FMT Swiss AG PREMAxx 230 V Instruction Manual

OPERATING INSTRUCTIONS
AND SAFETY NOTES
PREMAxx · Diesel Pump
230 V • 24 V-DC • 12 V-DC
87 987 932 A804 GB

2
GB Operating Instructions - PREMAxx Diesel Pump
FMT Swiss AG
This documentation is exclusively intended for the operating company and their sta.
Without our written consent, the content of this documentation (textes, gures, drawings,
charts, diagrams etc. ), must not be duplicated or distributed, neither in full or in part, utilized
for the purpose of competition or passed on/made availabe to third parties.
FMT Swiss AG
Fluid Management Technologies Swiss AG
Gewerbestraße 6
6330 Cham / Schweiz
Tel. [phone]
Fax [phone]
Email: [e-mail]
Internet: www.fmtag.com
Operating instructions translation
Date of issue: 05/2020
We reserve the right to make design and product modications, which serve to improve the product.

3
Operating Instructions - PREMAxx Diesel Pump GB
Table of Contents
1. Introduction ________________________________________________________________________4
1.1. Preface ____________________________________________________________________________4
1.2. Obligations of the personnel __________________________________________________________4
1.3. Symbols in this manual _______________________________________________________________4
1.3.1. Structure of the warning notes _________________________________________________________4
1.3.2. Hazard warning symbols ______________________________________________________________5
1.3.3. General symbols ____________________________________________________________________5
2. Safety notes ________________________________________________________________________5
2.1. Authorized personnel ________________________________________________________________6
2.2. Notes for maintenance, cleaning and repair ______________________________________________6
2.3. Intended conditions of use ____________________________________________________________6
2.4. Risks when handling the PREMAxx diesel pump ___________________________________________7
2.5. Risks when handling diesel and heating oil _______________________________________________7
3. Transport and temporary storage _______________________________________________________8
4. Design and functional description ______________________________________________________8
4.1. Area of application __________________________________________________________________8
5. Technical data ______________________________________________________________________8
6. Installation _________________________________________________________________________9
7. Operation _________________________________________________________________________11
7.1. First and re-commissioning ___________________________________________________________11
8. Preventive maintenance _____________________________________________________________12
9. Maintenance ______________________________________________________________________12
10. Troubleshooting ___________________________________________________________________13
11. Repair/Service _____________________________________________________________________13
12. Disposal___________________________________________________________________________13
13. Exploded view of the PREMAxx diesel pump 230 V ________________________________________14
14. Exploded view of the PREMAxx diesel pump 24 /12 V ______________________________________16
15. EC Declaration of Conformity _________________________________________________________18

4
GB Operating Instructions - PREMAxx Diesel Pump
1. Introduction
1.1. Preface
Please carefully read these operating instructions and observe in particular all safety notes!
Our sta will be pleased to provide support if you have any questions about the product.
Yours sincerely, FMT Swiss AG
1.2. Obligations of the personnel
Before they start to work, all persons who are entrusted with work with the PREMAXX diesel pump, are
obliged:
– to follow all applicable regulations on occupational safety and accident prevention.
– to read and to comply with all safety instructions and warning notes contained in these operating
instructions.
Please observe the following instructions in the interest of all concerned:
 Refrain from any unsafe working methods!
 Adhere to all hazard and warning notes contained in this manual!
 In addition to this documentation, keep to all generally accepted safety rules, legal provisions as
well as all other binding rules regarding occupational safety, accident prevention and environmental
protection!
 Wear appropriate protective clothing in accordance with the work to be done!
 Perform only work for which you have been suciently trained and instructed!
 Only genuine spare parts as well as original tools and auxiliaries of the manufacturer are allowed to be
used in order to ensure the functional safety and maintain the warranty coverage.
1.3. Symbols in this manual
1.3.1. Structure of the warning notes
The warning notes have the following structure:
SIGNAL WORD
Type and source of the hazard
 Consquences of non-compliance with the notes
 Measures to avoid that risk
Depending on the danger level, dierent signal words are used:
Signal word Danger level Consequences of non-
compliance
DANGER Imminent threat of
danger
Death or serious bodily injury
WARNING Possible threat of
danger
Death or serious bodily injury
CAUTION Possibly dangerous
situation
Minor bodily injury
ATTENTION Possibly dangerous
situation
Damage to material property

