Promeba PE-55 User manual
USER GUIDE
ELECTRICAL STEP PE-55
Review 09/19
Read the instruction
manual and store it for
future reference
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
3
01 INTRODUCTION
01.1 Using this manual ························································································································ 05
01.2 Meaning of Symbols ··················································································································· 07
01.3 Serving request ····························································································································· 07
01.4 Demolition ······································································································································ 07
01.5 Technical data sheet ···················································································································· 09
02 WARNINGS
02.1 General warnings ························································································································· 10
02.2 Specic warnings ························································································································· 13
02.3 Contradictions and side eects ······························································································ 15
02.4 Physical requirements of the operators ··············································································· 15
03 INSTALATION
03.1 Transporting and unpacking ··································································································· 16
03.2 Installing the device ····················································································································
03.2.1 Mounting Kit Contents ························································································· 17
03.2.2 Mounting ··················································································································· 17
04 ELECTRICAL CIRCUIT DIAGRAM
04.1 Electrical diagram of the automatic pedal ·········································································· 18
04.2 Electrical diagram of the automatic opening ···································································· 19
05 OPERATING
05.1 General elements of electrical step PE-55 ··········································································· 20
05.2 Elements of the electrical step PE-55 ···················································································· 21
06 MOUNTING AND COMPONENTS
06.1 Main exploded view ELECTRICAL STEP PE-55 ···································································· 22
06.2 Bill of materials main exploded view electrical step PE-55 ··········································· 23
07 TROUBLESHOOTING ··················································································································· 25
08 GENERAL MAINTENANCE ·········································································································· 27
09 LEGAL NOTICES ····························································································································· 28
10 PRODUCT WARRANTY ················································································································ 29
11 TRAINING REGISTER ····················································································································· 30
12 MAINTENANCE REGISTER ·········································································································· 31
INDEX
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
5
01.1 Using this manual
This manual provides using and maintenance instruc-
tions of the product, as well as the way of xing minor
faults that could appear.
It is recommended before the operation of the product
to read carefully this manual in order to avoid damages
caused by a misuse.
Do not lose this document, it should be accessible to
any doubt that could appear by medical personnel.
Remember that a good use and maintenance are ne-
cessary for the proper operation of the product.
Each product incorporates an identication sticker with
the serial number and the model. Keep these numbers
so that they can be indicated to the dealer if necessary.
01 INTRODUCTION
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
7
01 INTRODUCTION
01.2 Meaning of Symbols
General warning of
possible injuries
Read the user manual
This product is compliant
with the specications of
the Directive 93/42/CEE
ER-0687/1998
Certicate of Qua-
lity Management
System IQNet Certicate
QR Code
(Access Online Web)
Unlocked Locked
01.3 Serving request
For information of the correct interpretation of the instruction manual, the use, maintenance, insta-
llation and restoration of the product, please contact Promeba customer service T. 93 837 12 00, Fax
Sallent (Barcelona) · SPAIN.
01.4 Demolition
When the devices are no longer suitable for use, if they have not been contaminated by any particular
agent, they can be disposed of as normal solid waste, otherwise, follow the current demolition regula-
tions.
WARNINGS FOR THE CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DI-
RECTIVE 2012/19/EU WEEE:
At the end of his life, the product must not be disposed as household waste. Can be taken to
special recycling centers provided by local government, or return it to the dealer on purchase
of a new device of the same type and used for the same functions. Dispose of the product
separately avoids possible negative consequences for the environment and human health re-
sulting from inappropriate disposal and allows to recover the materials in order to obtain sig-
nicant savings in energy and resources. The symbol on the label indicates separate collection
of electrical and electronic equipment.
Warning: One incorrect disposal of electrical and electronic equipment could result in sanc-
tions.
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
9
MEASURES AND CHARACTERISTICS // ELECTRICAL STEP PE-55
OPEN-UP DIMENSIONS 555x530x200 mm
FOLDED DIMENSIONS 555x360x180 mm
TENSION 12 V
WEIGHT 7,5 Kg
MAX. LOAD 250 Kg
01 INTRODUCTION
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
10
02 WARNINGS
02.1 General warnings
·The product has to be used by trained personnel only, who must have specic training for the use of
this product and not for similar products.
·Training routines must be registered on a special register in which the names of the persons trained,
their trainers, the place and the date of the training are indicated. This registry, which will certify the
eligibility of the operators to use the Promeba product, must be retained for a period of 10 years after
the elimination of the product. This record will be made available to the competent authorities and/or
the manufacturer if requested.
·Promeba, S.L. is always at your disposal to plan the product formations.
