INSTALL TYPE SELECTION
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS
FORD
C-Max STD key 13-14 2 •
Edge STD key 11-13 1 •
Escape STD key 13-14 2 •
Explorer STD key 11-14 1 •
F150 STD key 11-13 1 •
F250 / Super Duty STD key 11-13 1 •
Fiesta STD key 14 2 •
Flex STD key 13 1 •
Focus STD key 12-14 2 •
Taurus STD key 13 1 •
LINCOLN
MKX STD key 11-13 1 •
Page 2 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
Doc. No.: ##13459##

TYPE 1 - WIRE CROSS REFERENCE CHART
*Wire color may vary, refer to pin-out.
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
FORD
Edge 11-13
Tx C252 Black 4 pin 3 Yellow/Orange (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple/Gray (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Purple/Orange (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black (-) PATS module, ignition switch ~
Explorer 11-14
Tx C252 Black 4 pin 3 Yellow/Orange (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple/Red or Purple/Gray* (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Purple/Orange (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black (-) PATS module, ignition switch ~
F150 11-13
Tx C252 Black 4 pin 3 Yellow/Orange* (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple/Gray* (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Purple/Orange (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black (-) PATS module, ignition switch ~
F250 /
Super
Duty
11-13
Tx C252 Black 4 pin 3 Purple/Gray* (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Yellow/Orange* (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Purple/Orange (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black (-) PATS module, ignition switch ~
Flex 13
Tx C252 Black 4 pin 3 Yellow (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Purple/Orange (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black/White (-) PATS module, ignition switch ~
Taurus 13
Tx C252 Black 4 pin 3 Yellow/Orange (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple/Gray (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Purple/Orange (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black/White (-) PATS module, ignition switch ~
LINCOLN
MKX 11-13
Tx C252 Black 4 pin 3 Yellow/Orange (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple/Gray (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Purple/Orange (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black (-) PATS module, ignition switch ~
Page 3 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
Doc. No.: ##13459##

TYPE 1 - WIRING DIAGRAM
Page 4 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
4321
1 3 4
N/A
TX
RX
PATS POWER (+)
<- REQUIRED
<- REQUIRED
<- REQUIRED
WHITE/BLACK - TX CONNECTOR SIDE
WHITE/BLACK - TX CONNECTOR SIDE
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
WHITE/RED - TX VEHICLE SIDE
WHITE/RED - TX VEHICLE SIDE
WHITE (NC)
WHITE (NC)
YELLOW/BLACK (NC)
YELLOW/BLACK (NC)
BLUE/RED (NC)
BLUE/RED (NC)
BROWN/RED (NC)
BROWN/RED (NC)
YELLOW/RED (NC)
YELLOW/RED (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK - RX
ORANGE/BLACK - RX
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - PATS POWER (+)
PINK - PATS POWER (+)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - TX VEHICLE SIDE
GRAY/RED - TX VEHICLE SIDE
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) GREEN/BLACK
(NC) GREEN/BLACK
(NC) BLUE/BLACK
(NC) BLUE/BLACK
(NC) RED/WHITE
(NC) RED/WHITE
(NC) BROWN
(NC) BROWN
(NC) PURPLE/YELLOW
(NC) PURPLE/YELLOW
(NC) PURPLE/BLACK
(NC) PURPLE/BLACK
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
(NC) GREEN
(NC) GREEN
(NC) PURPLE/WHITE
(NC) PURPLE/WHITE
BLACK CONNECTOR
IGNITION SWITCH
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
REMOTE STARTER
Doc. No.: ##13459##

