FORESIGHT VE05ALT User manual

1
VGA & Stereo Audio CAT5 Extender With Chainable Output
ITEM NO.: VE02AL, VE05AL, VE02ALR
VE02AL, VE05AL is designed for VGA +Stereo Audio signal over cost effective CAT5 cable to
instead of VGA and Audio cable. VE02AL receiver built in chainable output to cascade the other
receiver for working range over 300 meters. It is optimum video performance under long cable
run and perfect for multiple monitor display.
This AV Extender is the smart, fast and cost-effective, eliminates costly and bulky VGA and Audio
cable and the most efficient way to move multimedia content from player to display. Used in
pairs, the VGA & Audio Extender is used in Shopping malls, public address systems, airports, train
& bus station, boardrooms, trade shows, computer based training application.
VE02AL 1 in 3 Out VGA with Stereo Audio CAT5 Extender Distribution Amplifier –
Chainable Function
zExtends VGA and stereo audio over one UTP CAT5 cable.
zEach set including one piece VE02ALT transmitter and one piece VE02ALR receiver.
zSupport analog stereo audio.
zDigital transmission on analog stereo audio for sound undistorted.
zSupports up to 1600x1200 @85Hz.
zLong range transmission up to 300 meters (Max.)
zDual output: 1 VGA loop output for local, plus 2 x CAT5 RJ45 output for remote side.
zBuilt in equalization, gain adjustment, chainable CAT5 output at remote unit.
zRemote unit could be daisy chained to another VE02ALR receiver to extended
working range over 300 meters and multiple displays.
zLocal unit VE02ALT local output: supports DDC、DDC2、DDC 2B,and provides virtual DDC, DDC
backup function, to avoid wrong setting at high resolution/frequency and cause remote
monitor unable display.
zApplication for airports, train & bus stations, window display, trades shows, exhibitions.
VE05AL 1 in 5 Out VGA with Stereo Audio CAT5 Extender Distribution Amplifier -
Chainable function
zEach set including one piece VE05ALT transmitter and one piece VE02ALR receiver.
zDual output: 1 VGA loop output for local, plus 4 x CAT5 RJ45 output for remote side.
zEach VGA display equipment request one VE02ALR receiver at remote side. (Order
separately).
zUse CAT5 cable instead of VGA cable.
zLong range transmission up to 300 meters (Max.).
zBuilt in equalization, gain adjustment, chainable CAT5 output at VE02ALR remote unit.
zSupports up to 1600x1200 @85Hz.
Option Model:
VE02ALR VGA with Stereo Audio CAT5 Receiver– Chainable function
zWork with VE02ALT, VE05ALT as receiver for extra remote VGA display equipment.
zIt could be daisy chained for another VE02ALR to extended working range over 300
meters and multiple displays.
zBuilt in equalization, gain adjustment.
zSupports up to 1600x1200 @85Hz.
Installation View:
Cable:
Video Link cable using hi quality CAT5E UTP/STP or CAT6 UTP cable.
Please noted STP cable could enhance noise rejection, but also less transmission
range and picture sharpness quality.
RJ45 Define:
FORESIGHT CCTV INC. | 5863 Leslie Street, Unit#713, North York, Ontario,Canada, M2H 1J8 | http://www.foresight-cctv.com | 1-888-GO2-CCTV

Link Cable (TIA/EIA-568-B )
1. Orange-white Red +
2. Orange Red -
3. Green-white Green +
4. Blue Audio -
5. Blue-white Audio +
6. Green Green -
7. Brown-white Blue +
8.Brown Blue–
Panel View:
VE02ALT
VE05ALT
VE02ALR
View of installation:
VE02ALT/VE05ALT Local Unit Button Setting:
2
FORESIGHT CCTV INC. | 5863 Leslie Street, Unit#713, North York, Ontario,Canada, M2H 1J8 | http://www.foresight-cctv.com | 1-888-GO2-CCTV