5
Operating Instructions - PREMAxx Diesel Pump GB
NOTE
Indicates further information or tips which facilitate work.
1.3.2. Hazard warning symbols
Symbol Meaning
General hazard symbol. The warning note marked in this way contains sup-
plementary information on the type of hazard.
This symbol warns of dangerous electrical voltages.
This symbol warns of a hazardous explosive atmosphere.
1.3.3. General symbols
Symbol Meaning
A small black square indicates the work you have to perform.
–The dash denotes lists.
aThe arrow identies cross-references.
If cross-references to other chapters are required within the text, the expres-
sion is shortened for reasons of clarity.
Example: aChapter 2 Safety notes
This means: please refer to chapter 2 for the safety notes
2. Safety notes
Various dangers may occur if the PREMAxx diesel pump is improperly handled during installation,
comissioning and daily operation.
WARNING
Risk of injury and damage to material property because of improper handling!
 Hold the instructions at the disposal of the operating sta at the usage site
of the unit.
 Country-specic safety measures and accident prevention regulations must
be observed.

6
GB Operating Instructions - PREMAxx Diesel Pump
2.1. Authorized personnel
Only qualied and authorized persons are allowed to operate and to work on the PREMAxx diesel
pump.
Persons are qualied if they are, due to their training, experience, instruction and knowledge of the
relevant standards, able to assess assigned tasks and to identify potentially hazardous situations.
These persons must have been authorized by the person responsible for the safety of the unit and must
be able to identify and to avoid potential dangers.
All persons charged with installation, operation, maintenance and repair work, must have read and
understood this operation manual.
A copy of this operating manual must be stored permanently and ready at hand at the place of usage
of the pump.
2.2. Notes for maintenance, cleaning and repair
WARNING
Risk of injury and damage to material property because of improper
mainte-nance and repair!
 Keep to the specied inspection and maintenance intervals
(aChapter Maintenance).
 Should unusual noises occur, immediately stop the pump. Immediately
identify and eliminate the cause in order to avoid consequential damages.
 Observe the safety sheet for diesel and heating oil.
2.3. Intended conditions of use
The PREMAxx diesel pump is an electrically driven axial gear pump for the delivery of diesel fuel and
heating oil.
The temperature of the conveying liquid must be between –10 °C and + 35 °C.
Pumping of explosive uids is forbidden.
The use in the food industry is forbidden.
The pump may only be connected to a suitable power source (see nameplate).
Proper usage also includes complying with the operating manual, which must be completely read
before the unit is put into operation.
Any departure from the usage stipulations (other uid media, use of force) or user modications
(changes, use of non-original parts) can be dangerous and are considered as non-intended usage.
The user is liable for any damage resulting from non-intended use.
During repairs to any electrical components, the appropriate safety and test requirements are to be
observed.
Only genuine replacement parts are to be used for any repairs, because otherwise the warranty will be
invalidated.
Use of the pump only in compliance with the intended conditions of use.
Any application beyond the intended use can lead to hazardous situations and shall be regarded as non-
intended use.

