal is used, it is piped to the
remote set point connection and into remote set
point bellows. The remote signal expands the
bellows and moves the beam/flapper assembly. This
affects the controller output in the same way a
change in the INCREASE OUTPUT PRESSURE
adjustment affects the output.
Specifications
Specifications are shown in table 1.

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
3
Table 1. Specifications
Available Configurations
For additional information, refer to table 2
Type 2506: A receiver/controller(1) that is set for
either proportional or snap action (S) control or for
either direct or reverse (R) action
Type 2516: A Type 2506 that also provides
proportional-plus-reset control
Type 2516F: A Type 2516 that also provides
anti-reset windup control
Input Signal Range(2)
From a transmitter or control device, a signal of
0.2 to 1.0 bar (3 to 15 psig) or 0.4 to 2.0 bar (6 to
30 psig) is required depending on
receiver/controller range
Refer to the receiver/controller nameplate for
specific range.
Output Signal Range(2,3)
See table 3
Output Action
Direct Action: An increasing fluid, interface level,
or density increases output pressure or,
Reverse Action: An increasing fluid, interface
level, or density decreases output pressure
Remote Set Point Signal Range
From a control device, provide a remote set point
signal that is 0.2 to 1.0 bar (3 to 15 psig) or 0.4 to
2.0 bar (6 to 30 psig) that matches the
receiver/controller input signal range
Supply Pressure(2,4)
Normal Operating Pressure: See table 3
Maximum Pressure to Prevent Internal Part
Rupture: 3.4 bar (50 psig)
Steady State Air Consumption(3)
See table 3
Proportional Band(2) Reset(2), and Anti-Reset
Windup
See table 2 and the Changing Controller Action
procedure
Performance
Hysteresis: 0.6 percent of output pressure
change at 100 percent of proportional band for
Type 2506 proportional receiver/controllers only
Standard Supply and Output Pressure Gauge
Indications
See table 3
Standard Tubing Connections
All connections are 1/4-inch NPT female
Hazardous Area Classification
2506 Series receiver/controllers comply with the
requirements of ATEX Group II Category 2 Gas
and Dust
Operative Ambient Temperature Limits(4)
Standard: −40 to 71°C (−40 to 160°F)
High Temperature: −18 to 104°C (0 to 220°F)
Approximate Weight
4.54 kg (10 Pounds)
Declaration of SEP
Fisher Controls International LLC declares this
product to be in compliance with Article 3
paragraph 3 of the Pressure Equipment Directive
(PED) 97 / 23 / EC. It was designed and
manufactured in accordance with Sound
Engineering Practice (SEP) and cannot bear the
CE marking related to PED compliance.
However, the product may bear the CE marking
to indicate compliance with other applicable EC
Directives.
1. Receiver/controllers are field adjustable between direct or reverse action. If the receiver/controller is set for reverse action at the factory, an R suffix will appear in the type number.
Receiver/controllers are field-adjustable between proportional and snap action. If the receiver/controller is set for snap action at the factory, an S suffix appears in the type number.
2. These terms are defined in ISA Standard S51.1.
3. Normal m3/hr at 0°C, 1.01325 bar absolute (Scfh at 60°F, 14.7 psia).
4. The pressure/temperature limits in this document, and any applicable standard or code limitation should not be exceeded.

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
4
Table 2. Additional Information
Control Mode(1) Action (Full Output Change) Output Signal
Proportional control
(Type 2506) Proportional Band: Adjustable from 0 to 100% of transmitter signal. 0.2 to 1.0 bar (3 to 15 psig) or 0.4 to 2.0 bar (6 to 30 psig)
Snap action control
(Type 2506S)
Snap Action: Control output is at 0 or 100% of input supply pressure. Switching
depends on position of sensor and is adjustable.
0 to 1.4 bar (0 to 20 psig) or
0 to 2.4 bar (0 to 35 psig)
Proportional-plus-reset
control (Type 2516)
Proportional Band: Adjustable from 0 to 200% of transmitter signal. Recommended
setting is from 20 to 200%.
Reset: Adjustable form 0.01 to 74 minute per repeat with standard reset valve setting.
0.2 to 1.0 bar (3 to 15 psig) or
0.4 to 2.0 bar (6 to 30 psig)
Proportional-plus-reset
with differential relief
control (Type 2516F)
Proportional Band: Adjustable from 0 to 200% of transmitter signal. Recommended
setting is from 20 to 200%.
