FIVE OCEANS ATLANTIC Series User manual

ATLANTICATLANTIC
WINDLASS SERIESWINDLASS SERIES
OWNER MANUAL 600 & 900 MOTORS
SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS
Important safety instrucons
are included in this manual.

TABLE OF CONTENTSTABLE OF CONTENTS
Introducon
Specicaons
Protecon Noce
Fing
Electrical
Installaon
Basic Requirements
Accessories
Gypsy Suitability
Above Deck Preparaon
Below Deck Preparaon
Above Deck Fing
Under Deck Fastening
Loading Rope/Chain
Electrical Wiring
Electric Cable Selecon
Wiring
Control Switch Installaon
Wiring Diagram
Operaon
Manual Control
Power Down/Up
Windlass Operang Procedures
Servicing
Servicing Schedule
Troubleshoong
Warranty
Product Guide
3
3
4
5
5
5
5
5
5
5
6
6
7
7
7
7
8
8
9
10
10
10
11
12
12
13
14
16

3
FIVE OCEANS ATLANTIC SERIES
1- Introducon1- Introducon
Thank you for choosing Five Oceans. Five Oceans products are world
renowned for their quality, technical innovaon and proven performance.
With a Five Oceans product you will be provided with many years of out-
standing service.
Product Support
Five Oceans products are supported by a network of distributors and Au-
thorized Service Representaves. If you encounter any dicules with this
product, please contact your naonal distributor, or your local Five Oceans
dealer. Details are available at: www.ve-oceans.com.
Important informaon about this manual
Throughout this manual, you will see safety and product damage warnings.
You must follow these warnings carefully to avoid possible injury or damage.
Atlanc 600
2 - Specicaons2 - Specicaons
1/2"(12mm) 6.96
D (mm) D (in) P (in) W (in)P (mm) W (mm)
0.274
0.329
21.46 .845 10.41 .410
8.36 26.16
mm in mm in mm in
140 5 1/2"248 197
1.030 12.70 .500
1/4" HT G4
9/16" (14mm) 5/16" HT G4
Atlanc 900
DD
PP
AA
WW
CC
9 3/4"7 3/4"
BB
AA
BB
CC
Atlanc 600
Electric SpecicaonsElectric Specicaons
12
12
Atlanc 900
MODEL
MOTOR
Voltage Wa
600
900
600
900
1200
1650
kg lb
MAXIMUM
PULL
26
35
m/min. /min.
DROP SPEED
85
115
180
250
400
550
kg lb
WORKING
LOAD LIMIT
20
35
Amp
NORMAL
CURRENT
DRAW

4HORIZONTAL WINDLASS MANUAL VOLUME ONE
3- Protecon Noce3- Protecon Noce
At all mes it is the responsibility of the boat user to ensure that the anchor and rode are
properly stowed for the prevailing sea condions. This is parcularly important with high-speed
powerboats, because an anchor accidentally deploying while under way can cause considerable
damage. An anchor windlass is mounted in the most exposed posion on a vessel and is thus
subject to severe atmospheric aack resulng in a possibility of corrosion in excess of that
experienced with most other items of deck equipment. As the windlass may only be used
infrequently, the risk of corrosion is further increased. It is essenal that the windlass is
regularly examined, operated and given any necessary maintenance.
Please ensure that you thoroughly understand the operaon and safety requirements of the
windlass before commencing the installaon. Only persons who are completely familiar with
the controls and those who have been fully made aware of the correct use of the windlass
should be allowed to use it. If there is any doubt of how to install or operate this unit please
seek advice from a suitably qualied engineer.
• Windlasses used incorrectly could cause harm to equipment or crew.
• Windlasses should be used with care and treated with respect.
• Boang, like many other acvies can be hazardous. Even the correct selecon, mainte-
nance and
• use of proper equipment cannot eliminate the potenal for danger, serious injury or
death.
• Five Oceans windlasses are designed and supplied for anchor control in marine applica-
ons and are not to be used in conjuncon with any other use.
• Keep limbs, ngers, clothing and hair clear of windlass and anchor rope/chain and anchor
during operaon. Severe bodily harm would result.
• Ensure there are no swimmers or divers nearby when dropping anchor.
• When the Windlass is not in use the anchor must be ed o onto a cleat or equivalent
strong point to prevent damage to the boat.
• Windlass must not be used as the sole means of securing the anchor to the bow ng
especially under storm condions. Anchors should be independently secured to prevent
accidental release.
• Classicaon Sociees require that a vessel lying at anchor must have its anchor rope/
chain secured to a chain stopper or other suitable independent strong point.
• A windlass should never be used as a mooring bollard, the anchor rode MUST be secured
to a mooring cleat, chain stopper or other designated strong point. Using the windlass to
secure the rode will damage the windlass.
• Do not use windlass for ANY purpose other than deployment and recovery of anchor.
• Do not wrap chain around a capstan barrel or drum where ed.
• A circuit breaker/isolator should always be used with this windlass to protect the motor
and cables from overheang and damage.
• Always switch o this windlass at the circuit breaker/isolator when not in use.
• It is the unavoidable responsibility of the owner or master or other responsible party to
assess the risk of any operaon on the vessel.
• Windlass must not be operated whilst under the inuence of alcohol or drugs.

