Sinovision HDE01X User manual

USER MANUAL
HDMI OverEthernet
HDE01X
1Introduction
2Specifications
3Package Contents
4Panel Descriptions
5Connectionand operation
6Application diagram

1Introduction
HDMI OverEthernet isbasedonTCP/IP standard. It transmit yourHDdisplaywiththe
high resolutionsup to395 feet(120 meters)awayfromyourHDMIorDVI-D sourcebyusing
oneCAT5e/6cable.WiththeadvantageofTCP/IPstandard，youcanextendyourHD video
tomultipledisplays byusing an EthernetSwitch.
2Specifications
ØFollowing TCP/IPstandard.
ØSupport HDMI1.3protocol.
ØHDCP1.1 & 1.2protocolcompliant
ØSupport point-to-pointmode,onepoint-to-manymodeandcascadeconnection mode.
ØSupport IRextenderfunction allowsIRremotecontrolofSourcedevicesfromremote
viewing location bysendingIRcommandsreceived inthevicinityofthe Displaybackto
the Sourcedevices.
HDTV Resolutions 480p,576p,720p,1080p
Audio Samplerate：32kHz,44.1kHz and48kHz
IRremotecontrol 38KHz;NEC
HDMI HDMI 1.3
HDCP HDMI 1.2
Power adapter Input:100V -240V (50-60Hz)Output:5V/1A
Power consumption HDMISender: 3WHDMI Receiver: 3W
Size(L-W-H) 100×60×25mm
Weight 70g
Operating Temperature/Humidity 0℃-70℃/ 10% -80%RH(no condensation)
Storage Temperature/Humidity -10℃-80℃/5%-90%RH(no condensation)
3.0 PACKAGE CONTENTS
Beforeattemptingtousethisunit, pleasecheck the packagingandmakesurethe
following itemsarecontainedinthe shippingcarton:
1)Mainunit No. 1Sender, Mainunit No.2Receiver
2)Twopiecesof5V DC PowerSupply.
3)apiecesofIRtransmitterandapiecesofIRreceiver
4)User’sManual

4PanelDescriptions
HDMI Sender
5V/1A SupplypowerfortheSender
RESET Holddownthe keyfor10seconds,themodelwillRestorethe default setting
IR-OUT ConnectIRtransmittertothisPort.
HDMI - IN Connect HDMI Source tothisPort.
STATUS Whensystemstart up,theGreenLED will be on Whentransmit video, the
led will blink.
Power Power on,TheRed ledison
HDMI Receiver
5V/1A SupplypowerfortheReceiver
RESET Holddownthe keyfor10seconds,themodelwillRestorethe default setting
IR-OUT ConnectIRreceiver tothisPort.
HDMI - Out Connect HDMI sink device tothisPort.
STATUS Whensystemstart up,theGreenLED will be on Whentransmit video, the
led will blink.
Power Power on,TheRed ledison

5Connection andoperation
1) Connectthe HDMIsource (suchas DVD, PS3,STB )totheHDMIINofSender.
2)Connectthe IRsendertothe SenderIROUTPort,and BeDirectedatHDMI video source’sIR
receiver.
3) Connectthe HDMI outofReceivertoHDTV display.
4) Connectthe IR receivertothe Receiver IRINPort.
5) Useone Cat5e/6cableup to120mtoconnect the SenderandReceiver.
6) Plug twopieces of5Vpower supplyintothe Sender andReceiver.
7) Poweron the HDTV display and HDMIsource.
6Application diagram
Application1Application2
