Flavel Pure FPRG**RN2 User manual

Pure
DECORATIVE FUEL EFFECT GAS FIRE
User Instructions
Model No’s F RG**RN2 is for use on Natural Gas (G20) at a supply
pressure of 20 mbar in G.B. / I.E.
NB: “**” refers to fascia variant

INSTALLATION INFORMATION
CONDITIONS OF INSTALLATION
It is the law that all gas appliances are installed in accordance with the rules in
force only by a competent (e.g. CO GI egistered) Installer in G.B, and in
accordance with the installation instructions and the Gas Safety (Installation and
Use) egulations 1998. Failure to install appliances correctly could lead to
prosecution. It is in your own interest and that of safety to comply with the law.
The fire may be fitted below a combustible shelf provided that the shelf is at least
200mm above the top of the appliance and the depth of the shelf does not exceed
150mm.
The fire may be installed below combustible shelves which exceed 150mm deep
providing that the clearance above the fire is increased by 15mm for each 25mm
of additional overhang in excess of 150mm.
No purpose made additional ventilation is normally required for this
appliance when installed in G.B. When installed I.E. please consult
document I.S. 813 : 1996 Domestic Gas Installation which is issued by the
National Standards Authority of Ireland. Any purpose made ventilation
should be checked periodically to ensure that it is free from obstruction.
If this appliance is fitted directly on to a wall without the use of a fireplace or
surround, soft wall coverings such as wallpaper, blown vinyl etc. could be affected
by the heat and hot air and may discolour or scorch. This should be considered
when installing or decorating.
The Model number of this appliance is as stated on the rating plate affixed to the
base panel of the fire and the appliance is manufactured by:-
BFM Europe Ltd
Trentham Lakes
Stoke on Trent
ST4 4TJ
LEASE NOTE : THIS GAS FIRE IS A
DECORATIVE FUEL EFFECT
A LIANCE AND IS THEREFORE
INTENDED FOR DECORATIVE
UR OSES ONLY.
2

ABOUT YOUR NEW FLAVEL “ URE” GAS FIRE
The Flavel “Pure” decorative fuel effect gas fire incorporates a unique and highly
developed burner and fuel-bed system. The use of durable ceramic
material in the construction of the fuel-bed ensures long and trouble free
operation.
When first using the new fire a slight smell may be noticed. This is due to starch
used in the manufacture of the ceramic fuel-bed base and imitation gravel pieces,
it is non-toxic and will soon disappear.
Please take the time to fully read these instructions as you will then be able to
obtain the most effective and safe operation of your fire.
IM ORTANT SAFETY INFORMATION
WARNING
This appliance has a naked flame and as with all heating appliances a
fireguard should be used for the protection of children, the elderly and
infirm. Fireguards should conform to B.S. 8423 : 2002.
(Fireguards for use with gas heating appliances).
It is important that this appliance is serviced at least once a year by a CO GI
registered gas installer ( in G.B.) and that during the service the fire is removed
from the fire opening and the flue pipe / chimney visually checked for debris or
blockages which must be removed. During the annual service, replacement of the
Oxypilot and ribbed fuel-bed base panel must be completed. These are conditions
of the manufacturers guarantee. After installation or during servicing a spillage
test must always be carried out.
IF AT ANY OINT DURING USE OF THE A LIANCE, ANY FLUE
DEBRIS SUCH AS SOOT, MORTAR ETC. IS VISUALLY OBSERVED ON
THE FUEL-BED, THE A LIANCE MUST NOT BE USED UNTIL IT HAS
BEEN THOROUGHLY CLEANED AND INS ECTED BY A CORGI
REGISTERED ENGINEER.
ubbish of any type must NEVE be thrown onto the product, this could affect
safe operation and damage the fire.
Only the correct ribbed fibre fuelbed base panel must be used and only complete
and genuine replacement fuelbed base panel can be sourced from BFM Europe
Ltd. Always keep furniture and combustible materials well clear of the fire and
never dry clothing or items either on or near to the fire. Never use aerosols or
flammable cleaning products near to the fire when it is in use.
The trim, fuel-bed and glass panel remains hot for a considerable period
after use and sufficient time should be allowed for the fire to cool before
cleaning etc.
3

S ILLAGE MONITORING SYSTEM
This appliance is fitted with a spillage monitoring system which shuts down the fire
if the evacuation of combustion products from the fire is affected by a partially or
fully blocked flue pipe. If this system operates the fire will go out. If this occurs,
leave the fire for at least three minutes then follow the lighting procedure as
described in the previous section. In the event of repeated operation a CORGI
registered gas installer must be called to investigate and rectify the cause.
CHANGING THE BATTERIES - REMOTE HANDSET
The battery in the remote handset can be changed by removing the cover on the
rear of the handset and replacing the 1 off 6 9V type battery.
CHANGING THE BATTERIES - ULTRASONIC RECEIVER
The batteries in the ultrasonic receiver can be changed by removing the Pure
fascia. The ultrasonic receiver is located at the bottom right hand corner of the
appliance. Lift the receiver unit from the base panel, slide the top cover off and
replace the 4 off AA batteries.
4

