Forest Oppsum75ddm User manual

Making British gardens great

FIXING PACK CODE: MSUMFP5

FIXING PACK CONTAINS:

Z-Brackets(45mm)

QTY: 4

Barrel Bolts

QTY: 2

Cranked Hinges

QTY: 6

Turn Buttons

QTY: 3

Hotbed Handles

QTY: 2

4 x 50mm Screws

QTY: 83

3.5 x 30mm Screws

QTY: 164

3.5 x 25mm Screws

QTY: 61

Felt Tacks

QTY: 154

4 x 40mm Screws

QTY: 14

1.6 x 30mm Nails

QTY: 13

ISSUE: 0222

SUMMERHOUSE

INSTRUCTIONS

PENT SUMMERHOUSE (SIZE RANGE 7x5, 8x6, 10x6)

Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB

EU Authorised Representative: Authorised Representative Service, 77 Camden Street Lower Dublin, D02 XE80, Ireland

Thank you for purchasing your summerhouse from Forest Garden. Simply follow these step-by-step instructions

and our top tips, and you’ll be enjoying your summerhouse for many years to come. If you have any questions or

need advice, our friendly team is here to help.

Missing something or need more information?

Call our aftersales team on

0333 321 3142

Visit our website for spare instructions and

more information

www.forestgarden.co.uk

BEFORE YOU START

Please read through these instructions to familiarise yourself with your summerhouse. We recommend that you check

all the components using the lists found on the front and back pages before you start to build.

All of our summerhouses are constructed in the same way. They simply come with different components depending on

the type of summerhouse you have. Don’t worry if your xing pack contains some spare items at the end of the build

(you haven’t missed a bit!) we have sent you a generic xing pack to suit the summerhouse range.

Please note that your door windows have a coloured protective lm on them. We advise to keep the protective lm

on, until the build is complete to prevent any possible damages to the windows during assembly.

It is vital that you build your new summerhouse on a solid, level base. Timber or plastic bases are

ideal, as are concrete slabs or solid concrete.

We recommend using the following tools (not supplied):

If you have an existing base and think it is suitable for your new summerhouse to be sited on,

it is important that you check it is level and doesn’t deviate by any more than 15mm from edge

to edge. If this is not the case, the building will twist causing gaps to appear in the sections and

causing the roof, doors and windows to misalign.

There is more information on base preparation on our website www.forestgarden.co.uk

Assembly is relatively straightforward if you follow these step-by-step instructions.

We recommend aligning components properly before securing them together and pre-drilling

screw holes to avoid splitting the timber.

BASE PREPARATION

TOOLS NEEDED

Timber Base

Self-constructed/

Buy pre-made

Concrete

Concrete surface/

Concrete slabs

Pro Shed Base

Interlocking

eco-friendly base

Soil

A base of soil or

grass only

Broken Slabs/Gaps

Uneven slab sizes

with no cement

REMINDER

Always pre-drill before

screwing.

IMPORTANT

Assembly requires 2+

adults.

PLEASE KEEP PLASTIC BAGS AND SMALL PARTS AWAY FROM CHILDREN

Tape

Measure

Sharp Knife Pozidrive &

Flat-head

Screwdriver

Drill & 2mm

Drill Bit

Hammer Ladder Spirit Level Hand Saw

TO AVOID DANGER OF SUFFOCATION, PLEASE KEEP THIS FILM AWAY FROM BABIES AND CHILDREN

MOVEMENT, TWISTING & WARPING

Wood contains a natural level of moisture so decreasing humidity levels in the surrounding air may cause panels to change their

shape as the porous bres shrink. This can be exaggerated during prolonged periods of dry weather. Movement and gaps in

timber products are normal. In most cases, the wood will revert to its original form once the high temperatures subside and there

is more moisture content in the air. Similarly, in winter months, the opposite may occur with wood swelling.

CARE & ATTENTION

To help you get the most out of our products, it is useful to know a little more about the properties of timber, what

is normal and how your summerhouse may behave as the seasons change. Wood is an extremely durable material

for construction but, as a natural product, when used outdoors it is susceptible to changes in the environment.