7
Operating Instructions - PREMAxx Diesel Pump GB
DANGER
Risk of injury and material damage from explosive vapors!
 Never use the pump to deliver fatty substances or explosive uids such
as petrol or other uids with similar ashpoints!
 Since the motor and the switch are not explosion-protected, the pump must
not be operated in an explosion risk area.
 Pumping caustic or other hazardous chemical or biological substances is
forbidden.
 Do NOT use the pump in an explosion-risk area. No open re, no smoking.
Use the pump exclusively for delivering diesel fuels or heating oils.
2.4. Risks when handling the PREMAxx diesel pump
DANGER
Risk of injury and material damage because of improper installation,
electric current or contaminated media!
Never work on a pump that is running!
 Mount or remove attachments and accessories only when the pump is
switched o from all sources of energy.
 Before the pump is put into operation, this one must be tightly screwed to
the dispensing container.
 The pump is only allowed to be operated, if it is screwed to the dispensing
container and thus cannot carry out any uncontrolled movements.
 The pump is only allowed to be operated if the dispensing container, to
which the pump is connected, stands on a rm and level surface.
 For your own safety, disconnect the pump in addition from the power supply.
 Never leave the pump unattended.
 Check to ensure that the pump does not work against the closed nozzle
Do not pump contaminated uids
 Take special care to ensure that there are no contaminants in the uid to be
pumped.
 Install a strainer on the suction pipe.
Damaged attachments and accessories can lead to personal injury and
material damage
 Attachments and accessories must be checked for wear, splits or other
damage throughout their period of use.
 Damaged accessories and attachments must be replaced immediately.
 With reference to the period of use, please note the details in ZH 1/A45.4.2
or DIN 20066 Part 5.3.2
Escaping liquids can cause environmental harm
Comply with the stipulations of the German Water Resources Act (WHG) and
of the Plant Regulations of the German federal states (VawS).

8
GB Operating Instructions - PREMAxx Diesel Pump
2.5. Risks when handling diesel and heating oil
Diesel fuels and heating oils are ammable liquids. If improperly handled, they can cause risks to
human health or to the environment.
NOTE
Observe the safety sheet for diesel and heating oil!
3. Transport and temporary storage
Before transport, ensure that there is no liquid (diesel or heating oil residues) in the pump. All additional
extensions must be removed from the pump.
Do not use the cable to transport the pump!
Storage and transport conditions:
– Weather-protected storage with temperature control, protection against frost, moisture and rain.
Maximum relative humidity: 80 %.
– Storage temperature range from -5 °C bis +55 °C
4. Design and functional description
The PREMAxx diesel pump is an electrically driven axial gear pump for the delivery of diesel fuels and hea-
ting oil. It is only designed for use as a barrel pump and can be screwed on storage barrels and containers.
The PREMAxx diesel pump is not a self-priming pump.
Operate the pump by hand before putting the pump into operation for the rst time or if the uid
column has dropped down, because the radial shaft seal may be destroyed by a dry run of the pump.
The pump is compact and handy and quickly ready for use thanks to its integrated priming stage,
which allows to manually pump small quantities of uid before commissioning or in case of a power
failure.
To avoid environmental damage, the electric PREMAxx diesel pump is equipped with a siphon protection
system.
In case the discharge hose is damaged while the pump is stopped, siphon action will prevent the uid
from escaping.
The pump housing is made of high-quality, impact-resistant plastic.
Numerous accessories from FMT allow a simple and quick mounting on each installation.
The materials the pump is made from are compatible with uids like diesel fuel and heating oil.
The pump is electrically driven by an alternating current motor suitable for continuous operation. The
pump is directly ange-mounted to the motor. In case of overload, a thermal protection device auto-
matically switches o the electric motor.
When the motor has cooled down, the thermal protection device automaticall restarts.
Pump data aChapter„Technical data“.
The PREMAx diesel pump is available in the following versions:
– Premaxx, 48 l/min-12.6 gpm 230 V-1~AC-50 Hz
–Premaxx , 35 l/min-9.2 gpm 12 V-DC battery terminal clips
– Premaxx , 40 l/min-10.5 gpm 24 V-DC battery terminal clips
4.1. Area of application
The PREMAxx diesel pump is an electrically driven pump for the delivery of diesel fuels and heating oil. It
is only designed for use as a barrel pump and can be screwed on storage barrels and containers.
The temperature of the delivery uids must be between –10 °C and + 35 °C. The temperatures must not
be above or below these limit values.
Since the motor and the switch are not explosion-protected the pump must not be operated in an
explosion risk area.