O ERATING THE FIRE USING THE REMOTE CONTROL HANDSET
a) emove the “Pure” fascia as shown on page 7 of this book. The control
valve is positioned on the left hand side of the fire when viewed from
the front.
b) To operate the appliance automatically via the remote control handset,
ensure that the on / off switch is switched to the “on” position as shown
below in Fig. 1
Fig. 1
c) Switch the MANUAL control disc to the “ON” position. (Image above
shows “MANUAL” control disc set in the “MAN” position).
d) Switch the main valve knob to the “OFF” position. (Image above shows
“MAIN VALVE” knob set in the “OFF” position.
e) Press and hold the “STA ” button and “UP” button on the remote hand
set simultaneously, see Fig. 2 overpage for image of handset.
f) The valve will then emit an audible beep and commence its ignition
sequence. When the pilot flame has been established, the control will
continue to beep whilst the thermocouple heats up. When the
thermocouple has reached operating temperature, it will allow gas to
flow to the burner and the burner will light at high rate heat input
(6.9kW).
5
On / Off Switch
“MANUAL”
Control Disk
“MAIN VALVE” Knob

Fig. 2
g) To reduce the heat input, press the “DOWN / STANDBY” button until the
flame reduces to the low rate heat input setting (4.2kW). If you continue
to hold the “DOWN / STANDBY” button, the burner flame will extinguish,
and only the pilot flame will remain lit. If you wish to turn off the
fire altogether, press the “STA ” / “OFF” button.
AFTER THE ILOT FLAME HAS BEEN EXTINGUISHED, IF YOU
WISH TO RE-LIGHT THE A LIANCE YOU MUST WAIT AT LEAST
THREE MINUTES BEFORE TRYING TO RE-LIGHT THE FIRE.
6
“STAR” / “OFF” button
“UP” button
“DOWN” / “STANDBY”
button
“LED” h ndset light
NOTE : THE FIRE SHOULD NOT BE LEFT IN STANDBY
MODE (PILOT RUNNING ONLY) IF LEFT UNATTENDED.
PLEASE TURN OFF COMPLETELY.

REMOVAL & RE-FITTING THE “ URE” FASCIA
a) The “Pure ” fascia is fitted to the product by hooking the top edge of the
fascia over the mounting brackets as shown in Fig. 3 below, then
securing with magnets at the bottom.
Fig. 3
CERAMIC FUEL-BED GRAVEL
a) The gravel pieces should be randomly placed onto the grooved base of
the product as shown below in Fig. 4. The gravel pieces should be
uniformly distributed in a single layer only. (Do not place on top of one
another)
Fig. 4
7
Hook “Pure”
fsci onto top
mounting br ckets

The ceramic fibre back & imitation gravel used in this product is
manufactured from R.C.F (Refractory Ceramic Fibre). To ensure that the
release of fibres from this item is kept to a minimum, during installation and
servicing we recommend that you use a HE A filtered vacuum to remove
any dust accumulated in and around the appliance before and after working
on the appliance. When replacing these articles we recommend that the
replaced items are not broken up, but are sealed within heavy duty poly-
thene bags, clearly labelled as “RCF waste”. RCF waste is classed as a “sta-
ble”, non reactive hazardous waste and may be disposed of at a landfill
licensed to accept such waste rotective clothing is not required when
handling these articles, but we recommend you follow the normal hygiene
rules of not smoking, eating or drinking in the work area, and always wash
your hands before eating or drinking.
CLEANING - WARNING
Before attempting any cleaning operation ensure that the fire has been allowed to
fully cool.
CLEANING THE STAINLESS STEEL AND AINTED METAL ARTS
The “Pure” fascia that was supplied with this product must only be cleaned with a
clean, damp cloth.
Abrasive cleaners, chemical cleaning agents or any type of polish must
never be used as damage to the finish may result.
CLEANING THE CERAMIC FUEL-BED COM ONENTS
We do not recommend cleaning of the ceramic fuel-bed fibre base or imitation
ceramic gravel as these items are fragile and damage may result.
None of these parts must be washed or exposed to any cleaning agents or
water.
Any damaged parts must be replaced by contacting your dealer or telephoning
BFM Europe Ltd. on the number stated on the rear cover of this book. The
ceramic fibre base must only be replaced with a complete and genuine item and
the fire must never be run with a damaged item in position.
8

USER RE LACEABLE ARTS
We do not recommend any parts on this appliance are replaced by anyone other
than a CO GI registered engineer, with the exception of the following user
replaceable parts :-
Fuel-bed Mounting Board (Black Fibre) B-96000
Fuel-bed Mounting Board (Beige Fibre) B-97420
Fuel-bed gravel set (Grey / Cream 100 off approx. pieces) B-97530
Fuel-bed gravel set (Cream 100 off approx. pieces) B-99250
Due to our policy of continual improvement and development the exact
accuracy of descriptions and illustrations cannot be guaranteed.
art No. B-121100
Issue 1
BFM Europe Ltd.
Trentham Lakes
Stoke-on-Trent
Staffordshire
ST4 4TJ
www.bfm-europe.com
Telephone - General Enquiries : [phone]
Telephone - Service : [phone]
