Flux Reference Series User manual

COMPONENT SPEAKER
INSTALLATION MANUAL
Reference Series
RC 261
Maestro Competition Series
MC Comp 261

Passive Crossover
WARNING
Attention
Please read all the warnings that can be found in this manual. You can
install all components in your vehicle and experience an ultimate step by
step car audio instalation procedure with proper mechanical and electri-
cal instalations.
Hearing Damage
Continuous, excessive exposure to sound pressure levels in excess of
85dB can cause a loss of hearing. FLUX Components are capable of
producing sound pressure levels greater than 85dB.
Volume and Driver Awareness
Use of sound components can impair your ability to hear necessary traf-
fic sound and may constitute a hazard while driving your vehicle. FLUX
except no liability for hearing loss boardly injury or property damage as
result of use or missused of this product.
Congratulations
You already bought one of the best German Car Hifi Component loud-
speaker System. With our special treated coated paper cone woofer, and
the light silk dome neodymium tweeter and the latest vehicle adaptive
crossover technology, you will get the maximum listening pleasure and
ultimate sound reproduction you ever hear.
Warranty Return
FLUX product guarantee only applies if the enclosed guarantee card is
retruned to us and our dealer within you buy this product, maximum 10
(ten) day of purchase.
1

Passive Crossover
FEATURES AND CONTENTS
Product Features
- Reference Series (RC 261)
FLUX T 160 R2 • 6.5” midwoofer, 4 layer (paper+glass fiber+silk+ceramic) cone
• 37mm v/c with 90mm magnet diameter
• Aluminium die cast basket, vented basket
• copper phase plug
FLUX HT 25 R • 28mm v/c with special hand coated silk dome
• Duralium housing, screw connector
• Vented magnet with additional rear chamber
FLUX XR 261 • 2 way passive crossover for RC 261
• Real 24 KT gold plated
• Double sided PCB with 2 OZ copper thickness to maximize signal transfers
• Multiple setting Combination , to get the Best tonal accuracy and to
facilitate the sound setting
• Using selected silver solder to maximize contacts
• Selectable input for single or dual amplifiers
FLUX 160 MC2 • 6.5” midwoofer, triple sandwich (paper+glass fiber+silk) cone
• 37mm v/c with 90mm magnet diameter
• Auminium die cast basket, vented basket
• Aluminum phase plug
FLUX HT 25 MC • 25mm v/c with special hand coated silk dome
• Duralium housing, screw connector
• Vented magnet with additional rear chamber
FLUX XMC 261 • 2 way passive crossover for RC 261
• Real 24 KT gold plated
• Double sided PCB with 2 OZ copper thickness to maximize signal transfers
• Multiple setting Combination , to get the Best tonal accuracy and to
facilitate the sound setting
• Using selected silver solder to maximize contacts
• Selectable input for single or dual amplifiers
- Maestro Competition Series (MC Comp 261)
2

Passive Crossover
Getting Started
It is recommended that your new FLUX speakers are installed by an autho-
rized FLUX Authorized Dealers. This will ensure the use of proper installa-
tion techniques and material and will save you a lot of time and efforts.
Do not use your car until all component of the loudspeaker system have
been secured to the interior framework. Failure to do so, may cause danger-
ous to a vehicle flying projectitle during a sudden stop or accident.
Do not drill or drive screws through any vehicle interior or carpeted floor
before inspecting the underside for potential punctures to control lines or
cables. Take extreme care when working near the fuel tank, gas lines brakes
or hydraulic lines and electrical wiring.
Turn off the audio system. It is also advisable to disconnect the negative
[ - ] terminal of your vehicle battery whenever performing installation
work. If the installation finished turn on the various components and slowly
advance the volume.
Remember to check and re-check all connections to insure proper installa-
tion and use.
Do not exceed the indicated maximum operational power.
Please make sure the same polarity in loudspeaker, crossover and ampli-
fier are guaranted. if speakers are wired out of phase, an unnatural sound
without bass is the result.
INSTALLATION
3

Passive Crossover
Positioning & Choosing a Location
Using a component speaker gives you the freedom to place the woofer
and tweeter separately in your car. It could be good or bad in terms of
sound quality, it depends where you put it.
2 Way Speaker System
2 way speaker system tweeter and midbass drivers are supported.
commonly tweeter positioned on the dashboard in the A pillars, while
the midbass in the doortrim or placed under the door panels because the
size are big enough. Placement on the pillar A tweeters did not take place
on the dashboard and relatively unobtrusive view. This system is most
commonly used, because these systems are the simpliest. 2 way speaker
prices generally cheaper than a 3 way system and plenty of options, that
would also depend on the brand and type.
4
Woofer
6”
Woofer
6”
Midrange
3”
Tweeter
Tweeter