9
Operating Instructions - PREMAxx Diesel Pump GB
5. Technical data
Description 230 V
23 730
12 V
23 710
24 V
23 720
Connecting cable, length (m) (ft) 2 / 6.6
Connection container G 2‘‘ male, drum adapter
Connection suction side Hose tting DN 19
Connection discharge side G 1‘‘ male
Hydraulic data
Pump design axial gear
Delivery rate under free discharge (l/
min) / (gpm)
48 / 12.6 35 / 9.2 40 / 10.5
Suction height (m) / (ft) 2,5 / 8.2
Discharge height max. (m) / (ft): 15 / 49.2
Pumping media heating oil and diesel fuels
Temperature range of pumping media -10 °C / +35 °C
Motor data
Voltage (V) 230 12 DC 24 DC
Frequency (Hz) 50
Power consumption (A) 1,8 14 10
Power (kW) 0,42 0,18 0,24
Thermal protection self resetting
Duty cycle (min): 30
Rotation speed at 0,5 bar
counterpressure (rpm)
10000 7500 7500
Type of construction IMB 5
Protection class IP 34
Material of pump housing
and pump
PA 6
PA6 GF30
PA 6
PA6 GF30
PA 6
PA6 GF30
Dimensions of pump LxWxH (mm) / (inch) 130 x 130 x 350 / 5.1 x 5.1 x 13.7
Weight (kg) (lbs) 2,5 / 5.5
Tab. 5-1: Technical data
6. Installation
The Premaxx diesel pump is designed for installations in indoor and outdoor areas.
The installation must be carried out in the following sequences (see g. 6-1):
 Push the suction hose (2) on the suction tube (11) with lter (1).
 Push the hose clamp (10) over the suction hose (2) to the suction tube (11) and fasten the hose clamp
by means of a screwdriver.
NOTE
Before proceeding to the next step, please note the following:
When the pump is mounted on the storage container, the suction hose with
the suction tube must be long enough to reach the liquid in the storage
container even when the uid level is low.
 Cut the suction hose (2) to the desired length.
 Push the hose clamp (18) over the suction hose (2).
 Push the suction hose (2) on the suction port (19) on the pump.
 Push the suction clamp (18) to the suction port (19) and fasten the hose clamp by means of a
screwdriver.

10
GB Operating Instructions - PREMAxx Diesel Pump
NOTE
Do not overtighten the hose clamp at the suction port, because otherwise
the check valve may be jammed and the pump may stop working.
CAUTION
Risk of injury through incorrect installation!
 Mount and operate the pump only in vertical position on a storage
container.
 The pump is only allowed to be operated if it is rmly screwed with the
dispensing container, so that it cannot carry out any uncontrolled
movements.
 The pump is only allowed to be operated if the dispensing container, to
which the pump is connected, stands on a rm and level surface.
 Screw the pump rmly into the opening of the storage container by means of the barrel screw
coupling (20).
 When screwed in, the pump outlet can be moved to any desired position by turning the pump housing (5).
 Screw the union nut (13) of the black discharge hose down to the discharge port (21) of the pump.
 Screw the free end of the discharge hose with the male thread (8) into the thread of the nozzle valve
(6 or 7).
Fig. 6-1: Overview of the PREMAxx diesel pump with acessories