EXPANSION, CONTRACTION, SPLITS & CRACKS

All timber will expand and contract according to its environment. As a result of this expansion and contraction, it is very common

to see splits and cracks developing in the wood. Splits are common during the spring and summer months as the wood begins to

dry out. The outer surface dries rst and contracts over the still expanded core of the wood. The result is that splits and cracks

appear along the grain of wood. These splits are not a fault and do not affect the structural integrity of a product.

MOULD & BLUE STAIN

Mould is a surface-dwelling fungus that feeds on the nutrients and debris contained in the surface cells of timber. The most

common problems associated with mould are discoloured timber and an increase in permeability of the timber. Blue stain is part

of the same family but penetrates deeper into the surface layers of the timber. It stains the timber a dark blue, whereas mould is

usually black. These do not cause the timber to rot. Keep the building well ventilated to avoid mould.

POSITION YOUR SUMMERHOUSE IN THE BEST LOCATION IN YOUR GARDEN

Avoid areas where water pools and which are constantly wet. Position away from trees and cut back any overhanging foliage which can

cause moisture to be trapped against the summerhouse walls and debris to collect on the roof.

RAISE YOUR SUMMERHOUSE OFF THE GROUND

Ideally, any concrete base should be the same footprint as the summerhouse to allow surface water to run off without pooling. A timber

base can also be used. Raise your summerhouse 50mm above ground level.

SEAL THE BEARERS

If using a wooden base, we recommend treating it with a treatment containing wax or oil. Also coat the bearers that come into contact

with the ground to prevent moisture rising.

USE AN END-GRAIN PROTECTOR

To protect the corners and panel joins, an end grain treatment can be applied.

SEAL THE PANELS & WINDOWS

Use a exible silicone sealant around windows to prevent water ingress. This can also be used where two sections of the summerhouse join

together. Apply internally.

Treat your building annually. We advise the application of a high-quality preservative that contains a

mildewcide. For more information on the conditions of our guarantee see forestgarden.co.uk.

CONSIDER ADDING GUTTERS

Adding guttering around the fascia of the summerhouse will redirect rain water away from the summerhouse’s foundation.

KEEP VENTILATED

Good airow around the perimeter of the summerhouse and regular ventilation inside the summerhouse will help prevent mould and

mildew.

CONSIDER A WEATHERPROOFING STAIN OR CLEAR TREATMENT

We recommend you painting your summerhouse with a weatherproong treatment at least once a year. This will help maintain the wood,

stabilise timber movement and help prolong the life of your summerhouse.

THINGS THAT YOU MIGHT SEE IN YOUR PRODUCT

8 TOP TIPS TO ENSURE YOUR SUMMERHOUSE IS FULLY WATERPROOF

THE ROOF OF THIS BUILDING IS NOT A LOAD BEARING STRUCTURE

ADVICE ON FELT HANDLING & USAGE

Roof felt is exible at temperatures above 5°C. In cold temperatures, extra care must be taken when handling and installing to prevent cracking

and damage to the felt. The felt should not be rolled, folded or used in temperatures lower than 5° C. In cold temperatures, the felt should be

stored indoors above 10°C for 24 hours prior to use. Felt must be lifted, not dragged, and should be stored on its end on a dry surface.

HEALTH & SAFETY

We strongly recommend that PPE

(Personal Protective Equipment) is

used throughout your build to ensure

you are protected from any potential

health and safety risks. Do not

exempt yourself from wearing PPE.

PENT

7’

5’

PENT

8’

6’

PENT

10’

6’

KEY

A2ft Panel (Window)

(590 x 1603mm) B2ft Panel (Window)

(590 x 2059mm) C3ft Panel

(885 x 1603mm) D3ft Panel

(885 x 1717mm)

E3ft Panel (Window)

(885 x 2059mm) F4ft Panel

(1180 x 1603mm) G4ft Panel

(1180 x 1717mm) HDoor Panel

(1475 x 2059mm)

Indicates the panel orientation during construction. This will

apply to all of the corners for your chosen summerhouse.