TYPE 2 - WIRE CROSS REFERENCE CHART
*Wire color may vary, refer to pin-out.
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
FORD
C-Max 13-14
Tx C252 Black 4 pin 3 Yellow/Orange* (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple/Gray* (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Gray/Orange* (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black* (-) PATS module, ignition switch ~
Escape 13-14
Tx C252 Black 4 pin 3 Yellow/Orange* (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple/Gray* (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Gray/Orange* (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black* (-) PATS module, ignition switch ~
Fiesta 14
Tx C252 Black 4 pin 3 Yellow* (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Gray* (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Blue/White* (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black/White* (-) PATS module, ignition switch ~
Focus 12-14
Tx C252 Black 4 pin 3 Yellow/Orange* (DATA) PATS module, ignition switch ~
Rx C252 Black 4 pin 4 Purple/Gray* (DATA) PATS module, ignition switch ~
PATS power C252 Black 4 pin 1 Gray/Orange* (+) PATS module, ignition switch ~
Ground C252 Black 4 pin 2 Black* (-) PATS module, ignition switch ~
Page 5 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
Doc. No.: ##13459##

TYPE 2 - WIRING DIAGRAM
Page 6 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
4321 34
N/A
TX
RX
VEHICLE IGNITION (+)
<- REQUIRED
<- REQUIRED
<- REQUIRED
WHITE/BLACK - TX CONNECTOR SIDE
WHITE/BLACK - TX CONNECTOR SIDE
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
WHITE/RED - TX VEHICLE SIDE
WHITE/RED - TX VEHICLE SIDE
WHITE (NC)
WHITE (NC)
YELLOW/BLACK (NC)
YELLOW/BLACK (NC)
BLUE/RED (NC)
BLUE/RED (NC)
BROWN/RED (NC)
BROWN/RED (NC)
YELLOW/RED (NC)
YELLOW/RED (NC)
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK - RX
ORANGE/BLACK - RX
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE (NC)
ORANGE (NC)
PINK/BLACK (NC)
PINK/BLACK (NC)
PINK - IGNITION (+)
PINK - IGNITION (+)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED - TX VEHICLE SIDE
GRAY/RED - TX VEHICLE SIDE
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) GREEN/BLACK
(NC) GREEN/BLACK
(NC) BLUE/BLACK
(NC) BLUE/BLACK
(NC) RED/WHITE
(NC) RED/WHITE
(NC) BROWN
(NC) BROWN
(NC) PURPLE/YELLOW
(NC) PURPLE/YELLOW
(NC) PURPLE/BLACK
(NC) PURPLE/BLACK
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
(NC) GREEN
(NC) GREEN
(NC) PURPLE/WHITE
(NC) PURPLE/WHITE
C252 - BLACK
PATS MODULE
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
REMOTE STARTER
Doc. No.: ##13459##

INSTALLATION MODE SELECTION
1Press and release
programming button
to select installation mode.
2Press and hold
programming button
until LED turns solid GREEN
to register selection.
!After registration, follow Factory Reset Procedure to
change installation mode and restart this procedure.
LED fl ashes (1X) once = DATA MODE
LED fl ashes (2X) twice = STANDARD HARDWIRE MODE
TYPE 1 - MODULE PROGRAMMING PROCEDURE - 1 OF 2
1Insert key 1 into ignition.
2Turn key 1 to ON position.
ON
!If the module’s LED begins to fl ash RED, verify the RX
and TX connections between the module and the vehicle.
!If the module’s LED turns solid GREEN for 2 seconds,
the Module Programming Procedure is completed.
NOTE
I To complete this procedure,
both OEM keys are required.
5Remove key 1.
10 TIME RESTRICTI
 N
Complete steps 10 to 13
within 5 SECONDS.
Remove key 2.
6Insert key 2 into ignition.
7Turn key 2 to ON position.
ON
8Wait, LED will turn solid RED
then will turn OFF.
3Wait, LED will turn solid RED
then will turn OFF.
11 Press and release programming
button.
IMPORTANT: READ NEXT PAGE !
9Turn key 2 to OFF position.
OFF
4Turn key 1 to OFF position.
OFF
TIME RESTRICTI
 N COMING UP !
12 Insert key 2 into ignition.
Page 7 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
Doc. No.: ##13459##

TYPE 1 - MODULE PROGRAMMING PROCEDURE - 2 OF 2
15 Turn key 2 to OFF position.
OFF
14 Wait, LED will turn solid GREEN
for 2 seconds.17 Module Programming
Procedure completed.
13 Turn key 2 to ON position.
Do not start vehicle.
ON
16 Remove key 2.
Page 8 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
Doc. No.: ##13459##

