FORTA AIRON PLUS User manual

Contents
1.- Important
2.- Icons used on the label and in the manual
3.- Product use
4.- Product description
5.- Warnings and safety
6.- Assembly and use
7.- Technical Specifications
8.- Care and maintenance
9.- Recycling the product
10.- Storing the product
11.- Useful life
12.- Warranty and after-sales service
13.- Tests and trials carried out
14.- Manufacturer details
WALKER MANUAL - AIRON PLUS
1.- Important
Read the manual carefully before using this product and keep it in case of need.
If you cannot read or understand any warning, caution or instruction, contact the seller before using the
product or you may be at risk of harm.
Consult your physician or orthopaedic specialist before use. They will advise you as to the most
appropriate walking technique for you.

2.- Icons used on the label and in the manual
Manufacturer details Date of manufacture
Medical Device Observe safety instructions
Maximum user weight in kg Declaration of Conformity
Caution, danger of entrapment Check the user manual
Product recycling information Recycling centre
SN Product serial number LOT Product batch number
REF Product reference or code
3.- Product use
Walkers are aids to help people with walking difficulties and assist them to support themselves and keep
their balance while walking.

1. Ergonomic grip
2. Adjustable grip tube
3. Height adjustment clip
4. Seat
5. Backrest
6. Front wheels
7. Rear wheels
8. Platen
9. Ferrule
4.- Product description
5.- Warnings and safety
Failure to follow these safety precautions may result in serious injury.
Do not exceed the maximum weight limit of 110 kg.
If the walker has a basket, do not exceed its maximum weight capacity (3 kg). Loads can only be
carried in the basket. Do not place heavy objects on the walker. It might make it unstable.
Make sure all parts are securely fastened and in good working order before using the walker.
Make sure the walker is completely open and the seat is securely fastened before use.
Make sure that the two grips are fixed by the adjustment clip and are both at the same height.
Check that the walker is stable before putting your full weight on the handles.
Do not use the seat when the walker is on sloping or uneven ground. Only use the walker on flat,
solid surfaces.
Replace the wheels and ferules if they are badly worn or damaged.
Do not move the walker while you or another person is sitting on it. This product is a walking aid
and should not be used for transporting anything.
Do not use the walker on stairs or escalators.
Use only original Forta brand accessories and parts.
Do not use the walker to walk backwards, in the opposite direction to the direction you are facing.
Do not make any adjustment or change to the walker while it is in use.

To unfold the walker, follow the instructions below:
1. Lean the walker on its rear legs and push the
grips forward until they stop.
2. Lower the seat and fit it into the support tube.
3. Adjust the height of the grips and use the clip
to lock them in place.
To fold the walker, follow the instructions below:
1. Pull the seat out of the support tube by pulling
it upwards.
2. Lean the walker on its rear legs and pull the
grips until folded.
All wheels and ferrules must be in contact with the ground at all times.
Do not use the walker to mount curbs or sidewalks.
Do not use the product on wet, icy or snowy inclines.
If any part is damaged, broken or worn, contact your distributor for a replacement.
6.- Assembly and use
7.- Technical Specifications
Dimensions, load-bearing capacity and weights are listed below:

HEIGHT LENGTH WIDTH FOLDED LENGTH
850 - 910mm 560mm 560mm 200mm
SEAT MEASUREMENTS HEIGHT TO SEAT FRONT REAR DIAM. REAR WHEELS DIAM.
400x260mm 540mm 150mm 75mm
INSIDE WIDTH WEIGHT MAXIMUM LOAD
540mm 4,000kg 110kg
8.- Care and maintenance
Failure to care for and maintain the product in perfect condition may lead to the risk of an
accident.
Clean the product regularly with warm water and a soft cloth. Do not use abrasives, detergents or
solvents.
Wipe dry with a clean, soft, dry cloth.
Make sure there is no build-up of dirt or hair around the axle or wheels.
Do not use cleaning agents containing phenol or chlorine, which might damage the materials.
If the wheels squeak, lubricate them with a little oil.
In the event of a fault, do not repair the walker yourself. Consult an authorised distributor.
9.- Recycling the product
When the product has become unusable and requires disposal, contact your specialist dealer.
If you want to recycle it yourself, ask your local waste management company or nearest
recycling centre for advice on disposal.
10.- Storing the product
If not correctly stored, the product may be damaged leading to the risk of an accident.
Do not store this product for an extended period of time near a heat source or in the sun (e.g. in
front of a window or near a radiator) or near a cold source.
Keep the product away from flames and sparks.
Store the product as follows:
Store the product in a dry, cool place.
Protect the product from dust and rust by packaging or bagging it.
Store all removed parts or components together in one place so they do not get mixed up
with anything else or get lost.
Do not place any weight on any components (do not place heavy objects on the product or on
any component).

