FMI UV32C Quick start guide

Save this manual for future reference.
WARNING:Iftheinformationinthismanualisnotfollowed
exactly, a fire or explosion may result causing property
damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a
qualifiedinstaller,serviceagency,orthegassupplier.
WARNING: Improper installa-
tion, adjustment, alteration, ser-
vice, or maintenance can cause
injury or property damage. Re-
fer to this manual for correct
installation and operational pro-
cedures.Forassistanceor addi-
tionalinformationconsultaquali-
fied installer, service agency, or
the gas supplier.
WARNING: For use only with
decorative type unvented room
heaters.Donotbuildawoodfire.
This firebox may be installed in an aftermarket* manufactured (mobile) home, where not prohibited
by state or local codes.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer (i.e. Installation of this product is
permitted after the manufactured (mobile) home is sited).
UV32C (shown)
Circulating
Louvered and
RUV32 Non-
circulating
Smooth Face
Models
OWNER’S OPERATION AND INSTALLATION MANUAL
®
This firebox has been tested
and approved by I.A.S. under
theirREQ.2-97foruse withany
ANS Z21.11.2 approved gas
logs.
UNVENTED (VENT-FREE)
32" UNIVERSAL FIREBOX
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,

2
105383
UV32C and RUV32 UNVENTED 32" FIREBOX
FIREPLACE MANUFACTURERS INC.
1. This firebox shall not be installed in a
bedroom or bathroom.
2. Never install the firebox
• in a recreational vehicle
• wherecurtains,furniture, clothing, or
otherflammableobjects are less than
36inchesfrom the front, top, orsides
of the firebox
• in high traffic areas
• in windy or drafty areas
3. Do notusethis firebox as a wood-burn-
ing fireplace. Use only decorative
unvented room heaters (log sets).
4. Do not add extra logs or ornaments
suchaspine cones, vermiculite, or rock
wool. Using these added items can
cause sooting.
5. Youmustoperate this fireplacewiththe
fireplace screen, hood, and brick liner
in place. Make sure these parts are in
placeandscreens are closedbefore run-
ning firebox.
SAFETY
INFORMATION
IMPORTANT: Read this owner’s
manual carefully and completely
before trying to assemble, oper-
ate, or service this firebox. Im-
properuseofthisfireboxcancause
seriousinjuryordeathfromburns,
fire,explosion,electricalshock,or
carbon monoxide poisoning.
WARNINGS
CAUTION: Carefully review
theinstructionssuppliedwiththe
decorative type unvented room
heater for the minimum fireplace
size requirement. Do not install
the appliance in this firebox, un-
less this firebox meets the mini-
mumdimensionsrequiredforthe
installation.
WARNING: Any change to
this firebox or its controls can
be dangerous.
6. Do not allow fans to blow directly into
the firebox. Avoid any drafts that alter
burner flame patterns. Ceiling fans can
create drafts that alter burner flame
patterns. Altered burner patterns can
cause sooting.
7. Donotuseablowerinsert,heatexchanger
insert or other accessory not approved for
use with this heater. Do not use blower
accessory with Model RUV32. Use only
the provided hood or GA6096 polished
brass hood accessory (see Accessory on
page 11).
8. Vent-free gas log heaters installed in
these fireboxes require fresh air venti-
lation to run properly. See Air for Com-
bustion and Ventilation, pages 4
through 6.
9. Do not run firebox
• where flammable liquids or vapors
are used or stored
• under dusty conditions
10. Do not use this firebox to cook food or
burn paper or other objects.
11. Never place any objects in the firebox
or on logs.
12. Firebox front and screen becomes very
hot when running firebox. Keep chil-
dren and adults away from hot surfaces
toavoid burns orclothing ignition. Fire-
box will remain hot for a time after
shut-down. Allow surfaces to cool be-
fore touching.
13. Carefully supervise young children
when they are in the room with fire-
box.
14. Turn firebox off and let cool before
servicing. Only a qualified service per-
son should service and repair firebox.
15. Operating vent-free log sets in a fire-
box above elevations of 4,500 feet
could cause pilot outage.
16. Do not use the firebox if it has been
under water due to the shock hazard
that could result with the blower acces-
sary (if installed) in place.
Installandusefireplacewithcare.Followall
localcodes.Intheabsenceoflocalcodes,use
the latest edition of The National Fuel Gas
CodeANSZ223.1,alsoknownasNFPA54*.
Firebox must be electrically grounded in
accordancewiththeNationalElectricalCode,
ANS/NFPA70 (latest edition).
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
UNPACKING
1. With utility knife, cut the carton all the
way around above the staples on the
bottom tray. Lift the carton off the fire-
box. Remove packing. Note: The hood
is located in the packing on the right
hand side of the heater front. Lift the
heater off the bottom tray.
2. Check carton contents for the
following:
• Screen assembly (2)
• Screen support rod (2)
• Hood
• Hardware and parts bag containing
the following:
- Owners Operation and
Installation Manual
- 2 - Black #10 x 3/8" Phillips
screws
- 3 - Zinc #10 x 1/2" shouldered
hex screws
- 2 - Black #10 x 5/8" shouldered
hex screws
If any items are missing, inform
dealer where you bought firebox.
3. Check all items for any shipping dam-
age. If damaged, promptly inform
dealer where you bought firebox.
LOCAL CODES

