Flexa 3464227 User manual

Daybed - White
Dimensions
Length - 195cm
Depth - 96cm
Height - 81,5cm
Weight - 29kg
Issue 1 - 28/01/15
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@flexa.dk Produced in Estonia for FLEXA4DREAMS A/S.
Assembly Instructions - Please keep for future reference 3464227

Safety and Care AdviceSafety and Care Advice
Important – Please read these instructions fully before starting assembly
80-10106-20 Daybed
IMPORTANT! KEEP FOR FUTURE REFERENCE
PLEASE DISPOSE OF PACKAGING MATERIAL.
PLASTIC BAGS CAN BE DANGEROUS TO YOUNG CHILDREN
WARNING! Not suitable for children under 4 years.
WARNING! Do not place this child’s bed near heat sources, windows and other furniture.
WARNING! Do not use this child’s bed if any of the parts are broken, torn or missing.
WARNING! Once assembled, this bed must not be disassembled. Screws must not be removed once inserted.
This child’s bed is to be used with a 1900mm x 900mm ma ress.
Suitable for over 4 years old to adults.
All assembly Įxings should be checked periodically and re- ghtened where necessary.
Children are likely to play, bounce, jump and climb on beds, therefore the child’s bed should not
be placed too close to other furniture or windows, blind cords, curtain pulls or other strings or cords, and should be
placed either ght to any wall or have a gap of 300mm between the wall and the side of the bed.
Any addi onal or replacement parts should only be obtained from the manufacturer or distributor.
This product complies to standard BS8509: 2008+A1:2011
CARE AND MAINTENANCE
To clean use a damp cloth, avoiding the use of strong detergents or abrasives.
Always place the side of the bed with the safety rail against a wall.
1

Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could
damage the unit. Only use hand
screwdrivers.
• Dispose of all packaging
carefully and responsibly.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
2

Bedside x2
(186.7x8.9x2.0cm) 8Back rail x1 (186.7x6.5x2.0cm)
7
Endrail x4
(87.7x6.5x2.0cm)
3
Components - Parts
Please check you have all the parts listed below
Leg x2 (72.5x4.3x4.3cm)
1
Endrail x2 (87.7x6.5x2.0cm)
4
No. 12-02008772-20
Leg x2 (79.4.7x4.3x4.3cm)
2No. 12-04307941-20
Slat x14 (89.7x6.5x1.5cm)
5No. 12-01508971 Distance piece x1
(25.7x6.5x2.0cm)
6
No. 12-02002581-20
No. 12-020186710-20No. 1305-18673-20
If you have damaged or missing components,
call the Customer Helpline:
0045 7668 8055
Back rail x1
(186.7x6.5x2.0cm)
9
No. 4301-0808771-20
Filling x4
(87.7x27.6x0.8cm)
10
Filling x2
(91.0x27.6x0.8cm)
No. 4301-0809111-20
11
No. 12-020186711-20
3
No. 12-04307251-20
No. 12-020087724-20

4
Components - Fittings
Please check you have all the fittings listed below
M6x90mm Connecting bolt x4
Tools required
A
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
M6 ø10x14mm Barrel nut x4
B
E
4,0x30mm Chipboard screw x28
C
10x45mm Dowel x12
D
Phillips
screwdriver
(medium)
Small
hammer
Allen key
4mm incl.
Flatblade
screwdriver
(medium)
6,3x90mm Assembly screw x24
Ruler/tape
measure
Eye protection
(when using a
hammer or glue)
G
F
I
H
ø14x15,5mm Threaded bush x2
M8x10mm Grub screw x2 M4/ ø4,0x40mm dowel screw x2 ø8x38mm Connecting bolt x2
No. 3901-40030
No. 3930-10045
No. 3922-06014
No. 3913-06090
No. 4033-004
No. 3909-63090
No. 4020-001
No. 3933-14016
No. 3920-04040
No. 3917-08010

Attach the dowels Dto
bedsides 7, back rail
8and back rail 11 .
It may be necessary
to tap the dowels in
very gently with a small
hammer.
Attach endrails 3and
4to leg 2with screws
Eusing the allen key.
Note the position of the
grooves.
Repeat same procedure
for second headboard.
Slide MDF panels 10
between endrails 3and
4.
Attach leg 1to endrails
4and 3with screws
Eusing the allen key.
Repeat same procedure
for second headboard.
Assembly Instructions
Step 1
Step 2
Step 3
11
8
7
23
4
3
1
10
10 E
E
E
E
E
ED
D
x2
Groove downwards.
Groove upwards.
D
E
5

6
Attach connecting bolts
Ito dowel screws H.
Insert the dowel screws
Hinto the holes in
back rails 11 and 8.
Fasten with a flatblade
screwdriver.
Note that the hole in
connecting bolt Ishould
be facing horizontal with
back rails 11 and 8.
Insert threaded bushes
Finto the distance piece
6. Line up the holes in
bush Fwith the holes in
the end of the distance
piece 6. Place the
distance piece between
the two back rails 11 and
8. Insert grub screws
Ginto the threaded
bushes Fand secure
the distance piece 6
into place.
Slide MDF panels 9
into the grooves between
back rails 8and 11 .
Step 5
Assembly Instructions
Step 4
11
8
11
6
8
9
9
H
I
H
I
F
G
Horizontal
Aligned
Step 6
11
8
H
I
G
F
Bushes at
back side!

Assembly Instructions
Attach the assembled
backrail panel and
bedside 7to the
assembled headboards
by placing the dowels
into the holes in legs 2.
Push barrel nuts B
into the 2 small holes
in in bedside 7. Push
1 connecting bolt A
through legs 2to meet
the barrel nuts Band the
fasten with the allen key.
Push 4 assembly screws
Ethrough legs 2to
meet back rails 11 and
8. Fasten with the allen
key.
Attach bedside 7to
the bed by placing the
dowels into the holes in
legs 1.
Push 2 barrel nuts B
into the small holes
in bedside 7. Push
1 connecting bolt A
through each leg 1to
meet the barrel nuts B
and fasten with the allen
key.
Step 7
Step 8
7
2
2
8
11
7
1
1
B
B
A
A
A
E
B
B
E
E
A
B
E
A
B
7

8
Assembly Instructions
If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055
E-mail: order@flexa.dk
Ref.no. 44-01426-20 A Stand: 280115 Page 9 (80-10106-20)
Place one slat 5in the
centre of the bed. Follow
the measurement .
Place two slats 5in the
ends of the bed. Follow
the measurement .
Push the bedsides 7
together whilst attaching
middle slat 5to the
bed with two chipboard
screws C.
Position the remaining
eleven slats 5in the
bed with a distance of 73
mm between each.
Fasten each slat with two
screws C
Assembly is complete.
Step 9
Step 10
5
5 5 5 5 5 5 5 5 5 5 5 5
C
C
C
7
7
C C
C C
55
843 mm
15 mm
73 mm
C
C