IDENTIFY YOUR SUMMERHOUSE

From the section layout below, identify your summerhouse based on the width and depth dimensions – eg

7x5. You’ll need this to identify the side panel positions. Use the key and visuals below as a guide.

PANEL POSITION

When assemblying your wall panels, ensure the timber framing on the panels are

ush at the corners. The space left next to the board is for the cover strip to sit into.

Ensure to apply the same panel position to all corners.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

1a FLOOR & PANEL LAYOUT

1c RIGHT & LEFT APEX SECTIONS

1b SIDE PANELS

Position the oors in your desired location.

Turn the oors upside down to secure the

sections together by screwing through the

adjoining bearers.

Layout the panels around your summerhouse

base.

We recommend to start in a back corner then

work from the back panels to the front

panels for assembly.

(8x6 & 10x6 only). Secure the panels into

place by screwing into the oor bearers.

Attach the Right-Hand Apex Section by

screwing to the wall panels as shown below.

Secure the Right-Hand Apex Section to the

Front and Back Panel as shown below. Repeat

the process for the Left-Hand Apex Section.

Start at a back corner. See the section layout

on page 4 to conrm position. Secure the

corner as shown below.

Repeat the process for the remaining panels

and secure the panels together. Make sure

that the bottom frame of the wall panel rests

on the outer edge of the oor. Use 4 x 50mm

screws for the front and back panels only.

(7x5 only). Please note that the direction

of the oor bearers are different on the 7x5

summerhouse. Secure the panels into place by

screwing into the oor bearers.

EG. INSIDE CORNER

SIDE PANEL

BACK PANEL

EG. BACK PANELS

RIGHT-HAND APEX SECTION

EG. INTO FLOOR BEARERS

7X5

8X6 & 10X6

RIGHT-HAND APEX SECTION

OUTSIDE INSIDE

15x12

Beading

Plastic

Z-Strip

Window

Sits onto

Z-Strip

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

BE CAREFUL NOT TO HIT

THE WINDOW WHEN

NAILING THE BEADING

INTO PLACE.

30MM

NAILS

30MM

NAILS

2a WINDOWS, Z-STRIPS & BEADING

3a COVER STRIPS & DOOR STRIPS

2b INTERNAL WINDOW STRIPS

Place the Z-Strip into position. Trim the

Z-Strip to the window opening measurement.

Position the Window onto the Z-Strip.

Place the 15x12mm Beading onto the Z-Strip

and up against the Window. Secure in place

with 3 x nails per single window. (Use 2 x nails

per window for the front double window panel

if applicable).

Remove any protective lm after the assembly

is complete.

Attach the Back Cover Strips to the corners

and adjoining panels. Ensure they are ush to

the bottom edge of the panels.

Attach the Front Cover Strips to front corners

and adjoining panels. Attach the Side Cover

Strips to the adjoining side panels. Ensure they

are ush to the bottom edge of the panels.

Secure the Door Weather Strips. Ensure they

are in contact with the oor and against the

inside face of the wall panel frame.

Secure the Window into position by sliding the

Top and Bottom Strips into the frame and

screwing in place.

Further secure by sliding the Side Strips into

the frame and screwing in place.

Repeat the same process for the other

Windows. Ensure all Windows are xed into

place.

WINDOW BEADING Z-STRIP

INSIDE OUTSIDE

TOP/BOTTOM WINDOW STRIPS SIDE WINDOW STRIPS

WALL

PANEL

FRAME

DOOR

WEATHER

STRIP

BACK COVER STRIPS FRONT & SIDE COVER STRIPS DOOR WEATHER STRIPS

WINDOW POSITIONING

715.5mm 783mm

912mm

10x6

8x6

980mm

1010mm

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

3b DOOR STRIPS

4b ROOF SHEETS PREPARATION

4a ROOF BEAM(S)

Centralise the Top Weather Strip onto the

Door Weather Strips. Screw into place. All 3

strips will overhang into the door way.

Secure the Door Hinge Strips. Ensure they are

in contact with the door batten and against the

Door Weather Strips.

Attach the Canopy Strip. Ensure it is screwed

to the front panels frame. Attach the Kick

Plate Strip.Ensure it is ush to the batten.