5
FIVE OCEANS ATLANTIC SERIES
3.2 Fing3.2 Fing
• This equipment must be installed and operated in accordance with the instrucons con-
tained in this manual. Failure to do so could result in poor product performance, personal
injury and/or damage to your boat.
• Consult the boat manufacturer if you have any doubt about the strength or suitability of
the mounng locaon.
3.3 Electrical3.3 Electrical
• Make sure you have switched o the power before you start installing this product.
• This product requires installaon by a suitably qualied electrical engineer.
4.2 Accessories4.2 Accessories
Use only genuine Five Oceans parts and accessories to ensure top performance and eliminate
the risk of voiding your warranty. For replacement parts, please visit your dealer or
www.ve-oceans.com
4.3 Gypsy Suitability4.3 Gypsy Suitability
Gypsies ed to the Atlanc Horizontal windlasses are ideally suited to handling our factory
made Rope/Chain combinaon rodes, which consist of rope spliced to a chain tail. See 4.24.2
Specicaons for details.
Ropes used must be windlass grade, medium lay nylon. Ropes from dierent manufacturers
have wide variaons in stretch and consistency in diameter. Therefore, rope and chain from
othermanufacturers may require some experimentaon to determine the opmum size.
Should you have diculty in matching a gypsy to your chain please consult
info@ve-oceans.com.
4.4 Above deck preparaon4.4 Above deck preparaon
IMPORTANT - Plan locaon carefully and allow for the following:
4- Installaon4- Installaon
4.1 Basic requirements4.1 Basic requirements
Each installaon requires the following tools:
WINDLASS INSTALLATION
• An appropriate marine sealant
• Electric drill and 10mm (3/8”) drill bit
• 76mm (3”) Hole Saw
WIRING INSTALLATIONWIRING INSTALLATION
• Crimping Pliers / Wire Stripper
• Suitable electrical cable and crimp
terminals
25-60 mm
1" - 2 1/4"
21 3

