Forest MODULAR PERGOLA User manual

FIXING PACK CONTAINS:
It is vital that you build your new pergola on a level ground in your desired location.
4 x 60mm Screws
QTY: 36
5 x 100mm Screws
QTY: 16
Making British gardens great
MODULAR PERGOLA
BASE KIT INSTRUCTIONS
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
ISSUE: 0321
FIXING PACK CODE: MODPERGFP
We recommend using the following tools (not supplied):
Tape
Measure
Pozidrive
Screwdriver
Drill & 2mm
Drill Bit
Hammer Ladder Spirit Level
REMINDER
Always pre-drill before
screwing.
IMPORTANT
Assembly requires 2+
adults.
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
THE ROOF OF THIS PERGOLA IS NOT A LOAD BEARING STRUCTURE
Missing something or need more information?
Call our aftersales team on
0333 777 7089
Visit our website for spare instructions and
more information
www.forestgarden.co.uk

45mm
45mm
1
2
60MM
SCREWS
Lay the parts on a at surface to help with accuracy. Place 2 posts onto the matching half lap joint as shown above. Ensure all of
the faces are ush and screw into place with 60mm screws. Repeat this process with the other 2 posts.
Place a fascia board onto the 70 x 70mm frame. Ensure the one end is ush with the side of the 70 x 70mm post. This will result
in the opposite end protruding out. Before screwing, ensure the fascia board is overhanging the top of the frame by 45mm. Then
screw into place. Repeat the process for the other set of posts and frame.
60MM
SCREWS
CONSTRUCTION
3100MM
SCREWS
Stand all of the posts up with the fascia boards facing outwards. Screw the other 2 fascia boards onto the fascia boards already
secured. This will create a completed square shape. Ensure all fascia boards are ush at each corner and at matching heights.
Screw at the meeting faces.
Overhang
Flush
FRAME
POST
FASCIA BOARD
FASCIA BOARD
FASCIA BOARD

885mm
4
Screw the central boards to the fascia boards. Ensure each one is 885mm from the inner face of the fascia board shown above.
As a result, there will be an 80mm space between the central boards. Ensure the top edge is ush to the top edge of the fascia
boards.
60MM
SCREWS
Attach the additional batten to the central board (one for each board). Ensure the bottom face of the batten is ush to the
bottom face of the central boards. Secure with 4 x screws at each side shown above. Place and screw through the panel frame
and into the fascia to secure. Repeat for both panels.
5
80mm
100MM
SCREWS
60MM
SCREWS
STABILITY
We strongly advise that you anchor your pergola down with either xture examples shown below to enhance stability. You will need to
purchase these separately. Apply each xture to each leg after fully constructing your pergola. These are just two examples of many, that you
could use to anchor your pergola.
FOR PATIO/DECKING (HARD SURFACES)
Screw a ‘heavy duty’ bracket to each post and to
the oor to secure.
FOR GRASS/SOIL (SOFT SURFACES)
Screw the a ‘heavy duty’ bracket to each post and
use a ‘hex peg’ or similar type of xing to anchor
the bracket into the ground.
CENTRAL BOARD
SUPPORT BATTEN
SLATTED PANEL

WANT TO ADD MORE PRIVACY TO
YOUR PERGOLA?
You can purchase further packs of 2 x screens for your
pergola base kit. With the modular pergola, position the
screens to suit you and your garden.
Part Code Description No.
70702000HLPTR 70 x 70 x 2000mm Posts 4
100301910BPTR 100 x 30 x 1910mm Central Board 2
70701910HLPTR 70 x 70 x 1910mm Frame 2
55401910PTR 55 x 40 x 1910mm Support Batten 2
885MPSLAT 885 x 45 x 1910mm Slatted Panel 2
135301940BPTR
135 x 30 x 1940mm Fascia Board 4
Modular Pergola (MODPERG)
CHECK YOU HAVE ALL YOUR PARTS.
(The parts do not have codes on them. They are listed below should you need to order one.)
TREATED TIMBER CONTAINING A BIOCIDAL PRODUCT
CONTROL OF WOOD DESTROYING ORGANISMS
Active Ingredients - Propiconazole, Tebuconazole, IPBC, Permethrine, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated)
Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated)
Wear gloves when handling. Avoid inhalation of sawdust. Do not use in contact with drinking water or food. Do not use for animal
bedding or in sh ponds. Dispose of treated wood responsibly.
The components provided may be heavy. Please lift with caution and with a minimum of 2 people.
HEALTH & SAFETY
We strongly recommend that PPE (Personal Protective Equipment) is used throughout your build to ensure you are protected
from any potential health and safety risks. Do not exempt yourself from wearing PPE.
