Flow-Rite Eagle Eye Elite IV Installation instructions

Eagle Eye Elite IV
In-Valve Battery Level Sensor with
Pro-Fill Flex and Rigid Manifolds
INSTALLATION &
OPERATION INSTRUCTIONS
for BG-C48V-11-EA-WS & BG-C48V-21-EA-WS
Contents
(1) Deep cycle battery level sensor
(1) Mounting plate
(1) Instruction sheet
(2) Zip ties
Tools Required
1/2˝ wrench
Rubber gloves
Safety glasses
1/2˝ drill bit (For remote use)
Specifications
Max current draw: 7mA
Nominal operating voltage: 12 - 48V
Operating temperature: -22°F - 158°F
Locate your main batteries (main positive and
main negative).
Probe must be installed in a non-main battery.
Main Pos
Non-Main Batteries
Main Neg
BL-642-0721
Install the valves on the rigid manifolds by
inserting and twisting in to secure.
Note: Leave battery 4 open for flex manifold.
Snap the Eagle Eye sensor in the open space
on the flex manifold.
Insert flex manifold valves into battery 4 and
twist in to secure. Attach snake tubing to the
ends of the manifold.
Sensor Valve
Secure the control box with a provided zip tie
in a secure location.
Attach the red wire to the positive terminal of the
positive main battery. Connect the black wire to
the negative of the negative main battery.
12
34
56

Flow-Rite Controls
960 74th St.
Byron Center, MI 49315
phone: [phone]
www.flow-rite.com
NOTE:
• This product is intended to monitor electrolyte levels inside of flooded lead acid batteries. Failure to use this product in
the manner intended could compromise safety protection provided by the equipment.
• Probe should be wiped clean and terminals checked for corrosion each time the battery has preventative maintenance.
Failure to follow these instructions or use of unapproved installation equipment may cause injury and permanent damage
to the product or battery. Always use personal protection equipment when working on lead-acid batteries. Never work on
batteries if they are gassing or on charge.
WARNING!
Steady green light
indicates full water
level.
Blinking red light
indicates low water level.
Only water after charging.
Feed the light through the hole and through the
slot in the mounting plate. Snap the light into
the plate, remove the adhesive backing and
secure into place.
Not compatible with Trojan®Plus Series batteries.
Mounting Option 1: To install the remote
indicator first drill a 1/2˝ hole in the desired
mounting location.
Mounting Option 2: The remote light may be
mounted to a secure location inside the battery
compartment.
BL-642 0721
78
9
FULL LOW