Before placing the OSB Roof Sheets onto the roof, screw the 2 x Roof Strips along the edge

of the OSB Roof Sheets as shown below. Repeat the process for both ends. Please refer to the

assembly step which suits your summerhouse size.

(7x5 only). Screw 1 x Side Roof Strip at each

side along the other edge of the OSB Roof

Sheets as shown below. Ensure they are central.

Attach a Z-brackets onto the face at both

ends of your Beam(s) as shown below. The

Z-brackets will mould into shape once secured

to the front and back panels framework.

For the 7x5, you will have only one beam. Screw the Z-brackets to the centre of the front and

back panels using the measurement as shown below.

For the 8x6 & 10x6, you will have two beams Screw the Z-brackets to the front and back panels

using the measurements as shown below.

TOP WEATHER STRIP DOOR HINGE STRIPS

END ROOF STRIP

ROOF BEAM

KICK PLATE STRIP

CANOPY STRIP

KICK PLATE STRIP

Z-BRACKET7X5 8X6 & 10X6

END ROOF STRIP SIDE ROOF STRIP

7X5 8X6 & 10X6 7X5

50mm

DOOR FACE

PIN IN LINE

WITH DOOR

FACE

DOOR

150mm

5mm

150mm

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

Allow a 5mm gap at the top

when tting the door.

6a DOOR HINGES

5ROOF FELT & FASCIAS

Make sure the inner edge of the pin on the

hinge is in line with the door face.

Attach 3 hinges to the door frame. Use the

measurement provided below for positioning

the bottom hinge. Please take note of the

hinge position.

Place the door into the opening, ensuring it

is level. Make sure the hinges are up against

the Door Weather Strip face. Secure the hinges

in place.

Measure out 2/3 equal lengths of felt. Overlap

it on the top and around the edges. Fold at the

corners. Tack to keep secure. Ensure 50mm

of the felt covers the Roof Strips. Tack from the

bottom to the top.

Secure the Fascias with screws as shown below. Ensure to screw into the Roof Strips. Please refer

to the assembly step which suits your summerhouse size.

FRONT FASCIAS

DOOR

TOP TIP: Use a measuring tape to measure out

2/3 equal lengths & cut with a sharp knife. Hammer the

tacks into the felt. Add the tacks at 150mm intervals.

(8x6 & 10x6 only). Screw 2 x Side Roof Strips

at each side along the other edge of the OSB

Roof Sheets as shown below.

Secure the OSB Roof Sheets to the Roof Beam(s), Apex Section frames and wall panel frames as

shown below. Ensure to screw into the Roof Beams underneath. Use 8 x screws per OSB sheet.

Please refer to the assembly step which suits your summerhouse size.

HINGE POSITION

ROOF ASSEMBLY

7X5 8X6 & 10X6

TOP TIP: Mark the OSB sheet and draw a line to ensure you drill and screw into the framing & beam(s).

SIDE ROOF STRIP

7X5 8X6 & 10X67X5

8X6 & 10X6

SIDE FASCIAS SIDE FASCIAS

FRONT FASCIAS

8X6 & 10X6

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

PRE-DRILL

WITH 2MM BIT

FOR ALL STEPS

BELOW.

EXTERNAL DOOR FIXINGS

Fix a Turn Button to the top of the ‘closed’

door. Ensure to secure this onto the front of

the door.

Fix a Turn Button to the bottom of the same

door. Ensure to secure this onto the front of

the door.

Fix the Handles with the screws provided to

the front of the doors. Ensure to position the

handles to your desired height.

OUTSIDE OUTSIDE OUTSIDE

6b INTERNAL DOOR FIXINGS

Secure the Slamming Strip. Screw the

Slamming Strip to the door you want to be the

‘closed’ door.

Fix the Barrel Bolt as shown below, using its

own xings provided. Secure the Barrel bolt to

the top of the Slamming Strip.

Fix the other Barrel Bolt to the bottom of the

door with the Slamming Strip. Secure a Turn

Button to the bottom of the other door.

