FONESTAR TOUR-1T User manual

CONTROLS AND FUNCTIONS
1.- TOUR-1R receiver earphone output. Use the earphone provided for the receiver.
TOUR-1T transmitter mic./line input. Use the microphone provided for the transmitter.
If required use the transmitter input as a line level input, connect the audio source using a cable with a 3.5 mm stereo
plug. The transmission is mono (channel L). To adjust the input level to line level, press and hold the “-” button for
approximately 5 seconds. For more information, see Instructions for use.
2.- Information display.
3.- On/off button. Press and hold this button for approximately 2 seconds to switch the transmitter and/or the receiver
on/off.
Note: the receiver will switch off automatically if no signal is detected for 20 minutes.
The TOUR-1T transmitter also incorporates the MUTE function in this button, which deactivates the audio. Press the
button again during transmission to activate/deactivate the audio in the receivers.
4.- Volume control and channel selection. See Instructions for use for more information.
5.- Aerial (only available in the model TOUR-1T).
6.- Internal battery recharging input, micro USB B connector. Recharge the transmitter and/or the receiver using a
suitable cable or by making use of the optional charging case.
Note: the transmitter and the receiver will switch off during the battery charging process.
INSTRUCTIONS FOR USE
TRANSMISSION CHANNEL SELECTION
To change the transmission channel (both in the transmitter and in the receiver)), press and hold at the same time the
buttons “+” and “-” for approximately 2 seconds. At that moment, the channel indicator (CH) in the display will start to
flash indicating that the transmission channel can be modified.
Then press the buttons “+/-” to select the required channel. Wait 5 seconds and the channel will set automatically. The
channel indicator in the display (CH) will stop flashing and the lock indicator will light up again.
Make sure that the transmitter and the receiver operate in the same channel.
TRANSMITTER INPUT LEVEL ADJUSTMENT
The TOUR-1T transmitter automatically adjusts the input level depending on the input connected (mic. or line). If the input
level doesn’t adjust automatically, it can be done in the following way:
If connecting a line level input, press and hold the “-” button for 5 seconds until the loudspeaker symbol in the information
display starts to flash. The volume level in the display is set at 1.
If connecting a mic. level input, press and hold the “+” button for 5 seconds until the loudspeaker symbol in the information
display remains permanently lit. The volume level in the display is set at 4.
TOUR-1T, TOUR-1R
WIRELESS TOUR GUIDE SYSTEM AND POINT TO MULTIPOINT
TRANSMISSION
EN
TOUR-1T_TOUR-1R_MANUAL_(EN)_20170905_Maqueta ión 1 5/9/17 10:59 Página 1

TECHNICAL SPECIFICATIONS
TOUR-1T TOUR-1R
CHARACTERISTICS Wireless transmitter.
Compact size, lightweight and resistant
design.
Transmission to as many receivers TOUR-
1R as you wish on the same channel.
16 channels, GFSK mono modulation. Up
to 4 channels can operate simultaneously.
Range 50 m.
Delay 22 ms.
Internal rechargeable battery, up to 20
hours use.
Simple and intuitive handling.
LCD screen, displays chosen channel,
battery level and volume.
Automatic switch off.
Wireless receiver.
Compact size, lightweight and resistant
design.
16 channels, GFSK mono modulation.
Up to 4 channels can operate
simultaneously.
Range 50 m.
Internal rechargeable battery, up to 20
hours use.
Simple and intuitive handling.
LCD screen, displays chosen channel,
battery level and volume.
Automatic switch off.
RESPONSE 20-5,000 Hz
CONTROLS On/off and mute switch
Channel selection and volume control
On/off switch
Channel selection and volume control
INPUTS Mic./line with tie-clip microphone
included, 3.5 mm jack -
OUTPUTS - Earphone, 3.5 mm jack
POWER SUPPLY Rechargeable Li-ion battery, 3.7 V 600 mAh, micro USB B
Charging time 6 h
COLOUR White Blue
DIMENSIONS 40 x 88 x 12 mm depth
ACCESSORIES Lanyard
OPTIONAL TOURC-12: 12 receiver charging case
TOURC-35: 35 receiver charging case
TOURKS: receiver synchronizer
FONESTAR is a member of ECOEMBALAJES ESPAÑA, S.A. “ECOEMBES”, with number 03497 and all our products carry the symbol, backed by our membership
and subscription to the above mentioned organization with the recycling and subsequent management of our packaging.
FONESTAR is registered in the RAEE (Registro de Aparatos Eléctricos y Electrónicos) in a special section REI (Registro de establecimientos Industriales), with the
entry number 001851.
FO ESTAR S.A. - IF A28780443 - Polígono trascueto - 39600 Revilla de Camargo, Cantabria (Spain)
www.fonestar.com
DECLARATION OF CONFORMITY
FONESTAR SISTEMAS S.A.
Polígono de Trascueto s/n
39600 Revilla de Camargo, Cantabria (Spain)
Declares, under its responsibility, that the following equipment:
Description: Wireless tour guide system
Brand: FO ESTAR
Mode s: TOUR-1T, TOUR-1R
complies with that shown in the European Parliament and Council directive
1995/5/EC of 9th March 1999, transposed to Spanish legislation through the Real
Decreto 1890/2000, on 20th ovember.
Furthermore, it complies with the directives 2004/108/EC on Electromagnetic
Compatibility, 2006/95/EC on Low Voltage and 2011/65/EU on the restriction on the
use of certain dangerous substances in electrical and electronic appliances (RoHS).
This is class 1 equipment and has no use restrictions.
Revilla de Camargo, 16th October 2015
Juan Vallejo
Technical Engineer, Sales Departmentl
WARRANTY
This product has been tested and has passed the corresponding quality control prior to
being put on the market.
FONESTAR guarantees the suitability of the product for its specified use during a period
of 2 years from the delivery date and commits itself to repair or substitute the goods as
expressed in the Spanish law ‘La Ley General para la Defensa de los Consumidores y
Usuarios, Real Decreto Legislativo 1/2007 16 oviembre.
The lack of conformity in the first six months after purchase, due to a manufacturing
defect, will be rectified with no more than showing the proof of purchase. After six months
FONESTAR reserves the right to demand proof of the product being sold with that problem.
This warranty does not include damage produced by: inappropriate use or negligence,
accidents, worn out parts due to use, breakages, burns, spilt liquids or other substances,
excessive humidity, battery deterioration and internal manipulation of the device, the
software or its components by unauthorized persons, and in general any use that is
unrelated to the nature and purpose of the product.
If any service is needed during the warranty period because of lack of conformity, please
contact the business or distributor where the product was purchased in no more than 2
months after being conscious of the problem. It is only necessary to contact FONESTAR
if it is impossible or imposes an undue burden for them to solve it.
To benefit from this warranty it is necessary to show the proof of purchase with the date
clearly visible, with no corrections or crossing out.
This document adds information, and never decreases the consumers’ rights, which in all
cases are protected by the Spanish law ‘La Ley General para la Defensa de los
Consumidores y Usuarios, Real Decreto Legislativo 1/2007 16 oviembre.