·Before carrying out any type of operation on the product (training, installation, use), the operator
must carefully read the attached instructions, paying special attention to the correct safety precautions
and the procedures that must be followed for the installation and for the correct use.
·If you have any questions regarding the interpretation of these instructions, please contact Promeba,
S.L. for any kind of clarication.
·If the instructions belong to another device and not to the purchased device, inform the manufacturer
immediately and avoid the use of this device.
·Before each use of the device, the perfect functioning of the device must be veried, as specied in
the instruction manual. In case of detecting damages or anomalies that could inuence in some way
the correct functioning or safety of the device, the patient or the operator; the device must be imme-
diately removed from service and you must contact the manufacturer.
·In case of detecting any failure or incorrect functioning of the device, it must be replaced immediately
by a similar device in order to be able to guarantee the rescue procedures without any interruption.
·Regularly check the product, carry out the prescribed maintenance and respect the service life, as
indicated by the manufacturer in this manual.
·Do not allow people without training to help during the use of the device, because they could cause
damage to the patient or to themselves.
·It is totally forbidden to use the device in any other way than the one described in this manual.
·Do not alter or modify this device in any way; any modication of this device could cause malfunctions
and injuries to the patient and/or rescue personnel.
·Handle with care.
·The device must not be manipulated in any way (modication, adjustment, replacement). In such
cases all responsibility will be denied for any malfunctions or injuries caused by this device. In addition,
CE certication and product warranty will be considered void.
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
11
·All those who modify or have modied, prepared or have prepared medical devices in such way that
they no longer serve the purpose for which they were designed, or no longer provide the desired servi-
ce, must satisfy the valid conditions for the introduction of these in the market.
·Register and store with these instructions: lot number, place and date of purchase, rst date of use,
date of checks, name of operators and any other comments.
·Be sure to take all necessary precautions to avoid the dangers that may arise as a result of contact with
blood or body uids.
·Do not store the device under heavy objects that could cause structural damage.
·Store in a cool, dry, dark place and do not expose the device directly to the sun.
·Store and transport the product in its original packaging.
·The product must not be exposed or come into contact with any source of combustion or ammable
agents.
·Position and adjust the device being careful not to cause any obstruction to rescuers and/or any other
rescue equipment.
·When the product is being used, the assistance of qualied personnel must be guaranteed
·Attention: laboratory tests, post-production tests, instruction manuals cannot always consider all pos-
sible scenarios of use. This means that, in some cases, the performance of the product could have signi-
cantly dierent from results to date obtained. Instructions are continually updated and are under the
strict supervision of fully qualied personnel with the appropriate technical formation.
·In addition, both public and private services are obliged to inform the manufacturer of any measures
that should be adopted in order to take the necessary steps to guarantee the safety and health of pa-
tients and users of any medical device.
·As a distributor or end users of products manufactured and/or marketed by Promeba, S.L., it is strictly
required that you have a basic knowledge of any legal requirement that applies to the supplied devices,
for the countries in which they will end up (including laws and norms regarding technical specications
and/or safety requirements) and, therefore, it is also strictly required to have the necessary knowledge
to guarantee all aspects related to the total conformity of the products to the regulations in the corres-
ponding territory.
·Promptly notify Promeba, S.L. with respect to any revision that the manufacturer must carry out in
order to guarantee the conformity of the product to the legal specications of the territory (including
those resulting from rules and/or norms of other nature).
·Act, with due care and diligence, and help ensure compliance to general security requirements of all
devices marketed in the territory, providing end users with all the information necessary to perform
periodic checks of their devices, as specied in the instruction manual.
02 WARNINGS
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
12
·Actively contribute to the security controls of the products sold, communicating any relevant risk
analysis information both the manufacturer and to competent authorities so that the necessary mea-
sures can be taken promptly.
·You are aware that, in case of it does not comply with the above mentioned requirements, you will
be considered totally responsible for all damages that may occur. Therefore we expressly disclaim any
responsibility and/or liability for your non-compliance with the present regulatory provisions.
02 WARNINGS
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
13
02.2 Specic warnings
·Establish a maintenance program and periodic tests, identifying a reference employee. The person en-
trusted with the ordinary maintenance of the device must guarantee the basic requirements foreseen
by the manufacturer in the user manual.
·Use only accessories/spare parts original or approved by Promeba, S.L., in order to carry out any ope-
ration without altering or modifying the device; otherwise we assume no responsibility for the correct
operation or damage resulting from the device to the patient or the operator and the warranty will be
considered void, in accordance with the compliance of the Medical Device Directive 93/42/EEC.