SLAMMING STRIP INSIDE INSIDE

REMOVING THE PROTECTIVE FILM FROM YOUR DOOR WINDOWS

PEEL THE PROTECTIVE FILM OFF BY HAND

Simply nd a loose edge or corner around the frame and peel back to completely

remove the lm on that surface. There will be protective lm on the front and back

surface of each window.

APPLY WARM SOAPY WATER

We recommend applying warm soapy water to the surface to help loosen the lm and

rub rmly with a sponge or cloth to remove the adhesive residue. We advise warm

soapy water as many solvents and harsh chemicals can damage the styrene windows.

3STANLEY KNIFE

If the previous options are unsuccessful, we advise to carefully use a Stanley Knife in

a corner of the frame to provide a starting point to peel the protective lm. Use the

window frame as a guide. Be careful not to scratch the windows surface. We strongly

advise to use cut-resistant gloves to prevent any harm to yourself. Remove the rest

of the protective lm by hand.

We cannot be held responsible for damages incurred when not following the outlined

procedure.

CHECK & TIGHTEN ALL FIXINGS APPLIED TO THE PRODUCT ON A REGULAR BASIS

CHECK YOU HAVE ALL YOUR PARTS.

(The parts do not have codes on them. They are listed below should you need to order one.)

The components provided may be heavy. Please lift with caution and with a minimum of 2 people.

Use the labelled components to help identify the part code and description.

Label Part Code

Description No. Label Part Code Description No. Label Part Code Description No.

AOPMS590WP

Section A - 2ft Window Panel

(590x1603mm)

2 A OPMS590WP

Section A - 2ft Window Panel

(590x1603mm)

2 A OPMS590WP

Section A - 2ft Window Panel

(590x1603mm)

BOPMS590TWP

Section B - 2ft Front Window Panel

(590x2059mm)

1 E OPMS885TWP

Section E - 3ft Front Window Panel

(885x2059mm)

1 B OPMS590TWP

Section B - 2ft Front Window Panel

(590x2059mm)

COPM885PP

Section C - 3ft Panel

(885x1603mm)

2 F OPM1180PP Section F - 4ft Panel (1180x1603mm) 2 D OPPM885BP

Section D - 3ft Back Panel

(885x1717mm)

DOPPM885BP

Section D - 3ft Back Panel

(885x1717mm)

1 G OPPM1180BP

Section G - 4ft Back Panel

(1180x1717mm)

2 E OPMS885TWP

Section E - 3ft Front Window Panel

(885x2059mm)

GOPPM1180BP

Section G - 4ft Back Panel

(1180x1717mm)

1 H OPMS1475TDP Section H - Door Panel (1475x2059mm) 1 F OPM1180PP Section F - 4ft Panel (1180x1603mm) 2

HOPMS1475TDP Section H - Door Panel (1475x2059mm) 1 J MSBFL46 Floor (1180x1826x72mm) 2 G OPPM1180BP

Section G - 4ft Back Panel

(1180x1717mm)

IMSBFL257 Floor (737x2121x72mm) 2 L OPPMSUMRHA6 6ft Apex Section - Right (476x1770mm) 1 H OPMS1475TDP Section H - Door Panel (1475x2059mm) 1

LOPPMSUMRHA5

5ft Apex Section - Right (482x1475mm) 1 M OPPMSUMLHA6 6ft Apex Section - Left (476x1770mm) 1 K MSBFL56 Floor (1475x1826x72mm) 2

MOPPMSUMLHA5

5ft Apex Section - Left (482x1475mm) 1 N XT5301087 Window (530x1087x2mm) 2 L OPPMSUMRHA6 6ft Apex Section - Right (476x1770mm) 1

NXT5301087

Window (530x1087x2mm) 2 P XT3971105 Window (397x1105x2mm) 2 M OPPMSUMLHA6 6ft Apex Section - Left (476x1770mm) 1

OXT5301105

Window (530x1105x2mm) 1 Q 85009 PVC Z-Strip (30x12x610mm) 4 N XT5301087 Window (530x1087x2mm) 2

Q85009

PVC Z-Strip (30x12x610mm) 3 R 15120470PPT Window Beading (15x12x470mm 2 O XT5301105 Window (530x1105x2mm) 1