INSTALLATION MODE SELECTION
1Press and release
programming button
to select installation mode.
2Press and hold
programming button
until LED turns solid GREEN
to register selection.
!After registration, follow Factory Reset Procedure to
change installation mode and restart this procedure.
LED fl ashes (1X) once = DATA MODE
LED fl ashes (2X) twice = STANDARD HARDWIRE MODE
TYPE 2 - MODULE PROGRAMMING PROCEDURE - 1 OF 2
1Insert key 1 into ignition.
2Turn key 1 to ON position.
ON
!If the module’s LED begins to fl ash RED, verify the RX
and TX connections between the module and the vehicle.
!If the module’s LED turns solid GREEN for 2 seconds,
the Module Programming Procedure is completed.
NOTE
I To complete this procedure,
both OEM keys are required.
5Remove key 1.
6Insert key 2 into ignition.
7Turn key 2 to ON position.
ON
8Wait, LED will turn solid RED
then will turn OFF.
3Wait, LED will turn solid RED
then will turn OFF.
10 Press and release programming
button.
IMPORTANT: READ NEXT PAGE !
9TIME RESTRICTI
 N
Complete steps 9 to 11
within 5 SECONDS.
Turn key 2 to OFF position.
OFF
4Turn key 1 to OFF position.
OFF
TIME RESTRICTI
 N COMING UP !
Page 9 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
Doc. No.: ##13459##

TYPE 2 - MODULE PROGRAMMING PROCEDURE - 2 OF 2
13 Turn key 2 to OFF position.
OFF
12 Wait, LED will turn solid GREEN
for 2 seconds.15 Module Programming
Procedure completed.
11 Turn key 2 to ON position.
Do not start vehicle.
ON
14 Remove key 2.
Page 10 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
Doc. No.: ##13459##

XX-XX PAGE X-XCLASSIC PAGE 1-1
LED STATUS
DIAGNOSTICS
DURING PROGRAMMING DURING REMOTE START WITH IGNITION OFF
Flashing RED Missing/wrong information from
fi rmware or vehicle Incorrectly programmed Incorrectly programmed or connected
Solid RED Waiting for more vehicle information Incorrectly programmed Not programmed waiting for more
vehicle information
Flashing GREEN Additional steps required to complete
programming
Correctly programmed and
operational
False ground when running status
from remote starter
Solid GREEN then OFF Correctly programmed Reset in progress Reset in progress
OFF No activity or already programmed Invalid ground when running status
from remote starter
At rest and ready for a remote start
sequence
MODULE DIAGNOSTICS
FACTORY RESET PROCEDURE
7Repeat programming procedure.
!Failure to follow procedure may result with a DTC or a
CHECK ENGINE error message.
1DISCONNECT all connectors
from module EXCEPT the black
4-PIN standard or optional data
connector.





6RECONNECT all connectors.


 
2DISCONNECT black 4-PIN
standard or optional data
connector.

4When LED fl ashes red,
RELEASE programming button.
5LED will turn solid red for 2
seconds.
RESET COMPLETED.
3PRESS AND HOLD programming
button while connecting either
4-PIN standard or optional data
connector.
IDENTIFY VEHICLE YEAR
1Locate the Vehicle Identifi cation
Number (VIN) and identify the
10th character.
2Match the VIN’s 10th character
to its corresponding year.
L > 1990 S > 1995 Y > 2000 5 > 2005 A > 2010
M > 1991 T > 1996 1 > 2001 6 > 2006 B > 2011
N > 1992 V > 1997 2 > 2002 7 > 2007 C > 2012
P > 1993 W > 1998 3 > 2003 8 > 2008 D > 2013
R > 1994 X > 1999 4 > 2004 9 > 2009 E > 2014
4 Y 1 N53 A 5 T A L 8 D 5 R 0 X

Page 11 of 11 FLC-AL(TB)-FM3-EN 20140116
INSTALL GUIDE
WWW.FLASH-IT.COM Audiovox Electronics Corp. © 2013
TRANSPONDER BYPASS
Ford/LincoLn
Doc. No.: ##13459##