11
Operating Instructions - PREMAxx Diesel Pump GB
1 Suction lter with metal screen 12 Easy-turn swivel joint-DN 19
2 Hose for diesel, DN 19 13 Nut G1“
3 2-ear hose clamp 14 Lock
4 Hose for diesel, DN 19 15 Lever, automatic nozzle valve
5 PREMAxx diesel pump 16 Lever, standard nozzle valve
6 Automatic nozzle valve, diesel 17 On/o rocker switch
7 Nozzle valve-G 1“ female-80 l/min 18 Worm drive clamp
8 Press nipple 19 Intake pipe socket
9 Bend 90° 20 Barrel screw coupling
10 Worm drive clamp 21 Discharge port
11 Intake pipe socket for PREMAxx 22 Hand lever
 Connect the pump to a power source using the mains plug or the terminal clamps.
The pump is ready for commissioning.
CAUTION
Risk of injury from 24 V and 12 V batteries!
 When handling the 24 V and 12 V battery (lead-acid battery), observe
the specications and the material data safety sheet of the battery
manufacturer.
Carry out the following steps when connecting the pump (24/12 V) to the battery:
 The switch of the pump must be in the OFF position.
 Remove the protection cap from the positive battery terminal (+).
 Connect the red terminal clamp to the positive battery terminal.
 Remove the protection cap from the negative battery terminal (-).
 Connect the black terminal clamp to the negative battery terminal.
Proceed in reverse order when disconnecting the pump from the battery:
 At rst, disconnect the black clamp from the negative terminal and then the red clamp from the
positive terminal.
 Put the protection caps on the terminals again.
7. Operation
7.1. First and re-commissioning
Check the operativeness of the pump before use and after a failure-related or scheduled downtime.
Check the PREMAxx diesel pump and the installed accessories for completeness and damage. Replace
any damaged components immediately. Never use a pump if damaged.
NOTE
 Operate the pump by hand before putting the pump into operation
for the rst time or if the uid column has dropped down, because the
radial shaft seal may be destroyed by a dry run of the pump.
Preparing the pump for operation (see g. 6-1):
 Hold the nozzle valve (6 or 7) into a container.
 Push the lever (15 or 16) and keep it pushed or x it by the lock (14) (if equipped with automatic nozzle
valve). Hold the nozzle valve into the container to be lled.

12
GB Operating Instructions - PREMAxx Diesel Pump
 Manually pump uid by means of the hand lever (22) until uid is pumped out of the nozzle valve
(6 or 7). Due to the integrated siphon protection, the uid column may drop in case of long periods of
disuse so that a manual pumping may be necessary again.
 Actuate the rocker switch (17) to switch on the pump.
NOTE
Danger of product damage
 Never operate the pump without liquid. The PREMAxx diesel pump may be
damaged by running dry.
 Mount and operate the pump only in vertical position on a storage container.
 The diesel axial gear pump does not switch o automatically, therefore never
let the pump running without supervision during lling operations.
 For nishing the lling operation, release the nozzle valve control lever. Never operate the pump for
longer than 3 min with closed nozzle valve.
 Operate the rocker switch to switch o the pump.
 Position the nozzle valve so that no media can pollute the environment.
8. Preventive maintenance
In general, the PREMAxx diesel axial gear pump is very easy to maintain and to service.
Maintenance work has always to be done by qualied technical personal.
ATTENTION
Danger of contact with energized components!
 When working on the electrical system of the pump, disconnect the pump in
addition from the power supply and protect it against restarting.
Due to the operator responsibilities according to § 19i WHG (German Water Resources Act) the fol-
lowing components must be regularly checked and replaced as necessary to minimise the risk of
environmental or equipment damage or personal injury:
 Pump housing
 Delivery hose
 Nozzle valve
9. Maintenance
Maintenance must be done by qualied technical personnel. External impact may cause a loss of
performance, constitute a risk of damage to persons and/or property and void the guarantee.
Observe the following recommendations for operating the pump:
ATTENTION
Danger of contact with energized components!
 Before performing any maintenance work, disconnect the PREMAxx diesel
pump from all electric and hydraulic supply sources
 When working on the electrical system of the pump, disconnect the pump in
addition from the power supply and protect it against restarting.
 Always wear personal protective equipment when carrying out maintenance work.
 If there is danger of freezing, the pump and the circuit must be emptied and stored at a location
with a temperature not lower than 0 °C / 32 °F.

