FLIGHT LINE FLW204 User manual

Package list
Different equipment include different spareparts. Please refer to the following contents to check your sparepart list.
Fuselage
Main wing
Tail wing set
Foam parts
Fuel tank
No.Name No electronic
equipment
Pre-installed all
electronic parts Pre-installed
servo
PNP KIT Plus Airframe
1
2
3
4
5
No electronic
equipment
Pre-installed all
electronic parts Pre-installed
servo No electronic
equipment
Pre-installed all
electronic parts Pre-installed
servo
No.Name PNP KIT Plus Airframe
6
7
8
9
10
Propeller
Spinner & fixed part
Installed part & screw
Fiberglass tube & glue
Manual
986 mm
1120 mm
(44")
(38-4/5")
2
It em No.: FLW204
Focke-Wulf Fw 190 A8

3
It em No.: FLW204
Focke-Wulf Fw 190 A8
Installation
PWA2×8mm
Elevator, rudder
Install the servo of Elevator/rudder
Install elevator
A-
B-
C-
D-
Rear wheel
Rear gear supporting rod
Rear wheel shaft
E-buckle (Ø5×Ø2mm)
(Ø35×10mm)
A
B
C
D
A
A
B
A
B
D
C
(PA2.3×8mm)
Install the tail gear set
1.Refer to the right photo, install the tail
landing gear set.
2.Insert the tail gear set C to the fixed
plastic part B, and continue to insert to
the tail steering arm A.
3.Use screw D to fix the tail steering arm.
1.Use servo tester or radio to center the
servo.
2.Use screw A to fix the 9g servo on the
wood piece.
3.Insert the servo cable under the wood
piece, and put it to the battery
compartment.
Note: If you don't choose the factory servo, the
servo maybe don't fix since of its servo different size.
If like that, we need to remove the fixed wood piece,
and glue the servo in the servo position in fuselage, it
also can use in common.
1.As the above photo shown, install the left/right elevator on the tail fuselage.
2.Turn over the fuselage, and use 4 pcs screws to fix the elevator.
D - Screw
A- Tail steering arm
B- Rear gear fixed plastic part
C- Tail gear set
D- Screw (PA1.6×6mm)

4
It em No.: FLW204
Focke-Wulf Fw 190 A8
Installation
Install elevator/rudder pushrod
Rudder pushrod size Rudder pushrod mounting hole
Steering pushrod size Steering pushrod mounting hole
587mm
(23")
Pushrod diameter : Ø 1.2mm
Pushrod diameter : Ø 1.2mm
Elevator pushrod size Elevator pushrod mounting hole
587mm
(23-1/2")
Pushrod diameter : Ø 1.2mm
A
B
C
D
1.Insert one side of elevator pushrod A ,through plastic tube B, to the
servo arm C.
2.Buckle the clevis of elevator pushrod to the rudder horn D.
A
B
C
D
1.Insert one side of rudder pushrod A ,through plastic tube B, to the servo arm C.
2.Buckle the clevis of rudder pushrod to the rudder horn D.
Note: when install on the rudder pushrod, we need to make sure our tail
gear is in the center. Then install the rudder pushrod, and adjust the plastic
clevis to center the rudder.
1.Use glue to attach the rudder horn on the rudder.(as the
left photo shown).
2.Use rudder pushrod to connect the tail gear steering arm
and rudder horn.
41.5mm(1.6")

Installation
5
It em No.: FLW204
Focke-Wulf Fw 190 A8
Install main wing
1
2
B
C
A
D
5
1.Use servo tester or radio to center the
servo.
2.Use glue to install the servo and aileron
horn on the main wing.
3.Buckle the servo cable to the through,
after installed all the servos, stick on
the decal.
4.One side pushrod insert to the servo
arm, adjust its length. And insert the
clevis to the aileron horn.
5.Repeat the above four steps, install the
other side main wing servo and flap servo.
Install main wing servos
A - 9g servo
B - Main wing pushrod
C - Aileron horn
D - Main wing servo trough
Main wing
Aileron pushrod size Flap pushrod size
Aileron pushrod mounting hole Flap pushrod mounting hole
55mm (3-2/5") Pushrod diameter : Ø 1.2mm Pushrod diameter : Ø 1.2mm
1.Use epoxy glue to attach the
foam piece on the fuselage.
1.Place the main wing servo
wires in the fuselage along
the front direction.
2 Insert the main wing into .
the front of the fuselage.
PA3×42mm
1.Use 2 pcs screws to fix the drop tank.
41.5mm(3-1/2")

Installation
6
It em No.: FLW204
Focke-Wulf Fw 190 A8
A
B
C
D
A
B
C
D
-
-
-
-
(KA2.6×12mm)
Screw
Landing gear strengthening part
Nose landing gear
Landing gear mount
A
B
C
D
E
F
G
H
-
-
-
-
-
-
-
-
(M3×3mm)
(PA1.7*6mm)
(Ø65×16mm)
(Ø5.5×Ø4.2mm)
(M3×3mm)
Accessories
Nose gear main supporting rod
Nose wheel
Wheel chocks
Jimi screw
Nose gear cabin door
Screw
Retractable controller
Jimi screw
前起落架组装
Nose Landing Gear Assemble
Please assemble、 disassemble the nose landing gear according to the following photo.
Install on the tail hook
1.Insert the tail hook A on the tail hook
fixed part B, and keep the two plastic
holes alignment;
2.Use screw C to fix the tail hook A. Screw(PA2.0×6mm)
1
1
2
3
3
4
5
5
A
B
C
D
E
F
G
H

