Fluid Management HARBIL 5G User manual

HARBIL5GHighSpeedPaintMixer
with 8 -Minute Timer
EndUserGuide
Part
No:
24018
Rev
.J10.20

Your
customers have a vision,
you want to make it happen, and
Fluid Management can give you the answer.
Fluid Management is a global leader in dispensing
and mixing equipment used in the paint industry, as
well as, specialized equipment for the food and beverage,
chemical, health and beauty, and home improvement industries.
Located in the suburbs of Chicago, Illinois, Fluid Management is
a United States owned and operated company with historical roots
to the paint industry dating back to 1927. In 1996, IDEX Corporation
purchased Fluid Management giving the organization the financial
wherewithal and global footprint of a large organization while still maintaining
its deep values and history.
As industry leaders, Fluid Management provides trend-setting creativity in the
design, products, and services it offers. United with FMDirect, our nationwide
service team, we provide after-sales support around the clock—when you need
them. Being factory-direct employees, FMDirect technicians are experts on Fluid
Management equipment and understand customer needs from start to finish.
The combination of leading edge technology, excellent service and support, and
a company prepared for the future’s ever-changing business environment makes
Fluid Management an ideal partner to assist in providing solutions to your business
needs. Thank you for putting your trust in Fluid Management products and making
us part of your customer’s vision.

©2014 Fluid Management as published work all rights reserved.
Under the copyright laws, this material may not be copied, in whole or in part, without
the written consent of Fluid Management.
Your rights to the software are governed by the accompanying software license
agreement.
Use of Fluid Management trademarks, service marks, or logos for commercial purposes without
the prior written consent of Fluid Management may constitute trademark infringement and unfair
competition in violation of federal and state laws. Fluid Management, FMDirect, ColorPro,
DVX, Harbil, Blendorama, Accutinter, Duraflow, Fast & Fluid Management, GyroDispenser, Infina,
MicroTint,TintMaster, V1,and VR1are trademarks of Fluid Management, registered in the U.S.
and/or other countries.
Every effort has been made to ensure that the information in this guide is accurate.
Fluid Management is not responsible for printing or clerical errors.
Fluid Management
1023 Wheeling Road
Wheeling, Illinois 60090-5776 USA
800-462-2466
http://www.fluidman.com
Published in the United States.
Mention of third-party products is for informational purposes only and constitutes
neither an endorsement nor a recommendation. Fluid Management assumes no
responsibility with regard to the performance or use of these products.
2 | Harbil 5G Mixer 
Fluid Management Customer Service 1.800.462.2466

Contents

Safety Information
4 Mixer Warning Labels
5 Safety Notice Information
Introduction
6 Product Descriptions
7 Equipment Maintenance Log
8 Spare Parts Order
Unpacking Directions
9 Inspect the Crate for Damage
9 Unpacking and Setup
Electrical Conditions
10 Grounding
10 Danger
Aligning and Leveling Mixer
11 Aligning the Struts
11 Leveling
12 Remove Shipping Inserts
Getting to Know Your Paint Mixer
13 General Locations
14 Control Panel
14 Revisable Door
Important Information
15 Warnings
15 Cautions
Basic Operation
16 Basic Operation Procedure
Operational Test
19 Operational Test Procedure
Maintenance Procedures
20 General Lubrication
21 Super-Struts Lubrication
Troubleshooting
22 Troubleshooting Tables
Servicing and Repair
26 General Information
26 Safety Procedure
Opening Mixer
27 Remove the Exterior Panels
FFlluuiidd MMaannaaggeemmeenntt CCuussttoommeerr SSeerrvviiccee 11..880000..446622..22446666
Removing Shake Frame
28 Removing Shake Frame Procedure
30 Remove the Counterweights
Testing Shake Motor
32 Testing Shake Motor Procedure
Changing Shake Motor
33 Changing Shake Motor Procedure
Changing the V-Belt
34 Changing the V-Belt Procedure
Removing Circuit Board
35 Removing Circuit Board Procedure
Installing Rubber Pads
36 Installing Rubber Pads Procedure
Replacing/Adjusting DC Motor
38 DC Clamping Motor Replacement/Adjustment
Adjusting Clamping Force
39 Clamping Force Adjustment Procedure
Reversing Door
42 Reversing Door Procedure
Replacing Super-Struts
44 Removing the External Panels
44 Removing the Super-Struts
47 Installing the Super-Struts
Replacing Crankshaft
50 Access the Crankshaft
50 Remove the Crankshaft
51 Install New Crankshaft
Reassembling Mixer
53 Reassembling Mixer Procedure
54 Test Procedure
Parts Section
55 Sheet and Metal Outer Frame
59 Control Box Assembly
61 Inner Frame
63 Shake Frame
65 Clamping Motor Assembly
69 Top Plate Assembly
70 Crankshaft Assembly
Warranty
76 Paint Equipment Limited Warranty
Harbil 5G Mixer | 3

