Fontaine MFF-PRK1-CP User manual

MFF-PRK1-CP - Polished Chrome
MFF-PRK1-BN Brushed Nickel
MFF-PRK1-ORB - Oil Rubbed Bronze
Cinta selladora para rosca
Ruban pour tuyau
Pipe Tape
Destornillador cruciforme
Tournevis Phillips
Phillips ScrewdriverAdjustable Wrench
Clé à molette
Llaveajustable
Palais Royal Collection
Pull-down Kitchen Faucet
Installation/Installation/
Instalación
CUSTOMER SERVICE
TOLL-FREE 1-877-482-5422
Tools You Will Need / Outils dont vous aurez besoin / Herramientas necesarias
SAFETY TIPS
•If you use soldering for the installation of the faucet, the seats, cartridges and washers will have to be removed
before using flame. Otherwise, warranty will be void on those parts.
•Cover your drain to avoid losing parts.
•0℃~55℃.
CONSIGNES DE SÉCURITÉ
•Si vous posez le robinet par brasage, il est essentiel de retirer les sièges, les cartouches et les rondelles avant
d’appliquer la flamme, faute de quoi la garantie sur ces pièces sera annulée.
•Couvrez le drain pour ne pas perdre des pièces.
•0℃~55℃.
CONSEJOS DE SEGURIDAD
•En el caso de utilizar soldadura para instalar el grifo, remueva los asientos, cartuchos y arandelas antes de usar la
llama. De lo contrario, se anulará la garantía para esos componentes.
•Tape la boca del desagüe para prevenir la pérdida de piezas pequeñas.
•0℃~55℃.
Revised 4-2018

Turn on the handle and press the
spray head button into theposition
shown by the arrow to check the
operation. This position is for
stream function.
6
Install the water inlet hoses and
tighten with the wrench.
45
Press the spray head button into the
other position as shown by the
arrow to check for the operation.
This position is for the spray function.
Fasten the hoisting block component to
the spray hose with screw, and connect
the spray hose to the water inlet hose.
Retainer Clip
3
Hand Shower
4
2
Hose
5
Spout
DescriptionNO.
Nut
1
Cartridge
8
9
7
Weight
10
Mounting Hardware
Handle ASSY.
6
Hose Guide
11 Water Inlet Hose
12
Braided Hose(Hot)
13
5N0055200CP/AP/HA/HBW0
5G0009000CP0
5F0007700CP/AP/HA/HBW0
5L0024100PL0
5B0010800CP/AP/HA/HBW0
Part No.
5T1A0003AL
5D0005300PL0
5G0M0069CC
5G0M0068CC
5L0071700PL0
5G0M006601CC7
5G0004000CC7
5G0004100CC7
Braided Hose(Cold)
MFF-PRK1-CP
MFF-PRK1-BN
MFF-PRK1-ORB
Replacement Parts / Pièces de rechange / Repuestos
Installation/Installation/Instalación
Revised 4-2018Revised 4-2018
3
Install the 8”base and desk plate.
12
Install washer, gasket and mounting nuts
onto the shank to cover the mounting
hole.
Tighten the mounting nut.
01
03
02 04
05 06
07
08
09
10
11
12
13
Hot
Cold