·Always respect the maximum load capacity of the device, as indicated in this manual. The maximum
load capacity means the total weight distributed according to the human anatomy. When determi-
ning the load of the total weight on the product, the operator should consider the patient’s weight,
equipment and accessories. In addition, the operator must consider that the overall dimensions of the
patient do not reduce the functionality of the device.
·Never leave the patient without any assistance in the device, because he could be injured.
·The device and all its components, after being washed, should be allowed to dry completely before
storage.
·Lubrication must be carried out after cleaning and complete drying.
·Follow the procedures approved by the Emergency Medical Services for the immobilization and trans-
portation of the patient.
·Follow the procedures approved by the Emergency Medical Services for the positioning and transpor-
tation of the patient.
·Avoid contact with sharp objects.
·Do not use the device if it is pierced, torn or frayed.
·The maximum weight sustained by each rescuer must comply with the requirements prescribed by
the law of the country, related to health and safety at work.
·Make sure the product is well anchored at its corresponding anchor points.
·Always use the switch supplied by Promeba, S.L., otherwise, the manufacturer is not responsible for
possible breakdowns.
·Do not use the pedal to climb, if it is not fully extended, since the engine could be seriously damaged.
·The step must be folded whenever the vehicle is moving.
02 WARNINGS
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
15
02.3 Contradictions and side eects
The use of this device, if used as described in this manual, does not present any contradiction or colla-
teral eect.
02.4 Physical requirements of the operators
This product is intended only for use by specialized operators. The rescue team must have, at least, the
following requirements:
·Physical capacity to be able to operate the device.
·Being able to grasp the device rmly with both hands
·Strong back, arms and legs to lift, push and pull the device.
·Have a good muscular coordination.
02 WARNINGS
The operators must be trained to be able to transport eciently, eciently and safely.
For extremely heavy patient loading procedures, operations on dicult terrain and, in parti-
cular situations more operators may be needed (not only 2 as in normal conditions).
The capabilities of the various operators must be considered before determining the func-
tion they will have in the operation of the device.
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
16
03 INSTALATION
03.1 Transport and unpacking
1. Transport
Before transporting the product, make sure it is pro-
perly packed, making sure there are no risks of crashes,
bumps or falls during transport.
Keep the original packaging for use in case of any other
transport and storage. Damage to the product caused
during transportation and handling is not covered
by the warranty. Repairs or replacement of damaged
parts are the responsibility of the customer. The devi-
ce should be stored in a dry and cool place, away from
direct sunlight. It must not come into contact with che-
mical substances or agents that may cause damage
and reduce safety features.
Durante el almacenamiento, no coloque materiales pe-
sados sobre el dispositivo. El producto no debe consi-
derarse ni utilizarse como estante para ningún tipo de
material.
During storage, do not place heavy materials on the
device. The product must not be considered or used as
a shelf for any type of material.
· Always x the load, if it is necessary stack. you should
follow the diagram shown.
· Transport the level load and following all the precepts
and regulations regarding the transport of loads.
2. Unpacking
· Put the box on a at and stable surface, open the seal
carefully not to damage inside.
· Remove the product from the inside of the case.
Each product has been thoroughly inspected when
leaving the factory.To ensure that the transport has not
deteriorated it, please inspect the exterior and interior
carefully, and in the event of any damage, contact the
installer immediately.
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
17
03.2 Installing the device
03.2.1 Mounting Kit Contents
UNITS
·Switch 1
·Inverter xing plate 1
·Screw DIN 7981 2,9x9,5 4
·Connector 6
03.2.2 Mounting
1. Fix the PE-55 on the bottom of the chassis in a solid way through collisions or holes of 9 trying to
maintain the parallelism between the two supports to achieve a good operation.
2. Electrical connection of the inverter (fuse F 20 A).
3. Install the indicator light, which indicates that the pedal is extended, at the moment we give the
motor contact, to avoid accidents with the pedal out and the vehicle running.
4. How to use
The electric step works once installed through the switch, disconnecting automatically when it
reaches its position.
M
+
Negro Rojo
03 INSTALATION
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
18
04.1 Electrical diagram of the automatic pedal
04 ELECTRICAL CIRCUIT DIAGRAM
A: Micro or push button placed on the door
if when the door is closed the microphone is pressed, it must be NC for the relay coil to
be at rest
B: 12V DC 16A double contact relay
C: Switch. In case you want to hide the step while the door is open.
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
19
04 ELECTRICAL CIRCUIT DIAGRAM
04.2 Electrical diagram of the automatic opening
USER GUIDE //
ELECTRICAL STEP PE-55
Review 09/19
20
05.1 General elements of ELECTRICAL STEP PE-55
1. Motor
2. Electrical step
1
2
05 OPERATING
Table of contents
Other Promeba Mobility Aid manuals
