FLIR Raymarine CPT-S Assembly instructions

CPT-SIn-hullT
ransducerInstallation
sheet
Warning:Productinstallationand
operation
•Thisproductmustbeinstalledandoperatedin
accordancewiththeinstructionsprovided.Failure
todosocouldresultinpersonalinjury,damageto
yourvesseland/orpoorproductperformance.
•Raymarinerecommendscertifiedinstallation
byaRaymarineapprovedinstaller.Acertified
installationualifiesforenhancedproduct
warrantybenefits.ContactyourRaymarinedealer
forfurtherdetails,andrefertotheseparate
warrantydocumentpackedwithyourproduct.
Warning:Highvoltage
Thisproductcontainshighvoltage.DoNOTremove
coversorattempttoaccessinternalcomponents,
unlessspecificallyinstructedinthedocumentation
provided.
Warning:Switchoffpowersupply
Ensurethevessel’spowersupplyisswitchedOFF
beforestartingtoinstallthisproduct.DoNOT
connectordisconnecteuipmentwiththepower
switchedon,unlessinstructedinthisdocument.
Warning:Transduceroperation
Onlytestandoperatethetransducerinthewater.Do
NOToperateoutofwaterasoverheatingmayoccur.
Warning:Marine-gradesealant
Onlyusemarine-gradeneutralcurepolyurethane
sealants.DoNOTusesealantscontainingacetateor
silicone,whichcancausedamagetoplasticparts.
Caution:Transducercable
•oNOTusethetransducercabletoliftor
suspendthetransducer;alwayssupportthe
transducerbodydirectlyduringinstallation.
•oNOTcut,shorten,orsplicethetransducer
cable.
•oNOTremovetheconnector.
Ifthecableiscut,itcannotberepaired.Cutting
thecablewillalsovoidthewarranty.
isclaimer
R aymarinedoesnotwarrantthatthisproductiserror-freeorthatit
iscompatiblewithproductsmanufacturedbyanypersonorentity
otherthanRaymarine.
Raymarineisnotresponsiblefordamagesorinjuriescausedby
youruseorinabilitytousetheproduct,bytheinteractionofthe
productwithproductsmanufacturedbyothers,orbyerrorsin
informationutilizedbytheproductsuppliedbythirdparties.
eclarationofConformity
FLIRBelgiumBVBAdeclaresthattheCPT-SIn-hullTransducer
(partnumberA80691)isincompliancewiththeEMCDirective
2014/30/EU.
TheoriginalDeclarationofConformitycertificatemaybeviewed
ontherelevantproductpageatwww.raymarine.com/manuals.
Productdisposal
DisposeofthisproductinaccordancewiththeWEEEDirective.
TheWasteElectricalandElectronicEuipment(WEEE)Directive
reuirestherecyclingofwasteelectricalandelectroniceuipment
whichcontainsmaterials,componentsandsubstancesthat
maybehazardousandpresentarisktohumanhealthandthe
environmentwhenWEEEisnothandledcorrectly.
Euipmentmarkedwiththecrossed-outwheeled
binsymbolindicatesthattheeuipmentshould
notbedisposedofinunsortedhouseholdwaste.
Localauthoritiesinmanyregionshaveestablished
collectionschemesunderwhichresidents
candisposeofwasteelectricalandelectronic
euipmentatarecyclingcenterorothercollection
point.
Formoreinformationaboutsuitablecollection
pointsforwasteelectricalandelectronic
euipmentinyourregion,refertotheRaymarine
website:www.raymarine.eu/recycling.
IMOandSOLAS
Theeuipmentdescribedwithinthisdocumentisintendedfor
useonleisuremarineboatsandworkboatsNOTcoveredby
InternationalMaritimeOrganization(IMO)andSafetyofLifeatSea
(SOLAS)CarriageRegulations.
Warrantyregistration
ToregisteryourRaymarineproductownership,pleasevisit
www.raymarine.comandregisteronline.
Itisimportantthatyouregisteryourproducttoreceivefull
warrantybenefits.Y ourunitpackageincludesabarcodelabel
indicatingtheserialnumberoftheunit.Y ouwillneedthisserial
numberwhenregisteringyourproductonline.Y oushouldretain
thelabelforfuturereference.
Productoverview
•ConicalCHIRPsonarbeam.
•Easyinstallation.
•Theproductcomesreadytobefittedtocommon20°deadrise
hulls.
•Thetransducertubecanbecuttobefittedtoahullwitha0°or
12°deadrise.
•ConnectsdirectlytoAxiom™7DV,Axiom™ProS,Element™S
variantMFDs,andCP100sonarmodule.
•CompatiblewithAxiom™RV,Axiom™+RV,Axiom™ProRVX
MFDswhenusingadaptorcable(A80490).
•CompatiblewithElement™HVMFDswhenusingadaptorcable
(A80559).
•ConnectsdirectlytoDownVision™variantaSeriesandeSSeries
legacyMFDs.
Operationinstructions
Fordetailedoperationinstructionsforyourproduct,refertothe
documentationthataccompaniesyourdisplay.
