Forest CORNLINPL160 User manual

Making British gardens great
TALL CORNER LINEAR PLANTER
INSTRUCTIONS (1600x1600mm)
ISSUE: 0121
Tape Measure
We recommend using the following tools (not supplied):
Drill & 2mm
Drill Bit
Spirit Level
FIXING PACK CONTAINS:
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
REMINDER
Always pre-drill before
screwing.
IMPORTANT
Assembly requires 2+
adults.
Missing something or need more information?
Call our aftersales team on
0333 321 3142
Visit our website for spare instructions and
more information
www.forestgarden.co.uk
Pozidrive
Screwdriver
1 2
Position the Back Panels in your desired location. Begin
at the back corner and secure the Back Panels together
as shown above.
Secure the rst End Panel (360mm) to the Back Panel
(1600mm).
4 x 50mm Screws
QTY: 20
3.5 x 30mm Screws
QTY: 18
END PANEL (360mm)
BACK PANEL (1580mm) BACK PANEL (1600mm)
6 x 100mm Screws
QTY: 14
5 x 70mm Screws
QTY: 4
FIXING PACK CODE: CORNLINPL160FPPLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN
BACK PANEL (1600mm)

Secure the rst Front Panel (1248mm) to the End
Panel (360mm), using 50mm screws.
3 4
Secure the rst Front Panel (1248mm) to the second
Front Panel (1200mm), using 70mm screws.
FRONT PANEL (1248mm)
FRONT PANEL (1200mm)
70MM
SCREWS
Secure the other End Panel (360mm) to the Front
Panel and Back Panel, using 50mm screws. Screw in
between the slats into the battens.
78
Insert the Short Base (1200mm) into the space
provided. The Short Base will slot into the section with
the End Panel attached.
56
Insert the Long Base (1560mm) into the space
provided. The Long Base will butt up against the Short
Base in the corner.
SHORT BASE (1200mm)
LONG BASE (1560mm)
Fix the Long Base (1560mm) into place, by screwing
into the battens beneath as shown above.
100MM
SCREWS

9
Fix the Short Base (1200mm) into place, by screwing
into the battens beneath as shown above.
The Short Base (1200mm) will sit on top of the
battens provided. The panel battens will sit into the
base’s notches.
The Long Base (1560mm) will sit on top of the battens
provided. The panel battens will sit into the base’s
notches.
100MM
SCREWS
TOP TIP - MARK OUT WHERE EACH BATTEN IS LOCATED TO ENSURE YOU
SCREW DIRECTLY INTO THEM ONCE THE BASE SITS ON TOP.
TOP TIP - MARK OUT WHERE EACH BATTEN IS LOCATED TO ENSURE YOU
SCREW DIRECTLY INTO THEM ONCE THE BASE SITS ON TOP.
Layout and position the Jute Liner material inside
your planter. Overlap over the top edge and use the
Fascias to hold into place.
Secure the Fascias to the Panels. Ensure the Jute Liner
is held in position when screwing the Fascias into place.
10
JUTE LINER
FRONT PANEL FASCIA
BACK PANEL FASCIA
END PANEL FASCIA
11
CHECK & TIGHTEN ALL FIXINGS APPLIED TO THE
PRODUCT ON A REGULAR BASIS

CHECK YOU HAVE ALL YOUR PARTS.
(The parts do not have codes on them. They are listed below should you need to order one.)
The components provided may be heavy. Please lift with caution and with a minimum of 2 people.
Label Part Code Description No.
ASPLP1600TCR Back Panel 1600x828x48mm 1
BSPLP1580TCR Back Panel 1580x828x48mm 1
CSPLP0360TCR End Panel 360x828x48mm 2
DSPLP1248TCR Front Panel 1248x828x48mm 1
ESPLP1200TCR Front Panel 1200x828x48mm 1
FSPFB1200 Short Base 1200x360x30mm 1
GSPFB1560 Long Base 1560x360x30mm 1
HJLINER160160 Jute Liner 1
I60201600PAII45PT Back Panel Fascia 1600x60x20mm 2
J60200400PAII45PT End Panel Fascia 400x60x20mm 2
K60201260PAII45PT Front Panel Fascia 1260x60x20mm 2
Tall Corner Linear Planter 1600x1600mm (CORNLINPL160)
TREATED TIMBER CONTAINING A BIOCIDAL PRODUCT
CONTROL OF WOOD DESTROYING ORGANISMS
Active Ingredients - Propiconazole, Tebuconazole, IPBC, Permethrine, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated)
Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated)
Wear gloves when handling. Avoid inhalation of sawdust. Do not use in contact with drinking water or food. Do not use for animal
bedding or in sh ponds. Dispose of treated wood responsibly.
HEALTH & SAFETY
We strongly recommend that PPE (Personal Protective Equipment) is used throughout your build to ensure you are protected from
any potential health and safety risks. Do not exempt yourself from wearing PPE.
Use the labelled components to help identify the part code and description.
ABCD
E F G
I
J
K
H