Reset: Adjustable from 0.01 to 74 minute per repeat with standard reset valve setting.
Differential Relief: Provides relief when output pressure falls or when output pressure
rises depending on valve adjustment.
1. Proportional control is continuously active between 0 and 100 percent of the transmitter signal span. Differential gap provides snap action between 0 and 100 percent of the
transmitter signal. Do not use reset controllers in snap action.
Table 3. Supply Pressure Data
OUTPUT SIGNAL
RANGE
STANDARD SUPPLY
AND OUTPUT
PRESSURE GAUGE
INDICATIONS(1)
NORMAL
OPERATING
SUPPLY
PRESSURE(2)
AIR CONSUMPTION AT
NORMAL OPERATING
SUPPLY PRESSURE
Bar Psig Minimum(3) Maximum(4)
0.2 to 1.0 bar (3 to 15 psig) 0 to 30 psig 1.4 20 4.2 scfh(5) 27 scfh(5)
0.4 to 2.0 bar (6 to 30 psig) 0 to 60 psig 2.4 35 7 scfh(5) 42 scfh(5)
1. Consult your Fisher sales office for gauges calibrated in other units of measurement.
2. Control and stability may be impaired if this pressure is exceeded.
3. At zero or maximum proportional band or span setting.
4. At setting in middle of proportional band or span range.
5. If air consumption is desired in normal m3/hr at 0°C and 1.01325 bar, multiply scfh by 0.0268.
Educational Services
For information on available courses for Type 2506
Series receiver/controllers as well as a variety of
other products, contact:
Emerson Process Management
Educational Services, Registration
P.O. Box 190; 301 S. 1st Ave.
Marshalltown, IA 50158−2823
Phone: 800−338−8158 or
Phone: 641−754−3771
FAX: 641−754−3431
e-mail: [email protected]
Note
Neither EmersonR, Emerson Process
Management, Fisher, nor any of their
affiliated entities assumes
responsibility for the selection, use,
and maintenance of any product.
Responsibility for the selection, use,
and maintenance of any product
remains with the purchaser and
end-user.
Installation
WARNING
To avoid personal injury or property
damage resulting from the sudden
release of pressure:
DAlways wear protective clothing,
gloves, and eyewear when performing
any installation procedures to avoid
personal injury.
DCheck with your process or safety
engineer for any additional measures
that must be taken to protect against
process media.
DIf installing into an existing
application, also refer to the WARNING
at the beginning of the Maintenance
section in this instruction manual.

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
5
AD4913-H
A3844-1 / IL
235
(9.25)
232
(9.12)
171
(6.76)
44
(1.75)
70
(2.75)
70
(2.75)
57
(2.25)
41
(1.62)
mm
(INCH)
BELLOWS VENT
OR REMOTE
SET POINT
CONNECTION
OUTPUT CONNECTION
(MARKED DIAPHRAGM)
SUPPLY CONNECTION
INSTRUMENT
CONNECTION
MOUNTING
HOLES (2 PLACES)
5/16-18 UNC
TAPPED
VENT FOR
VENT LINE
(OPTIONAL)
CASE
VENT
REAR VIEW
BOTTOM VIEW
FRONT VIEW
Figure 3. Dimensions and Location of Connections
Mounting the Controller
Note
If a separate receiver/controller unit
has been ordered for field installation
with an existing valve/actuator
assembly or 2500 Series
controller/transmitter, additional
mounting parts may be required. Find
the mounting description in the parts
list at the end of this manual. Then,
order any additional parts.
Figures 3 through 8 show dimensions and
connection locations used when you install a
receiver/controller.
Actuator Yoke Mounting
See figure 4 for a typical mounting plate. Key
numbers are shown in figure 5.
1. Locate the mounting plate (key 164, figure 5).
Select appropriate mounting holes in the mounting
plate for the receiver/controller. Then, align the
mounting holes in the mounting plate with the
mounting holes in the receiver/controller case.
2. Place the two cap screws (key 48) through the
mounting plate from “back to front”. Engage the cap
screw threads in the mounting holes in the
receiver/controller case and tighten the cap screws
to attach the mounting plate to the back of the
receiver/controller.
3. Place cap screws (key 39) through the yoke
mounting holes in the mounting plate from “front to
back”. Place a spacer (key 174) over the threads of
the cap screws extending from the mounting plate to
properly separate the mounting plate and the lower
yoke boss of the actuator (figure 5).