Safety Information

Safety
Information
Mixer Warning Labels
You should become familiar with important warning labels which are affixed to the
mixer, as well as the symbols which appear throughout this manual. These warnings
have been included to help you safely perform your job.
Please read all warning labels that are on the mixer. Keep them clean so they are
easy to read. If the warning labels become damaged or unreadable, new labels can
be purchased from Fluid Management. See the parts list in the back of the manual
for ordering information.
Safety Notice Information
The two main safety notices used in this manual are Warning and Caution. Notices in
this manual will look like the example below.
Warning Notice
ELECTRICAL HAZARD
Do not operate the mixer with the door
open. Disconnect power before servicing.
WARNING
A Warning notice tells you about a hazard that could cause serious injury to you or
extensive damage to the mixer. This information is placed at the beginning of the
manual to emphasize the importance of safety to your well being.
When you see a Warning notice in this manual, read it carefully. Before continuing
with the operation of the mixer, take all necessary precautions to avoid potential
injury.
Caution Notice
CAUTION
ELECTRICAL HAZARD
All electrical components must be kept
dry. Never place containers of liquid on
or near the control box.
A Caution notice tells you about a danger that could cause injury to you or minor
damage to the mixer. When you see a Caution notice in this manual, read it carefully
and be sure you understand it before continuing.
4 | Harbil 5G Mixer 
Fluid Management Customer Service 1.800.462.2466

Safety Information

Information Notice
Note: If the cabinet vibrates, loosen the locking nuts on the right
front leveling foot and slightly adjust the length.
An Information notice gives details that will assist you in efficiently using the mixer.
When you see an Information notice in this manual, know that it is there to save you
time and energy.
Compliance Information
See the affixed labeling on the machine for safety and regulatory compliance
information. ETL Listed, conforms to UL STD 1450. Certified to CAN/CSA STD
C22.2 No.68 (120 V model only).
Fluid Management Customer Service 1.800.462.2466 Harbil 5G Mixer | 5

Introduction
Introduction The Harbil 5G High Speed Paint Mixer is a versatile, automatic mixer designed with
concern for safety, reliability and ease of use. Its features include:
• Heavy-duty, high-capacity components and adurable finish forlong
wear.
•Vibration-free mixing for blending and conditioning paint.
•Versatile mixing times from 30seconds to 8minutes
•Handles pint, quart, gallon, and 5-gallon containers.
Important safety features are:
• Automatic shut off if the door is opened during the shaking operation.
• Fully visible red STOP switch for emergency shut off.
Product Description
Specifications
Height 45.5” (115.6 cm)
Width 28” (71.0 cm)
Depth 28” (71.0 cm)
Weight 470 lb (213.2 kg)
Contain Capacity
Maximum height 17.5” (44.5 cm.)
Minimum height 0.5” (1.3 cm)
Diameter 13.5” (34.3 cm)
Typical Electrical Supply
See name plate for specific information.
120 V ± 10%, 60 Hz, 11.8 A
220 V ± 10%, 50 Hz, 6.0 A
6 | Harbil 5G Mixer Fluid Management Customer Service 1.800.462.2466

IntroductionIntroduction
EQUIPMENT MAINTENANCE LOG
RECORD MODEL NUMBER HERE:
RECORDSERI t\L NUMBERHERE:
SERVJCE
DESCRIPTION & PARTS REl'LACED
SERVICED
D
ATE
·tA'ff! Jf' (!Nfll?tl \\'All.¥1.A.,-a' V)
B
Y
Fluid Management Customer Service 1.800.462.2466 Harbil 5G Mixer | 7

Unpacking Directions
SPARE PARTS ORDER
Fluid Management Parts Order Form
Photocopy and use this form to
Mail or fax orders to:
Fluid Mangement A unit of IDEX Phone: [phone]
1023 Wheeling Road Fax: [phone]
Wheeling, IL 60090
Sold To: Ship To:
________________________ ________________________
________________________ ________________________
________________________ ________________________
________________________ ________________________
PurchaseOrder Number _____________________
Ship via: ________________________________ Collect ___________ Prepaid_______________
Taxable: Y_______ Tax Exempt: Y____________(Fax copy of exemption certificate)
Comments: _____________________________________________________
_____________________________________________________
______________________________ ____________
Signature Date
Harbil 5G Mixer | 8 Fluid Management Customer Service 1.800.462.2466
QllANIITY
PART
NUMBER
OESCRIPTI01'
UNIT
PRICE
s
s
s
s
s
s
s
s
s
>
s