3
105383
OWNER’S MANUAL
PRODUCT
SPECIFICATIONS
Figure 2 - Firebox Side View
Gas Line Access
35
1
/ 16 "
31
3
/ 4 "
16
1
/ 4 "
2
3
/ 4 "
2
3
/ 4 "
6
3
/ 8 "
19
3
/ 8 "
Figure 1 - Firebox Front View
Built-in
Nailing
Flanges
Standoffs (Model
RUV32 only)
Louvers
(Model UV32C only)
12
1
/ 2 "
2
3
/ 4 "
1
1
/ 2 "
9
3
/ 4 "
4
5
/ 8 "
2
1
/ 2 "
6"
32
3
/ 16 "
33
11
/ 16 "
Standoffs
(Model RUV32 only)
Electrical
Access Hole Electrical Access Hole with Bushing
22
1
/ 2 "
16
11
/ 16 "
31
5
/ 8 "
34
3
/ 8 "
35
5
/ 8 "
19
1
/ 4 "
Figure 3 - Firebox Top View

4
105383
UV32C and RUV32 UNVENTED 32" FIREBOX
FIREPLACE MANUFACTURERS INC.
Today’s homes are built more energy effi-
cient than ever. New materials, increased
insulation, and new construction methods
helpreduceheatlossinhomes.Homeowners
weatherstrip andcaulkaroundwindowsand
doorstokeepthecoldairoutandthewarmair
in. During heating months, home owners
want their homes as airtight as possible.
While it is good to make your home energy
efficient,yourhomeneedstobreathe.Fresh
air must enter your home. All fuel-burning
appliances need fresh air for proper com-
bustion and ventilation.
Exhaustfans,fireboxes, clothes dryers, and
fuel burning appliances draw air from the
house to operate. You must provide ad-
equate fresh air for these appliances. This
will insure proper venting of vented fuel-
burning appliances.
PROVIDING ADEQUATE
VENTILATION
The following are excerpts from National
Fuel Gas Code. NFPA 54/ANS Z223.1, Sec-
tion5.3,AirforCombustionandVentilation.
Allspacesinhomesfallintooneofthethree
following ventilation classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 4 through 6 will
help you classify your space and provide
adequate ventilation.
Unusually Tight Construction
The air that leaks around doors and win-
dows may provide enough fresh air for
combustion and ventilation. However, in
PRODUCT
FEATURES
Operation
This firebox is designed for use with ap-
proved ANS Z21.1.2 decorative type
unvented room heaters. (Physical size limi-
tations apply. Refer to minimum firebox
requirements supplied with log heater.) It
requiresnooutsideventingorchimneymak-
inginstallationeasyandinexpensive.When
used without the blower (model UV32C
only), the firebox requires no electricity
makingitidealforemergencyback-upheat.
Blower Accessory
TheUV32CfireboxwillaccepttheFA3700
accessory. The variable blower allows you
toselectthefanspeedyoudesire.Theblower
circulates heated air from the firebox into
the room. Use of blower is optional.
LOCATING
FIREBOX
Planning
Planwhere youwill installthe firebox.This
will save time and money later when you
install the firebox. Before installation, con-
sider the following:
1. Where the firebox will be located. Al-
lowforwall and ceiling clearances (see
Installation Clearances, page 7).
2. Everything needed to complete instal-
lation.
3. These models CANNOT be installed
in a bedroom or bathroom.
4. Proper air for combustion and ventila-
tion (see below).
AIR FOR
COMBUSTION AND
VENTILATION
WARNING: This firebox shall
notbeinstalledinaconfinedspace
or unusually tight construction
unless provisions are provided
foradequatecombustionandven-
tilation air. Read the following in-
structions to insure proper fresh
air for this and other fuel-burning
appliances in your home.
buildings of unusually tight construction,
you must provide additional fresh air.
Unusually tight construction is de-
fined as construction where:
a. walls and ceilings exposed to the
outside atmosphere have a con-
tinuous water vapor retarder with
a rating of one perm (6x10-11 kg
per pa-sec-m2) or less with open-
ings gasketed or sealed and
b. weather stripping has been
added on openable windows and
doors and
c. caulking or sealants are applied
to areas such as joints around
window and door frames, be-
tween sole plates and floors,be-
tween wall-ceiling joints, be-
tween wall panels, at penetra-
tionsforplumbing,electrical,and