6HORIZONTAL WINDLASS MANUAL VOLUME ONE
1. Use drilling template provided and choose an appropriate posion with reference to
the vessel’s bow roller and the chain locker below. Allow for the rotaon of the manual
operang wrench handle
2. If the deck is not at, a suitable mounng pad may be required to take up camber or
sheer.
NOTE: If in doubt about the suitable construcon of the pad consult a qualied marine
engineer.
The deck is an integral component of the windlass it has to secure the windlass and be
strong enough to cope with the high torque stresses involved in recovering the anchor.
Decks that are thin, or of foam or balsa laminate construcon, will require reinforcement
in order to spread the loads that will be applied to the deck while the windlass is in use.
3. Five Oceans recommends a minimum deck thickness of 25mm (1"), M8 Studs suit deck
and packing thickness of 25-60mm (1" - 2 1/4").
4.5 Below Deck Preparaon4.5 Below Deck Preparaon
IMPORTANT: The posioning of the windlass must be checked prior to cung for deck/hull and
bulkhead clearance. Lead from the roller should be fed horizontally back to the top of the gypsy
and along its centre line within +6˚. There must be sucient vercal fall (minimum
of 300 mm /12” at all mes) for the chain or rope when hauling in.
4.6 Above Deck Fing4.6 Above Deck Fing
Using the template and aer you have checked all the above and below deck requirements cut
the following holes: Using a 10mm (3/ three holes for the mounng studs and two for the 8”)
diameter drill bit, make the motor cables. With a 76mm (3”) diameter hole saw, make one hole
for the rode to pass through.
1. When all the holes have been made, remove the template. To help avoid water absorpon
by the deck, apply an appropriate marine sealant to the freshly cut hole edges.
2. Assemble and ghten studs into base unl they boom out in their holes.
3. Place the base mat in posion on the deck. Apply a suitable sealant to the base of the
windlass, any mounng pad or around the studs.
300 mm
(12”)
6°
1 2 3
WARNING! Failure to respect the
300 mm vertical fall may cause
malfunction.

7
FIVE OCEANS ATLANTIC SERIES
4.7 Under deck fastening4.7 Under deck fastening
1. Fit windlass to deck. Trim the studs back to 3/16” or 1/4” (5mm or 6mm) below the fully
ghtened nuts to prevent snagging anchor rope/chain if necessary.
• NOTE: If using silicone or other rubbery type sealant, it is advisable to allow curing of the
sealant before nal ghtening of the mounng nuts.
4.8 Loading rope/chain4.8 Loading rope/chain
For safety and performance Five Oceans recommends the use of matched Five Oceans anchor
rodes.
5- Electrical wiring5- Electrical wiring
5.1 Electric cable selecon5.1 Electric cable selecon
Five Oceans recommends the installer source and install cable that meets the requirements of
the standards and regulaons relevant to the installaon and codes of pracce.
The cable table gives recommended cable sizes based on total length of cable required, from
the baery, following the route of the cables.
CABLE SIZING FOR LENGTH OF CABLE RUN
1. Pull out control arm.
2. Feed anchor rope/chain into entry hole. Tie o to suitable strong point in the anchor locker.
3. Align rope/chain in gypsy. Release control arm and wrap rope/chain around gypsy.
4. Turn on the breaker and power load rest of anchor rope/chain.
Windlass performance is directly related to cable size and length. Voltage drop over the
complete wiring run must not exceed 10%.
DO NOT use a permanent
adhesive/sealant eg.5200
WARNING! Isolate (turn off) the
windlass using circuit breaker / isolator.
Atlanc 600 6 AWG (16 mm²) 2 AWG (25 mm²)
Atlanc 900 2 AWG (25 mm²) 1 AWG (35 mm²)
MODEL up to 24  (up to 8 m) 24 - 50  (8 - 16 m)
DO NOT confuse cable length
with the length of the vessel
3/16"5mm
6mm1/4"

8HORIZONTAL WINDLASS MANUAL VOLUME ONE
5.2 Wiring5.2 Wiring
Plan the installaon to suit the controls and give the operator a full view of the windlass. The
wiring system should be of the fully insulated type, which avoids possible electrolyc corrosion
problems.
We recommend the use of type III stranded, nned copper wire with copper crimp
terminals (NOTE: we recommend that the cable are shorter if possible.). Most modern installa-
ons are negave return (negave ground) but polarity should be checked. Overload protec-
on, in the form of the circuit breaker provided must be built into the windlass wiring circuit.
• Circuit breaker supplied:
Atlanc 600 Series (Circuit Breaker: 60 Amps - 80 Amps)
Atlanc 900 Series (Circuit Breaker: 80 Amps)
• The circuit breaker should be posioned close to the baery in a dry, readily accessible place.
• The breaker must be manually reset should an overload occur that causes it to trip to the o
posion.
Warning
If you are not sure you understand these guidelines, seek professional help. Ensure that the
installaon complies with USCG, ABYC, NMMA or other local regulaons.
5.3 Control switch installaon5.3 Control switch installaon
The unit is supplied with
Visit www.ve-oceans.com for more informaon
Contactor box (should be located within an dry area) and control box used in some installaon
refer to wiring diagram S 5.4