Unpacking Directions
Inspect the Crate for Damage
IMPORTANT If any damage is found, notify the carrier at once
and arrange for inspection in order to claim
recovery. Claims for damage must be made by
the consignee (You). The carrier assumes full
responsibility upon acceptance of shipment and
will not entertain any claims by the consignor
(Fluid Management).
Unpacking and Setup
Refer to the Unpacking and Setup Instructions affixed to the shipping carton in a
mailing pouch.

Fluid Management Customer Service 1.800.462.2466 Harbil 5G Mixer | 9

Electrical Connections
Electrical
Connections The unit must be plugged into a dedicated electrical line
with no other equipment using the same circuit. DO NOT
use an adapter or extension cord with this product.
CAUTION
Improper use of the grounding plug can result in a risk
of electric shock.
WARNING
Grounding
This product must be grounded. In the event of an electrical short circuit, grounding
reduces the risk of electrical shock by providing an escape for the electric current.
This product is equipped with a cord that has a grounding wire and an appropriate
grounding plug. The plug must be inserted into an outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
Check with a qualified electrician or service person if
grounding instructions are not completely understood or
if in doubt as to whether product is properly grounded.
WARNING
Danger
Improper installation of the grounding plug can result in a risk of electric shock. If
repair or replacement of the cord or plug is necessary, do not connect the grounding
wire to either flat blade terminal. The insulation wire with green or green and yellow
stripes on the outer surface is the grounding wire. Check with a qualified electrician
if the grounding instructions are not completely understood, or if in doubt about
whether the product is properly grounded. DO NOT modify the plug provided. If it will
not fit into the outlet, have the proper outlet installed by a qualified electrician.
10 | Harbil 5G Mixer

Fluid Management Customer Service 1.800.462.2466

Aligning and Leveling Mixer
Aligning the Struts
1. Make sure that the power is removed from the mixer.
2. Remove the top cover of the unit. Save the screws.
3. Check the inner frame and struts by grasping the frame at the top.
Vigorously rock the frame back and forth to see that all struts move freely on
their supports. No kinking in the springs should occur at the bottom of the
struts. The shake frame will return to the center position and appear level
when it comes to rest.
4. If one or more of the struts is not seated properly, it (they) can be realigned
as follows:
•Remove the upper rear cabinet (sheet metal covering). See Figure 5,
“Removing the Mixer Covers” on page 27.
• Raise the inner frame closest to the unseated strut. The frame should be
high enough for the strut pin to clear the strut body.
•Carefully lower the frame while guiding the pin into the strut body.Take care
not to raise the frame so high that the other struts become unseated.
•Repeat this procedure for each misaligned strut.
5. Move the mixer to its permanent, leveled area. Leave ample room around
the paint mixer to facilitate maintenance and safe operation.
Leveling
Although the mixer is leveled by the manufacturer, variations in floor surfaces may
necessitate further adjustment.
Aligning and
Leveling
Mixer
WARNING
Improper leveling may cause severe damage to the
paint mixer when in mixing operation.
1. Level the mixer by adjusting the 4 feet as necessary.
2. Lock the feet into place by tightening the lock nut to the frame insert.

Fluid Management Customer Service 1.800.462.2466 Harbil 5G Mixer | 11

Aligning and Leveling Mixer
Remove Shipping Inserts
After you have plugged the mixer into a dedicated power line and leveled it, inspect
to be sure that you have removed the shipping materials inside the mixer.
1. Make sure the front door of the paint mixer is closed. A safety switch
prevents the operation of the paint mixer while the door is open.
2. Apply power to the paint mixer by placing the POWER switch in the ON
position.
3. Turn the button labeled EMERGENCY STOP clockwise until the button pops
out to the ON position. If the button does not turn, then it is already in
the ON position. To stop or turn off the paint mixer, push the button to
the OFF position.
4. Push the UP button. Wait several seconds until the top plate raises high
enough for you to remove the shipping inserts.
5. Open the front door of the paint mixer. Remove the shipping inserts and the
wooden disc insert. If there is not enough room to remove the inserts,
then push the UP button again.
6. Be sure that you save the plywood and the foam rubber discs. These will be
used with 5-gallon pails.
7. Before performing an operational test, read the following information Getting
To Know Your Mixer.
12 | Harbil 5G Mixer Fluid Management Customer Service 1.800.462.2466

