Fisher WB-100B Operating instructions

Fisher Engineering
February 1, 2019
Lit. No. 43587, Rev. 02
85102
50 Gordon Drive, Rockland, Maine 04841-2139 • www.fisherplows.com
WB-100B
Walk-Behind Broadcast Spreader
Owner's Manual and Installation Instructions
Original Instructions
This document supersedes all editions with an earlier date.
CAUTION
Read this document before operating or
servicing the spreader.
This document is for FISHER®WB-100B walk-behind broadcast spreaders
with serial numbers beginning with 0000 and higher.

Lit. No. 43577/43587/43597, Rev. 02 February 1, 2019

Lit. No. 43577/43587/43597, Rev. 02 3 February 1, 2019
TABLE OF CONTENTS
PREFACE..................................................................................................................................................................5
Owner's Information Form ..................................................................................................................................5
SAFETY ....................................................................................................................................................................6
LOADING ..................................................................................................................................................................8
ASSEMBLY...............................................................................................................................................................9

Lit. No. 43577/43587/43597, Rev. 02 February 1, 2019

Lit. No. 43587, Rev. 02 February 1, 2019
PREFACE
This manual has been prepared to acquaint you with
the safety information, operation, and maintenance
of your new walk-behind spreader. Please read this
manual carefully and follow all recommendations. This
will help ensure profitable and trouble-free operation
of your spreader. Keep this manual accessible. It is a
handy reference in case minor service is required.
Register your spreader online at www.fisherplows.com
OWNER'S INFORMATION
Owner's Name: _______________________________________________________________________
Date Purchased: ______________________________________________________________________
Outlet Name: ______________________________________________ Phone: ___________________
Outlet Address: _______________________________________________________________________
Spreader Type (Model):________________________________ Weight: ____________________ lb/kg
Spreader Serial Number:________________________________________________________________
When service is necessary, bring your walk-behind
spreader to your distributor. They know your spreader
best and are interested in your complete satisfaction.

Lit. No. 43577/43587/43597, Rev. 02 6 February 1, 2019
SAFETY
SAFETY DEFINITIONS
NOTE: Indicates a situation or action that can lead
to damage to your spreader and vehicle or other
property. Other useful information can also be
described.
CAUTION
Indicates a potentially hazardous situation
that, if not avoided, may result in minor or
moderate injury. It may also be used to alert
against unsafe practices.
WARNING
Indicates a potentially hazardous situation
that, if not avoided, could result in death or
serious personal injury.
LABELS
Please become familiar with the labels on the
spreader.
NOTE: If labels are missing or cannot be read, see
your sales outlet.
Open/Close Label
Serial Number Label
Code Definition
MM 2-Digit Month
YY 2-Digit Year
LL 2-Digit Location Code
#### 4-Digit Sequential Number
PPPPP 5-Digit Assembly PN

Lit. No. 43577/43587/43597, Rev. 02 7 February 1, 2019
SAFETY
SAFETY PRECAUTIONS
Improper installation and operation could cause
personal injury and/or equipment and property
damage. Read and understand labels and this
Owner's Manual before assembling, operating, or
making adjustments.
WARNING
• Always make sure personnel are clear of
areas of danger when using equipment.
• Before working with the spreader, secure all
loose-fitting clothing and unrestrained hair.
• Do not climb into or ride on spreader.
• Never attempt to lift a unit with material in it.
• Always inspect unit for defects and replace any
broken, missing, or worn parts immediately.
• Always check areas to be spread to be sure
no hazardous conditions or substances are
in the area.
CAUTION
• Do not operate a spreader in need of
maintenance.
• Before operating the spreader, reassemble
any parts or hardware removed for cleaning
or adjusting.
• Before operating the spreader, remove
materials such as cleaning rags, brushes,
and hand tools from the spreader.
• Never use wet materials or materials with
foreign debris with this spreader. This
unit is designed to handle dry, clean,
free-flowing material.
CAUTION
DO NOT leave unused material in
hopper. Material can freeze or solidify,
causing unit to not work properly.
Empty and clean after each use.
NOTE: Lubricate grease fittings after each use.
Use a good quality multipurpose grease.
PERSONAL SAFETY
• Wear only snug-fitting clothing while working on
your spreader.
• Do not wear jewelry or a necktie, and secure long
hair.
• Wear safety goggles to protect your eyes from dirt
and dust.
NOISE
Airborne noise emission during use is below 70 dB(A)
for the spreader operator.
VIBRATION
Operating spreader vibration does not exceed 2.5 m/s2
to the hand-arm or 0.5 m/s2to the whole body.

