Timago TGR-R RT 892G User manual

1
INSTRUCTIONS FOR USE
Steel 3-wheeled rollator
Product code: TGR-R RT 892G
1. Characteristics
3-wheeled rollator is made of powder coated steel frame. The rollator
is equipped with brakes with locking mechanism, basket with
removable tray, and zip-fastened shopping bag. The product is supplied
with solid wheels 8’’ in diameter and height adjustable ergonomic
handles.
The set includes:
•Steel frame
•Two anatomic push handles
•Basket
•Tray
•Shopping bag
•Locking knobs – 2 pcs
Elements of the rollator:
a. push handle
b. brake
c. locking knob
d. basket
e. shopping bag
f. brake cable
g. hinge
h. upper adjustment of brake
i. lower adjustment of brake
2. Application
The rollator is designed for patients with reduced mobility who need
stable support and help while walking. It is also recommended to the

2
elderly as an aid in keeping balance, improving walking comfort and
ensuring safety from falling. The use of the rollator affects positively on
the return to activity of the people with locomotion and tilting to erect
position problems. It guarantees better stabilization, support and
security while walking.
3. Assembly
Unfolding and folding the rollator
•To unfold the rollator, pull the frame apart at the rear wheels.
•Press the hinge located in the middle of the frame until the
rollator is completely unfolded.
•Fix push handles into the mounting openings and block them with
locking knobs.
•To fold the rollator, pull the hinge of the crossbar which is located
in the middle of the metal crossbar and fold the rollator with the
use of handles or frame.
•Hang basket with tray on small hooks in the front part of the
frame.
•Shopping bag can be removed by unclasping the clips which are
on both sides of the frame.
Brakes
•To stop the rollator, pull the brake handle upwards and hold.
•While stop or using the seat, lock the brake with locking
mechanism by pushing down the brake handle.
•To release the brake, pull the brake handle upwards.
Height adjustment of handles
•To adjust the height of the handles, unscrew the locking knobs
which are located below the push handles, select appropriate
height and tighten the locking knobs.

3
Adjustment of brakes
Adjustment of upper brake
•Unscrew the nut of the cable, pull it up to the appropriate length
and lock it by tightening the locking nut.
Adjustment of lower brake
•Loosen the mounting screw with the use of open-end wrench, pull
the black brake cable to adjust the tension of the cable, and then,
tighten the mounting screw.
4. Technical data
Overall width
62 cm
Overall depth
56 cm
Handles height adjustment
82-97 cm
Weight
7.7 kg
Maximum capacity
110 kg
Maximum capacity of the
shopping bag and basket
5 kg
Frame colour
blue
5. Notes
Timago International Group does not bear responsibility of improper
use of the rollator, failure to comply safety regulations and misuse.
6. Maintenance
Cleaning
Control the technical condition of the rollator regularly:
•Clean the frame with damp cloth and dry thoroughly.
•Do not use strong polishing agents due to the damage of
protecting coatings.
•Clean the dirt from moving parts of the rollator regularly (hinges,
clamping screws, locks).

4
7. Storage and transport conditions
Device should not be exposed to direct sunlight, water or moisture.
8. Warranty information
All products distributed by our company are covered by a warranty, the
terms of which are described in the warranty card available on our
website. Please contact the retailer from whom you purchased the
product. Please, keep in mind that for warranty purposes, the proof of
purchase (receipt or invoice) should be retained
9. Labels
Reference
number
Manufacturer
LOT number Manufacture date
Serial number Medical device
Note
Please read the
instruction
The manufacturer checked for compliance with
essential medical devices requirements.
Our complete line of products is available from our distributors.
Learn more at: www.timago.com. Thank you for choosing Timago!

5
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12
43-316 Bielsko-Biała, Polska
T.: [phone]
F.: [phone]
E.: [e-mail]
Rev. II, date 20.05.2021