3
VE02ALT/VE05ALT LED:
Blue (front panel): power on/off
RJ45 LED (Link cable connector):
Green: status (Refer the below)
Yellow: status (Refer the below)
LED status indication:
CH1 ~ CH4
Green on/off: VGA Signal
Green flash：EDID checksum error
Yellow on: use monitor DDC
Yellow off：use built in DDC
Yellow flash: monitor EDID checksum Error
Yellow, Green, Blue all flash：Memory error
VE02ALT/VE05ALT local unit EDID set up:
Setup Monitor EDID: When Yellow LED off, press “SETTING” button until Blue LED flash,
then release the “SETTTING” button, yellow LED will be on.
Setup Built in EDID：When Yellow LED on, press “SETTING” button until Blue LED flash,
then release the “SETTTING” button, yellow LED will be off.
Reset factory default: First to unplug the power, then press “SETTTING” button until
reconnect power and Blue LED flash.
Auto Backup EDID：Change new monitor，it will start the monitor EDID backup.
VE02ALR Remote unit adjustment:
EQ equalization (sharpness)
Gain signal boost (brightness)
VE02ALR LED:
Blue (front panel): power on/off
RJ45 LED (Link cable connector):
Green: signal lock (LED on )
Caution:
The cabling must away from any equipment with electromagnetic wave, i.e.: microwave,
radio equipment, high voltage lines.
FORESIGHT CCTV INC. | 5863 Leslie Street, Unit#713, North York, Ontario,Canada, M2H 1J8 | http://www.foresight-cctv.com | 1-888-GO2-CCTV

Specification:
ITEM NO. VE02ALT VE05ALT
Resolution Up to 1600 x 1200 non-interlaced to 85 Hz
Video Bandwidth Local 750MHz / Remote 350MHz-3db
Video Input / Output RGB Analog, 75Ω, 0.7Vp-p
Sync Input / Output H/V Separated, 5V TTL
Horizontal Frequency 30-95 KHz
Vertical Frequency 50-180 Hz
VGA Connector 15-pin Mini D-Sub (High Density)
Analog Audio Input / Output 10KΩ, 3Vp-p (Max)
Analog Audio Bandwidth 20-20KHz -3dB
Analog Audio Connector 3.5mm Stereo Phone jack
Connector Optical
Link Connector 2 x RJ-45 4 x RJ-45
Max Distance Up to 1000 ft. (300M)
Power Supply 5V DC 2000mA Regulated (External)
Power Consumption 700mA (Max)
Dimensions (mm) 125 x 96 x 30
Weight (g) 280
ITEM NO. VE02ALR
Resolution Up to 1600 x 1200 non-interlaced to 85 Hz
Video Bandwidth 150MHz
Video Output RGB Analog, 75Ω, 0.7Vp-p
Sync Output H/V Separated, 5V TTL
Horizontal Frequency 30-95 KHz
Vertical Frequency 50-180 Hz
VGA Connector 15-pin Mini D-Sub (High Density)
Analog Audio Output 10KΩ, 3Vp-p (Max)
Analog Audio Bandwidth 20-20KHz
Analog Audio Connector 3.5mm Stereo Phone jack
Link Connector RJ-45
Max Distance Up to 1000 ft. (300M)
Power Supply 5V DC 2000mA Regulated (External)
Power Consumption 700mA (Max)
Dimensions (mm) 88 x 96 x 30
Weight (g) 200
Installation Tips:
1. Due to the inside of CAT5 cable that the pairs of wires are twisted at different rates, AND the different
quality on cable itself and installation that will cause different signal arrival time at each pair. If there
are big different at arrival time, that will cause RGB skew status. This is seen on the monitor as
separation, or lack of convergence in colors. Normally it happens on long CAT 5 cable runs.
2. Recommend to use following cabling way to reduce skew status, to add special made “skew immunized
adaptor”, 2 pieces included at the package.
CAUTION: to avoid display equipment damaged, be sure to make correct cable connection and
power for VE02ALT, VE05ALT, and VE02ALR before connecting VE02ALT, VE05ALT, and VE02ALR.