gas lines, and at other openings.
If your home meets all of the three
criteria above, you must provide ad-
ditional fresh air. See Ventilation Air
From Outdoors, page 6.
If your home does not meet all of the
three criteria above, proceed to Deter-
mining Fresh-Air Flow For Firebox
Location , page 5.
Confined Space and Unconfined
Space
TheNationalFuelGasCode(ANSZ2123.1,
1992 Section 5.3) defines a confined space
as a space whose volume is less than 50
cubicfeetper1,000Btuperhour(4.8m3per
kw) of the aggregate input rating of all
appliances installed in that space and an
unconfined space as a space whose volume
is not less than 50 cubic feet per 1,000 Btu
per hour (4.8 m3per kw) of the aggregate
inputratingofallappliancesinstalledinthat
space.Rooms communicatingdirectly with
the space in which the appliances are in-
stalled*, through openings not furnished
with doors, are considered a part of the
unconfined space.
This heater shall not be installed in a con-
fined space or unusually tight construction
unlessprovisions are providedfor adequate
combustion and ventilation air.
*Adjoiningroomsarecommunicatingonly
iftherearedoorlesspassagewaysorventila-
tion grills between them.

5
105383
OWNER’S MANUAL
DETERMINING FRESH-AIR FLOW FOR FIREBOX LOCATION
Determining if You Have a Confined or Unconfined Space
Use this work sheet to determine if you have a confined or unconfined space.
Space:Includes the room in which you will install firebox plus any adjoining rooms with doorless passageways or ventilation grills
between the rooms.
1. Determine the volume of the space (length x width x height).
Length x Width x Height = _________________cu. ft. (volume of space)
Example : Space size22 ft. (length) x 18 ft. (width) x 8 ft. (ceiling height) = 3168 cu. ft. (volume of space)
If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of
the space.
2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.
__________ (volume of space) ÷50 cu. ft. = (Maximum Btu/Hr the space can support)
Example: 3168 cu. ft. (volume of space) ÷50 cu. ft. = 63.3 or 63,300 (maximum Btu/Hr the space can support)
3. Add the Btu/Hr of all fuel burning appliances in the space.
Gas water heater* _____________________ Btu/Hr
Gas furnace _____________________ Btu/Hr
Vented gas heater _____________________ Btu/Hr
Gas firebox logs _____________________ Btu/Hr
Other gas appliances*+ _____________________ Btu/Hr
Total = _____________________ Btu/Hr
* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.
4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.
_____________________Btu/Hr (maximum the space can support)
_____________________Btu/Hr (actual amount of Btu/Hr used)
Example: 63,300 Btu/Hr (maximum the space can support)
79,000 Btu/Hr (actual amount of Btu/Hr used)
ThespaceintheaboveexampleisaconfinedspacebecausetheactualBtu/HrusedismorethanthemaximumBtu/Hrthespacecansupport.
You must provide additional fresh air. Your options are as follows:
A. Rework worksheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoin-
ing room or add ventilation grills between rooms. See Ventilation Air from Inside Building, page 6.
B. Vent room directly to the outdoors. See Ventilation Air from Outdoors, page 6.
C. Install a lower Btu/Hr firebox, if lower Btu/Hr size makes room unconfined.
If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no
additional fresh air ventilation.
AIR FOR
COMBUSTION
AND VENTILATION
Continued
WARNING: If the area in which the firebox and gas log heater may be operated is smaller than that defined as
an unconfined space or if the building is of unusually tight construction, provide adequate combustion and
ventilation air by one of the methods described in the National Fuel Gas Code, ANS Z223.1, 1992, Section 5.3 or
applicable local codes.
Continued
Example:
Gas water heater 40,000 Btu/Hr
Vent-free firebox
with log heater + 39,000 Btu/Hr
Total = 79,000 Btu/Hr

