FOGE VL-BAL Series User manual

Instruction Manual
Product: VL-BAL Series
Long Bar Light
FÖGE ELEKTRONIK GMBH
Böhleswasenweg 11
72555 Metzingen
www.fogegmbh.com
info@fogegmbh.com
+49 7123 9570508
P1 Ver. 20.3.001

1. Intended Use
2. Technical Information
VL-BAL Series Long Bar Light is designed for use in industrial areas.
Purpose of the product is inspection of parts, code reading, OCR and
other applications need to be illuminated directly or with angle. Light is
positioned between part and camera..
The system must be operated within the limits specified in technical data
and used according to technical specifications as well as installation
instructions. The system must be used in such a way that no person are
in danger or machines and other material goods are damaged in the
event of malfunction or total failure of the system. Take additional
precautions for safety and damage prevention in case of safety related
applications
P2 Ver. 20.3.001
VL-BAL-25-400-R-24-C30 R 660nm 24VDC 11W M8 4 pin w 300mm cable 25 400 49 455 100
VL-BAL-25-400-W-24-C30 W 9000K 24VDC 16W M8 4 pin w 300mm cable 25 400 49 455 100
VL-BAL-25-500-R-24-C30 R 660nm 24VDC 14W M8 4 pin w 300mm cable 25 500 49 555 100
VL-BAL-25-500-W-24-C30 W 9000K 24VDC 20W M8 4 pin w 300mm cable 25 500 49 555 100
VL-BAL-25-600-R-24-C30 R 660nm 24VDC 16W M8 4 pin w 300mm cable 25 600 49 655 100
VL-BAL-25-600-W-24-C30 W 9000K 24VDC 24W M8 4 pin w 300mm cable 25 600 49 655 100
VL-BAL-25-700-R-24-C30 R 660nm 24VDC 19W M8 4 pin w 300mm cable 25 700 49 755 100
VL-BAL-25-700-W-24-C30 W 9000K 24VDC 28W M8 4 pin w 300mm cable 25 700 49 755 100
VL-BAL-25-800-R-24-C30 R 660nm 24VDC 22W M8 4 pin w 300mm cable 25 800 49 855 100
VL-BAL-25-800-W-24-C30 W 9000K 24VDC 32W M8 4 pin w 300mm cable 25 800 49 855 100
VL-BAL-25-900-R-24-C30 R 660nm 24VDC 24 M8 4 pin w 300mm cable 25 900 49 955 100
VL-BAL-25-900-W-24-C30 W 9000K 24VDC 36W M8 4 pin w 300mm cable 25 900 49 955 100
VL-BAL-25-1000-R-24-C30 R 660nm 24VDC 27 M8 4 pin w 300mm cable 25 1000 49 1055 100
VL-BAL-25-1000-W-24-C30 W 9000K 24VDC 40W M8 4 pin w 300mm cable 25 1000 49 1055 100
VL-BAL-25-1100-R-24-C30 R 660nm 24VDC 30 M8 4 pin w 300mm cable 25 1100 49 1155 100
VL-BAL-25-1100-W-24-C30 W 9000K 24VDC 44W M8 4 pin w 300mm cable 25 1100 49 1155 100
VL-BAL-25-1300-R-24-C30 R 660nm 24VDC 35W M8 4 pin w 300mm cable 25 1300 49 1355 100
VL-BAL-25-1300-W-24-C30 W 9000K 24VDC 52W M8 4 pin w 300mm cable 25 1300 49 1355 100
VL-BAL-25-1500-R-24-C30 R 660nm 24VDC 40W M8 4 pin w 300mm cable 25 1500 49 1555 100
VL-BAL-25-1500-W-24-C30 W 9000K 24VDC 60W M8 4 pin w 300mm cable 25 1500 49 1555 100
VL-BAL-25-1700-R-24-C30 R 660nm 24VDC 46W M8 4 pin w 300mm cable 25 1700 49 1755 100
VL-BAL-25-1700-W-24-C30 W 9000K 24VDC 68W M8 4 pin w 300mm cable 25 1700 49 1755 100
VL-BAL-25-2000-R-24-C30 R 660nm 24VDC 53W M8 4 pin w 300mm cable 25 2000 49 2055 100
VL-BAL-25-2000-W-24-C30 W 9000K 24VDC 80W M8 4 pin w 300mm cable 25 2000 49 2055 100
VL-BAL-25-2500-R-24-C30 R 660nm 24VDC 65W M8 4 pin w 300mm cable 25 2500 49 2555 100
VL-BAL-25-2500-W-24-C30 W 9000K 24VDC 100W M8 4 pin w 300mm cable 25 2500 49 2555 100
Model
Wavelength/
Color
Temperature
Power
Suppy Power Consumpon Connecon A(mm) B(mm) C(mm) D(mm) E(mm)
Colour

3. Dimensions / Installation
System operation assumes knowledge of the assembly instructions. The
symbols used for safety is shown in section 8(Safety) of manual.
P3 Ver. 20.3.001
Sample Applications
Diaper inspecon, non woven
inspecon, web inspecon
Part posioning, locaon on
large bins
Color check, part assembling,
posioning
Big metal part posioning,
checking holes, classificaon
Part posioning, existance,
angle checking Large part posioning,
orientaon to robots, LCD
panel
Large area counng parts, cap
counng, posioning
Large area linescan
applicaons, washing
machine drum
Camera
VL-BAL
Part

Product does not have this specification.
P4 Ver. 20.3.001
4.Electrical Connection
5. Display/Controls

6. Faults
In any case do not open the product.
If the leds not on check the connection and power supply.
If still leds are not on contact FÖGE or distributor.
7. Warnings
Connect the power supply and the display/output device according to the safety
regulations for electrical equipment.
The supply voltage must not exceed the specified limits.
Avoid shocks and impacts to the sensor.
Protect the cable against damage.
•
•
•
•
Possible Results of Avoidance
Risk of injury by electric shock
Damage to or destruction of the sensor
P5 Ver. 20.3.001

8. Safety
System operation assumes knowledge of the assembly instructions. The
following symbols are used in these assembly instructions:
9.Liability for Material Defects
All components of the device have been checked and tested for functionality at the production
facility. However, if defects occur despite our careful quality control, FÖGE or your dealer must be
notified immediately.
The liability for material defects is 12 months from delivery.
Within this period, defective parts, except for wearing parts, will be repaired or replaced free of
charge, if the device is returned to FÖGE with shipping costs prepaid. Any damage that is caused by
improper handling, the use of force or by repairs or modifications by third parties is not covered by
the liability for material defects. Repairs are carried out exclusively by FÖGE.
Further claims can not be made. Claims arising from the purchase contract remain unaffected. In
particular, FÖGE shall not be liable for any consequential, special, indirect or incidental damage. In
the interest of further development, FÖGE reserves the right to make design changes without
notification.
10. Decommissioning, Disposal
Remove the power supply and output cable on the sensor.
Incorrect disposal may cause harm to the environment.
Dispose of the device, its components and accessories, as well as the packaging materials in
compliance with the applicable country-specific waste treatment and disposal regulations of the
region of use.
Indicates a hazardous situation which, if not avoided, may result
in minor or moderate injury.
Indicates a situation that may result in property damage if not
avoided.
Indicates an electrical shock if not avoided or properly follow
comments.
P6 Ver. 20.3.001
This manual suits for next models
41