9
FIVE OCEANS ATLANTIC SERIES
5.4 Wiring Diagram5.4 Wiring Diagram
Positive Wire
Negative Wire
A2A2A1A1
M1M1 M2M2
CC
BatteBatteryry
12 VDC12 VDC
2
22
22
2
1
11
Main Switch
Rocker Switch
Electric Deck Switch
Foot Up Foot Down
FUSE
Motor Fuse
Solenoid
top view
side view
*For a safe and secure installation, place the Circuit Breaker as close to the battery as possible.
Circuit
Breaker*

10 HORIZONTAL WINDLASS MANUAL VOLUME ONE
6- Operaon6- Operaon
6.1 Manual Control
Use this method for quicker anchor deployment, in an emergency involving loss of power or to
save baery power. Observe marime anchor deployment safety rules.
6.2 Power Down/Up
1. Turn o all power to motor windlass and release any anchor locks.
2. When safe insert the Five Oceans wrench in to the capstan drive cap. Rotate clockwise to
grip the gypsy and anclockwise to free the gypsy controlling the rate of descent of the
anchor. Once deployed adjust desired scope if using a rope/chain, lock the clutch by turn-
ing the drive cap clockwise and engage the anchor locks. Remove the wrench handle.
To release anchor:
1. Check unit is not in manual mode.
2. Release any anchor locks.
3. Engage the circuit breaker/isolator.
4. Press down buon connuously unl you’ve reached the necessary length of chain/
rope.
5. Disengage the circuit breaker/isolator.
6. Lock anchor locks.
To retrive anchor:
1. Release any anchor locks
2. Engage the circuit breaker/isolator.
3. Press the UP buon connuously to retrieve the anchor.
4. Disengage the circuit breaker/isolator.
5. Lock anchor locks.
WARNING! Isolate (Turn off) the
windlass using circuit breaker / isolator.
WARNING! Trapping, crushing or
entanglement danger whiIst operating
windlass manually or under power
WARNING! Always remove
wrench handle aer use.
DONT FORGET
1 2 3

11
FIVE OCEANS ATLANTIC SERIES
This is an anchor recovery device. DO NOT use the windlass to pull the boat to the anchor as it
will damage the mechanism. Vessels at anchor will snub on the rode and this can cause slippage
or apply excessive loads to the windlass. Best pracce is to use a bollard or other strong point
when at anchor and use the vessels engines to break the anchor free. Otherwise excessive load
will cause the freefall funcon to seize and can cause damage to the gearbox.
When anchoring, power rode out allowing the vessel to take up stern away prevenng the rode
tangling with anchor. Use this method for mooring stern rst to a jey. To aid recovery, under
power, move vessel towards anchor but not over and beyond, as this can cause damage to
topside. As anchor approaches the vessel use careful adjustments of controls to avoid damaging
vessel, start and stop the windlass to bring the anchor slowly into the bow roller. Pulling the last
bit of rode and anchor into the bow roller at full speed can damage the boat, bow roller and
windlass. When stowing it is important to make sure, parcularly with rode lines that there is at
least 300mm (12”) of free space below the windlass (See §4.5). Stop and check during the
stowing process to determine if there is sucient space on you vessel. If the rode pile is too
close to the underside of the windlass, re-distribute the rode away from directly below the
windlass. If the rode gets too close to the underside of the windlass it will cause problems with
good rode recovery and may cause damage to the line.
6.3 Windlass Operang Procedures
When retrieving anchor do not
overload or stall in windlass.
The rode should be secured directly to a bollard, sampson
post or cleat and a chain secured by a chain stopper.