11.- Useful life
The expected useful life of the product is 3 years in normal conditions of use, safety and maintenance.
After that time, the product can be used as long while it remains in perfect conditions of use and
maintenance. Some parts or components may in any event have to be replaced due to normal wear and
tear within less than this time.
12.- Warranty and after-sales service
Warranty terms and conditions:
Only original Forta products purchased from authorised dealers are covered by the warranty against
defects in parts and workmanship.
The warranty runs from the date of purchase for 3 years for structure and components subject to the
following conditions:
Only original FORTA products purchased from authorised dealers will be covered by the warranty
against defects in parts and workmanship.
The purchasing establishment must give notice of any defect in the product immediately.
The manufacturer will not have any liability for defects caused by improper handling, negligence or
failure to follow the instructions set out in this manual.
During the warranty period, any part that proves defective due to faulty assembly or materials will
be repaired or replaced free of charge by Forta.
The warranty will be absolutely void if incorrect modifications or adjustments are made to the
product or if parts or options not supplied for the product model are fitted.
Damage from rust caused by misuse or negligence or the action or any liquid or gas that may
damage the product are excluded from the warranty.
THE WARRANTY DOES NOT COVER THE CONSEQUENCES OF ANY TRAVEL PROBLEM, IN
PARTICULAR ISSUES RELATING TO TRANSPORT, LOSS OF PROFIT, EXPENSES, ETC.
Forta will have NO liability in the following circumstances:
Normal wear and tear of the product or inappropriate or incorrect use.
Defects in any assembly or repair carried out by the purchaser or a third party.
Negligent handling or maintenance or use of unsuitable parts.
Repairs or modifications carried out in non-official workshops.
Forta will have no liability for any harm or loss suffered by the user or any third party as a result of
any modification to or alteration of any product.
The warranty also excludes modifications made other than with original Forta parts.
EThe warranty certificate must be sent to FORTA, S.L. together with a photocopy of the purchase invoice
within 15 days from the date of purchase. To validate the warranty, the user must submit the warranty
certificate bearing the stamp the seal of the outlet that sold the product. You can download the warranty
certificate here: www.fortasl.es/en/manuales/doc/GARANTIA CONTRACTUAL.pdf.

13.- Tests and trials carried out
FORTA products comply with Annex IV to MDR (EU) 2017/745, are CE marked and have been designed
and tested in accordance with UNE-EN ISO 11199-2:2021. Forta is obliged to certify compliance by its
products with a number of essential requirements. There is a standard that specifies the inspection and
testing methods to show compliance of the products with those requirements. The standards that the
product complies with are listed below:
Brief description of relevant law Current law
Information provided by the manufacturer UNE-EN 1041:2009+A1:2014
Quality management system UNE-EN ISO 13485:2018
Risk management UNE-EN ISO 14971:2020
Testing of medical devices and walkers UNE-EN 12182:2012
UNE-EN 11199-2:2021
Biological assessment of medical devices UNE-EN ISO 10993-1:2021
Maximum load 110 kg
14.- Manufacturer details
FORTA - FABRICACIONES ORTOPÉDICAS ALBACETE, S.L.
Pq. Emp. Campollano, c/C 90 Nave 1
02007 Albacete
España - Spain
[email protected]
www.fortasl.es
MADE IN EUROPE