4. Attach the mounting plate with receiver/controller
to the lower yoke boss of the actuator yoke. Be sure
the spacers support the mounting plate. Be sure the
receiver/controller is parallel with the actuator yoke
and then tighten the cap screws into the yoke boss.
5. If supply pressure is piped through a
filter/regulator, bolt the regulator directly to the upper
yoke boss using the cap screws (key 85). Provide
appropriate piping from the filter/regulator output
connection to the receiver/controller supply
connection.
Wall Mounting
See figure 6 for key number locations. The mounting
plate is shown in figure 5.

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
6
IC2218-E / IL
13
(0.50)
83
(3.25)
57
(2.25)
13
(0.50)
14
(0.58)
102
(4.00)
38
(1.50)
14
(0.56)
17
(0.69)
17
(0.69
)
35
(1.38)
mm
(INCH)
8 HOLES
11/16 DIAMETERS
(17)
Figure 4. Mounting Plate for Yoke Mounting, Wall Mounting
38b39604-A / IL
AD44913-H
A3848-1 / IL
REGULATOR OUTPUT
(SUPPLY CONNECTION
ON OPPOSITE SIDE)
MOUNTING PLATE
(KEY 164)
CAP HEAD SCREW
(KEY 48)
CAP SCREW AND
LOCKWASHER
(KEYS 39 AND 83)
SPACER (KEY 174)
Figure 5. Yoke Mounting
AD4913-H
A3847-1 / IL
194
(7.62)
mm
(INCH)
MOUNTING
PLATE
(KEY 164)
SPACER
(KEY 78)
CAP SCREW AND
LOCKWASHER
(KEYS 39 AND 83)
SPACER (KEY 174)
SIDE VIEW
Figure 6. Wall Mounting
AD4913-H
A3846-1 / IL
mm
(INCH)
121
(4.75)
86
(3.38)
MOUNTING
BRACKET
(KEY 164)
CAP HEAD
SCREW
(KEY 48)
CAP HEAD SCREW
(KEY 39)
Figure 7. Case Mounting
1. Install lock washers (key 83) on the cap screws
(key 39). Then, insert the cap screws through the
mounting plate from “back to front”. Place a spacer
(key 174) over the threads of each cap screw as it
extends from the mounting plate. The spacers are
required to properly separate the receiver/controller
from the mounting plate. Then, thread the cap
screws into the mounting holes in the
receiver/controller case and tighten.
2. Install lock washers (key 83) on the cap screws
(key 48). Then, insert the cap screws through the
mounting plate from ‘‘front to back’’. Place a spacer
(key 174) over the threads of each cap screw as it
extends from the mounting plate. The spacers are
required to properly separate the mounting plate
from the wall mounting position. Then, thread the
cap screws into holes prepared at the wall mounting
position and tighten.
3. Provide appropriate piping from the filter/regulator
output connection to the receiver/controller supply
connection.
Actuator Diaphragm Case Mounting
To mount a receiver/controller to the diaphragm
casing of a standard Fisher diaphragm actuator,
remove two hex nuts and hex head cap screws
securing the upper and lower diaphragm casings. If
necessary, refer to the appropriate actuator
instruction manual to locate the hex head cap
screws and nuts.
See figure 7 for key number locations.
1. Locate the receiver/controller mounting holes in
mounting bracket (key 164, figure 7).
2. Place the two cap screws (key 48) through the
receiver/controller mounting plate holes from ‘‘back

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
7
to front’’. Engage the threads in the
receiver/controller mounting holes and tighten the
cap screws to attach the mounting plate to the back
of the receiver/controller.
3. Locate the receiver/controller mounting position
on the horizontal edge of the diaphragm case. A
typical Fisher diaphragm actuator features upper
and lower diaphragm casings held together with hex
head cap screws and hex nuts. Remove the hex
nuts from two hex head cap screws joining the upper
and lower casing. Then, remove the cap screws.
4. Place the mounting bracket over the empty
casing holes. Insert the casing cap screws through
the mounting bracket, upper casing, and lower
casing. Add the nuts and tighten to secure the
mounting bracket with receiver/controller to the
casing.
5. If supply pressure is piped through a
filter/regulator, the regulator may be attached in one
of two locations:
DAttach the regulator directly to the upper yoke
boss using the cap screws (key 85) for yoke
mounting.