Getting to Know Your Paint Mixer
General Locations
• CONTROL PANEL – All controls are in one location.
•DOOR SAFETY SWITCH – The Door must be closed continuously to operate
the paint mixer.
•WARNING STICKERS – Read these important messages for YOUR safety.
• ADJUSTABLE FEET – The leveling feet adjust in order to level the mixer.
Getting to
Know Your
Paint Mixer
Control Panel
Safety Label
Safety Label
Door Safety Switch
Hinge
Door Handle
Door
Adjustable Foot Adjustable Foot
Figure 1. General Locations

Fluid Management Customer Service 1.800.462.2466 Harbil 5G Mixer | 13

Getting to Know Your Paint Mixer
Control Panel
• EMERGENCY STOP button for quickly stopping the mixer.
•POWER rocker switch for applying power to the machine.
•UP button for raising the toppressure plate.
•START button for activatingthe mixer.
•TIMER for setting the desired mix time from 30 seconds to 8minutes.
Note
Figure 2. Control Panel
Reversible Door
The door on the mixer can be easily reversed using a slotted screwdriver.
Instructions for reversing the door are found in the maintenance section of this
documentation.

Getting to
K
now
Y
our Paint Mixer
14 | Harbil 5G Mixer Fluid Management Customer Service 1.800.462.2466

Important Information
Before operating the mixer, carefully read the following important information.
Warnings
• Verify that your paint mixer is properly levelled. Improper leveling may cause
severe damage to the machine during the mixing operation.
•Always shut off the master POWER switch and unplug the mixer from the AC
power outlet before servicing the paint mixer.
•THIS MACHINE IS NOT EXPLOSION-PROOFAND MUST NOT BE USED IN
AFLAMMABLEATMOSPHERE.
Cautions
• Do not run the paint mixer without a container in place.
• Do not mix more than one full case (four 1-gallon cans) of paint at one time.
The maximum weight limit is 80 pounds for paint and 60 pounds for
stucco mixture. See BASIC OPERATION, Figure 3, “Gallon Can
Placement” on page 16.
•On 5-gallon metal containers, use the flake-board disc for recessed bottoms
that do not have a center support. Use the discs for recessed tops.
See BASIC OPERATION, Figure 4, “5-Gallon Container Cut-Away
View” on page 17.
•On 5-gallon plastic containers, use the foam discs for the recessed tops
around the bung hole. Do not use the flake board disc on plastic
containers.
Important
Information
Fluid Management Customer Service 1.800.462.2466 Harbil 5G Mixer | 15

Basic Operation
Basic
Operation
Open the door. If you need to raise the top plate to accommodate the container to
be mixed, turn on the POWER switch and push the UP button. Wait a few seconds
until the UP light goes out. This will raise the top plate about two inches. Repeat if
necessary.
To quickly stop the machine, push the EMERGENCY
STOP button. If you open the door during the operation,
the paint mixer will stop.
Note
1. After opening the front door, place the container(s) near the center of the
table. The diagram below illustrates the proper gallon can placement.
Cans must be removed from cardboard case before mixing.
2 Gallon Cans
Lead Screw Centerline
3 Gallon Cans
Lead Screw Centerline
4 Gallon Cans
Lead Screw Centerline
Figure 3. Gallon Can Placement
16 | Harbil 5G Mixer

Fluid Management Customer Service 1.800.462.2466

Basic Operation
2. When using 5-gallon plastic or metal containers with recessed lids, place the
foam disc on top of the container even with the rim.
Note: Both thick and thin discs come with the mixers. Foam discs
eliminate flexing of the container. On metal containers with
recessed bottoms and no center support, place the flake
board disc underneath the container.
Foam Rubber Pad
Used with plastic or metal container.
Flake Board Disk for
metal containers only
5 Gallon Container
Table
Figure 4. 5-Gallon Container Cut-Away View
3. Close the door firmly. The paint mixer will not operate with the door
open.
4. Set the timer on the control panel to the desired shaking time.
5. Apply power to the mixer by pressing the POWER rocker switch to the ON
position and turning the EMERGENCY STOP button clockwise until it pops
out to the ON position. If the button does not turn, then it is already in the
ON position. To stop the paint mixer, depress the EMERGENCY STOP
button.
Fluid Management Customer Service 1.800.462.2466 Harbil 5G Mixer | 17
