Operator Manual
SEM-10 and SEM-10FT
Electronic Flow Meter

2
Safety Notices
•MISUSE AND ABUSE OF THIS METER CAN CAUSE SERIOUS INJURIES.
•READ ALL CAUTIONS AND INSTRUCTIONS BEFORE USING METER.
•INSPECT BEFORE USING AND REPLACE ANY DEFECTIVE COMPONENTS.
•EXPOSURE TO CHEMICALS CAN CAUSE SERIOUS INJURIES. ALWAYS WEAR
PROPER PROTECTIVE CLOTHING AND DEVICES WHEN METERING CHEMICALS.
•REFER TO AND FOLLOW CHEMICAL MANUFACTURER’S HANDLING
INSTRUCTIONS.
Description
Scienco Products Model SEM-10 and SEM-10FT flow meters are identical in operation and
performance. The SEM-10 is intended for fixed mounting to a pump or other device that can
provide support. The SEM-10FT is designed for mounting at hose end. The female threaded
connection on the SEM-10FT should be connected to the hose and a ball valve should be
connected to the male threaded connection.
Theory of Operation
The SEM-10/SEM-10FT flow meter is a positive displacement, nutating disk, fluid metering unit.
As fluid flows through the unit, it causes the nutating disk to move which in turn causes the
rotation of a hermetically sealed magnet disk. The meter electronic assembly counts the
number of revolutions of the magnet and mathematically determines, based on the calibration
number, the quantity of liquid that has passed through the meter. The self-contained electronic
assembly features a large Liquid Crystal Display (LCD), and simple four-button operation.
Features
•Simple, one touch operation
•Large, 0.7-inch LCD Display Characters
•Choice of three calibration modes
•Large positive touch buttons

3
Technical Specifications
Inlet Port, SEM-10 ------------------------- 1-inch Male NPT
Outlet Port, SEM-10 ------------------------- 1-inch Male NPT
Inlet Port, SEM-10FT ------------------------- 1-inch Female NPT
Outlet Port, SEM-10FT ------------------------- 1-inch Male NPT
Flow Range ------------------------- 2 to 30 GPM
Maximum Pressure ------------------------- 60 PSI (410 kPa)
Accuracy ------------------------- +- 0.5%
Maximum Total ------------------------- 999,999.9
Battery ------------------------- Lithium CR 2032 (3 Volt)
Auto Shut Off ------------------------- 40 Seconds
Auto Wake Up ------------------------- With Flow
Material of Construction
Fluid Housing/Form Cover ------------------------- Nylon or Polypropylene
Meter Chamber ------------------------- Polypropylene Sulfide
(PPS), Stainless Steel
O-rings ------------------------- Viton or EPDM
Electronic Housing ------------------------- Nylon
Screws ------------------------- Stainless Steel
Note: The Polypropylene SEM-10 and SEM-10FT is designed to pump chemicals with a low
PH. Ensure chemical compatibility between liquid metered and the meter’s wetted parts
before using.
Note: Meter should NOT be used to transfer flammable petroleum products. Do NOT use with
fluids that have a flashpoint lower than 100°F.

4
Figure 1: SEM-10
Figure 2: SEM-10FT

5
Meter Operation
Wakes up display in Current Total mode. Unit will
automatically shut off after 40 seconds with no input.
Resets Current Total to zero. Also used to enter CAL-3 mode,
and to increase the CAL
-
3 number during the
calibration
.
When depressed and held with Current Total displayed it shows Total 2.
Also used to enter the CAL-2 mode, and to decrease the CAL-3 number.
Push to enter into the three calibration modes, starting with CAL-1.

6
Operating Procedures
TO METER FLUID: With pump properly installed onto a pumping system meter will wake-up
automatically and begin to display Current Total as fluid is pumped.
TO DISPLAY CURRENT TOTAL: Press “ON” button.
TO RESET CURRENT TOTAL TO ZERO: Press and hold the “RESET” button for 3 seconds
while Current Total is displayed. Current Total is reset to “.00”. TO DISPLAY TOTAL-2; With
Current Amount showing, press and HOLD “TOTAL-2”. Total number will be displayed as long
as “TOTAL-2” is pressed. Once released Current Amount is shown. Note: Total-2 can not be
reset to zero.
TO DISPLAY FLOW RATE: With the meter on, press and hold the “ON” button for two
seconds. The display will read “FX.X”, with the numbers indicating flow rate in units of volume
per minute. To return to total volume dispensed, press and hold the “ON” button for two
seconds again.
Calibration Procedures
Model SEM-10/SEM-10FT Flow Meter has three calibration options, CAL-1, CAL-2, and CAL-3.
This flow meter can be calibrated in any unit desired (i.e. gallons, liters, pounds, acres, pints,
etc.). CAL-1 requires pumping 5 units of fluid. CAL-2 requires the pumping of a known quantity
of any units; this quantity is then entered into the electronics. CAL-3 allows calibration without
pumping fluid by manually changing the calibration constant.
Before performing meter calibration, turn pump on and purge pump and hose of all air. For best
results, calibrate at normal dispensing conditions, i.e. flow rate and pressure.
CAL-1 Calibration
1. Press “ON” button to wake up meter.
2. Press and hold the Reset button to zero (“.00”) the Current Total screen.
3. Press “CAL-1” to enter calibration sequence.
4. Pump liquid into a calibrated container that holds five units (gallons, liters, etc.). Note:
The display will blink as fluid is being pumped.
5. Press “CAL-1” to complete the calibration process. Note: The display will return to the
Current Total screen and should read previous total.