Documentnumber:88101-2AB;22255;2020-11-16 T14:13:23Date:11-2020

Allproductdocumentationisavailabletodownloadfromthe
R
aymarinewebsite:www.raymarine.com/manuals.
Partssupplied
Thefollowingpartsaresuppliedinthebox.
Unpackyourproductcarefullytopreventdamageorlossof
parts.Checktheboxcontentsagainstthelistbelow.Retainthe
packaginganddocumentationforfuturereference.
1.In-hulltransducertube
2.In-hulltransducer
3.R-clip
L
ocationrequirements
Itisimportanttoensurethatthetransducerisinstalledinalocation
thatprovidesoptimumperformance.Followtheguidancebelow
toensureyouchooseasuitablelocation.
Forbestperformance,transducersshouldbeinstalledinalocation
withtheleastturbulenceandaeration.
TheTransducershouldbeinstalled:
•onasolidsectionofafiberglasshullthathasnocoringorairgap
•withthetransducerkeelarrowspointingtowardsthecenter
lineofthevessel
•onthedeadriseofthehullascloseaspossibletothevessel’s
centerline
•perpendiculartothevessel’scenterline
•inalocationwherethehullwillalwaysbeincontactwiththe
water
•inalocationwherewaterflowingunderthehullisleastturbulent
•inalocationwherethetransducer’sbeamwillnotbeobstructed
orreflectedbythekeel,orpropellershafts.Thetransducerhas
a25ºconicalbeamwidth:
•awayfromanyeuipmentordevicesthatmaycause
interferencesuchashighvoltagecablesorothertransducers.
Important:
DoNO Tinstallthetransducer:
•closetoorinlinewithengineintakeordischargeports.
•overanyprotrusionssuchasribsandstrakes.
•onthecoredsectionofafiberglasshull.
Transducertubeorientation
Thetransducertubemustbeinstalledperpendiculartothekeel
(centerline)ofthevessel.Thetransducertubeincludesmarkings
whichshouldpointtowardsthekeel.
Note:
Incorrectpositioningcanaffecttransducerperformance.
1.Transducertube.
2.Keelarrows.
3.Vesselcenterline.
4.Hulldeadrise
5.Keel
Thetopofthetransducertubeshouldbelevel.Thisshouldbe
checkedusingaspiritlevel.
Productdimensions
A—6m(19.69ft)Cablelength
B—76mm(2.99in)Ø
C—58mm(2.28in)0°
—80mm(3.15in)12°
E—99mm(3.90in)20°
Toolsandequipment
Thefollowingtoolsandeuipmentarereuiredtoinstallyour
transducer.
Note:
Thelistoftoolsandeuipmentbelowarereuiredforthe
recommendedinstallationasdetailedinthisdocument.
1.Anglefinder
2.Saw(finetooth)
3.Plasticbag
4.Twistties
2CPT -SIn-hullTransducerInstallationsheet

5.Carpenter’
ssuare
6.Markerpen
7.Milddetergent
8.Sandpaper
9.Discsander(maybereuired)
10.Rubbingalcohol
11.File
12.Marine-gradeneutralcurepolyurethanesealant
13.Spiritlevel
14.Fiberglassresin
15.Marineantifreeze(Propyleneglycolbasednon-toxic)
Cuttingthetransducertube
Forvesselswithaa0°or12°deadrise,thetransducertube
reuirescutting.Adigitalanglefindercanbeusedtoidentifythe
deadriseanglereuired.
Note:
Thetransducertubedoesnotreuirecuttingwheninstalling
ona20°deadrise .
1.Thecutmustbemadeasclosetothebottomoftherelevant
tubeflangeaspossible .Thedottedlinesillustratedbelow
showtherespectivecutlocations.
T estingthetransducer
Itisrecommendedthattransducerperformanceistestedpriorto
installation.Itisrecommendedthatforthetestthevesselistaken
outtothedeepestwatersitwillbeexpectedtooperatein.
1.Ensureyourdisplayhasthelatestversionofsoftware .
ChecktheRaymarinewebsiteforthelatestsoftwareforyour
products:www.raymarine.com/software
2.Decideonthebestlocationforyourtransducerbasedonthe
locationreuirementsprovided.
3.Placethetransducerinasealedplasticbagthatishalffullof
water .
4.Ensurethatthetransducerfaceiscompletelysubmergedin
thewater.
5.Connectthetransducertoyourdisplay/sonarmodule.
6.Holdthetransducerina0°positionwiththetransducer’skeel
arrowpointingtowardsthekeel.
7.Assesstheperformanceofthetransducerusingyourdisplay’s
Fishfinder/Sonarapplication.
8.Repositionandretestifnecessary.
Preparingthehullandtransducertube
Note:
Ensurethatthechosenlocationmeetsthelocationreuirements
fortheproduct:Locationrequirements
1.Cleantheareausingamilddetergenttoremoveanydirtor
grease.
2.Usingacarpenter’ssuareandmarkerpen,drawa
perpendicularlinefromthekeelthroughthecenterofthe
transducertube’sdesiredlocation.
3.Placethetransducertubeatthedesiredlocationensuringthe
keelarrowsonthetransducertubearealignedwiththeline
drawnonthehullandthatthetopofthetransducertubeis
level.