DAttach the regulator to the casing using a
mounting bracket (key 177). The mounting bracket
for the regulator is the same as the mounting bracket
for the receiver/controller. Follow steps 1 through 4
to mount the regulator.
6. Connect the filter/regulator output connection to
the receiver/controller supply connection.
Pipestand Mounting
See figure 8 for key number locations.
1. Locate the mounting plate (key 164). Select
appropriate mounting holes in the mounting plate for
the receiver/controller. Then, align the mounting
holes in the mounting plate with the mounting holes
in the receiver/controller case.
2. Place the two cap screws (key 48) through the
mounting plate from ‘‘back to front’’. Place a spacer
(key 174) over the threads of each cap screw as it
extends from the mounting plate. The spacers are
required to properly separate the receiver/controller
from the mounting plate.
AD4913-H
A3845-1 / IL
mm
(INCH)
157
(61.9)
51 jPIPE
(2.00)
MOUNTING PLATE
(KEY 164)
SPACE SPOOL
(KEY 78)
CAP SCREW
AND
LOCKWASHER
(KEYS 39
AND 83)
PIPE
CLAMP
(KEY 175)
1
2
2
NOTES:
PIPE CLAMP INCLUDES NUTS
FILTER/REGULATOR MOUNTING AREA
1
Figure 8. Pipestand Mounting
3. Engage the cap screw threads in the mounting
holes in the receiver/controller case and tighten the
cap screws to attach the mounting plate to the back
of the receiver/controller.
4. Attach the mounting plate with receiver/controller
to a 2-inch (nominal) pipe with pipe clamps (key
175). Each pipe clamp includes two nuts. Tighten
clamp nuts.
5. If supply pressure is piped through a
filter/regulator, the regulator may be attached to the
mounting plate using cap screws (key 85), lock
washers (key 84), and hex nuts (key 40).
6. Provide appropriate piping from the filter/regulator
output connection to the receiver/controller supply
connection.
2500 Series Controller/Transmitter and
2506 Series Receiver/Controller
Mounting
If the controller/transmitter and receiver/controller
are ordered simultaneously, the factory will mount
them together before shipment (figure 9). For
examples of typical transmitter/receiver mounting
arrangements, see figures 10 and 11.
If the receiver/controller is ordered separately for use
with a 2500 Series controller/transmitter, it may not
have the required mounting parts. If mounting parts
are required, consult the parts list under the specific
mounting application.
See figure 9 for key number locations.

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
8
AR5748-B
3V7594-B
B2115-1 / IL
TUBING
(KEY 169)
TUBING
(KEY 168)
TRANSMITTER
OUTPUT
OUTPUT
CONNECTION
(MARKED
DIAPHRAGM)
1/4 NPT SUPPLY
(ON REGULATOR)
MOUNTING PLATE (KEY 164)
CAP SCREW AND LOCKWASHER
(KEYS 39 AND 83)
BELLOW VENTS OR
REMOTE SETPOINT CONNECTION
INSTRUMENT INPUT
CONNECTION
SUPPLY CONNECTION
1/4 NPT REMOTE
LEVEL INDICATOR
REAR VIEW
406
(16.00)
60
(2.37)
235
(9.25)
FRONT VIEW
mm
(INCH)
Figure 9. 2500 Series Controller-Transmitter and 2506 Series Receiver-Controller Mounting
1. Install lock washers (key 83) on the cap screws
(key 39). Then, insert the cap screws through the
mounting plate from ‘‘back to front’’. Thread the cap
screws into the mounting holes in the
receiver/controller case and tighten.
2. Install lock washers (key 83) on the cap screws
(key 48). Then, insert the cap screws through the
mounting plate from ‘‘back to front’’. Thread the cap
screws into the mounting holes in the
controller/transmitter.
3. If supply pressure is piped through a
filter/regulator, bolt the regulator to the back of the
controller/transmitter.
4. Provide appropriate piping connections between
the units as shown in figures 10 or 11.
Connections
WARNING
The controller is capable of providing
full supply pressure to connected
equipment. To avoid personal injury or
property damage caused by parts
bursting from system overpressure,
make sure the supply pressure never
exceeds the maximum safe working
pressure of any connected equipment.
To complete the installation of a receiver/controller,
make connections with tubing and fittings between
the receiver/controller and the actuator. The fittings,
tubing, and mounting parts required depend on the
type number and optional equipment such as filter,
regulator, and bypass valve.