13
Operating Instructions - PREMAxx Diesel Pump GB
 Check to ensure that the labels and decals have not become illegible and have not come loose in the
course of time.
 Check at regular intervals that the line connections have not worked loose in order to avoid that liquid
escapes.
 Regularly check and clean the suction line lter.
 From time to time, check the pump housing and remove any dirt.
 Check to ensure that the power cables are in perfect working order.
10. Troubleshooting
Malfunction Cause Solution
Motor does not run No power supply Check the electric connections
Discharge rate too low Discharge hose kinked or
clogged
Suction line
resistance too high
Filter resistance too high
Nozzle valve not completely
open
Check the discharge hose
Check the suction line, it may be
kinked or clogged
Check the suction lter and the check
valve
Check and clean the suction lte
Completely open the nozzle valve
Tab. 10-1: Troubleshooting
11. Repair/Service
The PREMAxx diesel pump was developed and produced according to the highest quality standards.
Should a problem develop, despite all quality controls, please contact our customer service:
FMT Swiss AG
Tel [phone]
Fax [phone]
[email protected]
12. Disposal
The operating company is responsible for the proper disposal of the pump.
Hereby, the industry-specic and local regulations must be observed when disposing of the dierent
materials.
Only qualied personnel is authorized to disassemble and dispose of the PREMAxx diesel pump.

14
GB Operating Instructions - PREMAxx Diesel Pump
13. Exploded view of the PREMAxx diesel pump 230 V
Fig. 13-1: Exploded view of the PREMAxx diesel pump 230 V

15
Operating Instructions - PREMAxx Diesel Pump GB
Pos. Quantity Description PREMAxx 230 V
11 Rocker switch, illuminated in green
21 Cable H05 RN F2 G 1,0-2 m
31 Pump shaft PREMAxx
41 Housing cover PREMAxx
51 Intermediate cover pump
61 Shaft seal ring DIN 3760
71 Impeller for PREMAxx
81 Housing PREMAxx
91 Spacer
10 1 O-ring NBR 70-31x2,2
11 1 Fitting
12 1 Threaded bolt
13 1 Con-rod for PREMAxx pump
14 1 Piston PREMAxx pump
15 1 Pump cylinder
16 1 Valve cone
17 1 Lever PREMAxx
18 4 Screws 4x20
19 2 Chipboard screw 4,5x70/40
20 2 Grooved taper pin DIN 1471
21 1 Ball stainless steel
22 1 Tapping screw 3,9x9,5
23 1 O-ring NBR 70-35 x2
24 4 Chipboard screw 3x16
25 1 Con-rod bolt Premaxx pump
26 1 Piston seal
27 1 Ball stainless steel, D = 19,05 mm
28 1 Flat seal
29 1 Compression spring
30 1 Grooved taper pin DIN 1471
31 1 O-ring NBR 70-7x2,5
32 1 Rivet DIN 660
33 2 Safety washer
34 1 O-ring FKM 80
35 1 Cable sleeve support
36 4 O-ring NBR 70-4x1
37 1 Nut DIN 985
38 1 Blade receptacle DIN 46345
39 1 Blade receptacle DIN 46245
40 1 Washer DIN 125A
41 1 Electric motor -230 V-50/60 Hz
Tab. 13-1: Overview of the components of g. 13 -1

16
GB Operating Instructions - PREMAxx Diesel Pump
14. Exploded view of the PREMAxx diesel pump 24 / 12V
Fig. 14-1: Exploded view of the PREMAxx diesel pump 24 / 12 V