6
105383
UV32C and RUV32 UNVENTED 32" FIREBOX
FIREPLACE MANUFACTURERS INC.
AIR FOR
COMBUSTION AND
VENTILATION
Continued
VENTILATION AIR
Ventilation Air From Inside
Building
Thisfreshairwouldcomefromanadjoining
unconfined space. When ventilating to an
adjoining unconfined space, you must pro-
vide two permanent openings: one within
12" of the ceiling and one within 12" of the
floor on the wall connecting the two spaces
(seeoptions1and2,Figure4).Youcanalso
remove door into adjoining room (see op-
tion 3, Figure 4). Follow the National Fuel
Gas Code NFPA 54/ANS Z223.1, Section
5.3, Air for Combustion and Ventilation for
required size of ventilation grills or ducts.
WARNING: Rework work-
sheet, adding the space of the
adjoiningunconfinedspace.The
combined spaces must have
enough fresh air to supply all
appliances in both spaces.
Figure 5 - Ventilation Air from Outdoors
Ventilation Air From Outdoors
Provide extra fresh air by using ventilation
grills or ducts. You must provide two per-
manent openings: one within 12" of the
ceiling and one within 12" of the floor.
Connecttheseitemsdirectlytotheoutdoors
orspacesopentotheoutdoors.Thesespaces
include attics and crawl spaces.
IMPORTANT: Do notprovide openingsfor
inlet or outlet air into attic if attic has a
thermostat-controlledpowervent.Heatedair
enteringtheatticwillactivatethepowervent.
Figure 4 - Ventilation Air from Inside Building
,,,,
,,,,
,,,,
,,,,
,,,,
,,,,
,,,,
,,,,
,,,,
,,,,,
,,,,,
,,,,,
,,,,,
,,,,,
,,,,,
,,,,,
,,,,,
,,,,,
,,,,,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
,
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills
Into Adjoining
Room,
Option 1
12"
12"
Outlet
Air Ventilated
Attic
Outlet
Air
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,