1
3
2
4
5
6
Servo cable length
7
It em No.: FLW204
Focke-Wulf Fw 190 A8
Before connect the battery and ESC, please switch
on the transmitter power and make sure the throttle
stick is in the lowest position.
Installed on the battery and before start throttle stick,
please make sure that no things is in the propeller
diameter range, in order to avoid accidents and injury.
Battery compartment cover
Battery tray
Battery install on the front of
fuselage, and use magic tape to fix.
Battery Cabin Size：155×52×42mm
4S 14.8V 2600mAh ~ 4S 14.8V 4000mAh
Discharge rate of C > 30C
Velcro
Battery
1
2
3
4
5
6
400mm
400mm
200mm
200mm
100mm
100mm
If you need to purchase other brand servo, please
refer to the following list to choose correct size servo.
Positive
Positive
Reverse
Positive
Positive
Positive
Servo installing position
No.
Pos./Rev.
Aileron servo (Left 9g plastic)
Aileron servo (Right 9g plastic)
Flap servo (Left 9g plastic)
Flap servo (Right 9g plastic)
Rudder servo (9g MG)
Elevator servo (9g MG)
Servo connection
1.Use a Y-wire to connect the No. 1, No.2 this two servos, and
insert to the aileron channel in receiver.
2.Use a Y-wire to connect the No.3,No.4 this two servos, and
insert to the flap channel in receiver.
3.Use a Y-wire to connect the left/right nose landing gear, and
insert it to the landing gear channel in receiver.
Insteae forward, and the battery
compartment to unlock

Install 2-blade propeller high power system
F
G
A
BCD
E
A
B
C
D
E
F
G
-
-
-
-
-
-
-
(12×8)
(Ф14×1.5×Ф6.2mm)
Screw
2-blade spinner
Propeller fixing bolt
Washer
2-blade propeller
2-blade propeller fixed plate
3648-880KV brushless motor
(PM3×8mm 1pcs)
We prepared a 2-blade high power system for this
airplane, it can improve its power and flight speed, reduce the propeller
use cost! You can contact our distributor to purchase its high power system.
Install on ESC
A
B
C
D
A
B
C
D
-
-
-
-
(PWA3×8mm 4pcs)
Put the ESC under the battery tray, there
is a special designed ventilation ducts, it
can cool the electric equipment effectively.
Screw
Battery tray
ESC
Tray holder
ABCDE
A
B
C
D
E
-
-
-
-
-(HM2.5×10mm 4pcs)
(KM3×5mm 4pcs)
Screw
Motor X-fixed base
3648-830KV out-runner motor
Propeller folder
Screw
C
D
E
A
B
C
D
E
-
-
-
-
-
(PA3×10mm 4pcs)
(PA2.3×16mm 8pcs)
Motor fixed mount
Screw
Screw
Scale propeller (10x6, 3-blade )
Scale propeller fixed plate
A
B
C
A
B
C
D
-
-
-
-
(Pm3×mm 1pcs)
(Ф14×1.5×Ф6.2mm)
Screw
Spinner (scale 3-blade spinner)
Propeller fixing bolt
Washer
Install power system
8
It em No.: FLW204
Focke-Wulf Fw 190 A8
A
B

ESC
Item No. KV Value Volate
(V)
Current
(A)
Pull
(g)
Motor
Resistance
Weight
(g)
No Load
Current
830RPM/V 14.8 41 2500 0.02 170 2.3A/10V 60A
MO136483
Propeller
880RPM/V 14.8 53 2600 0.02 165 2.3A/10V 60A
MO136484
3-Blade10×6
2-Blade12×8
Unit: mm
18.0
24.0
11.0
8.8
12.5
3.0
11.5
53.0
∅12.0
Ø9.0 Ø6.0 4-Ø2.6
Ø20
4-Ø3.2
4-Ø3.2
43.5
25
Motor shaft, X-fixed base
Unit: mm
4-M3.0
47
2.3
5
25
4-M2.5
12.5
Ø9.0 Ø37.5
Ø9.6
3648-830KV / 3648-880KV
Motor size
85mm
(3-2/5")
9
It em No.: FLW204
Focke-Wulf Fw 190 A8
Parameter of Motor

10
It em No.: FLW204
Focke-Wulf Fw 190 A8

H1
11
It em No.: FLW204
Focke-Wulf Fw 190 A8
H1/H2 12mm/12mm
H1/H2 12mm/12mm
H1/H2 7mm/7mm
H1/H2 17mm/17mm
H1/H2 12mm/12mm
H1 28mm
H1 15mm
H1/H2 18mm/18mm
Aileron Elevator Rudder Flaps
Low Rate
High Rate D/R Rate：100%D/R Rate：100%D/R Rate：100%
D/R Rate：60%D/R Rate：75%D/R Rate：60%
Install the loose-leaf
The surface control use no-hinge connection design, although after a lot of use, has proved to be a reliable design.
However, we don't exclude, in the use process, due to the errors, and cause the control surface fall off.
Step one
Use knife to cut the
surface control
Select the appropriate location,
cook mark. Make sure the three
points in the middle position.
Step two
As the right photo shown, choose
two or three position, attach the
glue on the long end of loose-leaf,
and insert to the three positions.
Step three
As the right photo shown,
repeat the "step two", attach
the control surface to the
loose-leaf.
H1
H2
H1
H2
H1
H2
According to our test experience,refer to the following data to control kinds of control surface,we consider its helpful
for flight.In the low rate,the plane can be controlled softer, suit for some players who lack of flight experience. And in
high rate,the plane can be controller more sensitive,suit for more experience players.We advise you use the big rate
in the first flight,and according to your own demanding to choose one rate for flight.