17
Operating Instructions - PREMAxx Diesel Pump GB
Pos. Quantity Description PREMAxx 24 V Description PREMAxx 12 V
11 Rocker switch, illuminated in green Rocker switch, illuminated in green
21 Pump shaft PREMAxx Pump shaft PREMAxx
31 Housing cover PREMAxx Housing cover PREMAxx
41 Intermediate cover pump Intermediate cover pump
51 Shaft seal ring DIN 3760 Shaft seal ring DIN 3760
61 Impeller for PREMAxx Impeller for PREMAxx
71 Housing PREMAxx Housing PREMAxx
81 Spacer Spacer
91 O-ring NBR 70-31x2,2 O-ring NBR 70-31x2,2
10 1 Fitting Fitting
11 1 Threaded bolt PREMAxx pump Threaded bolt PREMAxx pump
12 1 Con-rod for PREMAxx pump Con-rod for PREMAxx pump
13 1 Piston PREMAxx pump Piston PREMAxx pump
14 1 Pump cylinder Pump cylinder
15 1 Valve cone Valve cone
16 1 Lever PREMAxx Lever PREMAxx
17 4 Screws 4x20 Screws 4x20
18 2 Chipboard screw 4,5x70/40 Chipboard screw 4,5x70/40
19 2 Grooved taper pin DIN 1471 Grooved taper pin DIN 1471
20 1 Ball stainless steel Ball stainless steel
21 1 Tapping screw 3,9x9,5 Tapping screw 3,9x9,5
22 1 O-ring NBR 70-35x2 O-ring NBR 70-35x2
23 4 Chipboard screw 3x16 Chipboard screw 3x16
24 1 Con-rod bolt PREMAXX pump Con-rod bolt PREMAXX pump
25 1 Piston seal Piston seal
26 1 Ball, D = 19,05 mm Ball, D = 19,05 mm
27 1 Flat seal Flat seal
28 1 Compression spring Compression spring
29 1 Grooved taper pin DIN 1471 Grooved taper pin DIN 1471
30 1 O-ring-FKM 70 - 7x2,5 O-ring-FKM 70 - 7x2,5
31 1 Button head rivet DIN 660 Button head rivet DIN 660
32 2 Washer Washer
33 1 O-ring FKM 80 O-ring FKM 80
34 4 O-ring FKM 70 - 4x1 O-ring FKM 70 - 4x1
35 1 Hexagon nut DIN 985 Hexagon nut DIN 985
36 1 Blade receptacle DIN 46345 Blade receptacle DIN 46345
37 1 Blade receptacle DIN 46245 Blade receptacle DIN 46245
38 1 Washer DIN 125 A Washer DIN 125 A
39 1 Cable sleeve support Cable sleeve support
40 1 Cable with terminal clips-3 m Cable with terminal clips-3 m
41 1 Electric motor 24 V Electric motor 12 V
Tab. 14 -1: Overview of the components of g.14-1

18
GB Operating Instructions - PREMAxx Diesel Pump
15. EC Declaration of Conformity
Manufacturer:
FMT Swiss AG
Fluid Management Technologies Swiss AG
Gewerbestraße 6
6330 Cham / Switzerland
Declares under his sole responsibility that the machine:
Model type PREMAxx diesel pump
23 730 (230 V)
23 720 (24 V)
23 710 (12 V)
Motor voltage 230 / 24 / 12 V
Weight 2,5 kg
Power 23 730 (230 V) - 0,42 kW
25 720 (24 V) - 0,24 kW
23 710 (12 V) - 0,18 kW
Function Pumping of diesel fuel and heating oil
Complies with all relevant provisions of the following directives:
EC Directives 2006/42/EG Machinery Directive
2011/65/EC EU-Directive (RoHS)
Applicable standards EN 809:1998+A1:2009+AC:2012
EN ISO 12100:2010
EN 60204-1:2006+A1:2009
EN 60335-1:2012+A11:2014
Authorized representative for the compilation of the technical documentation:
Name: Manuel Bredenbruch
Address: Fluid Management Technologies Swiss AG
Gewerbestraße 6
6330 Cham / Switzerland
Phone: [phone]
FMT Swiss AG
Cham, 19.05.2020
Dipl.-Ing. Rudolf Schlenker
(Managing Director)

19
Operating Instructions - PREMAxx Diesel Pump GB

FMT Swiss AG
Fluid Management Technologies Swiss AG
Gewerbestraße 6
6330 Cham / Schweiz
Tel. [phone]
Fax [phone]
[e-mail]
www.fmtag.com