7
105383
OWNER’S MANUAL
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
QQQQQQ
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
¢¢¢¢¢¢
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,
,,,,,,,
42"
16"
Face or
Cabinet
Mantel
Corner
Mantel
12"
Floor - 0"
INSTALLATION
CLEARANCES
WARNING:Maintainthemini-
mum clearances. If you can, pro-
vide greater clearances from
floor, ceiling, and adjoining wall.
Carefullyfollowtheinstructionsbelow.This
will ensure safe installation.
Minimum Wall and Ceiling
Clearances (see Figure 6)
A. Clearances from the side of the firebox
openingto any combustiblewall should
not be less than 16 inches for a cabinet
mantel or 12 inches for a corner instal-
lation.
B. Clearances from the top of the firebox
openingto the ceilingshouldnot be less
than 42 inches.
C. When the firebox is installed directly
on carpeting or other combustible ma-
terial, other than wood flooring, the
firebox should be installed on a metal
or wood panel extending the full width
and depth of the enclosure.
INSTALLATION
CAUTION: Log heaters in-
stalledinthisfireboxcreatewarm
aircurrents.Thesecurrentsmove
heat to wall surfaces next to fire-
box. Installing firebox next to vi-
nyl or cloth wall coverings or
operating firebox where impuri-
ties(suchastobaccosmoke,aro-
matic candles, cleaning fluids,
oilorkerosenelamps,etc.)inthe
air exist, may discolor walls.
IMPORTANT: Vent-free gas log heaters
add moisture to the air. Although this is
beneficial, installingfireboxinroomswith-
out enough ventilation air may cause mil-
dew to form from too much moisture. See
AirforCombustionandVentilation,pages4
through 6.
IMPORTANT: Make sure the firebox is
level. If firebox is not level, log set will not
work properly.
NOTICE: A qualified service per-
son must install firebox. Follow
all local codes.
WARNING: Never install the
firebox
• in a bedroom or bathroom
• in a recreational vehicle
• where curtains, furniture,
clothing, or other flammable
objectsarelessthan42inches
from the front, top, or sides of
the firebox
• in high traffic areas
• in windy or drafty areas
Figure6-MinimumClearancetoWalland
Ceiling
Clearances for Cabinet or
Corner Mantel Installation
Note: Clearances are
the same if using
cabinet mantel or
built-in installation.
MINIMUM
CLEARANCE
Mantel Clearances for Built-In
Installation
If placing custom mantel above built-in
firebox,youmustmeettheminimumallow-
ableclearancebetweenmantelshelfandtop
of firebox opening shown in Figure 7 on
page 8. These are the minimum allowable
mantel clearances for a safe installation.
Use larger clearances wherever possible to
minimize the heating of objects and materi-
als placed on the mantel.
Continued
NOTICE: This heater is intended
foruseassupplementalheat.Use
this heater along with your pri-
mary heating system. Do not in-
stall this heater as your primary
heatsource.Ifyouhaveacentral
heating system, you may run
system’scirculatingblowerwhile
usingheater.Thiswillhelpcircu-
late the heat throughout the
house. In the event of a power
outage, you can use this heater
as your primary heat source.
CAUTION: Do not allow the
vent-free gas log heater to touch
or extend beyond the fireplace
screen.
If your installation does not meet the mini-
mum clearances in Figure 7, you must:
• raise the mantel to an acceptable height,
OR
• remove the mantel.
Note :YourVanguardfireboxisdesignedto
beusedinzeroclearanceinstallations.Wall
or framing material can be placed directly
against any exterior surface on the rear,
sides, or top of your firebox, except where
stand-off spacers are integrally attached. If
stand-off spacers are attached to your fire-
box, these spacers can be placed directly
against wall or framing materials.
Use the dimensions shown for rough open-
ings to create the easiest installation (see
Built-In Fireplace Installation, page 10).

8
105383
UV32C and RUV32 UNVENTED 32" FIREBOX
FIREPLACE MANUFACTURERS INC.
Built-In Installation of Blower
Accessory
1. Install blower assembly per instruction
sheet included.
2. Before replacing bottom of firebox,
remove screw holding duplex outlet to
the support bracket in the bottom of
firebox. Remove duplex outlet.
3. Clamp electrical cable into firebox
through smallest hole in outer casing
using strain relief provided.
4. Route wiresfrom electrical boxthrough
hole in side of heater and hole in sup-
port bracket (see Figure 9).
5. Connect wires from the electrical box
to duplex outlet. Match wire colors to
those indicated on duplex outlet. Be
sure to connect ground wire.
6. Replace duplex outlet with screw.
7. Plug blower power cord into duplex
outlet.
8. Replace bottom of firebox.
NOTICE: A qualified electrician
must connect electrical wiring to
duplex outlet for built-in installa-
tion. Follow all local codes. In
absenceoflocalcodesfollow The
National Electrical Code ANS/
NFPA 70.
Figure 9 - Routing Blower Accessory
Power Cord for Built-In Installation
INSTALLING BLOWER
ACCESSORY
(Model UV32C only)
You may install blower accessory FA3700
with a cabinet mantel installation or with
built-in installation (page 10) with model
UV32C only. To install blower accessory,
see instruction sheet included with the kit.
Cabinet Mantel Installation of
Blower Accessory
1. Install blower assembly per instruction
sheet included in blower accessory kit.
2. Before replacing bottom of firebox,
route blower power cord through hole
in support bracket in bottom of firebox
and through hole in side of firebox to
grounded, three-prong 120 volt electri-
cal outlet (see Figure 8). Plug electri-
cal cord into outlet.
3. Replace bottom of firebox.
Figure 8 - Routing Blower Accessory
PowerCordforCabinetMantelInstallation
Electrical
Outlet
Side
Opening
Support Bracket
Opening
Blower Power Cord
Blower
INSTALLATION
Continued
Supplied
Firebox Hood
Must Be Used
at All Times
Wire-mesh
Screen
Firebox
Mantel Shelf
13" 16" 19" 21"
18.5" 20" 21" 22" For RUV32 Series
noncirculating
smooth face models
2
1/2
"
6"
8"
10"