R15120470PPT

Window Beading (15x12x470mm) 3 S 15120352PPT Window Beading (15x12x352mm) 2 P XT3971105 Window (397x1105x2mm) 2

T26120531PPT

Top/Bottom Window Strips

(26x12x531mm)

6 T 26120531PPT

Top/Bottom Window Strips

(26x12x531mm)

4 Q 85009 PVC Z-Strip (30x12x610mm) 5

V26121065PPT

Side Window Strips

(26x12x1065mm)

4 U 26120399PPT

Top/Bottom Window Strips

(26x12x399mm)

4 R 15120470PPT Window Beading (15x12x470mm 3

W26121083PPT

Side Window Strips

(26x12x1083mm)

2 V 26121065PPT

Side Window Strips

(26x12x1065mm)

4 S 15120352PPT Window Beading (15x12x352mm) 2

X44161695PT Back Cover Strip (44x16x1695mm) 3 W 26121083PPT

Side Window Strips

(26x12x1083mm)

4 T 26120531PPT

Top/Bottom Window Strips

(26x12x531mm)

Y44161910PT Side Cover Strip (44x16x1910mm) 2 X 44161695PT Back Cover Strip (44x16x1695mm) 3 U 26120399PPT

Top/Bottom Window Strips

(26x12x399mm)

Z44162039PT Front Cover Strip (44x16x2039mm) 3 Y 44161910PT Side Cover Strip (44x16x1910mm) 2 V 26121065PPT

Side Window Strips

(26x12x1065mm)

AA 50121667PPT Door Weather Strip (50x12x1667mm) 2 Z 44162039PT Front Cover Strip (44x16x2039mm) 3 W 26121083PPT

Side Window Strips

(26x12x1083mm)

AB 40121237PPT

Top Weather Strip (40x12x1237mm) 1AA 50121667PPT Door Weather Strip (50x12x1667mm) 2 X 44161695PT Back Cover Strip (44x16x1695mm) 4

AC 45121650PPT Door Hinge Strip (45x12x1650mm) 2AB 40121237PPT

Top Weather Strip (40x12x1237mm) 1 Y 44161910PT Side Cover Strip (44x16x1910mm) 2

AD 45121180PPT

Kick Plate Strip (45x12x1180mm) 1AC 45121650PPT Door Hinge Strip (45x12x1650mm) 2 Z 44162039PT Front Cover Strip (44x16x2039mm) 4

AE 28281200PBNPT

Canopy Strip (28x28x1200mm) 1AD 45121180PPT Kick Plate Strip (45x12x1180mm) 1AA 50121667PPT Door Weather Strip (50x12x1667mm) 2

AF 45451468PAII77

Angled Roof Beam (45x45x1468mm) 1AE 28281200PBNPT Canopy Strip (28x28x1200mm) 1AB 40121237PPT Top Weather Strip (40x12x1237mm) 1

AH OSB168811158 OSB Roof Sheet - (1688x1115x8mm) 2AG 45451810PAII79

Angled Roof Beam (45x45x1810mm) 2AC 45121650PPT Door Hinge Strip (45x12x1650mm) 2

AI 28281115

End & Side Roof Strip (28x28x1115mm) 6AH

OSB20328288

OSB Roof Sheet - (2032x828x8mm) 3AD

45121180PPT

Kick Plate Strip (45x12x1180mm) 1

AM 59121132PPT Front Fascia (59x12x1132mm) 2AJ 28281242 End Roof Strip (28x28x1242mm) 4AE 28281200PBNPT Canopy Strip (28x28x1200mm) 1

AP 59121688PPT

Side Fascia (59x12x1688mm) 2AL 28280988 Side Roof Strip (28x28x988mm) 4AG 45451810PAII79 Angled Roof Beam (45x45x1810mm) 2

AR SDR575X1645PTBI Door (1645x575mm) 2AN 59121259PPT Front Fascia (59x12x1259mm) 2AH OSB203210258 OSB Roof Sheet - (2032x1025x8mm) 3