Lit. No. 43577/43587/43597, Rev. 02 8 February 1, 2019
LOADING YOUR SPREADER
Material Weights
Material Density
(lb/ft3)
Rock Salt 80–90
LOADING
SPREADING TIPS
• Use care when operating spreader near
pedestrians.
• Spread ice melting materials "with the storm" to
prevent unmanageable levels of ice from building
up.
• For a wider pass, increase pace.
• For a heavier pass, decrease pace.
ACCESSORIES
A Poly Deflector Kit accessory (PDK-020) is available
from your distributor. It provides a tighter spread
pattern for areas such as sidewalks and walkways.
WARNING
Never remove spreader from vehicle with
material in it as this could cause damage to
the frame assembly.
WARNING
Do not overload spreader. Use chart below
to calculate weight of material. Weights of
material are an average for dry materials. CAUTION
DO NOT leave unused material in
hopper. Material can freeze or solidify,
causing unit to not work properly.
Empty and clean after each use.
CAUTION
Read and adhere to manufacturer's
ice-control material package
labeling including Safety Data
Sheet requirements.

Lit. No. 43577/43587/43597, Rev. 02 9 February 1, 2019
5. Slide the handle assembly on to the frame stand
and fasten with two 1/4" x 1-3/8" cap screws and
1/4" locknuts.
ASSEMBLING YOUR SPREADER
1. The spreader is shipped with tires partially
inflated. Using a manual pump, fully inflate the
tires to the psi setting shown on the tire sidewall.
2. Feed the gate actuator rod through the keyhole
slot in the frame stand.
3. Move the gate handle to the fully open position.
4. Insert the upper end of the gate actuator rod into
the gate handle.
1/4" x 1-3/8"
Cap Screw
Handle
Assembly
1/4 "
Locknut
Frame
Stand
ASSEMBLY
Gate
Actuator
Rod
Gate Handle
WARNING
Use safety glasses and gloves when inflating
and installing the tires. Use manual pump
only to inflate. Refer to the tire sidewall for
manufacturer's recommended pressure. Do
not exceed the maximum inflation pressure.

Lit. No. 43577/43587/43597, Rev. 02 10 February 1, 2019
ASSEMBLY
6. Insert the gate actuator rod end into the gate cam
and secure with a hairpin cotter.
Gate
Actuator
Rod
Gate Cam
Hairpin Cotter
7. Spin the tires and make sure the spreader is
running smoothly.
8. Tighten all fasteners.
9. Place the screen inside the hopper and put the
hopper cover on.

Lit. No. 43577/43587/43597, Rev. 02 11 February 1, 2019
LUBRICATION
To keep your spreader running smoothly, observe the
following recommendations:
NOTE: Gears and axles must be lubricated and
greased every 20 hours of use.
MAINTENANCE
Luricate both fittings
with a good quality
multipurpose grease.
Remove the gear
housing and apply
chain lube spray
lubricant.

Copyright © 2019 Douglas Dynamics, LLC. All rights reserved. This material may not be reproduced or copied, in whole or in part, in any
printed, mechanical, electronic, film, or other distribution and storage media, without the written consent of Fisher Engineering. Authorization
to photocopy items for internal or personal use by Fisher Engineering outlets or spreader owner is granted.
Fisher Engineering reserves the right under its product improvement policy to change construction or design details and furnish equipment when
so altered without reference to illustrations or specifications used. Fisher Engineering offers a limited warranty for all spreaders and accessories.
See separately printed page for this important information. The following is a registered (®) trademark of Douglas Dynamics, LLC: FISHER®.
Printed in U.S.A.
A DIVISION OF FISHER, LLC
Fisher Engineering
50 Gordon Drive
Rockland, ME 04841-2139
www.fisherplows.com
This product conforms to EU Machinery Directive 2006/42/EC.