All pressure connections on the 2506 Series
receiver/controllers are 1/4-inch NPT female fittings
(figures 3 and 9). Use 1/4-inch piping or 3/8-inch
tubing to these connections.
If remote venting is required, see the Vents
subsection below.
Supply Connection
WARNING
Severe personal injury or property
damage may occur if the instrument
air supply is not clean, dry and oil free
or non-corrosive gas. While use and
regular maintenance of a filter that

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
9
DF5357-A
A3701-2 / IL
2500 SERIES
CONTROLLER/
TRANSMITTER
SUPPLY
2506 SERIES
RECEIVER/
CONTROLLER
FROM DIAPHRAGM
CONNECTION TO
ACTUATOR
DIAPHRAGM
ACTUATOR
CONTROL
VALVE
1
1
1
NOTE:
SEE FIGURE 9 FOR REAR VIEW
1
Figure 10. Typical Transmitter with Receiver and Control Valve Installation Assembly
remove particles larger than 40
microns in diameter will suffice in
most applications, check with a Fisher
Field office and Industry Instrument air
quality standards for use with
corrosive gas or if you are unsure
about the proper amount or method of
air filtration or filter maintenance.
If the existing supply is corrosive,
make sure the tubing and instrument
components that contact the corrosive
medium are of suitable
corrosion-resistant materials, or
change to a noncorrosive supply
medium.
WARNING
Personal injury or property damage
may occur from bursting parts due to
overpressuring any system
component. To avoid injury or
damage, provide pressure-relieving or
pressure-limiting devices if supply or
input pressure could exceed the
maximum allowable pressures listed in
table 3.
It is recommended that supply pressure pass
through a filter/regulator combination such as a
67CFR. See table 3 for recommended supply
pressures to the receiver/controller.
Typical supply pressure for the 67CFR is clean dry
air or a gas at a pressure of 2.5 bar (35 psig) to a
maximum of 17 bar (250 psig). For specific regulator
limits, see the appropriate regulator instruction
manual.
Output Connections
See figure 3.
Use 3/8-inch tubing between the actuator and the
receiver/controller. Connect the output (diaphragm)
connection to the appropriate actuator connection.

2506 Series Receiver/Controllers
Instruction Manual
Form 1041
November 2005
10
DF5379-A
A3702-2 / IL
CONTROLLER/
TRANSMITTER
SUPPLY
3
2500 SERIES
CONTROLLER/
TRANSMITTER
INDICATOR
SUPPLY
PANEL
LOADER
REMOTE
SET POINT
ADJUSTMENT
CENTRALIZED
CONTROL
PANEL
CONTROLLER OUTPUT
PIPING
2506 SERIES REMOTE
RECEIVER/CONTROLLER
DIAPHRAGM
ACTUATOR
CONTROL VALVE
RECEIVER/
CONTROLLER SUPPLY
4
1
4
2
NOTES:
PIPING FROM TRANSMITTER OUTPUT TO PANEL INDICATOR
PIPING FROM TRANSMITTER OUTPUT TO PANEL RECEIVER/CONTROLLER
INSTRUMENT INPUT. SEE FIGURE 3 FOR CONNECTION LOCATION
PIPING FROM PANEL LOADER TO RECEIVER/CONTROLLER REMOTE SET POINT
CONNECTION. SEE FIGURE 3 FOR CONNECTION LOCATION.
SEE FIGURE 3 FOR CONNECTION LOCATION.
2
1
3
4
Figure 11. Typical Transmitter and Receiver Installation with an Indicator and Remote Set Point Connection
Instrument Connection
See figure 3.
Use 3/8-inch tubing to connect the output from the
control device to the INSTRUMENT connection on
the receiver/controller.
Vents
WARNING
If a flammable or hazardous gas is
used as supply pressure medium,
personal injury or property damage
could result from fire or explosion
caused by the accumulated gas. Injury
or property damage could also result
from contact with the flammable or
hazardous gas.
The case and cover assembly does not
form a gas-tight seal and flammable or
hazardous gas could leak from this
unit. Therefore, if the
receiver/controller unit is enclosed,
install a remote vent line to remove
part of the exhaust gas to a properly
ventilated area. However, a remote
vent line cannot be relied upon to
remove all hazardous gas. Vent line
piping should comply with local and
regional codes and should be as short
as possible. Select vent line piping
with adequate inside diameter and
install with few bends to reduce case
pressure buildup.