For UV32C Series
circulating louvered
models only
Note :
All vertical measurements
are from top of fireplace
opening to bottom of mantel
shelf. All measurements
are in inches.
Facing material (above
firebox) may be of
combustible material,
including decorative
mantel ornaments.
Figure 7 - Minimum Mantel Clearances for Built-In Installation
Cables From
Electrical
Source
Duplex
Outlet
Screw
Blower Power Cord
Blower Support
bracket

9
105383
OWNER’S MANUAL
INSTALLATION
Continued
5. Attach gas log heater base to firebox
bottom using instructions provided
with log set owner’s manual.
6. Replace fireboxbottom and securewith
screws.
NOTICE:Mostbuildingcodesdo
not permit concealed gas con-
nections. A flexible gas line is
recommended to allow accessi-
bility from the firebox. The flex-
ible gas supply line connection
to the manual shutoff valve
should be accessible.
Figure 10 - Removing Firebox Bottom
1. Remove four screws holding firebox
bottom in place.
2. Lift and remove firebox bottom (see
Figure 10).
3. If installing FA3700 BlowerAccessory
(Model UV32C only), see Installing
Blower Accessory, page 8.
4. Route flexible gas line from manual
shutoff valve into firebox through side.
INSTALLING LOG HEATER IN
FIREBOX
CAUTION: Do not pick up log
base assembly by burners. This
could damage burners. Only
handle base by grates.
INSTALLING FIREPLACE
SCREEN
1. Insert each rod through nine rings lo-
cated at top of screen.
2. Insert first rod into rear hole in left side
of firebox. Fasten rod to rear hole near
center of firebox using black shoulder
screw.
3. Insert other rod into front hole on right
sideoffirebox and fastenusingremain-
ing shoulder screw.
Figure 11 - Installing Fireplace Hood
Hood
Hood
Mounting Slot
Screw
Shoulder
Screw
INSTALLING FIREPLACE
HOOD
1. Attach three zinc-colored shoulder
screws to back of hood.
2. Insert hood into hood-mounting slots
on firebox.
3. Hold hood in place. Insert two black
Phillipsscrewsthrough bottom of hood
and tighten.
Figure 12 - Installing Fireplace Screen
(Shown Without Fireplace Hood for
Clarity)
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
,,,,,,,,,,
Rod
Front
Hole
Ring
Screen
Screw
Rear Hole
Continued
CAUTION:Donotremove the
metal data plates attached to the
heater base assembly. The data
platescontainimportantwarranty
information.