7
CAL-2 Calibration
1. Press “ON” button to wake up meter.
2. Press and hold the Reset button to zero (“.00”) the Current Total screen.
3. Press “CAL-1” to enter calibration mode.
4. Press “CAL-2” to enter calibration CAL-2 mode.
5. Dispense desired amount. Note: For greatest accuracy pump a minimum volume of 2.5
gallons or 9.5 liters. The minimum amount required is 0.5 gallons or 1.9 liters.
6. Press “CAL-1”. Note: The last volume entered will appear on the display. Example: If
you have previously calibrated on 30 quarts then “30.00” would appear. First time
default is “5.00”.
7. Press “UP or DOWN ARROW KEYS” to scroll in the amount actually pumped. Use the
desired units. Example: If you pump 2 gallons but you want the meter to display in
quarts, enter “8.00”.
8. Press “CAL-1” to enter amount and finish the calibration process. Note: The display
will return to the Current Total screen and should read previous total.
Note: “ERR” will be displayed if too few or too many counts have been received during the
calibration. You must record a volume between 0.5 to 20 units for a valid calibration. If
“ERR” is displayed no calibration change has taken place.
CAL-3 Calibration
1. Press “CAL-1” to enter calibration mode.
2. Press “CAL-3”. The current CAL-3 number will show.
3. Press the “UP or DOWN” ARROW KEYS”.
4. Press “CAL-1” to enter the new number.
Use of the “CAL-3” function will now automatically override any previous units of volume entered
if “CAL-2” mode had been used. The change prevents a conflict between the “CAL-2” units and
the “CAL-3” number, and will be transparent to users who do not use “CAL-2” for calibration.
A typical “CAL-3” number for water is 600. Recording “CAL-3” numbers for various products
dispensed after calibration, and resetting the meter to those numbers when the liquid is pumped
again is a convenient method to accurately and quickly measure various liquids dispensed.

8
Meter Installation Procedures
Flow can be metered in either direction through the SEM-10 and SEM-10FT meters.
SEM-10: Thread the meter inlet into the female discharge port of the pump. Using an elbow or
coupling, screw the discharge hose onto the other port of the meter. Use thread sealant tape,
or pipe dope to seal threaded connections.
SEM-10FT: Thread the meter inlet (female threads) onto the end of the hose. Install a 1-inch
ball valve on the meter outlet (male threads). Use thread sealant tape, or pipe dope to seal
threaded connections.
! CAUTION !
DO NOT OVERTIGHTEN THREADED CONNECTIONS.
BREAKAGE CAN OCCUR, RESULTING IN EXPOSURE TO FLUID.
! CAUTION !
DO NOT MOUNT METER IN A LOAD BEARING MANNER. EXCESSIVE LOADS CAN
CAUSE BREAKAGE, RESULTING IN FLUID EXPOSURE AND LEAKAGE.
Battery Removal/Replacement
If the LCD display becomes dim, the battery should be replaced. The meter electronics can be
removed without exposure to the fluid inside the meter.
! CAUTION !
OPEN VALVE TO RELIEVE SYSTEM PRESSURE AND DO NOT
PRESSURIZE SYSTEM DURING THIS PROCEDURE.