12 HORIZONTAL WINDLASS MANUAL VOLUME ONE
7.1 Servicing Schedule
The service period is determined by the frequency of use. Professional user will need to carry
out these operaons more oen than the weekend user. Before commencing any work on this
or any other electrical product, isolate from the power source.
Bedding in period:
When new there are some areas that will need frequent checking. If no movement is found
they can be inspected less oen.
• Examine all electrical connecons, to make sure they are sound and corrosion hasn’t set
in. Tighten if necessary and protect if required.
• Check mounng studs are rmly clamped and ghten if required.
Aer use:
• Wash down the windlass using fresh water.
• Ensure rode is at least 12” (300mm) below the windlass
• Check anchor locker drain
• Check rode and splice for wear.
Annually or more oen if frequent user:
• Examine all electrical connecons, to make sure they are sound and corrosion hasn’t set
in. Tighten if necessary and protect if required.
• Check mounng studs are rmly clamped and ghten if required.
• Check rode and splice for wear.
• Check gypsy as it is a high wear item
7- Servicing 7- Servicing
WARNING! Isolate the windlass
using circuit breaker/isolator
WARNING! Ensure rode is adequately
secured to an independent strong point

13
FIVE OCEANS ATLANTIC SERIES
8 Troubleshoong
1. Anchor falls down independently while windlass is not in use.
• This problem is a result of not securing the anchor rode combined with the gypsy drive
cap being slack. Tighten the gypsy drive cap using the Five Oceans wrench and always
secure the anchor rode independently of the windlass when not in use.
2. Failure to operate or sluggish operaon.
• The majority of these problems are electrical in nature. It is essenal that the proper
voltage be maintained. The proper voltage on a 12 Volt system is 13.5 Volts, constant low
voltage will damage motor.
• Ensure electrical cable size is large enough to handle the current draw and keep voltage
drop within acceptable limits (maximum 10%).
• Check control switches, connecons, baery condion, isolator switch, fuse and motor
for operaon failure.
3. Failure to operate.
• Is there a voltage at the input terminals to the contactor and switches. Check the circuit
breaker/ isolator switch and any fuses.
• Operate the switch. Is there voltage at the posive switch terminal on the solenoid. If
not, the switch (or its wiring), is difecve.
• Keep the switch acvated. Is there voltage at the main output terminal on the contactor.
If not check the contactor coil ground circuit. If okay, replace the contactor.
• Check the voltage at the motor. If voltage of at least 12.5 volts is present and the motor
does not operate, the motor is defecve.

14 HORIZONTAL WINDLASS MANUAL VOLUME ONE
9 - Warranty
All Five Oceans® products sold by Baron USA, LLC or any of the product resellers is war-
ranted to be free from defects in material and workmanship from date of purchase.
1. PRODUCT: Windlass Series (Altanc & Pacic)
2. WARRANTY PERIOD:
Exclusive ve (5) Windlass Series Warranty from purchase date
◦1 year warranty: motor+gear box, electrical component including solenoid, switch panel, foot switch,
circuit breaker.
◦5 year warranty: product housing
3. CONDITIONS AND LIMITATIONS:
a. This warranty only applies to the original Buyer and it is not transferable.
b. Proof of purchase is required for warranty service. If a product purchased in the
USA. Please register within ninety (90) days from the date of purchase. Simply
complete registraon by including a copy of the purchase receipt as proof of
original purchase. All Buyer must register their product purchased directly at
Five-Oceans.com within the USA territory at
hps:www.ve-oceans.com/pages/register.
c. The warranty shall be limited to the repair or replacement of any parts of the
product which are defecve in materials or workmanship.
d. Responsibility for the selecon of products appropriate for the use intended by the
Buyer shall rest solely with the Buyer.
e. This warranty does not cover any incidental costs, incurred for the invesgaon,
removal, carriage, transport or installaon of the product.
f. A unit provided as an exchange or replacement parts will be subject to the warranty
of the original unit. The length of the warranty governing the exchanged unit will
remain calculated by reference to the purchase date of the original unit.
4. WARRANTY EXCLUSIONS:
This warranty does not cover the following:
a. Normal wear: Products with mechanical and electrical components need periodic
parts and service to perform well. This warranty does not cover repair when normal
use has exhausted the life of a part or the equipment as a whole.
b. Environmental condions, including but not limited to extreme temperatures, etc.
c. Normal maintenance is not covered by this warranty.
d. Failures due to acts of God and other force majeure events beyond the manufactur-
er’s control.
Other Exclusions - This warranty excludes:
◦ Cosmec defects such as paint, decals, etc.
◦ Corrosion & Normal Wear and tear of items such as winch cable, chains, hooks,
power/electric cables, etc.
◦Accessory parts such as storage covers.