AS 40121635PPT

Slamming Strip (40x12x1635mm) 1AQ 59121020PPT Side Fascia (59x12x1020mm) 4AK 28281537 End Roof Strip (28x28x1537mm) 4

AT 1AR SDR575X1645PTBI Door (1645x575mm) 2AL 28280988

Side Roof Strip (28x28x988mm) 4

AS 40121635PPT

Slamming Strip (40x12x1635mm) 1AO 59121555PPT Front Fascia (59x12x1555mm) 2

AT 1AQ 59121020PPT Side Fascia (59x12x1020mm) 4

AR SDR575X1645PTBI Door (1645x575mm) 2

AS 40121635PPT Slamming Strip (40x12x1635mm) 1

AT 1

Label Part Code

Description No. Label Part Code Description No. Label Part Code Description No.

ASDMS590WP

Section A - 2ft Window Panel

(590x1603mm)

2 A SDMS590WP

Section A - 2ft Window Panel

(590x1603mm)

2 A SDMS590WP

Section A - 2ft Window Panel

(590x1603mm)

BSDMS590TWP

Section B - 2ft Front Window Panel

(590x2059mm)

1 E SDMS885TWP

Section E - 3ft Front Window Panel

(885x2059mm)

1 B SDMS590TWP

Section B - 2ft Front Window Panel

(590x2059mm)

CSDM885PP

Section C - 3ft Panel

(885x1603mm) 2 F SDM1180PP Section F - 4ft Panel (1180x1603mm) 2 D SDPM885BP

Section D - 3ft Back Panel

(885x1717mm)

DSDPM885BP

Section D - 3ft Back Panel

(885x1717mm) 1 G SDPM1180BP

Section G - 4ft Back Panel

(1180x1717mm)

2 E SDMS885TWP

Section E - 3ft Front Window Panel

(885x2059mm)

GSDPM1180BP

Section G - 4ft Back Panel

(1180x1717mm)

1 H SDMS1475TDP

Section H - Door Panel (1475x2059mm) 1 F SDM1180PP Section F - 4ft Panel (1180x1603mm) 2

HSDMS1475TDP

Section H - Door Panel (1475x2059mm) 1 J MSBFL46 Floor (1180x1826x72mm) 2 G SDPM1180BP

Section G - 4ft Back Panel

(1180x1717mm)

IMSBFL257

Floor (737x2121x72mm) 2 L SDPMSUMRHA6 6ft Apex Section - Right (476x1770mm) 1 H SDMS1475TDP Section H - Door Panel (1475x2059mm) 1

LSDPMSUMRHA5

5ft Apex Section - Right (482x1475mm) 1 M SDPMSUMLHA6 6ft Apex Section - Left (476x1770mm) 1 K MSBFL56 Floor (1475x1826x72mm) 2

MSDPMSUMLHA5

5ft Apex Section - Left (482x1475mm) 1 N XT5301087 Window (530x1087x2mm) 2 L SDPMSUMRHA6 6ft Apex Section - Right (476x1770mm) 1

NXT5301087

Window (530x1087x2mm) 2 P XT3971105 Window (397x1105x2mm) 2 M SDPMSUMLHA6 6ft Apex Section - Left (476x1770mm) 1

OXT5301105

Window (530x1105x2mm) 1 Q 85009 PVC Z-Strip (30x12x610mm) 4 N XT5301087 Window (530x1087x2mm) 2

Q85009

PVC Z-Strip (30x12x610mm) 3 R 15120470PDT Window Beading (15x12x470mm 2 O XT5301105 Window (530x1105x2mm) 1

R15120470PDT

Window Beading (15x12x470mm) 3 S 15120352PDT Window Beading (15x12x352mm) 2 P XT3971105 Window (397x1105x2mm) 2

T26120531PDT

Top/Bottom Window Strips

(26x12x531mm)

6 T 26120531PDT

Top/Bottom Window Strips

(26x12x531mm)

4 Q 85009

PVC Z-Strip (30x12x610mm) 5

V26121065PDT

Side Window Strips

(26x12x1065mm) 4 U 26120399PDT

Top/Bottom Window Strips

(26x12x399mm)