10
105383
UV32C and RUV32 UNVENTED 32" FIREBOX
FIREPLACE MANUFACTURERS INC.
INSTALLATION
Continued
34 3/4"
17 3/4"
33" (UV32C)
34 1/4" (RUV32)
Figure 13 - Rough Opening for Installing
in Wall
BUILT-IN FIREBOX
INSTALLATION
Built-in installation of this firebox involves
installing firebox into a framed-in enclo-
sure. This makes the front of firebox flush
with wall. If installing a mantel above the
firebox, but you must follow the clearances
shown in Figure 7, page 8. Follow the in-
structionsbelowtoinstallthefireboxinthis
manner.
1. Frame in rough opening. Use dimen-
sions shown in Figure 13 for the rough
opening
If installing in a corner, use dimensions
shown in Figure 14 for the rough open-
ing. The height is 33" (UV32C) or 34
1
/ 4 "
(RUV32),whichis the same asthewall
opening in Figure 13.
2. Install gas piping to firebox location.
This installation includes an approved
flexible gas line (if allowed by local
codes) after the manual shutoff valve.
The flexible gas line must be the last
item installed on the gas piping. See
Connecting to Gas Supply in log set
owner’s manual.
3. If using FA3700 blower accessory
(Model UV32C only), see Installing
Blower Accessory for built-in installa-
tion, page 8.
4. Attach flexible gas line to log set. See
Connecting to Gas Supply in log set
owner’s manual.
5. Carefully insert firebox into rough
opening.
Height Front Width Depth
Model # Actual Framing Actual Framing Actual Framing
UV32C 32 3/16" 33" 34 3/8" 34 3/4" 16 11/16" 17 3/4"
RUV32 33 11/16" 34 1/4" 34 3/8" 34 3/4" 16 11/16" 17 3/4"
Figure 15 - Attaching Firebox to Wall
Studs
Nailing
Flanges
Nails or Wood
Screws
39 3/8" 27 7/8"
55 5/8"
34 3/4"
Figure 14 - Rough Opening for Installing
in Corner
6. Attach firebox to wall studs using nails
or wood screws through holes in nail-
ing flange (see Figure 15).
7. Check allgas connections forleaks.See
Checking Gas Connections in log set
owner’s manual.

11
105383
OWNER’S MANUAL
BLOWER ACCESSORY -
FA3700
Use with Model UV32C only. The variable
speed blower allows you to select the de-
sired speed. The blower circulates heated
air from the fireplace into the room.
Purchase this heater accessory from your
local dealer. If they can not supply this
accessory, call Fireplace Manufacturers
Incorporated's Parts Department at 1-800-
888-2050 for referral information. You can
also write to the address listed on the back
page of this manual.
ACCESSORY
REPLACEMENT
PARTS
Note: Use only original replacement parts.
Thiswillprotectyourwarrantycoveragefor
parts replaced under warranty.
PARTS UNDER WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call Fireplace Manufacturers
Incorporated's Technical Service Depart-
ment at 1-888-427-8322.
WhencallingFireplaceManufacturersInc.,
have ready
• your name
• your address
• model number of your heater
• how heater was malfunctioning
• type of gas used (propane or natural gas)
• purchase date
Usually,wewillaskyoutoreturnthedefec-
tive part to the factory.
PARTS NOT UNDER
WARRANTY
Contact authorized dealers of this product.
If they can’t supply original replacement
part(s), call Fireplace Manufacturers
Incorporated's Parts Department at 1-800-
888-2050 for referral information.
WhencallingFireplaceManufacturersInc.,
have ready
• model number of your heater
• the replacement part number
TECHNICAL
SERVICE
You may have further questions about in-
stallation, operation, or troubleshooting. If
so, contact Fireplace Manufacturers
Incorporated's Technical Service Depart-
ment at 1-888-427-8322.

12
105383
UV32C and RUV32 UNVENTED 32" FIREBOX
FIREPLACE MANUFACTURERS INC.
ILLUSTRATED
PARTS
BREAKDOWN
RUV32
5
14
16
16
16
13
15
17
17
17
16
6
1
16
7
16
8
20
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
12 18
10
19
9
4
2
3
2
16
11
18
18

13
105383
OWNER’S MANUAL
PARTS LIST
RUV32
This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions
listed under Replacement Parts on page 11 of this manual.
KEY
NO. PART NUMBER DESCRIPTION QTY.
1 101872-03 Firebox Top 1
2 101889-01 Firebrick Retainer 3
3 101929-02 Rear Firebrick 1
4 101932-02 Side Firebrick 2
5 103207-01 Outer Casing 1
6 103208-01 Outer Shell Base 1
7 103245-01 Firebox Wrapper 1
8 103297-01 Assembly Screen 2
9 103217-01CK Hood 1
10 103773-02CK Front Assembly 1
11 103250-01CK Firebox Bottom 1
12 103809-01 Screen Rod 2
13 103816-01 Firebox Insulation 1
14 101348-01 Firebox Support 2
15 101357-03 Outer Casing Top 1
16 M11084-26 Hex Head Screw, #10-16 49
17 098194-02 Stand Off 3
18 098304-01 Phillips Pan Head Screw, #10 13
19 099230-01 Hex Head Screw 3
20 099230-02 Shoulder Screw 2

