Camera Compatibility
JVC DR-HD100
Weighing one pound and only 1.5 inches thick, the Focus DR-HD100 Portable DTE
Recorder brings Direct To Edit®recording technology to your JVC GY-HD100/110 se-
ries or HD200/250 series ProHD camcorder. Whether it’s mounted directly to your
camcorder or clipped to your belt, the JVC DR-HD100 is designed to excel in the field.
Focus DR-HD100 Portable DTE Recorder
Featuring a comprehensive backlit display, an easy-to-use menu system, a hard drive, and
a removable, rechargeable battery, the Focus DR-HD100 is the perfect DTE companion
for JVC GY-HD100/110 series and HD200/250 series ProHD camcorders. Audio, video,
timecode, and control information is passed through a single FireWire cable, allowing you
to record to disk and tape simultaneously. Designed for use in even the roughest condi-
tions, the DR-HD100 includes a six- or ten-second electronic shock cache to ensure that
you never lose footage. Advanced features such as time lapse (DV mode only) retro disk
recording and scene marking make the DR-HD100 Portable DTE Recorder the perfect DTE
companion for handheld shoots.
When recording is complete, your footage is ready to edit instantly—no capturing, file
transfer, or file conversion is required. The DR-HD100 is compatible with a wide range of
nonlinear editing systems. For a complete list of DTE-compatible NLE software, please visit
www.focusinfo.com.
Configurations
MODEL DR-HD100
60GB
DR-HD100
100GB
Recording Time
DV 4.5 hours 7.5 hours
HDV 1080i 4.5 hours 7.5 hours
HDV 720p 6 hours 10 hours
HDV Recording Mode
.m2t 1080i 50/60 • •
.m2t 720p 24/25/30/50/60 • •
QuickTime 1080i 50/60 • •
QuickTime 720p 24/25/30 • •
DV Recording Mode
AVI Type 1 • •
AVI Type 2 • •
AVI Type 2 24p • •
Avid OMF • •
Canopus AVI • •
Matrox AVI • •
MXF • •
Pinnacle AVI • •
QuickTime • •
QuickTime 24p • •
RawDV • •
Native QuickTime HDV Support
With the DR-HD100, you can record
720/24p, 25p, and 30p as native Quick-
Time HDV. The DR-HD100 extracts and
decodes the audio from the incoming
HDV stream, combines it with the vid-
eo stream, and wraps it as a QuickTime
HDV file. When recording is complete,
your QuickTime HDV file can be import-
ed directly into Final Cut Pro—no cap-
ture or conversion is required.
Applications
Athletics
Broadcasting
Corporate and Industrial Production
Education and Training
Events and Entertainment
Government
Healthcare
Independent Film
Security and Surveillance
Video Production
Weddings and Events
Worship

DR-HD100
DR-HD100 Page 2 of 2
www.focusinfo.com 800.338.3348
European Headquarters
COMO Computer & Motion GmbH
A Focus Enhancements Company
Lise-Meitner-Str.15
24223 Raisdorf
Germany
P [phone]
F [phone]
E [email protected]
©2007. Focus Enhancements, Inc. Specifications
are subject to change. All brand and product
names are trademarks of their respective compa-
nies. 8/07 MANL-1005-04
Corporate Headquarters
Focus Enhancements
1370 Dell Avenue
Campbell, CA 95008
P 800 338 3348 (toll free)
P 408 866 8300
F 408 866 4859
E [email protected]
E [email protected]
Technical Specifications
The Direct To Edit Advantage
With the Focus DR-HD100 Portable DTE
Recorder, you’ll go from acquisition to
editing with unparalleled speed, effi-
ciency, and reliability. Designed specifi-
cally for JVC GY-HD100/110 series and
HD200/250 series ProHD camcorders
and compatible with most third-party
editing software, the DR-HD100 fea-
tures Direct To Edit (DTE) video record-
ing technology that converts the output
from your DV or HDV camcorder or VTR
to a nonlinear editing (NLE) format and
records it on the internal disk drive. By
combining DTE Technology®with ad-
vanced caching and redundant tape and
disk recording, the DR-HD100 ensures
that you never miss an important shot or
lose critical footage.
MODEL DR-HD100
Input/Outputs DV25 or HDV video I/O (1 x 6-pin IEEE-1394)
FireWire computer I/F–up to 400 Mbps (1 x 6-pin IEEE-1394)
GPI and RS-232C control (1 x 3.5mm minijack)
Audio DV embedded 2-channel (16-bit, 48 kHz) or 4-channel (12-bit,
32 kHz) (RawDV only); HDV embedded MPEG-1 Audio Layer II
Video (DV) 25 Mbps; 8-bit 4:1:1 (NTSC-DV) or 4:2:0 (PAL-DV) (model dependent)
Video (HDV) MPEG-2 (MP@H-14) 720p (8-bit,19.7 Mbps) or 1080i (8-bit, 25 Mbps)
Timecode DV embedded timecode (drop or nondrop)
DV DTE File Formats RawDV, AVI Type 1, AVI Type 2, Matrox AVI, Canopus AVI, QuickTime,
AVI Type 2 24p, QuickTime 24p, MXF, Pinnacle AVI, Avid DV OMF
HDV DTE File Formats .m2t 720p 24/25/30/50/60, QuickTime HDV 1080i 50/60 and 720p
24/25/30
Disk 60GB or 100GB
Disk Speed 5400 RPM; 8MB cache
Disk Format FAT32
OS Compatibility Windows 98SE, ME, 2000, XP; Mac OS 9, Mac OS X
Power Adapter 15V DC, 0.7A; minijack power connector
Battery Custom removable Li-ion rechargeable battery
Battery Capacity1
(for battery included with model)
60GB configuration: Standard-capacity battery (90 minutes)
100GB2configuration: High-capacity battery (180 minutes)
Dimensions (h x w x d) 1.59" x 5.6" x 3.74" (40mm x 142mm x 95mm)
Weight 1.0 lb. (0.45 kg)
Shock Vibrations Operating: 50cm; Non-operating: 100cm; 50Hz–60Hz (1G constant)
Temperature Operating: 0°–40°C (32°–104°F); humidity: 30%–90% RH
Storage: -20°–60°C (-40°–140°F); humidity: 85% RH or less
Compliance CE, C-Tick, FCC, and RoHS
Warranty 2 years
Optional Accessories Standard-capacity Li-ion rechargeable battery (90 minutes)1; high-capac-
ity Li-ion rechargeable battery (180 minutes)1; external battery charger;
wired remote control unit; camera mount kit
1 Estimated recording time
2 Includes high-capacity cradle