9
Battery Removal: To replace battery, remove the eight (8) (PH-13) screws that hold the
electronic assembly to the meter assembly. Remove the electronic housing, one battery will be
found on the back side. Remove and dispose of used battery.
Battery Replacement: Install the new battery into the batter holder. Note the polarity marking,
(+) and (-), shown for the battery. Place the gasket and electronic assembly onto the meter
assembly. Re-install the eight (8) screws to secure the electronic assembly to the meter
assembly.
Meter Chamber Removal
! CAUTION !
EXPOSURE TO CHEMICALS CAN CAUSE BODILY HARM. BEFORE DIS-ASSEMBLING,
THOROUGHLY FLUSH THE METER WITH WATER. ALWAYS WEAR GLOVES AND
PROPER EYE PROTECTION WHILE WORKING WITH CHEMICALS.
! CAUTION !
ENSURE THAT THE METER IS NOT UNDER PRESSURE BEFORE CONTINUING.
Remove the eight (8) (PH-13) screws to remove electronic assembly (S10-11 COMPLETE).
Remove the four (4) (PH-03) screws that secure the meter plate (S10-02N) to the fluid housing
(S10-05N). Remove the meter plate and O-ring (S10-03). The meter chamber can now be
removed for cleaning or replacement.
Meter Assembly Procedure
Ensure that the bottom O-ring (S10-04) is in place. Insert the meter chamber into the fluid
housing (S10-05N). Place O-ring (S10-03) around the bottom of meter plate (S10-02N) and
place on top of the fluid housing. Secure with four (4), short screws (PH-03). Torque the
screws to 25-28 inch-pounds. Install the gasket (S10-06) and the electronic assembly (S10-
01N-ASSY-R1) using the eight (8), long screws (PH-13). Torque to 25-28 inch-pounds.

10
Troubleshooting Guide
Problem: Meter reads high or low.
Solution: Check for the following:
•Ensure lines are full and there is no trapped air in the system before
calibrating.
•Pump may be sucking air due to low fluid level or bad pump inlet
connection.
•Calibrating at one flow rate and operating at a different rate. Or
calibrating on one less viscous fluid (water) while pumping another more
viscous fluid (30wt oil).
Problem: Meter flashes “ERR” at end of calibration procedures.
Solution: Check for the following:
•Meter Electronics is not sensing the rotation of the magnet. To verify no
rotation look at the CAL-1 or CAL-2 while fluid is being pumped through
meter, if it does not “BLINK” then the electronics is not sensing rotation.
Disassemble meter and clean out or replace the meter chamber (SEM-10
KIT).
•Volume dispensed to calibrate is too small or too large. Must dispense a
volume of at least 2.5 gallons, and no larger than 70 gallons.
Problem: No liquid will pass through the meter or the meter will not register the
flow.
Solution: Foreign material is in the metering cartridge and is obstructing flow or
preventing the nutating disk from moving freely. Remove the meter
cartridge and clean.
Problem: The meter will not power up or the display appears dim.
Solution: Replace the battery.
For additional Trouble Shooting Questions please call
Flowserve-Scienco Technical Service & Support: 1-800-343-PUMP (7867)

11
Parts List and Parts Diagram
Note: All parts are common to the polypropylene
SEM-10 and SEM-10FT except the fluid housing.
For additional assistance please call
Flowserve-Scienco Sales Department: 1-800-343-PUMP (7867)
Polypropylene/Nylon SEM-10/SEM-10FT Parts L st
Qty. Part No. Description
8 PH-13 SS. Screw, Long
1 S10-11 COMPLETE Electron cs Assembly
1 S10-12 Meter Gasket
4 PH-03 SS. Screw, Short
1 S10-02 Meter Plate
1 SEM-10 KIT-2
Meter ng Chamber
K t:
S10-03 or S10-07
S10-04 or S10-08
SFM10000-01
SFM10000-02
SFM10000-03-0A
S10-14
1 S10-05/05N
SEM-10 Flu d
Hous ng
1 S10-10/10P
SEM-10FT Flu d
Hous ng

12
Figure 3: SEM-10 and SEM-10FT Parts Diagram
Note:
S10-05N is 90°Nylon Housing
S10-10 is Nylon flow through Housing
S10-10P is Polypropylene flow through Housing

13
Product Warranty
Flowserve Corporation (the Company) warrants that the Equipment will be free of defects in
material and workmanship for a period of twelve months from the date of placing the Equipment
in operation or eighteen months from the date of shipment, whichever shall first occur. Parts
shall be warranted for a period of six (6) months from date of shipment. The Purchaser shall
promptly report any failure to conform to this warranty, in writing to the Company within said
period, whereupon, the Company shall, at its option, repair the Equipment or furnish a
replacement part F.O.B. point of shipment, provided the Purchaser has stored, installed,
maintained and operated the Equipment in accordance with good industry practices. The
Company shall not be liable for any repairs, replacements, or adjustments to Equipment or any
cost of labor performed by the Purchaser or others.
The effects of corrosion, erosion and normal wear and tear are specifically excluded.
The Company makes no other warranty or representation whatsoever, expressed or implied,
except that of title, and all implied warranties of merchantability and fitness for a particular
purpose, are hereby disclaimed.
Technical Service & Support
3732 Cook Blvd. Suite 101
Chesapeake, VA 23323-1628 USA
Telephone: [phone] (343-PUMP)
Fax: [phone]
Website: www.flowserve.com
Email: [email protected]
Revised 4/2014