14
105383
UV32C and RUV32 UNVENTED 32" FIREBOX
FIREPLACE MANUFACTURERS INC.
ILLUSTRATED
PARTS
BREAKDOWN
UV32C
5
16
16
15
16
17
22
6
1
16
7
16
14
21
13
8
20
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
,,,,,,
12 18
10
19
9
4
2
3
2
16
11
18
18

15
105383
OWNER’S MANUAL
PARTS LIST
UV32C
This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions
listed under Replacement Parts on page 11 of this manual.
KEY
NO. PART NUMBER DESCRIPTION QTY.
1 101872-03 Firebox Top 1
2 101889-01 Firebrick Retainer 3
3 101929-02 Rear Firebrick 1
4 101932-02 Side Firebrick 2
5 103207-01 Outer Casing 1
6 103208-01 Outer Shell Base 1
7 103245-01 Firebox Wrapper 1
8 103297-01 Assembly Screen 2
9 103217-01CK Hood 1
10 103773-01CK Front Assembly 1
11 103250-01CK Firebox Bottom 1
12 103809-01 Screen Rod 2
13 M12461-2 Screw, Outlet Mounting 1
14 101348-01 Firebox Support 2
15 101357-01 Outer Casing Top 1
16 M11084-26 Hex Head Screw, #10-16 49
17 103771-01 Strain Relief Fitting 1
18 098304-01 Phillips Pan Head Screw, #10 13
19 099230-01 Hex Head Screw 3
20 099230-02 Shoulder Screw 2
21 103769-01 Duplex Outlet 1
22 103457-01 Button Plug 1

105383 01
KEEP THIS WARRANTY
WARRANTY INFORMATION
Always specify model and serial numbers when communicating with the factory.
We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty.
We make no other warranty, expressed or implied.
Model
Serial No.
Date Purchased
2701 South Harbor Boulevard
Santa Ana, CA 92704
105383-01
Rev. A
11/98
NOT A UPC
LIMITED WARRANTY
VENT-FREE FIREBOX
Fireplace Manufacturers Incorporated warrants this product to be free from defects in materials and components for one (1) year from
thedateoffirstpurchase,providedthattheproducthasbeenproperlyinstalled,operatedandmaintainedinaccordancewithallapplicable
instructions. To make a claim under this warranty the Bill of Sale or cancelled check must be presented.
This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to restore this heater to
proper operating condition and an allowance for labor when provided by a Fireplace Manufacturers Incorporated Authorized Service
Center.Warrantypart(s)MUSTbeobtainedthroughauthorizeddealersofthisproductand/orFireplaceManufacturersIncorporatedwho
will provide original factory replacement parts. Failure to use original factory replacement parts voids this warranty. The heater MUST
be installed by a qualified installer in accordance with all local codes and instructions furnished with the unit.
This warranty does not apply to parts that are not in original condition because of normal wear and tear, or parts that fail or become
damaged as a result of misuse, accidents, lack of proper maintenance or defects caused by improper installation. Travel, diagnostic cost,
labor, transportation and any and all such other costs related to repairing a defective heater will be the responsibility of the owner.
TOTHEFULL EXTENT ALLOWED BYTHELAWOFTHE JURISDICTION THAT GOVERNSTHESALEOF THE PRODUCT;
THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL OTHER EXPRESSED WARRANTIES AND LIMITS THE DURA-
TION OF ANY AND ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE TO ONE (1) YEAR ON ALL COMPONENTS AND FROM THE DATE OF FIRST PURCHASE;
ANDFIREPLACEMANUFACTURERSINCORPORATED’SLIABILITYISHEREBYLIMITEDTOTHEPURCHASEPRICEOF
THE PRODUCT AND FIREPLACE MANUFACTURERS INCORPORATED SHALL NOT BE LIABLE FOR ANY OTHER
DAMAGES WHATSOEVER INCLUDING INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of incidental or consequential
damages, so the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
For information about this warranty write:
