Icron USB 2.0 Ranger 2304 User manual

USB 2.0 Ranger® 2304
4-Port USB 2.0 100m Cat 5e
Extender System
Quick
Start
Guide
12
34
Connect the REX to the AC adapter
and plug it into a power source.
Connect the LEX to the computer
using the included USB cable.
Attach USB device(s) to the REX.
Computer
Pro AV
KVM Extension
Digital Signage
Medical Imaging
Industrial Automation
Digital Projection
Icron’s USB and Video
Extension Solutions
For additional details on configuration and
operation of your USB 2.0 Ranger 2304,
refer to the complete user guide
available online at:
icron.com/2304
For technical support with your
USB 2.0 Ranger 2304 product, contact:
icron.com/support
icron.com
Max 100m (Cat 5e cable not included)
1Place extenders where desired and connect
the Cat 5e extension link cabling to the
Link ports (RJ45) on the LEX and REX.
Link
Pair Config
Link
Pair
DC IN 24V@1A Config
Link
Pair
DC IN 24V@1A Config
Link
Pair Config
Host
Activity
Link
Power
Icron’s ExtremeUSB® high performance USB 2.0 extension technology enables users
to connect any USB device over any transport media. ExtremeUSB is used in most
applications where USB devices need to be more than five meters away from a host
computer. The ExtremeUSB protocol preserves standard USB functionality while
accommodating the increased cable delay inherent in extended range transmissions.
This technology is available in consumer ready extension products and various form
factors for OEM and embedded applications.
icron.com
Extending USB over Cat 5,Wireless, Fiber and Powerline
Before you get started, ensure that all the drivers required for your USB device(s) are installed.
LEX = Local Extender, REX = Remote Extender
90-01095-A02