4.Holdthetransducertubeinplaceanddrawaroundthe
transducertubewithamarkerpen.
5.Sandanareaslightlylargerthanthemarkedareatoremove
anydebrisandenablegoodadhesion.
Forveryroughhulls,itmaybenecessarytouseadiscsander
tosmooththehullsurface.
6.Cleantheareawithrubbingalcoholandallowtodry.
7.Ifnecessary,redrawthelinesonthehull.
8.Ifthetransducertubehasbeencut,sandorfileanyburrsso
thatthebottomsurfaceofthetubeisflat.
9.Sandthebottomsurfaceofthetransducertubetoenable
goodadhesion.
10.Cleanthebottomsurfaceofthetubewithrubbingalcohol
andallowtodry.
Mountingthetransducertube
Followthestepsbelowtomountthetransducertube.
1.Applyacontinuousthickbeadofmarine-gradeneutral
curepolyurethanesealantaroundthebottomflangeofthe
transducertube.
CPT -SIn-hullTransducerInstallationsheet3

For20°deadriseinstallations,thebottomofthetransducer
tubehasarecessthatshouldalsobecompletelyfilledwith
marine-gradeneutralcurepolyurethanesealant.
2.Ensuringcorrectalignment,placethetransducertubein
positiononthepreparedsurface
.
3.Gentlyapplypressuretothetransducertubesothatthe
sealantprotrudesfromtheedgesofthetransducertube.
Important:
Applyingtoomuchpressuremayresultinanineffectiveseal.
4.Usingaspiritlevel,ensurethatthetopofthetransducertube
islevel;adjustifnecessary .
5.Smooththesealantaroundtheinsideandoutsideedgeofthe
transducertube.
6.Allowspecifiedcuringtimeforthemarine-gradesealant.
Curingtimewillbedependentonthesealantbeingused,but
caninsomecasesbe24to36hours.Ensureyoureadthe
sealantinstructionscarefully,andallowthefullcuringtime.
Note:
Forincreasedrigidityitisrecommendedthatfiberglassresinis
usedtostrengthenthetube-to-hullbond.
Coredfiberglasshullmounting
Thetransducerisintendedtobemountedinasolidnon-cored
sectionofthehull.
Important:
Ifyourvesselhulltypereuiresthetransducertobeinstalledin
acoredsectionofthehullthenthisshouldonlybecarriedout
byacompetentmarineinstaller .
Insertingthetransducer
Thetransducerisfittedandlock edintothetransducertube.
Important:
Ensurethatthesealanthascompletelycuredbeforeattempting
tofillthetransducertube .
1.FillthetransducertubetothefilllinewithaPropylene
glycol-basednon-to xicmarineanti-freeze.
2.Toaidtransducerinsertion,applyasmallamountofthemarine
anti-freezetothetransducer’sO-ring.
3.Alignthemarkonthetopofthetransducerwiththelocking
holeonthetransducertubeandslowlyinsertthetransducer
intothetransducertube.
Asmallamountofanti-freezemayspilloverthetopofthetube
whentheliuidisdisplacedbythetransducer.
4.Holdthetransducertubesecurelywithonehand,andusing
yourotherhandturnthetransducer45°intothelocked
position.
Becarefulwhenturningthetransducer;ensurethatthe
transducerisinsertedfullyandthatthetransducertubeisheld
securelyinplacetopreventthetransducertubefromtwisting
anddamagingtheseal.
5.InserttheR-clipintothelockingholes.
Cablerouting
Cableroutingreuirementsforthetransducercable.
Important:Toavoidinterference,thecablemustberouted
asfarawayfromVHFradioantennadevicesandcablesas
possible.
•Checkthatthecableislongenoughtoreachthedisplayitwill
beconnectedto.Optionalextensioncablesareavailable,if
reuired.
•Ensurethereisenoughslackinthetransducercable,atthe
transducerend,toallowthetransducertoinsertedandremoved
fromthetransducertube.
•Securethecableatregularintervalsusingthesuppliedcable
clips.
•Anyexcesscableshouldbecoiledupataconvenientlocation.
•DoNOTbendcablesexcessively.Whereverpossible,ensure
aminimumbenddiameterof200mm(8in)/minimumbend
radiusof100mm(4in).
Makingconnections
Followthestepsbelowtoconnectthecable(s)toyourproduct.
1.Ensurethatthevessel'spowersupplyisswitchedoff.
2.Ensurethatthedevicebeingconnectedtotheunithas
beeninstalledinaccordancewiththeinstallationinstructions
suppliedwiththatdevice.
3.Ensuringcorrectorientation,pushthecableconnectorfully
ontothecorrespondingconnectorontheunit.
4.Turnthelockingcollarclockwisetosecurethecable.
Conformancespecification
Thisproducthasbeentestedtomeetorexceedthefollowing
Standards:
BSENISO8846:2017(supersedesBSEN28846:1993)
Note:ForalistofadditionalapplicableStandards,referto
themanualapplicabletotheconnectedsonarmoduleor
multifunctiondisplay.
4CPT -SIn-hullTransducerInstallationsheet