4 R 15120470PDT

Window Beading (15x12x470mm 3

W26121083PDT

Side Window Strips

(26x12x1083mm) 2 V 26121065PDT Side Window Strips

(26x12x1065mm) 4 S 15120352PDT Window Beading (15x12x352mm) 2

X40121695DT

Back Cover Strip (44x16x1695mm) 3 W 26121083PDT Side Window Strips

(26x12x1083mm) 4 T 26120531PDT

Top/Bottom Window Strips

(26x12x531mm)

Y40121910DT

Side Cover Strip (44x16x1910mm) 2 X 40121695PDT Back Cover Strip (44x16x1695mm) 3 U 26120399PDT

Top/Bottom Window Strips

(26x12x399mm)

Z40122039DT

Front Cover Strip (44x16x2039mm) 3 Y 40121910PDT Side Cover Strip (44x16x1910mm) 2 V 26121065PDT Side Window Strips

(26x12x1065mm) 6

AA 50121667PDT

Door Weather Strip (50x12x1667mm) 2 Z 40122039PDT Front Cover Strip (44x16x2039mm) 3 W 26121083PDT Side Window Strips

(26x12x1083mm) 4

AB 40121237PDT

Top Weather Strip (40x12x1237mm) 1AA 50121667PDT Door Weather Strip (50x12x1667mm) 2 X 40121695PDT Back Cover Strip (44x16x1695mm) 4

AC 45121650PDT Door Hinge Strip (45x12x1650mm) 2AB 40121237PDT

Top Weather Strip (40x12x1237mm) 1 Y 40121910PDT Side Cover Strip (44x16x1910mm) 2

AD 45121180PDT

Kick Plate Strip (45x12x1180mm) 1AC 45121650PDT Door Hinge Strip (45x12x1650mm) 2 Z 40122039PDT Front Cover Strip (44x16x2039mm) 4

AE 28281200PBNDT

Canopy Strip (28x28x1200mm) 1AD 45121180PDT Kick Plate Strip (45x12x1180mm) 1AA 50121667PDT Door Weather Strip (50x12x1667mm) 2

AF 45451468PAII77

Angled Roof Beam (45x45x1468mm) 1AE 28281200PBNDT Canopy Strip (28x28x1200mm) 1AB 40121237PDT Top Weather Strip (40x12x1237mm) 1

AH OSB168811158 OSB Roof Sheet - (1688x1115x8mm) 2AG 45451810PAII79

Angled Roof Beam (45x45x1810mm) 2AC 45121650PDT Door Hinge Strip (45x12x1650mm) 2

AI 28281115

End & Side Roof Strip (28x28x1115mm) 6AH OSB20328288 OSB Roof Sheet - (2032x828x8mm) 3AD 45121180PDT Kick Plate Strip (45x12x1180mm) 1

AM 59121132PDT Front Fascia (59x12x1132mm) 2AJ 28281242

End Roof Strip (28x28x1242mm) 4AE 28281200PBNDT Canopy Strip (28x28x1200mm) 1

AP 59121688PDT

Side Fascia (59x12x1688mm) 2AL 28280988 Side Roof Strip (28x28x988mm) 4AG 45451810PAII79 Angled Roof Beam (45x45x1810mm) 2

AR SDR575X1645DT Door (1645x575mm) 2AN 59121259PDT Front Fascia (59x12x1259mm) 2AH OSB203210258 OSB Roof Sheet - (2032x1025x8mm) 3

AS 40121635PDT

Slamming Strip (40x12x1635mm) 1AQ 59121020PDT Side Fascia (59x12x1020mm) 4AK 28281537 End Roof Strip (28x28x1537mm) 4

AT 1AR SDR575X1645DT Door (1645x575mm) 2AL 28280988 Side Roof Strip (28x28x988mm) 4

AS 40121635PDT

Slamming Strip (40x12x1635mm) 1AO 59121555PDT Front Fascia (59x12x1555mm) 2

AT 1AQ 59121020PDT

Side Fascia (59x12x1020mm) 4

AR SDR575X1645DT Door (1645x575mm) 2

AS 40121635PDT

Slamming Strip (40x12x1635mm) 1

AT 1