15
FIVE OCEANS ATLANTIC SERIES
5. VOIDING OF THE WARRANTY:
This warranty under the following
circumstances:
a. Use of a product in an applicaon for which it was not designed or intended;
b. Failure to service or maintain the product in accordance with the manufacturer’s
recommendaons;
c. Faulty or decient installaon of the product
d. Any modicaon or alteraon of the product;
e. Condions that exceed the product’s designed capacity, performance,
specicaons or safe working loads.
f. This warranty will not apply if the product is deemed to have been misused,
abused, neglected, involved in an accident, abused, used/loaded beyond the prod-
uct’s limits, modied, installed improperly or connected incorrectly to any electrical
component.
g. Use of parts that are not original Five Oceans
6. LIMITS OF IMPLIED WARRANTY AND CONSEQUENTIAL DAMAGE:
a. Baron USA, LLC or any of the product resellers disclaims any obligaon to cover any
loss of me, use of this product, freight, or any incidental or consequenal claim by
anyone from using this product.
b. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
c. Baron USA, LLC or any of the product resellers will not be liable for death, injuries
to persons or property or for incidental, conngent, special or consequenal
damages, loss or expense arising in connecon with the use or inability whatever,
regardless of whether damage, loss or expense results from any act or failure to act
by Baron USA, LLC or any of the product resellers, whether negligent or willful, or
from any other reason.
CONTACT INFORMATION
Five Oceans
Customer Service
11200 NW 107th St Suite 6-B, Miami, FL 33178 USA
info@ve-oceans.com | www.ve-oceans.com
Technical Service
info@ve-oceans.com
Inquiries outside the United States, please view our dealer page for the region which
pertains to you.

16 HORIZONTAL WINDLASS MANUAL VOLUME ONE
10 - Product Guide10 - Product Guide
Atlanc 600 Horizontal Windlass (Product Number: 3930) For more info click here.
Atlanc 900 Horizontal Windlass (Product Number: 3442) For more info click here.
Package Include (one (1) circuit breaker per windlass)
• Rocker Switch Panel w/Main Switch (Product Number: 3290)
For more info click here.
• Circuit Breaker 60 Amp (Product Number: 3295) For more info click here.
• Circuit Breaker 80 Amp (Product Number: 3294) For more info click here.
• Dual Direcon Solenoid (Product Number: 3292) For more info click here.
• Foot Switch (Product Number: 3291) For more info click here.
Not Included in Package (examples)
• Stainless Steel Chain Stopper (Product Number: 75) For more info click here.
• Stainless Steel Chain Stopper (Product Number: 2990) For more info click here.
• Anchor Roller | 11" (Product Number: 72) For more info click here.
• Stainless Steel Self-Lauch Anchor Roller (Product Number: 3696)
For more info click here.
• Stainless Steel Hinged Anchor Roller (Product Number: 4184)
For more info click here.

17
FIVE OCEANS ATLANTIC SERIES

18 HORIZONTAL WINDLASS MANUAL VOLUME ONE

19
FIVE OCEANS ATLANTIC SERIES

www.ve-oceans.com
VOLUME ONE
© Copyright 2019 Baron USA, LLC All rights reserved