Installation Components
Installation Using 1 Amplifier
XR 261
+ -
+ -
+ -
Input Jumper Position
Single Amp (1Amp)
Input jumper position
Single Amp (1 Amp)
WARNING
Jumper configuration for Bi Amp input must be installed correctly
or You can damage the Amplifier!!!
HT 28R
T 160 R2
Reference Series [RC 261]
6
Amplifier

Installation Using 2 Amplifier
XR 261
+ -
+ -
Input Jumper Position
Bi Amp (2 Amp)
Input jumper position
Bi Amp (2 Amp)
WARNING
Jumper configuration for Bi Amp input must be installed correctly
or You can damage the Amplifier!!!
T 160 R2
Installation Using 2 Amplifier
Installation Using 2 Amplifier
Installation Components
Installation Using 1 Amplifier
HT 28R
Reference Series [RC 261]
7
+ -
Woofer
Amplifier
+ -
Tweeter
Amplifier

Standard Jumper Settings
XR 261
TWEETER
0 -3 -6 -9 1 2 3 1 2 1 2 1 2 3 1 2 3
LEVEL ( dB ) FREQ Q FREQ Q LEVEL Q
WOOFER
Jumper positions are attached,
you can still change it based on
your style of sound. Or it can be
adapted to the conditions.
TWEETER
0 -3 -6 -9 1 2 3 1 2
LEVEL ( dB ) FREQ Q
1 2 1 2 3 1 2 3
FREQ Q LEVEL Q
WOOFER
Reference Series [RC 261]
8

Tweeter Setting RC 261
LEVEL
1 2 3 4
0 dB
-3 dB
-6 dB
-9 dB
FREQ
1 2 3
1 2 3 4
LEVEL (dB)
1 2 3
FREQ
Q
1 2
1 2
Q
Reference Series [RC 261]
9

Woofer Setting RC 261
1 2 3
Q LEVEL
1 2 3
Q LEVEL
FREQ
1 2 3
1 2
FREQ
1 2 3
Q
1 2 3
Q
Reference Series [RC 261]
10

Installation Components
Installation Using 1 Amplifier
XMC 261
+ -
+ -
Input Jumper Position
Single Amp (1Amp)
Input jumper position
Single Amp (1 Amp)
WARNING
Jumper configuration for Bi Amp input must be installed correctly
or You can damage Amlifier!!!
HT 25 MC
T 160 MC2
Maestro Competition Series [MC Comp 261]
11
+ -
Amplifier

Installation Using 2 Amplifier
XMC 261
+ -
+ -
Input Jumper Position
Bi Amp (2 Amp)
Input jumper position
Bi Amp (2 Amp)
WARNING
Jumper configuration for Bi Amp input must be installed correctly
or You can damage the Amplifier!!!
Installation Using 2 Amplifier
Installation Using 2 Amplifier
Installation Components
Installation Using 2 Amplifier
HT 25 MC
T 160 MC2
Maestro Competition Series [MC Comp 261]
12
+ -
Woofer
Amplifier
+ -
Tweeterv-
vaaa
Amplifier

Standard Jumper Settings
XMC 261
TWEETER
0 -3 -6 -9 1 2 3 1 2 1 2 1 2 3 1 2 3
LEVEL ( dB ) FREQ Q FREQ Q LEVEL Q
WOOFER
Jumper positions are attached,
you can still change it based on
your style of sound. Or it can be
adapted to the conditions.
TWEETER
0 -3 -6 -9 1 2 3 1 2
LEVEL ( dB ) FREQ Q
1 2 1 2 3 1 2 3
FREQ Q LEVEL Q
WOOFER
Maestro Competition Series [MC Comp 261]
13

Tweeter Setting XMC 261
LEVEL
1 2 3 4
0 dB
-3 dB
-6 dB
-9 dB
FREQ
1 2 3
1 2 3 4
LEVEL (dB)
1 2 3
FREQ
Q
1 2
1 2
Q
Maestro Competition Series [MC Comp 261]
14

Woofer Setting XMC 261
1 2 3
Q LEVEL
1 2 3
Q LEVEL
FREQ
1 2 3
1 2
FREQ
1 2 3
Q
1 2 3
Q
Maestro Competition Series [MC Comp 261]
15

Ringstrasse 20 | 85386 Eching | Germany Email : info@flux-audio.com | Website : www.flux-audio.com
